TK-STAR PET GPS TRACKER
Thank you for purchasing the GPS tracker. This manual shows how to operate the device smoothly and
correctly. Make sure to read this manual carefully before using this product. Please note that specification and
information are subject to changes without prior notice in this manual. Any change will be integrated in the
latest release. The manufacturer assumes not to be responsible for any errors or omissions in this document.
1. SUMMARY
Working Based on existing GSM/GPRS network and GPS satellites, this product can locate and monitor any
remote targets by SMS or internet. The most advanced technology of GPS and GSM dual positioning.
Content
Dim.
Weight
Network
Band
GPS sensitivity
GPS accuracy
USER MANUAL
PREFACE
Specs.
70mm x 37mm x 20mm(2.7"*1.4"*0.78")
44g
GSM/GPRS
850/900/1800/1900Mhz
-159dBm
5m
1
Advertisement
Related Manuals for TK-STAR TK909
Summary of Contents for TK-STAR TK909
-
Page 1: Specifications
TK-STAR PET GPS TRACKER USER MANUAL PREFACE Thank you for purchasing the GPS tracker. This manual shows how to operate the device smoothly and correctly. Make sure to read this manual carefully before using this product. Please note that specification and information are subject to changes without prior notice in this manual. -
Page 2: Led Indicator Status
Cold status 45s Time To First Fix Warm status 35s Hot status 1s 12—24V input Car charger 5V-1A output 110－220V input Wall charger 5V-1A output Battery Chargeable changeable 3.7V 1000mAh Li-ion battery Stand by 400hours Storage Temp. -40°C to +85°C Operation Temp. -
Page 3: Parameters/Codes In Sms Message
Open the rubber cover on the side of device ,insert the sim card into sim card slot , i f you have purchased a MICRO SIM , you will need to use the Micro SIM adapter enclosed, like this: 2.2 USE THE GPS DEVICE Turn on the unit outdoors by insert sim card, In 10 or 40 seconds, the unit will begin to work and acquire the GSM signals as well as the GPS signals. -
Page 4: Sms Tracking
1. Google Maps link: This is the link to the Google map showing the position of the tracker unit.When click the link, if a map is displayed, there is GPS information for the unit. If there is no may, there is no GPS information for the tracker. -
Page 5: Command Instruction To Set Apn
APN information is from sim card carrier ,every sim card carrier has different APN information, there are two ways to find APN out: check sim card carrier on internet or put sim card into own cell phone to find check APN 3.2.2 COMMAND INSTRUCTION TO SET THE ACCES POINT NAME (APN) INSTRUCTION COMMAND... - Page 6 Select “Log in by IMEI” on the bottom of screen Server: 2.tkstargps.net IMEI : on the back side of cover Password: 123456 Note: When the device can't get GPS signal in one minute or in sleep mode, it will reply history position (V:V ); the device will send real time tacking information until it get GPS signal (V:A).
