Summary of Contents for Identivision IIP-CB3100FWL
- Page 1 IIP-CB3100FWL Indoor WIFI true D&N IP Camera IIP-CL3200F Outdoor true D&N IR LED IP Camera Installation Manual Ver. 1.1...
-
Page 2: Table Of Contents
TF card installation ......................6 Installation on bracket ....................... 6 Camera Design, parts ......................7 2.4.1 IIP-CB3100FWL Cube type WIFI indoor true D&N IP camera ......... 7 2.4.2 IIP-CL3200F/06 Outdoor True D&N IP camera ............8 2.4.3 Network connection： .................... 8 IE log-in basic operation ........................ - Page 3 4.5.3 Auto-maintain ....................... 46 4.5.4 Default ........................47 4.5.5 Upgrade ......................... 49 4.5.6 Reboot ........................49 Device info ........................49 4.6.1 Log ......................... 49 4.6.2 Version ........................50 Cloud Function ..........................52 FAQ & Maintenance ........................59 FAQ and answer ....................... 59 Maintenance ........................
-
Page 4: Important Safeguards And Warnings
Please install in ventilated place. Keep the vent clean. Use within the rating input and output scope. Suitable products： This manual is suitable for all series of IP Camera from Identivision including indoor box type, IR waterproof type, whelk type, dome type, home-use robot type, etc. Special announcement：... -
Page 5: Product Introduction
1 Product introduction 1.1 Product summary The IPC can online apply as a part of a safety surveillance network. With the professional network video surveillance software it achieves the strong network communication ability and telecommunication ability. And IPC can individually work also. It is applied to all kinds of occasion that need network remote monitoring, such as: ... -
Page 6: Open Case Checking And Cable Connection
Telecom interface With RS485 interface for PTZ control With Ethernet port for remote access function, remote upgrade & maintance function. Intelligent operation For the same setting operation on menu, you can do copy & paste operation. 2 Open case checking and cable connection 2.1 Open case checking When you receive this product, Firstly, check model No. -
Page 7: Camera Design, Parts
2.4 Camera Design, parts 2.4.1 IIP-CB3100FWL Cube type WIFI indoor true D&N IP camera DC12/5V Power Supply：12/5V DC power supply, wrong power supply will make the device unusable Indication Light: It's working status of device, when power on is red, finish startup is green, local record is green flicker, alarm activated is red flicker ... -
Page 8: Iip-Cl3200F/06 Outdoor True D&N Ip Camera
Antenna: Use for WIFI 2.4.2 IIP-CL3200F/06 Outdoor True D&N IP camera 2.4.3 Network connection： Connect to LAN and WAN via common standard, using the PC that is in the same LAN line with IPC by software or IE browser to set parameters, real-time preview, remote playback and download, etc. -
Page 9: Ie Log-In Basic Operation
3 IE log-in basic operation Remark: keys in grey means do not support 3.1 Boot Connect to power, and then IPC is auto boot. Remark： 1. Make sure that the input voltage corresponds with the switch of the IP Camera power supply. 2. -
Page 10: Preview
Pic: 3.1 Log-in For safety reason, at first log-in, please go to “Account” to modify user name and password, see chapter 4.5.2 account manage). 3.4 Preview After log-in successfully, will come out window of bit rate type as pic 3.2, and can choose the main stream or extra stream u want for preview, and also can click at left side of preview page to set it. -
Page 11: Record
Pic: 3.3 shortcut menu 3.5.1 Record Record function including: device record and snapshot settings. 1. Record setting Device should install TF card to realize this function. -
Page 12: Playback
Pic: 3.4 Record setting Pic: 3.5 Snapshot setting 3.5.2 Playback To play the video file in TF card, can click at upper left side on monitor page, to enter video playback page. Remark: Device normal playback, the TF card that used for video storage should be set as read/write or read only (please refer to HDD manage). - Page 13 Pic 3.6 Playback 【Playback control button】see detail in below chart； Button Function Button Function Play Pause Slow-play Fast-play Previous frame Next frame Stop Chart 3.1 playback control button list Remark：Playback by frame should under the status of playback pause. 【Operate tips】to show the button function when cursor point it Special feature：...
-
Page 14: Image Color
Partial enlargement：when single view full screen playback, can use right button to choose any size of area from the image, click left button in the chosen area, can enlarge this area to playback, double click left button will exit. 3.5.3 Image color Set image parameter of chosen channel (when single view preview, it should be current channel, when multi-view preview, it should be the channel where the cursor stay), you can enter the page by shortcut menu. -
Page 15: Main Menu
4 Main Menu 4.1 Main menu guideline Main Submenu Function summary Menu Record Set record config, record type, record period, etc. Record Snapshot Set snapshot period, type , etc. Set motion detect alarm channel, sensitivity, area, Video Alarm linkage parameters: alarm output, snapshot,... - Page 16 Set video blind alarm channel, sensitivity, linkage Video parameters, alarm output, snapshot, recording, PTZ, blind email sending and ftp upload, etc. Set video lost alarm channel and linkage parameters: Video lost alarm output, recording, snapshot, PTZ, Email sending, FTP upload, etc. Set alarm input channel and linkage parameters: Alarm alarm output, recording, snapshot, PTZ, email...
- Page 17 Set channel, PTZ protocol, address, baud rate, data Config bit, stop bit, parity Set protocol, address, baud rate, data bit, stop bit, RS485 parity Set serial port function, baud rate, data bit, stop bit, RS232 parity Exposure mode, Day/Night mode, Backlight Camera compensation, Auto iris, profile, AE reference, AGC,...
-
Page 18: Record
4.2 Record Device do operation regarding record, including: record & snapshot. 4.2.1 Record setting Set IPC parameter, when firstly turn on, system is default with record for 24hours. You can go to【 Device Config】>【Record】>【Record】to do related setting. Remark: Device installed with TF card and set it as Read/Write, and then it can normally record. (Detail please refer to chapter 4.5.1 HDD manage) Pic: 4.1 Record setting 【Length】to set the length of each recording file between 1-120min, default is 60min；... -
Page 19: Snapshot Storage
Regular：The DVR Performs the regular recording in the set time section. The video file type is “R”. Detect: Trigger the “motion detect”, “camera mask” or “video loss” signal. When above alarm is set as opening recording, the “detection recording” state is on. The video file type is “M”. Alarm: Trigger the external alarm signal in the set time section. -
Page 20: Alarm Function
【Type】Three types: regular, detect and alarm 【Record type】Three types: regular, detect and alarm Regular: snapshot at set period Detect: snapshot at set period when motion detect, video blind and video loss which are preset for snapshot enable. Alarm: snapshot at set period when alarm in which is preset for snapshot enable. Note: for related alarm function, please refer to chapter 4.3. - Page 21 Pic: 4.4 motion detect setting interface 【Enable】 means enable motion detect function, enable it firstly then can do related setting. 【Sensitivity】base on sensitivity can set 6 grades: ，the higher of sensitivity to the moving objects, the easier to sense the motion happens； 【Region】Click Setting，enter the setting region of PAL22X18，light blue region is the guard area of motion detect, dark blue region is the unguarded area (show the monitor page), see pic 4.5.
- Page 22 Pic: 4.5 region setting 【Period】Trigger the motion detect signal in the set time section, see pic: 4.6. You can set according to week or set uniformly. Each day is divided into four time sections. Tick , mean setting is valid.
- Page 23 图4.6 time setting 【Interval】Only one alarm signal is turned on even there are several motions detect signals in the set interval 0-600s. 【Alarm output】Start the external equipment of corresponding linkage alarm when the motion detect alarm is turned on.； 【Delay】Delay a few moments and stop when the alarm state is turned off. The range is 10~300 seconds.
-
Page 24: Video Blind
【Delay】When alarm is over, recording will last some seconds (10~300sec), then stop.； 【EMAIL sending】tick ，means when alarm happen, link email sending to inform user. Remark：sending email, need to do related setting at【Net service】. 【FTP upload】tick ，means when alarm happens, if record or snapshot channel was chosen, the record file and snapshot image will be uploaded to the appointed position. -
Page 25: Abnormal
Pic: 4.9 Video lost Setting detail: refer to chapter 4.3.1 motion detect. 4.3.4 Abnormal Analyze and detect the software and hardware of current device, when abnormal issue was detected, device will make related actions. -
Page 26: System Setting
Pic: 4.10 abnormal 【Event type】choose event type at drop-down box, 【Enable】tick to enable，open abnormal deal function, setting is valid only if it is enabled. 4.4 System setting To set parameter of all kinds of functions, setting including: General、Encode、Network、Net service、GUI display、PTZ config/RS485、RS232、Camera parameter. -
Page 27: General Setting
4.4.1 General setting Pic: 4.11 General setting 【System time】You can set current date and time of IP Camera. 【Date format】choose date showing format, including：year/month/date、month/date/year, date/month/year, 【Date separator】Choose list separator of the data format, 【Time format】choose time format, including: 24-hour and 12 hour； 【Language】at present support 29 kinds of language: simplified Chinese, Tradition Chinese, English, Bosnian, Finnish, French, Greek, Hungarian, Italian, Japanese, Germany, Polish, Portuguese, Russian, Spanish, Thai, Turkish, Vietnamese, Romanian, Brazilian, Indonesian, Swedish,... -
Page 28: Encode Setting
Pic: 4.12 DST (Week) setting Pic: 4.13 DST (Date) setting 4.4.2 Encode Setting Set video/audio encode parameters, including image parameters of record file, remote monitor, etc. Left part is to set the encode parameter of each separated channel, right part is to set encode parameter of extra stream, dual stream is using one high bit rate stream for local high definition storage, support D1/HD1/CIF/QCIF encode, one low bit rate stream (QCIF encode) for net transmission, in order to maintain local storage and remote net transfer. - Page 29 Pic: 4.14 Encode setting Encode setting 【Compression】Standard H.264MP； 【Resolution】show types of resolution: D1/HD1/CIF/QCIF； 【Frame rate】adjustable, real-time standard is： PAL，25 fps NTSC，30 fps； 【Bit rate type】you can choose CBR or VBR, image quality have 6 grades to choose under VBR type, then you can manual choose the bit rate value under CBR type. 【Image quality】set bit rate value to change the image quality, if supporting facility is available, the larger of bit rate value, the better of image quality.
-
Page 30: Network Setting
PAL：VGA（512~2048kbps） CIF（64~1024kbps） QCIF（64~512kbps） QVGA（256~1024kbps ） QQVGA（64~512kbps） NTSC：VGA（512~2048kbps） CIF（64~1024kbps） QCIF（64~512kbps） QVGA（ 256~1024kbps） QQVGA（64~512kbps） PAL：D1（512~2560kbps） HD1（384~2048kbps） CIF（64~1024kbps） QCIF（64~512kbps） NTSC：D1（512~2560kbps） HD1（384~2048kbps） CIF（64~1024kbps） QCIF（64~512kbps） PAL：720P（1024~4096kbps） NTSC：720P（1024~4096kbps） PAL： 1080P（676~5415kbps） NTSC： 1080P（578~4630kbps） 4.4.3 Network setting Pic: 4.15 Network setting 【Net card】you can choose wired net card； 【DHCP enable】to auto get IP address (not suggested) ；... -
Page 31: Net Service
【DNS setting】Domain Name Server. It translates the domain name into IP address. The IP address is offered by network provider. The address must be set and reboot then it works.； 【TCP port】default is 34567； 【HTTP port】default is 80； 【High speed download】Network high speed download； 【Transfer policy】there are 3 policies, adaptive, quality preferred, fluency preferred. - Page 32 Pic: 4.17 PPPOE Enable：Tick means chosen enable it firstly, and then the setting is valid Input user name and password that provided by ISP（Internet server provider）, save it and reboot device, after reboot, IPC will auto connect to network by the way of PPPoE, if it is successful 【IP address】will be changed to the dynamic WAN IP that just get.
- Page 33 4.19 EMAIL setting SMTP server：address of email server，can be IP address or domain name（if it is domain name, need to make sure the DNS is correct, and then domain name can be correctly analyzed） Port: Email server port number.； SSL: Decide whether using Secure Socket Layer protocol to login； User Name: Apply the email server user name.
- Page 34 Pic: 4.20 IP authority setting（black list） Pic: 4.21 IP authority setting（white list） 【DDNS】 Pic: 4.22 DDNS setting To analyze server via dynamic domain name, choose DDNS type Host domain name：Provide the domain name registered by DDNS； Server domain name：the domain name that analyze server； User name：Provide the account registered by DDNS.
- Page 35 When the DDNS is successfully configured and start, you can connect the domain name in the IE address column to visit. 【FTP setting】 FTP is available only when alarm happens, or alarm activates record and snapshot, it will upload related record and snapshot pictures to FTP server. Pic: 4.23 FTP setting 【Enable】Click Enable, then all settings will be available 【Host IP】：IP address of FTP server；...
- Page 36 Pic: 4.24 ARSP setting 【Type】：choose DNS 【Enable】：tick means chosen, setting is valid only when it is enable. 【Server IP】：IP address of DDNS server 【Port No】：port No of device, corresponding to the listen port of DDNS； 【User name】：the user name that for device to log-in DDNS； 【Password】：password for above user name 【Upgrade period】：Time interval of device synchronously to DDNS.
- Page 37 【Alarm report】tick means chosen, report alarm information to server 【Log report】tick means chosen, report log information to server 【Mobile monitor setting】 To visit the device by mobile, please make a router mapping of this port and use CMS to monitor and operate it by protocol. Pic: 4.26 Mobile monitor setting 【Enable】tick means chosen, open mobile monitor function, setting is valid only when it is...
-
Page 38: Wi-Fi Settings
【TCP】：Router will automatically distribute TCP port for the device, when monitoring via CMS, it need this port. 【Mobile Port】Router will automatically distribute Mobile Port for the device, when mobile monitor, it need this port. 4.4.5 Wi-Fi settings Enable – You can enable the Wi-Fi network card Search –... -
Page 39: Gui Display
4.4.6 GUI display At local preview interface, including：Channel name, Time title, Channel title, Region cover Pic: 4.28 GUI display 【Channel Name】Click the channel name modify button and enter the channel name menu. Modify the channel name. The 16 Chinese characters and 25 letters are supportive. 【Time title】tick ；... - Page 40 【Region ，choose Cover】tick region cover quantity, then click setting ，enter related channel, user can use mouse to choose any size of cover region, (the covered region, video output should be in black) 【Time title】&【Channel title】set time title and channel title whether need be show out and the position to show.
-
Page 41: Rs232
Pic: 4.30 Channel and time title setting 4.4.7 RS232 Pic: 4.31 RS232... -
Page 42: Camera Parameter
【Serial Port Function】Common serial port is used to debug and update program or set up specific serial port. 【Baud rate】Choose the corresponding baud rate length 【Data bits】Include 5-8 options. 【Stop bits】Include 2 options； 【Parity】Include odd, even, mark, space.。 4.4.8 Camera parameter Pic: 4.32 camera parameter 【Expose】can choose automatic（0.1 milisecond-80 millisecond）, or manual（1/25，1/50，... -
Page 43: Advanced
【IR_CUT】can choose automatically switch or IR synchronous switch, default is automatically switch 【Mirror image】tick ，means enable the convert of left and right of monitoring page 【Over turn】tick ，means enable the convert of up and down of monitoring page. 【Anti-flicker】tick ，enable anti-flicker if the lighting is solved with fluorescent light. 【Front-end Command】fill in command and send out, front end of IP camera will carry out this command 4.5 Advanced... -
Page 44: Account
4.5.2 Account Manage the user authority of this device Remark：1. The character length is 8 bytes at most for the following user and user team name. The blank ahead or behind the character string is invalid. The middle blank in the character string is valid. - Page 45 Pic: 4.35 Modify passwords 【Add user】Add a user in the team and set the user purview. Enter the menu interface and input the user name and password. Choose the team and choose whether cover using the user. Cover using means that the account can be used by multiple users at the same time. Once choose the team the user purview is the subclass of the team.
-
Page 46: Auto-Maintain
Pic: 4.37 add group 【Delete user】Delete the current user. Choose the user and click delete user button. 【Delete Group】Delete the current group. Choose the group and click delete group button. Pic: 4.38 delete group 4.5.3 Auto-maintain The user can set the auto reboot time and auto file deleting time limit. -
Page 47: Default
Pic: 4.39 auto maintain 4.5.4 Default The system restore to the default setup. You can choose the items according to the menu.）... - Page 48 Pic: 4.40 default...
-
Page 49: Upgrade
4.5.5 Upgrade Pic: 4.41 system upgrade 【Upgrade file】to select upgrade file via IE or client software to do upgrading. 4.5.6 Reboot To do soft reboot of IP camera 4.6 Device info Shows information of device, including： Log, Version 4.6.1 Log Base on set searching way to check log information LOG type can be divided into：system operation, configuration operation, data management, alarm affair, recording operation, user management, file management and so on. -
Page 50: Version
Pic: 4.43 Log info 4.6.2 Version Display the basic information such as hardware information, firmware version, built date, serial No. and so on. - Page 51 Pic: 4.44 version info...
-
Page 52: Cloud Function
5 Cloud Function Make sure the device IP address is in the same LAN of router, default IP address is 192.168.1.10 Go to CD->English->Software to find Upgrade Tool and install it Run Upgrade Tool, Clock "IP Search”, you will find the device IP, see below picture Picture2.2 IP Configure Select the device to config IP, see below picture Picture2.3 IP Configure... - Page 53 Picture 2.5 WEB GUI After login, enter into below picture Picture2.6 WEB GUI after login Client Software Operation Go to CD->English->Software, find CMS Install CMS, run it, default user name: super, no password Picture 2.7 CMS Interface Device manage: System->Device manage, see below picture...
- Page 54 Picture2.8 Device manage Add Device, see below picture Picture 2.9 Add device Add device modes: IP address, domain name, serial number and MAC address. Add IP address ---- IP search and manually add IP address IP search: Click "IP search" and select the DVR IP address to add device Manually add IP address: Click "add device”, then fill with IP address, TCP port, user name, and password Device connection: double click the device name, then choose main stream or extra stream, see...
- Page 55 Picture 2.10 Connect device successfully Monitor the device by WAN (cloud server) If this is the first time for you to visit it, please read it （1）Login Cloud http://xmeye.net （2）User guide, see below picture. （3）Clicks „Next”, then search IP address, see below picture:...
- Page 56 （4）Click "Next", see below picture （5）Click "Next", see below picture. （6）Click "Next", enter to user registration page, and see below picture. （7）Click "Next", its shown device serial number and another name, see below picture. （8）Click "Next", its shown registration finished page, see below picture.
- Page 57 （9）Click "Finish", see below picture. 2.3.2 Login by User, device manage (you can manage multiple devices if login by user). （1）Login ; click "By User", input user name and password http://xmeye.net （2）After login, click "Device manage" -> "Add device”, see below picture （3）Enter "My device", double click device name, and then you can monitor the device, see below picture...
- Page 58 Login by device and device manage （1）Go to http://xmeye.net ,click "By Device", fill with serial number and verify number. （2）Enter into monitor live, see below picture...
-
Page 59: Faq & Maintenance
6 FAQ & Maintenance 6.1 FAQ and answer If the problem u meet is not included in below items, please contact to local technical support or call customer service of headquarter, we will whole-heartedly serve for you. Q：there is dark corner of lens A：... -
Page 60: Maintenance
c. IP address of camera and router is not in the same network segment. Q: NTP function in net service is not working A： enable related function of NTP server. Q：cannot search out recent video file, if we set client side recording via CMS A：If the client side is under recording, you cannot search out file, you need to stop recording firstly, and then you will search out. -
Page 61: Appendix 1.Tf Card Capacity Calculation
3、Do not pull out the video signal line or RS-232 port or RS-485 port with the power on。 4、Please keep the IPC away from heat resource, and regularly investigate system and maintenance. 7 Appendix 1.TF card capacity calculation First time install IP Camera; make sure the TF card was installed 1.
