- Page 1 ® Operating Instructions 60 Years of Innovation Swiss Precision since 1954 Made in Switzerland Design Patent Pending...
-
Page 2: Power Supply
Pundit Pulse Echo Transducer* Pundit Pulse Echo Cable* Pundit Pulse Echo Contact Tester* Power Supply USB Cable DVD with Software Documentation* Carrying Strap Calibrated Tape* *Part of the “Pundit Pulse Echo Trans- ducer” package (Part No. 327 40 130) © 2015 Proceq SA... - Page 3 Overview Pundit PL-200PE 10 10 © 2015 Proceq SA...
-
Page 4: Table Of Contents
Settings ................8 Exporting Data ..............21 Measurement Screen ............10 Further Functions ............22 Measurement Modes ............11 Measuring with Pundit PL-200PE ........15 Explorer ..............16 Analysis of B-Scans ............17 Ordering Information ..........17 Units .................17 Transducers ..............17 Accessories ..............18 © 2015 Proceq SA... -
Page 5: Safety And Liability
All information contained in this documentation is presented in good faith and believed to be correct. Proceq SA makes no warranties and excludes all liability as to the completeness and/or accuracy of the information. © 2015 Proceq SA... -
Page 6: Technical Specifications
Indoor use only Battery Lithium Polymer, 3.6 V, 14.0 Ah Pollution Degree Mains 9 V – 15 V / 2.0 A Installation Category Weight About 1525 g (incl. Battery) Dimensions 250 x 162 x 62 mm © 2015 Proceq SA... -
Page 7: Operation
No. 327 01 049) for operation with standard P-wave transducers. A full • Charging time is much longer if the instrument is in use. listing of the standard transducers can be found on the Proceq website. The Pundit PL-200 operating manual is provided on the product DVD. -
Page 8: Main Menu
The current setting is displayed on the right hand side. Tap on an Filter item to adjust it. Filters are used to filter out unwanted noise, to make it easier to identify the correct echo. © 2015 Proceq SA... - Page 9 1 cm is recommended. For a quicker initial scan a coarser spacing may be used, e. g. 2.5 cm corresponding to the spacing markers on the Pulse Echo Transducer. When searching for larger objects such as © 2015 Proceq SA...
-
Page 10: Measurement Screen
This can be used in both the horizontal and vertical directions when making a measurement. Zoom out by placing thumb and index finger apart on the screen and pinching them together. Pan the image from left to right by dragging. © 2015 Proceq SA... -
Page 11: Measurement Modes
Pulse Velocity between thet two echos is displayed. Enter the thickness of the object under test. Manually adjust the colour intensity. The result is the transmission time and pulse velocity of the material un- der test. © 2015 Proceq SA... - Page 12 If the measurement is repeat- ed by pressing the snapshot button, the previous value is overwritten. The black areas were excluded by dragging the cursor to the next posi- tion to be measured. © 2015 Proceq SA...
- Page 13 • Move the transducers to the next point of the scan. Make the second measurement and continue. • The current A-Scan is shown on the right hand side of the screen. • The current status of the B-Scan is shown on the main part of the screen. © 2015 Proceq SA...
- Page 14 In order to find a suitable range, it is advisable to first carry out an auto- matic pulse velocity estimation and then to do a quick B-Scan to deter- mine the range of the back wall. © 2015 Proceq SA...
-
Page 15: Measuring With Pundit Pl-200Pe
• For Area Scans and B-Scans a test grid should be drawn out on the to set the gate between 200 μs and 300 μs. surface. Alternatively Proceq provide a calibrated tape (Part No. 327 In the distance mode, the gate can also be set using the distance scale 010 71) that can be stuck on the surface for the test and then removed at the top of the screen as an aid. -
Page 16: Explorer
The reason for this is that if the object is too narrow, reflections from the side walls will interfere with the echo from the rear wall. © 2015 Proceq SA... -
Page 17: Analysis Of B-Scans
• All of these items may be adjusted later in PL-Link once the files have 325 40 049 2 S-Wave Transducers 250 kHz, incl. couplant been downloaded to a PC. 327 40 130 Pulse Echo Transducer, incl. cable and contact tester © 2015 Proceq SA... -
Page 18: Accessories
Calibration rod 100 μs for Pundit PL-200 Warranty Information 327 01 070 Snap Ferrite for BNC Adapter cable* Each instrument is backed by the standard Proceq warranty and extend- 327 01 051 Pundit Pulse Echo Cable ed warranty options. 327 00 027 Pundit Pulse Echo Contact Tester complete •... - Page 19 Pundit Touchscreen Unit. Click on the double arrow icon in the first column to see more details: The following window will be displayed: Select “USB” as the communica- tion type. © 2015 Proceq SA...
- Page 20 Right click in the folder section to create a new folder. Click on the Symbol to obtain a larger graphical display of the scan in a separate window. © 2015 Proceq SA...
- Page 21 • Drag the cross hairs to a point of interest using the right mouse button. The position is shown in the details on the right hand side. • The current A-Scan (e. g. #22) is indicated in the table. © 2015 Proceq SA...
- Page 22 In both cases, the preview window shows the effects of the current out- put selection. Finish by clicking on export to select the file location, name the file and in the case of a graphical output to set the output graphic format: .png, .bmp or .jpg © 2015 Proceq SA...
- Page 23 Ul. Optikov 4 korp. 2, lit. A, Office 410 197374 St. Petersburg Russia Phone/Fax + 7 812 448 35 00 info-russia@proceq.com Subject to change. Copyright © 2015 by Proceq SA, Schwerzenbach. All rights reserved. 82032703E ver 05 2015 Made in Switzerland...
