Page 1: User Manual
Ultra Short-Throw Laser Projector USER MANUAL Serial DET Short-Throw Laser Projector Models DET-3300XST DET-3600XST WXGA DET-3300WST DET-3600WST 1080P DET-3300PST DET-3600PST... -
Page 2: Table Of Contents
Table of Contents Table of Contents ..........................2 Usage Notice ............................. 3 Safety Information ..........................3 Package Overview ..........................4 Product Overview ..........................5 Input/Output Connections ....................... 6 Laser Projector IR Receiver ....................... 8 Laser projector ceiling ........................ 9 Projection Distance ........................10 Connecting the Projector ....................... -
Page 3: Usage Notice
Usage Notice Safety Information The equilateral triangle exclamation alerts you to the attached device An important description of the operation and maintenance of the data. Warning: Using the proper power cord that the machine comes with. Be careful: The power cord that the projector comes with can only be used with this projector. Do not use it with any other machines. -
Page 4: Package Overview
Package Overview Unpack and inspect the box contents to ensure all parts listed below are in the box. If something is missing, please contact your nearest customer service center. Installation of the Batteries If you want to open the battery cover, please face up the controller at first. Press the grip point on the cover and push down as the arrow it points. -
Page 5: Product Overview
Product Overview Main Unit 1. Power button 2. WIFI LED 3. Menu button 4. Left select keys 5. Up select keys 6. OK button 7. Right select keys 8. Down select keys 9. WIFI button 10. Laser projector lens... -
Page 6: Input/Output Connections
Input/Output Connections 11.IR Receiver 12.min-USB port 13. RS-232 Connector (9-pin DIN Type) 14. Audio Output Connector (3.5mm Mini Jack) 15. Audio Input connector (3.5mm mini jack) 16 Audio Input connector 17. VGA-In/YPbPr Connector 18.Height adjustment knob 19. .Power Socket 20.RJ45.Connector 21.USB .Connector 22.Foucus Scribing 23.HDMI .Connector... -
Page 7: Remote Control
Remote Control 1. Power button 2. Focus test 3. HDMI1, HDMI2, VGA1, VGA2, USB1, USB2, AV 4. Volume+ 5. Volume- 6. Picture model 7,8,9. Four Directional select keys 10. Menu 11. Play button 12. Stop button 13. Fast rewind button 14. -
Page 8: Laser Projector Ir Receiver
Laser Projector IR Receiver Effective range of remote control Both the front panel and interface panel of the projector have the IR remote sensor. When holding the controller, it must keep an orthogonal angle of thirty degrees with the IR remote sensor to make it work well. -
Page 9: Laser Projector Ceiling
Laser projector ceiling... -
Page 10: Projection Distance
Projection Distance XGA /WXGA/1080P series: Projection Image Size from 80” to 150.0” (0.4to 0.756 meters). inch Screen wide Screen High Project distance 162.6 121.9 40.3 203.2 152.4 50.4 223.5 167.6 55.4 243.8 182.9 60.5 284.5 213.4 70.6 304.8 228.6 75.6 Unit: cm WXGA (16:... -
Page 11: Connecting The Projector
Connecting the Projector Connect to Computer/Notebook Usage Notice Turn off and unplug the power plug from the AC outlet before cleaning the product. Use a soft dry cloth with mild detergent to clean the display housing. Disconnect the power plug from AC outlet if the product is not being used for a long period of time. -
Page 12: Powering The Projector On / Off
Eye Safety Warnings ▀■ Avoid staring/facing directly into the projector beam at all times. Keep your back to the beam as much as possible. ▀■ When projector is used in a classroom, adequately supervise students when they are asked to point out something on the screen. ▀■... -
Page 13: Powering Off The Projector
When Power mode (Standby) is set to Eco (<0.5W), the VGA output and Audio pass-through will be deactivated when the projector is in standby. Turn on the projector first and then select the signal sources. Installation Powering off the projector 1. -
Page 14: Adjusting The Projected Image
cooling cycle and has entered standby mode. Once in standby mode, simply press “ ” button to restart the projector. 3. Disconnect the power cord from the electrical outlet and the projector. the projector immediately following a power 4. Do not turn on off procedure. - Page 15 Adjusting the Projector’s Focus To focus the image, rotate the focus ring until the image is clear. XGA /WXGA 1080Pseries: The projector will focus at distances from 0.40 to 0.76meters.
-
Page 16: Manu Tree
Manu Tree... -
Page 17: Manu
Manu The Projector has multilingual On-screen Display menus that allow you to make image adjustments and change a variety of settings. How to operate ◄► Press the MENU button to open the OSD menu. Press the cursor button to move to the Image Menu. -
Page 18: Picture
Picture Picture Mode There are many factory presets optimized for various types of images. Bright: Maximum brightness from PC input. Computer: Good color and brightness from PC input. Movie: For home theater. Standard: Standard model Text: This mode is recommended for projecting in a classroom. User: User’s settings. - Page 19 Select to enter the Hue Manager. Press the ◄► buttons to adjust the Hue. Sharpness Adjust the sharpness of the image. Press the to decrease the sharpness. Press the to increase the sharpness. Nosie Reduction Press the ◄► buttons to select “high” , ”middle” or “ low” adjust the noise reduction. Aspect Ration Use this function to choose your desired aspect ratio.
-
Page 20: Sound
Sound Sound Mode There are many factory presets optimized for various types of sound. Treble Displays the treble setting bar.Number for Remote ID setting used. Bass Displays the bass setting bar.Number for Remote ID setting used. Balance Displays the balance setting bar.Number for Remote ID setting used. Mute Select “open”... -
Page 21: Option
Option OSD Language Choose the multilingual OSD menu. Press or into the sub menu and then use the or key to select your preferred language. Press “Enter” to finalize the selection. Auto Source On: The projector will only search current input connection. Off: The projector will search for other signals if the current input signal is lost. - Page 22 Fan Mode Displays the fan mode setting bar.Number for Remote ID setting used. This feature is useful in high altitude areas where the air is thin. Ceiling Mount Front-Desktop This is the default selection. The image is projected straight on the screen. Front-Ceiling When selected, the image will turn upside down.
- Page 23 3D Type Use this feature to select the 3D format. Options are: “Side-by-Side (Half)”, “Top and Bottom” LRSwap If you see a discrete or overlapping image while wearing DLP 3D glasses, you may need to execute “LRSwap” to get best match of left/right image sequence to get the correct image.
-
Page 24: Network
Network DHCP Use this function to select your desired startup screen. If you change the setting from one to another, when you exit the OSD menu, the new setting will take effect on next open. On: Assign an IP address to the projector from an external DHCP server automatically. Off: Assign an IP address manually. -
Page 25: Information
Information Displayed the projector Resolution , Marchine model, Lamp hour, user ver.information on screen. - Page 26 USB storage display If you need to access stored on flash media files on your USB, please perform the following operations: 1 on the "Input" menu, select "USB". 2 use the key to select a file type, and press the "OK" button 3 use the key to select the file you want to view, and press the "OK"...
-
Page 27: Rs232 Commands And Protocol Function List
RS232 Commands and Protocol Function List RS232 Pin Assignments Baud Rate : 115200 Data Bits: 8 Parity: None Stop Bits: 1 Flow Control : None UART16550 FIFO: Disable Projector Return (Pass): P Projector Return (Fail): F Contral command format as follows: 0xaa 0x55 Par1... -
Page 28: Wall Mount Installation
0x02 0 to 6 Signal 0：hdmi1 1：hdmi2 2：vga1 3：vga2 4：av 5：usb1 6：usb2 0x03 0x04 0x05 0x06 0x07 0x08 Wall Mount Installation 1. To prevent damage to your projector, please use ceiling mount. 2. If you wish to use a third party ceiling mount kit, please ensure the screws used to attach a mount to the projector meet the following specifications: Screw type: M5*4 Maximum screw length: 14mm... -
Page 29: Maintenance And Troubleshooting
2. Be sure to keep at least 10 cm gap between the ceiling and the bottom of the projector. 3. Avoid installing the projector Please note that damage resulting from incorrect installation will void the warranty. Maintenance and troubleshooting The way of maintenance 1. -
Page 30: Warranty And Copyright Information
Confirm that if it is electric. Confirm that if the batteries of the controller are electric. Confirm that if the distance is too long. Check that the vision labels are plugged in securely. Choose the right video source. Warranty and copyright information Limited warranty In the case of normal use and storage, our company provides warranty of any material or defects. - Page 31 5. Verify the resolution setting is lower than or equal to UXGA (1600 × 1200). 6. Select the “Change” button under the “Monitor” tab. 7. Click on “Show all devices”. Next, select “Standard monitor types” under the SP box; choose the resolution mode you need under the “Models” box. 8.
- Page 32 Press “Menu” button on the remote control or projector panel, go to “DISPLAY Format” and try the different settings. Image has slanted sides If possible, reposition the projector so that it is horizontally centered on the screen and below the bottom of the screen. Press “Keystone +/-”...
