  • Page 1 EN Installation, Operation and Maintenance Instructions FR Instructions d’installation, d’utilisation et d’entretien ES Instrucciones de instalación, operación y mantenimiento Freezers Congélateurs Congeladors ML24FA...
  • Page 2: Table Of Contents

    CONTENTS Contents: Important Safety Instructions Safety information ...............2 Warnings and safety instructions appearing in this guide Unpacking your appliance ..........3 are not meant to cover all possible conditions and situa- Warranty registration .............3 tions that may occur. Common sense, caution, and care Installing your appliance ............4 must be exercised when installing, maintaining, or operat- Cabinet clearances ............4...
  • Page 3: Unpacking Your Appliance

    UNPACKING YOUR APPLIANCE Warranty Registration WARNING It is important you send in your warranty registration card immediately after taking delivery of your appliance or you can register online at www.agamarvel.com. EXCESSIVE WEIGHT HAZARD Use two or more people to move product. Failure to do so can result in personal injury.
  • Page 4: Installing Your Appliance

    The over- An optional stacking kit, shown in Table "A", is required all height of your Marvel appliance may be adjusted higher to stack products. Failure to use a stacking kit could (by turning the leveling leg out, CCW) and lower (by turning result in personal injury.
  • Page 5: Electrical Connection

    INSTALLING YOUR APPLIANCE WARNING Electrical Shock Hazard Do not remove • Do not use an extension cord with this appliance. ground prong They can be hazardous and can degrade product performance. • This appliance should not, under any circumstanc- es, be installed to an un-grounded electrical supply. •...
  • Page 6: Installing The Anti-Tip Device

    INSTALLING THE ANTI TIP DEVICE FOR FREESTANDING INSTALLATIONS Anti-Tip WARNING Bracket Leveling Leg • ALL APPLIANCES CAN TIP RESULTING IN INJURY. • INSTALL THE ANTI-TIP Bottom View of ⁄ " BRACKET PACKED WITH Freezer (54.6 cm) THE APPLIANCE. • FOLLOW THE INSTRUC- TIONS BELOW Front of cabinet Figure 7...
  • Page 7 INSTALLING THE ANTI TIP DEVICE FOR FREESTANDING INSTALLATIONS NOTE When the floor mounted anti-tip bracket is used the mini- mum adjusted height of the cabinet is increased by ⁄ " (9 mm). "V" notches Rear Leveling leg in bracket Figure 8a Screw ⁄...
  • Page 8: Product Dimensions

    ⁄ " to 34 ⁄ " ⁄ " ⁄ " ⁄ " ⁄ " ML24FA(S) (61 cm) (86.4 to 88.9 cm) (60.7 cm) (85.7 to 88.3 cm) (60.2 cm) (65.2 cm) (117.9 cm) (65.2 cm) 24" **34 ⁄ " to 35 ⁄...
  • Page 9 PRODUCT DIMENSIONS PRODUCT DATA ELECTRICAL PRODUCT MODEL REQUIREMENTS # WEIGHT 140 lbs ML24FA(S) 115V/60Hz/15A (63.6 kg) 140 lbs ML24FA(P) 115V/60Hz/15A (63.6 kg) "J" "H" "D" "G" "E" ⁄ " Figure 11 (54.6 cm) "F" * Depth dimension of rough-in opening may vary depend- ing on each individual installation.
  • Page 10: Using Your Electronic Control

    USING YOUR ELECTRONIC CONTROL Temp Temp On/Off Lock System Status Minus Plus keypad keypad keypad Display Area keypad indicators Figure 12 Electronic single zone control To wake the display press any keypad. A confirm tone will sound, and the current storage compartment temperature will be displayed.
  • Page 11: Adjusting The Temperature

    USING YOUR ELECTRONIC CONTROL Adjusting the temperature: Temperature mode: To set or check the set-point temperature (with the control The temperature mode is preset from the factory in Fahren- out of sleep mode), press the "-" or "+" keypads. "SET" will heit (°F) but you have the option to change it to Centigrade be indicated on the user interface panel and the current (°C).
  • Page 12: Temperature Sensor Error Codes

    USING YOUR ELECTRONIC CONTROL Temperature Sensor Error Codes The temperature sensors are monitored continuously. Any OPEN or SHORTED circuit condition will initiate an ERROR CODE as listed below: Temperature Sensor Error Codes Displayed Error Sensor Code Description Action to Take Call service to have the Failed temperature sensor in the single temperature sensor replaced...
  • Page 13: Power Failure

    USING YOUR ELECTRONIC CONTROL This alarm condition can be reset by momentarily pressing the "On/Off" keypad. If this alarm occurs it is recommended that you check the condition of your Power Failure ALARM RESET stored contents, even though the appliance is operat- ing normally and the temperature has recovered, as prolonged temperature excursions could spoil perish- ables.
  • Page 14: Overlay Door Panel Installation

    OVERLAY DOOR PANEL INSTALLATION If you purchased an overlay panel model, your unit is WARNING equipped with articulated hinges to allow fully integrated built-in installations. Custom panel thicknesses of ⁄ " (15 mm) and ⁄ " (18 mm) are accommodated. Use extreme caution with the articulated hinges.
  • Page 15 OVERLAY DOOR PANEL INSTALLATION Step 2: Remove the door gasket With the door laying on a flat surface and starting at a corner of the door remove the magnetic door gasket from Overlay panel the interior side of the door, see Figure 15. Set the gasket flush with top aside on a flat surface.
  • Page 16 OVERLAY DOOR PANEL INSTALLATION Clearance for CAUTION Clearance for screw head, screw head, 4 places 4 places Weight of overlay door panel must not exceed 15 pounds (6.8 kg) for a solid door model. Figure 18 Right Hand Hinged Door Figure 16 24"...
  • Page 17 OVERLAY DOOR PANEL INSTALLATION Step 5: Install the door Step 4: Assemble the panel to the door Carefully open the top and bottom hinges on the door being The preferred method of attaching the panel to the door careful as there are many pinch points. Place the hinges is to clamp the panel to the door so it cannot move while over the 4 screws in the cabinet, 2 at the top and 2 at the drilling the screw pilot holes.
  • Page 18: Shelving Configurations

    SHELVING CONFIGURATIONS Loading Tips and Suggestions Your appliance is equipped with a cantilever shelf and basket system which provides maximum adjustability and customizing of the storage arrangements listed below. Figure 23 Perforated metal shelf Figure 22 Freezer: 24" (61 cm) Wide Models: Shown with a solid door.
  • Page 19 SHELVING CONFIGURATIONS To install or remove a shelf: Remove stored product from the shelf. Do not try to remove a loaded shelf from the appliance. Grasp the shelf front with both hands, rotate the front upward and lift out. (See Figure 25b).
  • Page 20: Care And Cleaning

    CARE AND CLEANING AND ENERGY SAVING TIPS The following suggestions will minimize the Front Grille cost of operating your refrigeration appliance. Be sure that nothing obstructs the required air flow open- ings in front of the cabinet. At least once or twice a year, brush or vacuum lint and dirt from the front grille area (see 1.
  • Page 21: Obtaining Service

    If Service is Required: • If the product is within the first year warranty period please contact your dealer or call AGA MARVEL Cus- tomer Service at 800.223.3900 for directions on how to obtain warranty coverage in your area. •...
  • Page 22: Troubleshooting

    TROUBLESHOOTING Before You Call for Service WARNING If the appliance appears to be malfunctioning, read through this manual first. If the problem persists, check the trouble- shooting guide below. Locate the problem in the guide and Electrocution Hazard refer to the cause and its remedy before calling for service. •...
  • Page 23: Warranty

    Limited One Year Parts and Labor Warranty Not Supplied or Designated by AGA MARVEL AGA MARVEL warrants that it will supply all necessary The above warranties also do not apply if: parts and labor to repair or replace in the end user’s home or office, any component which proves to be defective •...
  • Page 24 www.agamarvel.com 1260 E. VanDeinse St. Greenville MI 48838 800.223.3900 41014058-EN Rev A All specifications and product designs subject to change without notice. Such revisions do not entitle 12/1/15 the buyer to corresponding changes, improvements, additions, replacements or compensation for previously purchased products.
