Summary of Contents for DALIAN GOODDISPLAY CO. GVD-CBSV3M-CI SERIES
-
Page 1: User Manual
DALIAN GOODDISPLAY CO.,LTD DALIAN GOODDISPLAY CO.,LTD DALIAN GOODDISPLAY CO.,LTD FULL HD-SDI CAMERA GVD-CBSV3M-CI* GVD-CBSV3M-CI* GVD-CBSV3M-CI* User Manual... - Page 2 1、HD-SDI product introduction: 1．HD-SDI Camera characteristics : HD - SDI digital camera use SONY CMOS image sensor, it is suitable for various electronic equipment that need to capture video signal. Support 1080p, 1080I and 720p format. Uses the HD - SDI / 3GSDI digital signals, with night vision function, wide dynamic, image flip, dynamic fill point and IR - CUT switching, English OSD display, RS485 line control&...
-
Page 3: Main Menu
Description for cables 2． ③ ① Power in 12V DC ② SDI signal HD-SDI、3G SDI output。 ④ Keyboard Connect to keyboard。 connector RS485/CDS Connect RS485 or CDS。 ⑤ Press “ENT” to Main MENU; Press UP Keyboard and Down to choice item; Press Left/Right Keyboard to change parameters。... - Page 4 OUT MODE：signal output. Support 720P25/30/50/60、1080I50/60、1080P25/30/50/60。 SAVE ALL：save all of parameters. When change parameters, move cursor to “EXEC” then press left or right to save. EXIT：exit menu. Move cursor to“(––” ， press Left or right exit Menu。 2．GENERAL settings On Main Manu, choice “SEL”...
- Page 5 3．AE MODE: Choice AE MODE on Main Menu and press left or right into submenu. Display as： AE MODE AE HOLD AUTO AGC LIMIT (DB) SHUTTER TIME AUTO BACK TO MENU (– – AE HOLD：Exposure mode setting. Choose HOLD（Lock mode）, fixed model. Or choose AUTO mode， i.e., According to an outside light automatic correction image brightness signal strength and color signal shade.
- Page 6 Product image: Dimension picture:...
-
Page 7: Safety Instruction
Safety Instruction The following is about the correct way of using the products and prevent danger, prevent property damage, etc, and when using please be sure to abide by. 1. Operating Requirement: Please read carefully before using this manual, and keep it for future use 。 Equipment should be installed in accordance with the manufacturer's instructions by the professional service personnel, don't do STH or remove this camera without authorization.
