- Page 1 LED COLOR TV Operating Instruction E32D7212 Please read these instructions before operating your set and retain them for future reference. SACL00-Exxx...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions – All the safety and operating instructions should be read before this product is operated. 2. Keep these instructions – The safety and operating instructions should be retained for future reference. 3. Heed all warnings – All warnings on the appliance and in the operating instructions should be adhered to.
- Page 3 WARNING: The battery (battery or batteries or battery pack) shall not be exposed to excessive heat such as sunshine, fire or the like. WARNING: The mains plug is used as disconnect device, the disconnect device shall remain readily operable. This equipment is a Class II or double insulated electrical appliance. It has been designed in such a way that it does not require a safety connection to electrical earth.
- Page 4 Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
-
Page 5: Table Of Contents
CONTENTS 1. Connection and Preparation of TV..........2 1.1 Accessories ................. 1.2 Installation of Stand............. 1.3 Installation of Wall Mount Kit(Optional) ........2 1.4 Keys and Interfaces............. 1.5 Remote Control..............4 1.6 Installation of Batteries............2. Basic Operation................5 2.1 Power ON/OFF.............. -
Page 6: Connection And Preparation Of Tv
LE D COLOR TV... -
Page 7: Keys And Interfaces
1.4 Keys and Interfaces The design and specification takes actual products as the standard 1. Remote sensor window 2. Power indicator 3. Speaker 4. Power switch 5. Menu key 6. Program “ ” key 7. Program “ ” key 8. Volume “ ” key 9. -
Page 8: Remote Control
LE D COLOR TV 1.5 Remote Control 1. POWER: Standby turn on and off. 2. SOURCE: Select the signal source. 3. 0~9: Continue to press the keys to select SOURCE a channel. :Dot button and minor channel number.Enter to confirm. 5. -
Page 9: Installation Of Batteries
1.6 Installation of Batteries 1. Open the back lid of the remote control. 2. Install two 7#(AAA)1.5V batteries. Ensure the correct polarity of the batteries. 3. Cover the back lid. Please take out of the batteries from the remote control for long time of no use. If the remote control doesn't work properly, please carry out the following checks. -
Page 10: Menu Option Adjustment
LE D COLOR TV Component HDMI1 MEDIA HDMI3 HDMI2 When selecting the signal source, the screen will display the information. TV mode When there is no signal from the selected source, the warning message will be displayed as per illustration. Either change the channel in TV mode or press Source button to change source. -
Page 12: Se Le Ct Input Source
LE D COLOR TV 2.6.1... -
Page 13: Main Menu Operution
2.7.1... - Page 14 LE D COLOR TV HDMI Mode...
-
Page 15: Sound Menu
2.7.2... -
Page 16: Time Menu
LE D COLOR TV 2.7.3... -
Page 17: Setup Menu
2.7.4... - Page 18 LE D COLOR TV...
-
Page 20: Lock Menu
LE D COLOR TV 2.7.5 System Lock/Input Block/US/Canade/RRT Setting/ Reset RRT. -
Page 21: Channel Menu
2.7.6... -
Page 22: Pc Menu
LE D COLOR TV 2.7.7 among H-Pos/V-Pos/Clock/Phase/Auto/Reset PC Settings. -
Page 24: Photo Menu
LE D COLOR TV 2.8.1... -
Page 25: Music Menu
2.8.2... -
Page 26: Movie Menu
LE D COLOR TV Movie Menu 2.8.3 MOVIE Press to select folder or file, press ENTER button to enter next folder ， press RECALL to return previous folder. Press to select the MOVIE that you want,press ENTER button to select playlist than press button to play. -
Page 27: Technical Speciication
E32D7212 NTSC M 8Wx2 Antenna Input (F Type) x 1 VGA (D-Sub 15 Pin Type) x 1 HDMI Connector x 3 Y Pb Pr Input Terminals x 1 Video Input RCA Terminals x 1 Stereo Audio x 1 RCA,x1(Phone J ack for VGA) USB x 1 1 set of Audio Output Terminals (RCA, L&R) -
Page 28: Supported Signal Modes
LE D COLOR TV 4. Supported Signal Modes VGA Mode Horizontal Vertical Resolution Frequency Frequency (KHz) (Hz) 640 x 480 31.50 60.00 35.16 56.25 800 x 600 37.90 60.00 1024 x 768 48.40 60.00 Note: You’re suggested to use the VGA connecting cord of not more than 5 meters to ensure the appropriate picture quality. -
Page 29: Simple Troubleshooting
5. Simple Troubleshooting If the display fails or the performance changes dramatically, check the Display in accordance with the following instructions. Remember to check the peripherals to pinpoint the source of the failure. Symptom Solution Power cannot be turned -Check that both ends of the power cable are on.(Power indicator plugged into the socket appropriately and the wall does not light.)
