RIKAIN G60 Serial Manual

High speed dome camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
G60 Serial
High Speed Dome Camera

IMPORTANT SAFEGUARDS AND WARNINGS

Prior to installation and use of this product, the following WARNINGS should be observed.
1 Do not attempt to disassemble the camera.
To prevent electric shock, do not remove screws or covers.
There are no user-serviceable parts inside.
Ask a qualified service personnel for servicing.
2 Handle the camera with care.
Do not abuse the camera. Avoid striking, shaking, etc. The camera could be damaged by improper handling or
storage.
3 Do not expose the camera to rain or moisture, nor try to operate it in wet areas.
This product is designed for indoor use or locations where it is protected from rain and moisture.
Turn the power off immediately and ask a qualified service personnel for servicing.
Moisture can damage the camera and also create the danger of electric shock.
4 Do not use strong or abrasive detergents when cleaning the camera body.
Use a dry cloth to clean the camera when it is dirty.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G60 Serial and is the answer not in the manual?

Questions and answers

Summary of Contents for RIKAIN G60 Serial

  • Page 1: Important Safeguards And Warnings

    G60 Serial High Speed Dome Camera IMPORTANT SAFEGUARDS AND WARNINGS Prior to installation and use of this product, the following WARNINGS should be observed. 1 Do not attempt to disassemble the camera. To prevent electric shock, do not remove screws or covers.
  • Page 2 When the dirt is hard to remove, use a mild detergent and wipe gently. Care should be taken not to scratch the dome when wiping it. Afterwards, wipe off the remained part of the detergent in it with a dry cloth. 5 Never face the camera towards the sun.
  • Page 3 temperature: +40°C (104°F)], and humidity is below 90 %. The input power source is AC 230V. 9 Do not install the camera near the air out-let of an air conditioner. The lens may become cloudy due to condensation if the camera is used under the following conditions.
  • Page 4 This symbol indicates that there are important operating and maintenance instructions in the literature accompanying this unit. 2、INSTALLATION INDOOR DOME OUTDOOR DOMR Dimension...
  • Page 5 INDOOR BRACKET CEILING MOUNT WALL MOUNT WALL MOUNT...

  • Page 6: Ceiling Mount

    CEILING MOUNT EMBEDDED MOUNT...
  • Page 7 OUTDOOR WALL Wall MOUNT MOUNT WITH POWER BOX 柱装支架尺寸 外墙角支架 POLE MOUNT CORNER MOUNT (pole diameter Ø100-150mm)

  • Page 8: Wall Mount Bracket

    WALL MOUNT BRACKET POWER BOX SUNSHIELD...
  • Page 9 2.1INDOOR SURFACE MOUNT Decide the mount position on the ceiling Drill 4 holes on firm ceiling for M4 screws 2. Mount the mount base on the ceiling with 4-M4 screws 3.Install the P/T/Z Module in the mount base with clock direction.
  • Page 10 2.2 INDOOR CEILING MOUNT 1 Drill four holes on firm ceiling for M6 expansion bolts with heavy-duty electrical drill . Mount the base of ceiling 支紧螺丝 bracket with 4nuts to the 4 expension bolts on the ceiling 2 Pull power ,RS485 and video cables the ceiling bracket base form the side concave cut.
  • Page 11 2.3 INDOOR WALL MOUNT 1 Drill 4 holes on firm wall for M6 expansion bolts with heavy-duty electrical drill . Push M6 expansion bolts into the holes. 2 Install the P/T/Z module in the mount base in the clock direction...
  • Page 12 2.4 INDOOR EMBEDED MOUNT： 2.Mount the embedded bracket on the false ceiling 1.Cut a hole as following in the false ceiling 3.Fix the embedded bracket with the supplied 4.Mount the secure line to the mount base 3 screws 防坠落保险索...
  • Page 13 Install the P/T/Z mount in the mount Base with the clock direction 装饰圈...
  • Page 14 6.Mount the decorocting ring with 2 screws Ring...
  • Page 15 2.5 OUTDOOR MOUNT A1WITH POWER BOX 1 Mount the power box on the confirm wall 2. Pull power, RS485 and video cables through the wall bracket 3.Connect all the cable in the power box 4.Mount the wall bracket on the power box with 4 nuts 5.Tigten the screw as following 防坠落保险索...
  • Page 16 A2WITHOUT POWER BOX 1Mount the wall bracket on the confirm wall 2. Pull all the RS485 ,video and power cables through the wall bracket 3.Tigten the screw as following 防坠落保险索 协议码、和地址码开关...
  • Page 17 2.5 OUTDOOR CEILING MOUNT B1WITHOUT POWER BOX 1Mount the ceiling bracket on the confirm ceiling 2. Pull all video ,RS485 and power cables through the ceiling bracket 3.Installate the P/T/Z module in the outdoor housing with the clock direction 4.Tighten the screw as following 防坠落保险索...
  • Page 18 B2 with power box 1Mount the power box on the confirm ceiling 2. Mount the ceiling bracket on the power box 3.Pull the video ,RS485 and power cables through the ceiling bracket 4. Install the P/T/Z module in the outdoor housing with right clock direction 5.
  • Page 19 without power box mounting as following 防坠落保险索 协议码、和地址码开关...
  • Page 20 OUTDOOR POLE MOUNT with power box mounting as following...
  • Page 21 CORNER MOUNT WITHOUT POWER BOX 1Mount the corner bracket on the corner of wall 2. Pull all the video ,RS485and power cable the the wall bracket 3.Mount the wall bracket an the corner plate 防坠落保险索 协议码、和地址码开关...
  • Page 22 Corner wall mount With power box 1 mount the cirner bracket on the corner of wall 2 mount the power box on the corner plate 3 pull the video ,RS485 and power cable throngh the wall bracket 4 mount the wall bracket on the power box 防坠落保险索...
  • Page 23 Connection 1. AC24V Power Input 3. Video Output 4. Alarm 5. RS485 data 6. Plastic Ring 7. Speed Dome 8. Plastic Ring 9. Mounting Base...
  • Page 24 1. AC24V Power Input 2. AC24 Heater &Fan AC24v input 3. Video Output 4. Alarm 5. RS485 data 7. Acrylic dome...

  • Page 25: Alarm Input

    ALARM INPUT alarm 1 orange alarm 2 yellow alarm 3 green alarm 4 black alarm COM ALARM OUTPUT brown normal close white COM normal com blue normal open when powered on , the dome camera performs a self-check (including one panning , tilting , zooming and focusing operation)
  • Page 26 3.4 Camera Address and protocol ID setting Address ID Setting...
  • Page 28 The NO.10 ID code should be set to “ON” for the last camera connected Protocol setting Protocol of this speed dome can be set as following Note: all setting must be operated after power off Protocol setting...

  • Page 29: Led Indication

    Pelco is the trade mark of Pelco Corperation LED INDICATION There are 2 LED(green , red ) Red: on----power on Green: on---RS485 connected OK Flashing ---the RS485 signal from controller OK 1. pan/tilt function...
  • Page 30 2.Zoom lens function 2.1 Zoom in and zoom out Zoom in : to press [TELE] Zoom out : to press [WIDE] INDEX FOR ALL MENU LEFT RIGHT DOWN JOCKSTICK...
  • Page 31 Menu display: [CALL] +[8]+[ENTER] menu exit: [PRESET] +[8]+[ ENTER] move joystick up or down to select move joystick right to confirm move joystick left to exit...

  • Page 32: Input Pass Word

    6 Menu Setting after powered on , the speed dome will self-cheek. The monitor will display as following （fig6-0-0） ： ：000 Dome ID ：B01 Protocol 图 6 - 0 - 0 The information will disappear after the self-cheek finished Enter menu :[call]+[8]+[enter]（6-0-1） ： The monitor display: Input pass word：...
  • Page 33 You must input password to enter menu ◆ the original password is “000000” Move joystick to the first×, [preset]+[0]+[enter] Means input “0”code Move joystick to the second × repeat the last operation After passed the password , the monitor display System Info System Setup Camera Control...
  • Page 34 6 Move the cursor to system in for move joystick right .Enter the submenu as following the version of dome Version 1.04 serial number which has been labeled on each camera ：///////////1 Serial ：2003 03 05 Date 6 - 1 - 1 This information can not be changed after factory QC passed 6 .
  • Page 35 图 6 - 2 - 1 Move the cursor to RS485 communication move the joystick right to enter this submenu as following ：000 Dome ID ：B01 Protocol （6-2-2） Move the cursor to constant speed Move joystick right to enter Move joystick up or down to select and move right to confirm same setting : Max speed ,min speed addon support when addon support is set “ON”...
  • Page 36 Input New Password ： - - - - - - Max length of PW Is 6 . Please Setup PW By Preset 0 to 9 . 图 6 - 2 - 3 Input new code , and input the one again New pass word OK will display after finished [call]+[1]+[enter] to exit this submenu 6 .
  • Page 37 ：ON Camera Power ：AUTO Back Light….. ：AUTO Day/Night ：OFF ：ON Digit Zoom ：AUTO Focus Mode 图 6 - 3 - 1 ◆ Back Light ： to set backlight ON/OFF ◆ Day/Night ： to set day /night function on/off/auto ◆ Osd ： to set OSD on/off ◆...
  • Page 38 ◆ Focus Mode ：Near ltd /Infinity/One push/ Manu /auto/AF Low/AF normal./Auto ◆ IRIS Adjust ：Auto/manual/priority ◆ White Balance ：auto/indoor/outdoor/one push/ATW/manual ◆ Image Freeze ：on/off ◆ Next ： Move the cursor to next and move joystick right to enter the next submenu ：OFF Image Reverse ：ON...
  • Page 39 ◆ ：ON/OFF Image Reverse ◆ ：ON/OFF Color Video ◆ ：AUTO/MANUAL Shutter Speed ◆ ：AUTO/MANUAL AGC Adjust ◆ Brightness Adjust ：Not use now ◆ Zoom Speed ：7/6/5/4/3/2/1 Focus Speed ：7/6/5/4/3/2/1 ◆ ：reset to factory setting Reset ◆ Next: 6 . 4 P re s e t c o n t ro l Move the cursor to preset control Move joystick right to enter the submenu ：001...
  • Page 40 Move the cursor to NO: Moving the joystick up or down to change the 0-9. move joystick right to confirm M o v e t h e c u r s o r t o t i t l e M o v i n g t h e j o y s t i c k u p o r d o w n t o s e l e c t t i t l e N O .
  • Page 41 Move the cursor to special function Move joystick right to enter submenu The monitor will display ：ON Proportional Pan ：ON Auto Resume ：FOCUS Joystick Auto Auto Mode Auto Running Privacy Zone 图 6 - 5 - 0 Proportional pan :ON/OFF The pan speed of dong will lower to capture clear picture according to zoom in when the proportional pan is set to ON.

  • Page 42: Delay Timer

    J o y s t i c k a u t o : f o c u s / n o n e / b o t h / i r i s A u t o m o d e Move the cursor to auto mode Move joystick right to enter submenu The monitor will display...

  • Page 43: Full Scan

    A u t o r u n n i n g ( t o u r ) p 2 p s c a n s e t l e f t a n d r i g h t l i m i t o f t h e d e s i re d v i e w a re a , i n p u t t h e o r d e r t o m a k e t h e c a m e r a s c a n b e t w e e n t h e t w o l i m i t s w i t h s e t s p e e d .
  • Page 44 ： Left Limit Right Limit ： Speed 6 - 5 - 3 No: 1/2/3/4 Move the cursor to left limit The monitor will display Call No 1 To save Preset No 1 esc Setting…… Move joystick up , down , left , right , and zoom in , zoom out to select the position you want the [call]+[1]+[enter] to save and exit the set the right limit Move the cursor to setting...
  • Page 45 Move joystick right to enter ,the monitor will display: Call No 1 To save Preset No 1 esc Setting…… Now move joystick up or down and zoom in or out to the position you wanted and [call]+[1]+[enter] to save and exit The monitor will display Speed : 3/2/1/8/7/6/5/4 “8”...
  • Page 46 6 - 5 - 5 mode : pan/both/tilt speed : 3/2/1/8/7/6/5/4 run : to scan automatically SEQ (AUTO TOUR) The preset position can be programmed to be recalled in a set of sequence .this sequence can e set to let the camera scan from one position the next in a cycle at a set speed .This feature is called auto cruise.
  • Page 47 NO: 1/4/3/2 Title :--------------------- Setting : to programe the tour The monitor displays Preset No 1 ESC. Format：No/SPEED/TIME CALL NO1 SAVE 6 - 5 - 7 Patrol function Patrol (path memory function) With this function , the camera can memorize the pan/tilt movements and lens command of the dome within 180 seconds .4 pattern routes are available .
  • Page 48 ： ： Title Record 6 - 5 - 8 No : 1/4/3/2 Title :--------------- Record : to programe patrol routing The monitor will display Call Preset No 1 To CONFRM… RECORD… 6 - 5 - 9...
  • Page 49 after setting , [call]+[1]+[enter] to save and exit the monitor will display WAITING RECORD OK RUN: to run to patrol / tour you set Privacy zone(Privacy masking setting ) When there is a house or even a window within the camera frame ,it is possible to make the area so that it will not appear on the monitor to proior to protect privacy .up to 8 masks of arbitrary size are available Move the cursor to privacy submenu The monitor will display...

  • Page 50: Ptz Position

    PTZ POSITION SCREEN POSITION SIZE ADJUST EXIT ENTER PTZ POSITION PTZ POSITION Now you move joystick up ,down , right , left , to select the position you want [call]+[1]+[enter] to save and exit move the cursor to SCREEN POSITION , and enter the submenu the monitor will display SCREEN POSITION Move the joystick to find the start position you want to mask [call]+[1]+[enter] to save and size adjust...
  • Page 51 The monitor will display SIZE ADJUST Move joystick down or right to mask the position you want [call]+[1]+[enter] to save and exit Active : OFF/ON ON : the masking will display Show : to show the NO. x masking position motion detection now not used Brush...
  • Page 52 Alarm in 1: 001 Alarm in2: 002 Alarm in 3: 003 Alarm in 4: 004 Mode : No Output: NO 6.6 Factory default Move the cursor to factory default Move joystick right to enter submenu The monitor displays FACTORY DEFAULT NO YES Move joystick left to say no Move joystick right twice to say yes...
  • Page 53 Appendix Ⅶ: Troubleshooting Trouble Possible Causes Solution No action, no If the red LED on the circuit connection board 1. Check the power supply to see if it is connected, video after in the housing is not lit, causes may be: or confirm if the plug contact well.
  • Page 54 3. 24Vac transformer outputs too low voltage. replacement of power PCB. 4.The power PCB is bad. Self-testing 1. The dome DIP switch setting is incorrect. 1. Reset the DIP switches as per the DIP switch and image are 2. The two poles of the control cables are setting chart.
  • Page 55 Fan does not 1. Wire connection of fan is not good. 1. Connect the fan wire. If the fan still does not function. function, contact the distributor or factory.
  • Page 56 Vertical roll on 1. Cameras are out of phase. 1. If you are wiring more than one dome to the monitor when same transformer, it is important to wire the switching power connector in each dome the same way. between That is, the wiring from one side of the transformer cameras.
  • Page 57 dome.
  • Page 58 Vague Image 1. Manual focus has been set. 1. Operate dome or call any preset. 2. Unclean down cover. 2. Clean the down cover.
