Page 1: Instruction Manual
Instruction Manual Model PWE-1800 Customer Help Line 1-800-673-1558 WARNING: To reduce the risk of injury, the user must read and understand the instructions before using this product. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE 93567-DP... -
Page 2: Quick Start
uick tart uide ackaGe ontent 1. Power washer unit 2. Manual 3. Nozzle cleaning wire (may be taped to the manual) Hose reel 4. High pressure hose storage only 5. Spray gun holder 6. Nozzle tray 7. Screws (1 for nozzle tray) 8. - Page 3 7. Connect lances to spray gun, 8. The adjustable spray nozzle insert lance into spray gun, had has two (2) positions: •IN push together and at the same OUT position position for high pressure IN position time twist clockwise to lock in spray.
-
Page 4: Table Of Contents
There are no warranties extended other than as provided herein. This limited warranty may be modified only by ECHO. Some states do not allow limitations on how long an implied warranty lasts, so the above limitations may not apply to you. Some states do not allow the exclusion or limitation of incidental or consequential damages, so you may also have other specific legal rights which vary from state to state. -
Page 5: Introduction
Congratulations on the purchase of your ECHO POWER WASHER! Your ECHO POWER WASHER is a power tool in every sense of the word that may be used outside your house and in. It is one of the finest most powerful home-use power washers in the marketplace today. -
Page 6: Gfci
• Never spray flammable liquids. • Never use a water supply to your power washer that exceeds 150 psi maximum. • Never use the power washer in areas that contain combustible dust, liquids or vapors. • Never disconnect the high pressure hose from the power washer while the system is •... -
Page 7: Package Content
ackaGe ontent 1. Power washer unit 2. Manual 3. Nozzle cleaning wire (may be taped to the manual) 4. High pressure hose 5. Spray gun holder 6. Nozzle tray 7. Screws (1 for nozzle tray) 8. High/Low nozzle 9. Turbo Nozzle 10. -
Page 8: Unpacking & Assembly
“PACKAGE CONTENTS” page. • The ECHO POWER WASHER requires some minor assembly. You’ll need a Phillips screwdriver to install the high pressure hose hook and the nozzle tray. - Page 9 High Pressure Hose • Screw the high pressure hose (clockwise) on the left of the unit at the bottom (Fig. 4). Pull back the collar and insert o-ring post into the water outlet far enough so the collar can thread onto the outlet threads until hand tight.
- Page 10 Spray Gun • To lock the trigger of the spray gun aim the gun away from you and push the lock button from right to left, (Fig. 7), after doing so, squeeze or pull the trigger to make sure it is locked and will not move. Always leave lock button in lock position when not in use.
- Page 11 • The adjustable spray nozzle had has two (2) positions (Fig. 10): OUT position IN position High pressure setting Low pressure setting OUT position IN position Spray Low pressure High pressure setting setting Pencil Spray Pencil Spray Fig.10 IN position for high pressure spray. Twist the nozzle counterclockwise until it stops and gap is closed. OUT position for low pressure spray for detergent function.
- Page 12 Water will only flow from the garden hose when it is connected to the clear adapter. • You have now completed the assembly of your ECHO POWER WASHER and are now ready to begin using your electric power washer. Read and observe all safety instructions.
-
Page 13: Operating Instructions
PeratinG nStructionS *!Turn on the water supply at the faucet.!* (Fig. 17) OFF/0 OFF/0 ON/I ON/I Fig. 17 Fig. 18 Powering Up • Make sure the “ON/OFF” switch is in the “OFF” position. The power switch has international symbols for ‘on’ and ‘off’: On (|) Off (O), (Fig. -
Page 14: How To Clean
Lean Cleaning nozzles • A clogged or partially clogged nozzle can cause significant reduction of water pressure coming out of the nozzle and/or cause the unit to pulsate while spraying. • Turn off the unit • Turn off the water supply to the unit •... - Page 15 You can vary the force of your power washer by controlling: a. the angle of the surface being cleaned b. the distance of the nozzle from the surface being cleaned • Never use a narrow high pressure stream of water or the turbo lance on soft surfaces susceptible to damage.
-
Page 16: Storage
toraGe • DO NOT store the power washer where it is exposed to freezing temperatures unless you use Pump Saver. It is recommended that you use Pump Saver for storing in freezing temperatures. Freezing will damage the pump unless Pump Saver is added to the power washer. •... -
Page 17: Pump Saver
aver Pump Saver is a product that protects and prolongs the life of the pump. This will keep the internal parts of the pump lubricated and protected from freezing while being stored in ALL climates. It also assists with protection from internal corrosion. Pump Saver Instructions Follow the previous storage instructions for your power washer. -
Page 18: Replacement Parts
WHEEL ASSEMBLY W/ GUARD ON/OFF SWITCH DETERGENT TANK LANCE HOLDER GFCI NOZZLE TRAY EXTENSION CORD HOOK ACCESSORY BRACKET HOSE, 20’ REAR COVER SPRAY GUN ASSEMBLY PUMP MOTOR ASSEMBLY HIGH/LOW LANCE/NOZZLE FRONT COVER TURBO LANCE/NOZZLE For replacement parts ordering, please visit www.echo-usa.com... -
Page 19: Troubleshooting And Faq
roubLeSHootinG and Unit will not turn on. Make sure the power washer is in the “OFF” position. Plug in the electrical cord to a grounded 120 volt outlet (no electrical extension cord should be used). If the electrical cord will not plug into your outlet, your electrical outlet is not properly grounded and should not be used. - Page 20 Model PWE-1800 W18000001001 - W18000999999 ECHO INCORPORATED 400 Oakwood Road Lake Zurich, IL 60047 1-800-673-1558 Customer Help Line www.echo-usa.com 1-800-673-1558 E-Mail: support@echo-usa.com...
