- Page 1 SILENT 5001DM SILENT 6001 DT SILENT 8002 DM SILENT 9002 DT MANUALE USO E MANUTENZIONE USE AND MAINTENANCE MANUAL GEBRUIKS- EN ONDERHOUDSHANDLEIDING GEBRAUCHSANWEISUNG UND WARTUNGSVORSCHRIFTEN MANUEL D’UTILISATION ET D’ENTRETIEN Rev. 1 S.S. 23/10/02 cod.41327...
-
Page 2: Table Of Contents
SILENT CONTENTS FAILURE TO ADHERE TO THE INSTRUCTIONS AND SPECIFICATIONS CONTAINED IN THIS USE AND MAINTENANCE MANUAL WILL INVALIDATE THE PRODUCT GUARANTEE. Figures ..............2 Wiring diagrams ........... 9 General information ........21 Scope of the manual ........21 Attached documentation ........ 22 Manufacturer-machine identification .... -
Page 3: General Information
SILENT 1.GENERAL INFORMATION Read this manually carefully before using the machine. 1.1 Scope of the manual Thank you for having chosen a MASE product. This manual was prepared by the Manufacturer and is an integral part of the components supplied with the machine. This information has been prepared for users and the personnel assigned to perform maintenance on such equipment. -
Page 4: Attached Documentation
SILENT 16 - Higth engine temperature 1.2 Attached documentation 17 - Emergency stop button lamp The following documentation is an integral part of this manual: The generating units in this series Silent have been designed for industrial use and are driven by highly - EEC conformity declaration (fig.1);... -
Page 5: Technical Specifications
SILENT 2.TECHNICAL SPECIFICATIONS MODEL SILENT 5001 DM SILENT 6001 DT SIELNT 8002 DM SILENT 9002 DT GENERATOR Type synchronous - 2-ph synchronous - 3-ph. synchronous - 2-ph synchronous - 3-ph. Power 3700 4600 6500 8100 Voltage Frequecy Current 28,2 11,7 Power factor cos.f Degree of protection... -
Page 6: Safety Regulations
SILENT 3.SAFETY REGULATIONS Power KVA 1-10 10÷20 20÷40 40÷60 60÷80 3.1 Precautions Section mm² 5 Carefully read the Instruction and Maintenance Manuals before starting up and using the machine. 4.SING THE GENERATOR The manufacturer declines any responsibility for dam- ages to persons or things stemming from noncompliance with the safety standards. -
Page 7: Protections
SILENT 6.MAINTENANCE The unit is hooked up to the automatic control panel through the 6-pin connector found on the unit instrument panel (fig. 4 ref. 6) and a power supply plug inserted in the outlet All maintenance operations on the located on the generator instrument panel (fig. -
Page 8: Replacing Of Air Filter
SILENT 6.7 Table of scheduled operations 3 - Tighten the vent screws once more and start up the engine. 4 - Repeat the above operations if the engine is still not OPERATION HOURS functioning properly. Check the level of the oil in the sump Clean the air filter Consult the engine use and Replacing the oil inside the air filter... -
Page 9: Wiring Diagrams List
SILENT 7.WIRING DIAGRAM LIST Fig.10 1 - Rotor 2 - Stator Fig.8 3 - Electronic voltage regulator 1 - Rotor 4 - Hour counter 2 - Stator 5 - Voltmeter 3 - Electronic voltage regulator 6 - Magnetothermal switch 4 - Hour counter 7 - Magnetothermal switch 5 - Voltmeter 8 - Singol phase socket...
