NOTEBOOK COMPUTER
CE Declaration of conformity
This equipment complies with the requirements relating to electromagnetic compatibility, EN
55022 class B for ITE, the essential protection requirements of Council Directive 89/336/EEC on
the approximation of the laws of the Member States relating to electromagnetic compatibility.
Canadian Department of Communication Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions from
digital apparatus set out in the Radio Interference Regulations of the Canadian Department of
Communications.
This class B digital apparatus complies with Canadian ICES-003.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identification or explanation and to the
owner's benefit, without intent to infringe.
Symbol for Separate Collection in European Countries
This symbol indicates that this product is to be collected separately.
The following apply only to users in European countries.
- This product is designated for separate collection at an appropriate collection point.
Do not dispose of as household waste.
- For more information, contact the retailer or the local authorities in charge of waste
management.
Advertisement
Table of Contents
Summary of Contents for Zotac NB-102
- Page 1 NOTEBOOK COMPUTER CE Declaration of conformity This equipment complies with the requirements relating to electromagnetic compatibility, EN 55022 class B for ITE, the essential protection requirements of Council Directive 89/336/EEC on the approximation of the laws of the Member States relating to electromagnetic compatibility. Canadian Department of Communication Statement This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of...
-
Page 2: Electronic Emission Notices
NOTEBOOK COMPUTER Electronic Emission Notices WARNING! Federal Communications Commission (FCC) Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 (Subpart B) of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 3 NOTEBOOK COMPUTER Precautions - Please read the manual carefully and thoroughly. - Keep the notebook away from humidity, high temperature, and dirty or dusty environments. - Always place the notebook on a stable surface when using. - Always handle the notebook with care. - Do not touch or put pressure on the LCD screen.
-
Page 4: Table Of Contents
NOTEBOOK COMPUTER Content 1. Notebook Overview ----------------------------------------------------------------------------------------- 7 1-1 Opened top side --------------------------------------------------------------------------------------- 7 1-2 Front side ------------------------------------------------------------------------------------------------ 8 1-3 Left side -------------------------------------------------------------------------------------------------- 8 1-4 Right side ------------------------------------------------------------------------------------------------ 8 1-5 Rear side (without battery) -------------------------------------------------------------------------- 9 1-6 Bottom side ---------------------------------------------------------------------------------------------- 9 2. - Page 5 NOTEBOOK COMPUTER...
-
Page 6: Notebook Overview
NOTEBOOK COMPUTER 1 Notebook Overview 1-1 Opened top side 1. Camera 4. Touch Pad 2. LCD Screen 5. Left Mouse Button 3. LED Indicators :- 6. Right Mouse Button - Wireless LAN - Power LED Indicator - HDD - Battery Charging LED Indicator - Num Lock (Red - Charging, Green - Present) - CAP Lock... -
Page 7: Front Side
NOTEBOOK COMPUTER 1-2 Front side Microphone Jack Headphone Jack Right Speaker Out Left Speaker Out 1-3 Left side Memory Card Reader (SD/MMC/MS) USB 2.0 Port VGA Port DC Jack (For power adaptor) 1-4 Right Side Safety Lock LAN Port (10/100) USB 2.0 Ports Express Card 34 Slot Notebook Overview... -
Page 8: Rear Side (Without Battery)
NOTEBOOK COMPUTER 1-5 Rear side (without battery) SIM Card Slot (optional) Battery Pack Connector 1-6 Bottom side HDD and Memory Cover Battery Latch Battery Pack Battery Lock Notebook Overview... -
Page 9: Getting Started
NOTEBOOK COMPUTER 2 Getting Started 2-1 Installing battery pack Despite using a power adapter, the notebook can be powered on by using the rechargeable battery. 1. Make sure the power adapter is disconnected from the notebook before installing battery. 2. To install the battery into the notebook, push the battery according to the direction shown in the picture below until the battery is locked into place. -
Page 10: Connect A/C Power Adapter
NOTEBOOK COMPUTER 2-3 Connect the A/C power adapter 1. Connect the power adapter with the power cord 2. Plug the DC end of the power adapter into the power jack of notebook 3. Insert AC end of the power adapter into power outlet 4. -
Page 11: Tips And Safety Notes
NOTEBOOK COMPUTER 3 Tips and Safety Notes 3-1 LCD 1. Fold up the notebook gently to prevent damage to the LCD. 2. Take out all materials on top of the keyboard before folding up the notebook. 3. Gently adjust the viewing angle of the LCD screen to fit posture. 4. -
Page 12: Using The Notebook
NOTEBOOK COMPUTER 4 Using the Notebook 4-1 Turn on the Notebook 1. Open the LCD screen and adjust the screen to a proper view. 2. Press the POWER button to turn on the notebook. POWER button 4-2 Adjusting the LCD brightness The brightness of the LCD can be adjusted by pressing function keys on the keyboard: <Fn>... -
Page 13: Using Keyboard
NOTEBOOK COMPUTER 4-3 Using keyboard The notebook keyboard is a U.S. standard keyboard with 83 keys, which is similar to a normal keyboard used with desktop computers, except the number pad keys and function keys are integrated with some of the normal keys. The characters in blue found on the keyboard represent those special functions. -
Page 14: Using Touch Pad
NOTEBOOK COMPUTER 4-4 Using touch pad The touch pad integrated in the notebook is a pointing device which is compatible with standard mouse in order to control the cursor on the screen and make selection with the two buttons located below the pad. The cursor moves accordingly by sliding a finger on the surface of the touch pad. -
Page 15: Using Express Cards
NOTEBOOK COMPUTER 4-6 Using Express card The notebook features an Express Card slot for hardware expansion. The slot can accept “Express Card/34” form factor cards. The card can only be inserted in one orientation. Using force to insert the card may lead to damage of card and the card slot. -
Page 16: Connecting An Analog Display
NOTEBOOK COMPUTER 4-8 Connecting an analog display The notebook PC supplies a VGA port for connecting an external analog display or compatible projective devices. 1. Turn off the notebook. 2. Insert the 15-pin D-sub plug of the monitor to the VGA port. 3. -
Page 17: Installing Hardware Inside The Notebook
NOTEBOOK COMPUTER 5 Installing Hardware inside Notebook 5-1 Removing hard disk 1. Open the hard disk cover of the notebook. HDD & Memory Cover Open Screws 2. Take out the original hard disk with hard disk bracket from the notebook. Hard Disk Bracket Hard Disk Drive (HDD) Screws... -
Page 18: Installing Hard Disk
NOTEBOOK COMPUTER 3. Detach the hard disk from hard disk bracket and keep the screws. Screw Hard Disk Bracket HDD Connector Hard Disk Drive Screws 5-2 Installing hard disk 1. Open the hard disk cover of the notebook. HDD & Memory Cover Open Screws Installing hardware inside Notebook... - Page 19 NOTEBOOK COMPUTER 2. Attach the new hard disk to hard disk bracket with the screws. 3. Place the hard disk inside the notebook. Hard Disk Drive Screw HDD Connector Bracket Screws Screws Hard Disk Bracket 4. Move the hard disk according to the direction shown to attach the hard disk into the connector.
-
Page 20: Removing Ram Module
NOTEBOOK COMPUTER 5. Close the hard disk cover. HDD & Memory Cover Screws 5-3 Removing RAM module 1. Open the hard disk cover. HDD & Memory Cover Open Screws Installing hardware inside Notebook... - Page 21 NOTEBOOK COMPUTER 2. Move the two arms of the RAM socket as the picture shows to release the RAM module. Socket Arm Hard Disk Drive (HDD) Memory Module Memory Socket Socket Arm 3. The RAM module can be easily taken out. Hard Disk Drive (HDD) Memory Module Installing hardware inside Notebook...
-
Page 22: Installing Ram Module
NOTEBOOK COMPUTER 5-4 Installing RAM module 1. Insert the RAM module into the RAM socket at a 45 degree angle. Hard Disk Drive (HDD) Memory Module 2. Gently press the RAM module down until it is locked by the arms of the socket. Hard Disk Drive (HDD) Memory Module Installing hardware inside Notebook... -
Page 23: Installing Mini-Pcie Card Module
NOTEBOOK COMPUTER 3. Close the hard disk cover. HDD & Memory Cover Screws 5-5 Installing Mini-PCIe card module 1. Open the hard disk cover. HDD & Memory Cover Open Screws Installing hardware inside Notebook... - Page 24 NOTEBOOK COMPUTER 2. Insert the Mini-PCIe card into the Mini-PCIe slot. Hard Disk Drive Screws Memory Module Mini-PCIe slot Mini-PCIe module 3. Use screw to fix the position of the card module. 4. Close the hard disk cover. HDD & Memory Cover Screws Installing hardware inside Notebook...
-
Page 25: Bios Configuration
NOTEBOOK COMPUTER 6 BIOS Configuration Press “F2” when the boot up screen is shown in order to enter the BIOS configuration utility. 6-1 Main The time and date of the system can be set in the “Main” page. Use “↑” and “↓” to move the cursor. -
Page 26: Boot
NOTEBOOK COMPUTER 6-3 Boot Boot order of various bootable devices can be configured on this page. Shift the boot order of the devices by pressing “+” or “-” buttons. BIOS Configuration... -
Page 27: Appendix A Troubleshooting
NOTEBOOK COMPUTER Appendix A Troubleshooting Q: What should be done on the notebook if the system is halted? A: Press and hold the Power button for about 5 seconds to turn off the notebook. Wait for a while and turn it on again. Q: What should be done when the notebook cannot be turned on? A: i) Use the power adapter to supply power to notebook and try to turn the notebook on. -
Page 28: Appendix B Specifications
NOTEBOOK COMPUTER Appendix B Specifications:- : Intel ATOM N270 (1.6GHz) Chipset : Intel 945GSE LCD Panel / Resolution : 10” WSVGA (1024x600) with LED backlight Graphic Engine : Intel GMA 950 with shared video memory HDD Storage : 2.5” SATA HDD Memory / Slot : Supports up to 2GB DDR2 via SODIMM slot Network...
