- Page 1 OWNER’S MANUAL 2017 12.5 ECO 12.5 RACING OSET Corp 425 Kristen Ct, Unit 6 Montrose, CO 81401, USA 303 990-2390. http://www.OSETBIKES.com info@OSETBIKES.com INS012455 - v1.1...
-
Page 2: Table Of Contents
Learning to ride all the way through to off road competitions. Limited Warranty: Page 37 The secret of learning to ride well is being able to ride a lot. OSET’s enable this to happen, Contact Us: Page 38 and can make the learning process very gratifying for both the children and the adults. -
Page 3: Please Read
If you do not understand any of this important information, please contact your selling OFF ROAD USE ONLY! dealer/distributor or the OSET Customer Service Department. OSET Electric Bikes are designed for off road use only and must not be used on public roads or sidewalks. Please check and obey all local laws. -
Page 4: Safe Operation
Adjust and lubricate the drive chain as necessary. See pages 18-33 of this manual for additional details regarding service, repair and maintenance. Check the OSET • Do not exceed the weight limit. Heavier riders may significantly reduce performance and /or render the vehicle unstable and/or over-tax the brakes and other control devices. -
Page 5: Safety Responsibilities
OBEY ALL LAWS It’s the law; obey it: Obey all laws. OSET bikes are for OFF-ROAD USE ONLY. OSET bikes can not be used on public roads or sidewalks. The purchaser, owner, and/or RIDING CONDITIONS. Braking and traction are significantly reduced in wet or riders of this machine are directly responsible to know and obey all local, state, and slippery conditions. -
Page 6: Bike Specifications
- 11T front sprocket, 76T rear. #25 chain. - 9T front sprocket, 62T rear. #219 chain. Motor: Motor: - 600w 24v OSET Neodymium magnet DC motor. - 600w 24v OSET Neodymium magnet DC motor. Chassis: Chassis: - Frame & Swing Arm - Steel frame &... -
Page 7: Unpacking And Assembly
Failure to properly assemble and adjust your bike prior to use may result in an 12.5 Eco: The 12.5 Eco is fitted with a front V-brake and a rear band brake. Both accident resulting in death, serious injury and/or property damage. If you are uncertain brakes will already be connected;... -
Page 8: Switches
Failure to properly install the batteries may result in an accident resulting in death, serious will be reduced to its minimum. injury and/or property damage. If you are uncertain about any aspect of the assembly and adjustment of your bike, seek help from a qualified mechanic or the OSET Customer POWER DIAL Service Department. -
Page 9: Chain Adjustment
CHAIN ADJUSTMENT MOTOR CARE Your OSET features a traditional chain and sprockets. It is direct drive, with no gears. With the motor mounted in the swingarm, suspension movement has no effect on tension. WARNING! However, the chain does need to be checked and adjusted regularly, especially when the bike is new. -
Page 10: Suspension
Undo the nut on the other side of the axle until the wheel can be removed. Your OSET is equipped with a single coil spring type rear shock. For a harder/stiffer ride To re-install the front wheel, it can help to loosen the front brake calliper bolts first (picture 4). -
Page 11: Brake Adjustment
WHEEL REMOVAL & INSTALLATION BRAKE ADJUSTMENT REAR WHEEL 12.5 ECO Front V-brake: Ensure power is switched off and the key removed. A visual check will show if the brake pads are engaging the rim properly. If they are not, the Lift the bike onto a block or stand so the wheels are off the ground. -
Page 12: Side Panel & Battery Removal
BRAKE ADJUSTMENT SIDE PANEL & BATTERY REMOVAL The brake levers can be adjusted for ‘reach’. Use a small 2mm Allen key. 12.5 RACING Turn anti-clockwise to bring the reach closer to the bar (for smaller hands). All brakes need periodic adjustment. If and when your brake shows any decline in efficiency The disc brakes on the 12.5 Racing are self adjusting to a point, but correct alignment is vital to or needs adjustment, it is very strongly recommended you take your bike to your local retailer get the maximum performance. -
Page 13: Charging Instructions
CHARGING INSTRUCTIONS IMPORTANT NOTES ABOUT CHARGING • Ensure that the key switch on your OSET is switched OFF before connecting the charger to the • It normally takes three to five hours to charge your batteries from a fully discharged bikes' charge port (see guide below). -
Page 14: Battery Care & Disposal
BATTERY USE AND MAINTENANCE BATTERY CARE AND DISPOSAL Your OSET features a 24v drive system, with 2 x 10ah lead acid batteries joined in series to WARNING! make the 24v. It is very important that the batteries are kept ‘balanced’. If one battery is... -
Page 15: Electrical Diagnostic Flow Chart
LONG TERM STORAGE If you do not plan to use your OSET for an extended period of time (1 month or more), remove the batteries from the bike for storage. • Fully charge the batteries before storing. -
Page 16: Wiring Diagram
WIRING WIRING DIAGRAM Your OSET is an electric bike, and features a considerable number of electrical components and wiring. All must be protected from water and dirt! The components are listed below: Controller: Shown below. This is the ‘brains’ of the drive system. It is a sophisticated and complex component and is non-serviceable. -
Page 17: Setting Up Your Oset For Riding
ALWAYS CHECK BEFORE RIDING. As the responsible adult, you must ensure that the OSET and its rider are ready to ride, every time. The bike must be set to the abilities of the rider, and you must ALWAYS supervise when, Set the ‘response’... -
Page 18: First Ride
When stopped, turn the power off. WARNING! OFF ROAD USE ONLY! OSET Mini Bikes are designed for off road use only and must not be used on public roads or sidewalks. Please check and obey all local laws. CAUTION If the rider drops the bike, ensure that the power is turned OFF before lifting the bike. It is... -
Page 19: Learning Some Technique
The OSET Limited Warranty does not cover or apply to any OSET product used for rental or commercial purposes unless the specific product is designated, labeled, or marketed by OSET as acceptable for rental or commercial use. - Page 20 OSET CONTACT INFORMATION WARNING! BE SAFE! Never use OSET bikes in unsafe situations! Follow all instructions. Follow all laws. VISIT THE OSET WEB SITE FOR YOUR COUNTRY TO: BUY SPARE PARTS AND ACCESSORIES. READ ARTICLES ON ADVANCED MACHINE SET-UP AND TECHNIQUES.
