Summary of Contents for Anleaf Technologies AP300W
-
Page 1: User Guide
Anleaf Technologies Co., Ltd. No.68-6, Zhongxiao Street, Tuku Township, Yunlin County 63359, Taiwan website: www.anleaf.com.tw / e-mail: jh.anleaf@msa.hinet.net USER GUIDE Portable Solar Power Generator Model : AP300W... - Page 2 H.M.I. (Human-Machine Interface) Configuration: Item Item 1 Master switch// LED : Power On/Off AC O/P Switch//LED 2 PV I/P -1: DC sockets for 5.0x2.1mm plug ; 8A 10 AC O/P sockets: Pure Sine Wave 3 PV I/P-2 : terminal block for 25AMax (total) 11 USB DC O/P socket: 5VDC 4 AC I/P// LED :100V~240Vac/ 50~60Hz 12 Battery Storage Display Switch...
-
Page 3: Specifications
Equipment Introduction: ogic Chart for Solar Power Box and PV Panel 1. L 2. Main Components: 2.1. The solar power panel applies to 12VDC energy storage battery system. 2.2. PV charge/discharge controller owns 12VDC/25A input and 12V/30A output. 2.3. Built-in constant current VAC/VDC & C.C Mode AC/DC power supply unit. 2.4. - Page 4 ≧85% Efficiency Overload / Short circuit protection Circuit control with self-recovery fuse 100%≦Load≦500% for 3S; 500%≦Load 1S Overload ability DC Output Cigarette lighter socket 9.6VDC~14.60VDC/6A max output DC plug 24VDC/3Amax (customized) 24V/3A VDC/A USB port 5V500mA 5/500 V/mA Others ℃ Working Temperature -20~75 ℃...
- Page 5 5. Turns on the electric power without a load, please note that the high voltage still runs on AC outlet. 6. Please avoid the environment of high temperature when the battery is using. 7. Do not un-screw the solar power box except the qualified engineer. 8.
-
Page 6: Trouble Shooting
2.1. High Power Storage Battery If the LED indicates green light, the power of battery shows in full level and the voltage is above 12.6V usually. 2.2. Low Power Storage Battery If the LED indicates yellow light, the battery power shows in low level, then user can choose the DC output;... - Page 7 2. Instantaneous over-load The total output of solar power bank is 300W with two AC output sockets. If the two AC outputs gets the value of loads which are more than 150 watts meanwhile, the protection system will auto-cutoff the electric power to protect the inverter.
