Xonax XM-VRSUN740BT User Manual

7 inch dash mp5 player
Hide thumbs

Advertisement

Quick Links

Download this manual
USERS MANUAL
7 INCH DASH MP5 PLAYER

Advertisement

loading
Need help?

Need help?

Do you have a question about the XM-VRSUN740BT and is the answer not in the manual?

Questions and answers

Summary of Contents for Xonax XM-VRSUN740BT

  • Page 1 USERS MANUAL 7 INCH DASH MP5 PLAYER...

  • Page 2: Summarizes The Basic Functions

    Summarizes the basic functions This product uses high-definition digital touch screen, Fine bright image, Coupled with high-quality audio processing chip, Has reached the perfect sensual touching visual effects. Efficient platform multimedia system, Supports one-touch GPS satellite navigation system, Bluetooth phone, Bluetooth, music player and plug- in IPOD, USB / SD player.
  • Page 3 Before switching off the ignition, turn off the head unit, otherwise it will cause consumption to car's battery. Make sure the disc entrance is cleaned. If the disc and then disc entrance are dusted, please clean it with soft tower. Otherwise it will bring the dust into the unit and cause unusual of the head unit.
  • Page 4 Connection guide, machine connection diagram (1)This machine uses voltage is DC 12V, negative ground system, pre-installation required to confirm whether your car's electrical system of this type. (2)This unit with automatic antenna subwoofer separately powered. (3)It must be connected with the wire of wiring diagram, if connected incorrectly, it may cause malfunction or damage to the vehicle's electrical system.
  • Page 5 FM Tuner frequency range…………………………………… ……87.5MH-108MHz noise sensitivity……………………………………………………≥37dB AM Tuner frequency range…………………………………………522kHZ-1620KHz noise sensitivity……………………………………………………≥37dB Total voltage ……………………………………………………………13.8V DC output power ……………………………………………………4CH× W real power ………………………………………………………4CH× W Speaker impedance ……………………………………………………4-8Ω Dimension ……………………177(length) ×145(width)×100(height)MM...
  • Page 6 Common icon function instruction Play/Pause Stop Previous chapter Fast backward function Next track Fast forward function Click into Blank screen Return to previous menu Return to main menu...
  • Page 7 Video play introduction MP3 select tracks player 1.Select tracks method 1: In selecting tracks from the list in MP3 mode, Press for next song, Turn for last song. 2.Select tracks method 2: In MP3 mode directly touch the song of the list you choose on the screen is ok when it is playing,also you can use the Remote Control with (0-9) button or 10+ button to select the track.
  • Page 8 Main menu (for touch screen functionality) Main Menu: Press POW button of the head unit , It will enter the main menu.
  • Page 9 Radio Click on the menu to enter radio mode, as shown FM interface Click the to switch between FM/AM. Click the radio will start with the current frequency to search and storage the stations automatically. Memorize the strong signal firstly, then the weak signal.
  • Page 10 Bluetooth phone interface Click the menu to enter the Bluetooth phone function, then using a mobile phone to search for Bluetooth device, connected with the mobile phone (can set up the password yourself,such as 0000),After connected, when there is a phone call coming,Bluetooth system would automatically covert to the Bluetooth hands-free interface, click for start conversation.When phone call end,the call ends,the unit system will automatically recover...
  • Page 11 Click the menu enter mode, as shown, Display AUX interface Click to display the image. Show...
  • Page 12 Setting Click into setting mode (as show) Any key power on/off Brake setting on/off Beep on/off Auto enter GPS on/off GPS mix on/off Click into steer key setting (as picture 1) Click into see GPS signal (as picture 2) Click into factory setting, password is 3368 (as picture 3) Click...
  • Page 13 (Picture 5) (Picture 6) Current version Language switch (In kind prevail) Time setting Click YEAR then press could up or down drag to adjust the correct years. Click MONTH then press could up or down drag to adjust the correct months. Click DATE then press could up or down drag to adjust the correct dates.

  • Page 14: Gps Navigation

    GPS Navigation Click on the main menu , enter into navigation mode (Note: If it is the first time you insert the map card , please follow these steps: click <GPS> - click <NAVI>Set up Select <Navi one>(navigation path) -- select NaviOne.exe file Return. Setting done.) When it is playing mode, please press <GPS>...
  • Page 15 Game Click into play game (as show):...

  • Page 16: Logo Setting

    LOGO setting Click into factory setting, put in password 3368, select LOGO click into LOGO selection. Click could select personalized boot LOGO, format as BMP.

  • Page 17: Change Wallpaper

    Change wallpaper Click change into different wallpaper, as follow: Click could select personalized background, format as BMP.
  • Page 18 MUTE MUTE MODE MODE DELETE DELETE BAND BAND VOL+ VOL+ ENTER ENTER SCAN SCAN VOL- VOL- MEDIA MEDIA - 1 0 - 1 0 + 1 0 + 1 0 ST/MO ST/MO...
  • Page 19 1.PWR:Power on/off 2.MODE:Mode conversion/Hang up the phone call. 3.AMS button:Browse stations/auto station storage. 4.MUTE:press it for mute. 5.BAND:Band conversion/Format conversion/Answer the phone. button:Menu selection/Up and down select tracks. 7.VOL+ button:Turn up volume 8.EQ button:Music mode selection button:Menu selection/On play mode,press it to select Mp3 /Mp5/photos.
  • Page 20 * Aim at the remote control receiver “IR” when you start to use the remote control. Take off the isolation film * Battery change Press the locking button and pull out the battery seat. Put the battery to the right position (With the mark “2025” up side). Fix the battery seat to the right position of the remote control * Instruction of the remote control When it is off, press...
  • Page 21 Mode conversion Press to converse the mode between TV, BT(phone call), IPOD, AUX IN, Radio, DVD, Bluetooth music, GPS, disc box and mode setting. Mark: When GPS is switch off, it will ignore GPS function Pause/Playing When it is playing, press to pause, press it again to recover to playing Mute button Press...
  • Page 22 Press to select the tracks you want to program, press to confirm the items. When the program is finished, confirm to play. Automatic scan/Repeat playing A. When it is playing MP3, repeat to press to switch between “track repeat ”, “list repeat ”“disc repeat (on)””disc repeat (off)”...
  • Page 23 * Volume Press increase the volume. * Zoom Press continuously to switch between “2 x” “3 x ”, “4 x ”,“1/2 x ”, “1/3 x ”, “1/4 x ” “ off”. Press to move the image. * SEL mode Press could select standard (ordinary style), CLASS (classical style), POPS (pop music), ROCK (ROCK music), the hall and movie six different listening acoustics.
  • Page 24 Simple Troubleshooting Guide...
