Whynter 3.4 cu.ft. Energy Star Stainless Steel Compact

Refrigerator/Freezer

Model # : MRF-340DS

INSTRUCTION MANUAL

Congratulations on your new Whynter product. To ensure proper operation, please read this Instruction Manual carefully before

using this product. Keep this manual in a safe place for future reference.

Table of Contents

Need help?

Do you have a question about the MRF-340DS and is the answer not in the manual?

Questions and answers

Summary of Contents for Whynter MRF-340DS

Page 1: Instruction Manual
Whynter 3.4 cu.ft. Energy Star Stainless Steel Compact Refrigerator/Freezer Model # : MRF-340DS INSTRUCTION MANUAL Congratulations on your new Whynter product. To ensure proper operation, please read this Instruction Manual carefully before using this product. Keep this manual in a safe place for future reference.
Page 2: Table Of Contents
Table of Contents PAGE Safety Precautions 3 - 4 Parts Product Features Installation 7 - 8 Operation and Controls 9 - 10 Reversing the Door Position Care and Maintenance Troubleshooting 13 - 14 Warranty Information...
Page 3: Safety Precautions
Safety Precautions TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK, OR INJURY WHEN WARNING USING YOUR APPLIANCE, FOLLOW THESE BASIC PRECAUTIONS:  Read all instructions before using the appliance.  Never clean appliance parts with flammable fluids. The fumes can create a fire hazard. Do not use an exces- sively wet cloth, industrial solvents, and oil-based products to clean this appliance.
Page 4 Safety Precautions  Transport the appliance in an upright position only.  Always place the appliance on even and hard and level surface.  Close the appliance doors immediately after putting in any items to maintain the internal temperature of the unit. ...
Page 5: Parts
Parts Item Description Freezer Compartment Freezer Door Freezer Rack Temperature Control and Light Refrigerator Rack Glass Shelves (2) Refrigerator Door Can Storage Crisper Drawer Bottle/Carton Storage Leveling Legs (2) NOTE: A drip tray is installed on top of the compressor which can be located at the back of the unit. This tray will catch all the condensation collected by the unit.
Page 6: Product Features
Perfect for workplace break rooms, dorm rooms, or an additional refrigerator for your entertainment space, the Whynter 3.4 cu.ft. Energy Star Stainless Steel Compact Refrigerator/Freezer can store both fresh or fro- zen food and beverages. This space-saving compact refrigerator/freezer is designed with a flat back, allowing it to fit cleanly against the wall or into corners.
Page 7: Installation
Installation Excessive Weight Hazard Two or more people should move and install the appliance. Failure to do so can result in back or other injury. REMOVE PACKAGING MATERIALS IMPORTANT: Do not remove any permanent instruction labels or the data label on your appliance REMOVE TAPE AND GLUE FROM YOUR APPLIANCE BEFORE USING ...
Page 8: Installation
Installation  A standard electrical supply (115 VAC only, 60 Hz, 10A), properly grounded in accordance with National Electrical Code and local codes and ordinances is required.  IMPORTANT: Do not kink or pinch the power supply cord between the appliance and wall or cabinet. MOVEMENT OF YOUR APPLIANCE ...
Page 9: Operation And Controls
Operation and Controls TEMPERATURE CONTROL To obtain the best possible results for your appliance, it is important that you operate it properly. This appliance uses a mechanical ther- mostat control knob which can be located at the inside cabinet of the appliance.
Page 10: Operation And Controls
Operation and Controls  Remove all food, ice cube tray and shelf or transfer to refrigerating compartment.  Clean and wipe out the melted frost with a cloth.  After defrosting, turn thermostat knob to origin position. Note: To avoid damaging the freezing compartment wall, do not use any sharp objects to remove the frost or separate the frozen food.
Page 11: Reversing The Door Position
Reversing the Door Position Caution: To avoid injury to yourself and/or property, we recommend someone assist you during the door reversal process. 1. To access the lower hinge assembly, tilt back or lay the appliance on its back 2. Remove both legs located at the front of the cabi- net: adjustable left on hinge side and fixed leg on opposite side.
Page 12: Care And Maintenance
Care and Maintenance CAUTION: Failure to unplug the appliance during service could result in electrical shock or personal injury. CLEANING YOUR APPLIANCE  Turn off the power, unplug the appliance, and remove all items including glass shelves and crisper drawer. ...
Page 13: Troubleshooting
Troubleshooting Problem Possible Causes Solutions The appliance does not oper-   There is a power failure Ensure the appliance is plugged in and  the power outlet has power The appliance is not plugged in   Replace the broken fuse or reset the A house fuse has blown or the breaker circuit breaker is tripped...
Page 14 Troubleshooting Problem Possible Causes Solutions  Display “E0”, “E1”. “E2”,  “E0” indicates the communication Call for service “E3”, “E4”, “E5” or “E7” error  “E1” or “E2” indicates that the air temperature sensor is failed  “E3” or “E4” indicates that the de- frost sensor in the evaporator is failed ...
Page 15: Warranty Information
When making a warranty claim, please have the original bill or invoice of purchase with purchase date available. Should your Whynter 3.4 cu.ft. En- ergy Star Stainless Steel Compact Refrigerator/Freezer prove defective within one year from the date of purchase, return the defective part or unit, freight prepaid (within two months of purchase;...
