Summary of Contents for Ogura HCC-19DF
- Page 1 Instruction Manual HCC-16DF HCC-19DF Before installing and operating this machine, read, understand and follow all instructions and operating procedures. Keep these instructions with the machine.
-
Page 2: Table Of Contents
Indicates a potentially hazardous situation which, if not avoided, will result in death or serious injury. *** Ogura & Co., Ltd. shall not be responsible for any incidental damages or personal injuries resulting from negligence of Warnings and Safety Instructions contained in the Instruction Manual. -
Page 3: Important Safety Instructions
• Use only the accessories or attachment described in • Do not carry the tool by the Trigger Switch as this may this Instruction Manual and the Ogura catalog. Use cause unexpected operation and damage or injury. of any other accessories or attachments may result in... -
Page 4: Safety Instructions For Reber Cutter
9. Do not use the tool in damp area or where it may become wet. 10. Use only Ogura genuine blades. 11. Damaged, deformed or cracked blades may cause serious accidents as well as impair opera- tion. Replace with new genuine blades immediately. -
Page 5: Name Of The Parts
Blade A Button Bar Holder HCC-16DF Blade B Battery Cutter Rod Switch Return Valve Pump Case Button Battery HCC-19DF Specifications Model HCC-16DF HCC-19DF Motor DC magnet motor Lithium-ion battery (BL1830) Battery 3.0 Ah, 22-minutes charge Voltage 18V DC Max. Cutting Capacity (Dia.mm) - Page 6 B (attached on the Cutter Rod side.) HCC-16DF (Ø 3 ~ 16) 9 mm , two holes M5 8 mm, two holes M5 HCC-19DF (Ø 3 ~ 20) 11.5 mm , two holes M6 10 mm, two holes M5 Note: Use only genuine Ogura blades.
-
Page 7: Battery Charge
Yellow Notes • The battery charger is for charging OGURA-battery cartridge. Never use it for other purposes or for other manufacturer’s batteries. • If you charge a battery cartridge from a just-operated tool or battery cartridge which has been left in a location exposed to direct sunlight for a long time, the charging light may flash in red color. -
Page 8: Cooling System
“trickle charge (maintenance charge)” mode and keep the battery cartridge fresh and fully charged. To maintain product SAFTY and RELIABILITY, repairs, any other maintenance or adjustment should be performed by a OGURA Authorized Service Centers, always using OGURA replacement parts. Cooling system •... - Page 9 2. Do not destroy battery by fire. 3. Do not expose battery to water or rain. 4. CAUTION - To reduce risk of injury, charge only OGURA rechargeable batteries. Other types of batteries may burst causing personal injury and damage.
-
Page 10: Operating Procedure
90 degrees to the blades as shown in the Stopper figure on the left. The Stopper (HCC-16DF) or the Hold Bolt (HCC-19DF) supports the rebar and keeps it perpendicular to the blades when cutting. HCC-19DF... - Page 11 Stopper (HCC-16DF) or the Hold Bolt (HCC-19DF). When cutting, hold the rebar on the Stopper (HCC-16DF) or Hold Bolt (HCC-19DF) side, as shown in the figure on the left. If not, the cut piece may fly off and cause serious injury to the HCC-19DF operator or bystanders.
- Page 12 The air hole controls the internal pressure and should not be obstructed. Rotating Function of Motor (HCC-16DF & HCC-19DF) The Motor Body can be rotated though 360 degrees, in ei- ther direction, during operation. This feature is particularly...
-
Page 13: Blades Replacement Procedure
BLADES REPLACEMENT PROCEDURE If the cutting edges of the blades are chipped, cracked, deformed, or damaged in any way, their cutting ability will be reduced. Cutting under such conditions may cause further damage and result in personal injury. The blades should be replaced as a set immediately if any damage is found. -
Page 14: Adding Oil
7. Repeat the above procedure several times until the oil level remains correct. CAUTION Only pure hydraulic oil as recommended by Ogura & Company Ltd., should be used in this tool. Recommended oils include the Ogura supplied hydraulic oil, Super Hyrando #46 (Nippon Oil Corporation);... -
Page 15: Trouble Shooting
TROUBLE SHOOTING WARNING: Remove battery before working on machine. PROBLEM CAUSE SOLUTION Top up oil. (Refer to “Adding Oil”) Cutter Rod will not Insufficient oil Manually push back Cutter Rod. extend. Cutter Rod has not returned completely Remove debris and clean due to build up of debris between Cutter Rod and Bar Holder. - Page 16 2661 Hongo Ebina City, Kanagawa-pref., Japan 243-0417 TEL : 046-238-1285 FAX : 046-238-4188 IOJIN.00000/0904...
