Condor UBL-8000 Urban User Instruction Manual

Bike lock

CONDOR UBL-8000 Urban BIKE LOCK USER INSTRUCTION MANUAL

STOP! WARNING: READ THIS FIRST!

First read and understand the instruction manual and product labels for important safety, set-up and troubleshooting information. If

you have problems setting up or using the UBL-8000 Urban Bike Lock by CondorTM , contact customer service @ 1-815-754-7418

or contact us via email @ www.condor-lift.com. The UBL-8000 Urban Bike Lock by CondorTM is not intended for use by

children.

Components in Package:

Remove all parts from shipping box, check the parts below to make sure you have all the parts needed to assemble your CondorTM

UBL-8000 Urban Bike Lock before beginning. In the unlikely event that you find a damaged or missing part, please call customer

support service at (815) 754-7418.

Component Photo

Item

Component Description

Flat Head Socket Cap Screws

3/8"-16 x 2"

Steel ball bearing

Hex key Alan Wrench 7/32

1/2" Concrete Drill bit

3/8" Concrete Drill bit

Anchor Sleeve tool

Concrete Anchor Sleeve

Urban UBL-8000 Main Frame

Urban UBL-8000 1" x 24" Round Securing Rod

6mm

3/8" x 1½"

Lock & Keys

QTY

Table of Contents

Do you have a question about the UBL-8000 Urban and is the answer not in the manual?

Page 1 Remove all parts from shipping box, check the parts below to make sure you have all the parts needed to assemble your CondorTM UBL-8000 Urban Bike Lock before beginning. In the unlikely event that you find a damaged or missing part, please call customer support service at (815) 754-7418.
Page 2: Installation Instructions
Installation Instructions: The UBL-8000 Urban Bike Lock is comprised of three main components; one Main Frame Unit (item I), one 1” x 24” Round Securing Rod (see item J), and one Lock & Keys set (item H). The Main Frame unit is to be securely bolted (see anchoring instructions below) to the ground using the existing hole locations of the Main Frame.
Page 3 Figure 1 Figure 2 Figure 3 Figure 4 Figure 5 Figure 6 Figure 7 Figure 8 Figure 9...
Page 4 Always make sure that the unit’s are at there optimum settings for the size of the motorcycle before use. Be sure to read and understand user instructions for the UBL-8000 Urban Bike Lock If instructions are not clear, additional information is available at www.condor-lift.com or call (800) 461-1344.
