Setting up the Polycom Media Cart
1
©2005, Polycom, Inc. All rights reserved. Polycom® and the Polycom logo are registered trademarks and VSX is a trademark of Polycom, Inc.
Kensington and the Kensington logo are registered trademarks of Kensington Technology Group.
M5 x 10 Phillips
M4 x 12 Phillips
panhead sems
flathead
i
www.polycom.com
1725-22668-001/A
1/4-20 x 3/4
Phillips panhead
1/4-20 x 3/4
1/4-20 x 3/8
Phillips flathead
Phillips panhead
M5 x 30 Phillips
panhead sems
M3 x 4
sockethead cap
