- Page 1 Dante-MY16-AUD2 Audio Interface Card Getting Started Guide v1.1 :: May 2016...
- Page 2 Avoid installing this unit where foreign objects may fall onto this unit and/or this unit may be exposed to liquid dripping or splashing. Audinate cannot be held responsible for any loss or destruction of data or damage caused by improper use of or modifications to the device.
-
Page 3: Regulatory Information
“ON”, please try to eliminate the problem by using one requirements. Modifications not expressly approved by of the following measures: Relocate either this product Audinate may void your authority, granted by the FCC, or the device that is being affected by the interference. to use the product. -
Page 4: Package Contents
Important Notices Welcome Thank you for choosing the Audinate Dante-MY16-AUD2 Interface Card. This card is an expansion card for use with compatible Yamaha professional audio equipment. It allows the transmission and reception of up to 32 (16x16) channels at 44.1kHz or 48kHz, or 16 (8x8) channels at 88.2kHz or 96kHz of uncompressed 16, 24 or 32- bit digital audio data, using Audinate’s Dante™... - Page 5 Dante network. See www.audinate.com for more information. Dante-MY16-AUD2 Overview The Dante-MY16-AUD2 card can be configured to handle 16 input channels and 16 output channels at 44.1kHz or 48kHz, or 8 input channels and 8 output channels at 88.2kHz or 96kHz, of 16, 24 or 32-bit uncompressed digital audio data using Audinate’s Dante audio networking standard.
-
Page 6: Features And Functions
Obtaining sync lock may take up to 45 seconds when multiple cards are installed. If sync is not achieved in 45 seconds, check the word clock configuration in both the Dante-MY16-AUD2 the card and the Yamaha equipment. Periods of solid red indicates network errors are being detected (such as dropped or corrupt packets). -
Page 7: Getting Started
You can also use Dante Via to route Dante audio - see www.audinate.com for more information. Connection Examples Example 1: Connect a Dante-MY16-AUD2 card to your PC or other Dante-enabled equipment directly using a standard Cat5 or Cat6 Ethernet cable:... - Page 8 Dante Redundancy can be set up and used between any supporting Dante-enabled audio equipment, including Dante-MY16-AUD2 cards. Example 3: Connect multiple Dante-MY16-AUD2 cards to each other in a daisy chain configuration. Requires that up-stream Dante-MY16-AUD2 cards are configured (using Dante Controller) to use Switched mode.
-
Page 9: Basic Operation
Before you configure your clock, you will need to decide whether your Yamaha equipment should be the clock master or whether it should sync to one of the Dante-MY16-AUD2 cards and use the Dante network clock. The Yamaha equipment will need to be configured accordingly – please consult your Yamaha Equipment manual. - Page 10 AUD2 card installed on that console is set to ‘Slave to External Word Clock’, and the Yamaha console has been configured to provide its internal word clock. The Yamaha console clock is now the system clock - it drives the installed Dante-MY16-AUD2 clock, which becomes the PTP Master Clock for the Dante network. System clock...
- Page 11 To redeem your DVS Token for a license ID, go to: www.audinate.com/RedeemDVSToken You will need to log in to the Audinate website, or register an account if you have not done so already. Type your token into the DVS Token text field.
-
Page 12: Important Notices
• Other Dante-enabled devices with Gigabit interfaces Sample Rate Configuration You will need to use the Dante Controller to view and set Dante-MY16-AUD2 sample rate. Please read the Dante- MY16-AUD2 and Dante Controller User Guides for instructions. Some important points: •... -
Page 13: Software Licensing Notice
Important Notices (cont’d) If the Yamaha equipment is providing the clock source (set to Int) all Dante-MY16-AUD2 cards should be set to this rate. • If using 88.2kHz or 96kHz, make sure your Yamaha equipment is set to double-speed, not double- channel. -
Page 14: Limited Product Warranty
Limited Product Warranty 1 GENERAL TERMS Subject to the provisions of this Warranty, Audinate warrants that the Product(s) herein shall conform to their Specifications and that the Hardware shall be free from material defects in materials and workmanship. This Warranty applies to all original purchases of Audinate supplied Product. - Page 15 In the absence of this clear proof of purchase, Audinate reserves the right to refuse to provide free of charge service and the product may be returned at the customer’s expense.
- Page 16 Copyright © 2016 Audinate Pty Ltd. All Rights Reserved. Audinate , the Audinate logo and Dante™ are trademarks of Audinate Pty Ltd ® Audinate Products are protected by one or more of US Patents 7747725, 8005939, 7978696, 8171152, and other patents pending or issued, see...
