WiFi NVR-Recorder PRO TX-64 User Manual V 1.0.0...
Page 2 Table of Contents Features and Specifications .......................1 Overview ..........................1 Features ..........................1 Specifications .........................3 Front Panel and Rear Panel .......................5 Front Panel ..........................5 Rear Panel..........................6 Mouse Operation ........................7 Device Installation ........................8 Check Unpacked TX-64 .......................8 About Front Panel and Rear Panel ..................8 HDD Installation TX-64 ......................8 Local Basic Operation .........................9 Boot up and Shutdown ......................9...
Page 3 4.5.3 Right Click Menu ......................19 4.5.4 Preview Display Effect Setup ..................20 4.5.4.1.1 Video Color....................... 20 4.5.4.1.2 Display ......................21 4.5.5 Preview Tour Parameters .................... 22 PTZ ............................23 4.6.1 PTZ Control ........................23 4.6.1.1 PTZ Function Setup ..................... 25 4.6.1.2 Call PTZ Function....................
Page 4 4.10.1.1.1 Motion Detect ....................50 4.10.1.1.2 Tampering ...................... 53 4.10.1.1.3 Video Loss ..................... 54 4.10.2 Alarm Setup....................... 54 4.10.3 Abnormality ....................... 58 4.11 Network ..........................59 4.11.1.1 TCP/IP ........................59 4.11.1.2 Connection ......................60 4.11.1.3 WIFI AP........................61 4.11.1.4 DDNS ........................62 4.11.1.5 UPnP ........................
Page 5 4.14.7 Logout /Shutdown/Restart ..................79 Web Operation ........................... 80 General Introduction ......................80 5.1.1 Network Connection..................... 80 5.1.2 Log in..........................80 LAN Mode..........................81 Real-time Monitor ....................... 83 PTZ ............................84 Image/Alarm-out ......................... 85 5.5.1 Image..........................85 Zero-channel Encode ......................85 WAN Login...........................
Page 6 5.8.3.2.2 IPC Offline ...................... 108 5.8.3.3 Abnormality ......................109 5.8.4 Storage ......................... 110 5.8.4.1 Schedule ......................110 5.8.4.2 Storage Media ..................... 112 5.8.4.2.1 Local Storage ....................112 5.8.4.2.2 HDD Setting ....................112 5.8.4.3 Record........................112 Main Stream, Sub Stream & Snapshot ................. 112 5.8.4.4 ADVANCED......................
Page 7 This device complies with the requirements of the standards referred to the Directive R&TTE 2014/53/EU. The Declaration of Conformity you find here: www.technaxx.de/ (in bar at the bottom ―Konformitätserklärung‖). Before using the device the first time, read the user manual carefully.
Page 8 1 Features and Specifications 1.1 Overview This series TX-64 is a high performance network video recorder. This series product support local preview, multiple-window display, recorded file local storage, remote control and mouse shortcut menu operation, and remote management and control function. This series product supports centre storage, front-end storage and client-end storage.
Page 9 various connected peripheral devices.  Alert you via email/sms.  Through network, sending audio/video data compressed by IP-CAM or NVS to client-ends, then the data will be decompressed and display.  Support max 128 connections at the same time. Network Monitor ...
Page 10 1.3 Specifications Model TX-64 System System Resources 4-channel series product support connection. Total bandwidth supports 28Mbps. Embedded Linux real-time operation system Operation Interface WEB/Local GUI Decode Video Decode Type H.264/MJPEG/MJPEG4 Decode Capability Max. 2-ch 5M 25fps or Max. 4-ch 3M 25fps or Max.
Page 11 Model TX-64 Air pressure 86kPa～106kPa Dimension 260mm×264mm×48mm Weight 0.5kg (Exclude HDD) Installation Mode Desk installation...
Page 12 2 Front Panel and Rear Panel 2.1 Front Panel The front panel is shown as in Figure 2-1. Figure 2-1 Refer to the following sheet for detailed information. Name Function HDD status indictor The blue light becomes on when HDD light connection is abnormal.
Page 13 2.2 Rear Panel The TX-64 rear panel is shown as below. See Figure 2-2. Figure 2-2 Refer to the following sheet for detailed information. Port Name Connection Function USB2.0 port. Connect to mouse, USB USB2.0 port storage device, USB burner and etc. 10M/100Mbps self-adaptive Ethernet port.
Page 14 2.3 Mouse Operation Refer to the following sheet for mouse operation instruction. Left click When you have selected one menu item, left click mouse to view menu mouse content. Modify checkbox or motion detection status. Click combo box to pop up dropdown list In input box, you can select input methods.
Page 15 3 Device Installation Note: All the installation and operations here should conform to your local electric safety rules. 3.1 Check Unpacked TX-64 The protective materials used for the package of the TX-64 can protect most accidental clashes during transportation. Then you can open the box to check the accessories. Check the items in accordance with the list.
Page 16 4 Local Basic Operation 4.1 Boot up and Shutdown 4.1.1 Boot up Caution Before the boot up, make sure:  For device security, connect the TX-64 to the power adapter first and then connect the device to the power socket. ...
Page 17 Click Cancel button or Next button, system goes to login interface. See Figure 4-2. System consists of four accounts:  Username: admin. Password: admin. (administrator, local and network)  Username: 888888. Password: 888888. (administrator, local only)  Username: default. Password: default (hidden user). Hidden user ―default‖ is for system interior use only and can not be deleted.
Page 18 Figure 4-4 Click Next button, you can go to remote device interface. See Figure 4-5. For detailed information, refer to chapter 0. Figure 4-5 Click Next button, you can go to Schedule interface. See Figure 4-6. For detailed information, refer to chapter 4.7.2.
Page 19 Figure 4-6 Click Finish button, system pops up a dialogue box. Click the OK button, the startup wizard is complete. See Figure 4-7. Figure 4-7 4.3 Navigation Bar You need to go to the Main menu->Setting->System->General to enable navigation bar function;...
Page 20 4.3.1 Main Menu Click button to go to the main menu interface. 4.3.2 Dual-screen operation Important This function is for some series only. Click to select screen 2, you can view an interface shown as below. See Figure 4-9. It is a navigation bar for screen 2.
Page 21 4.3.8 Alarm Status Click button , system goes to alarm status interface. It is to view device status and channel status. Refer to chapter 4.10. 4.3.9 Channel Info Click button , system goes to the channel information setup interface. It is to view information of the corresponding channel.
Page 22 4.4 Remote Device 4.4.1 Remote Device Connection From Main menu-> Setting-> Remote device or right click mouse preview interface and then select remote device item, you can see the following interface. Figure 4-12. Figure 4-12 Click Device search button, you can view the searched IP addresses at the top pane of the interface.
Page 23 4.4.3 Image From main menu->setting->camera->image, you can see the image interface is shown as below. See Figure 4-22.  Channel: Select a channel from the dropdown list.  Saturation: It is to adjust monitor window saturation. The value ranges from 0 to 100. The default value is 50.
Page 24  Auto: The auto white balance is on. System can auto compensate the color temperature to make sure the vide color is proper.  Sunny: The threshold of the white balance is in the sunny mode.  Night: The threshold of the white balance is in the night mode. ...
Page 25 4.5 Preview After device booted up, the system is in multiple-channel display mode. See Figure 4-24. Note the displayed window amount may vary. The following figure is for reference only. Refer to chapter 1.3 Specifications for the window-amount your product supported. Figure 4-24 4.5.1 Preview If you want to change system date and time, you can refer to general settings (Main...
Page 26 There are two ways for you to zoom in.  Drag the mouse to select a zone, you can view an interface show as Figure 4-26. Figure 4-26  Put the middle button at the centre of the zone you want to zoom in, and move the mouse, you can view an interface shown as in Figure 4-27.
Page 27  Alarm output: Generate alarm output signal manually.  Main menu: Go to system main menu interface. Tip: Right click mouse to go back to the previous interface. Figure 4-28 4.5.4 Preview Display Effect Setup 4.5.4.1.1 Video Color Here you can set hue, brightness, contrast, saturation, gain, white level, color mode and etc.
Page 28 Item Note or too bright. Note the video may become hazy if the value is too high. The recommended value ranges from 40 to 60. Contrast It is to adjust monitor window contrast. The value ranges from 0 to 100. The default value is 50. The larger the number, the higher the contrast is.
Page 29 Figure 4-30 Now you can set corresponding information.  Resolution: There are five options: 1280×1024 (Default), 1280×720, 1920×1080, 1024×768 and 3840×2160. Note the system needs to reboot to activate current setup. Note 3840×2160 is for some series only.  VGA+HDMI2: It is for dual-screen operation. Select from the dropdown list according to your actual situation.
Page 30 Figure 4-31. Here you can set tour parameter.  Enable tour: Check the box here to enable tour function.The general tour supports all types of window split mode.  Interval: Input proper interval value here. The value ranges from 1-120 seconds. ...
Page 31 The PTZ setup is shown as you see in Figure 4-33. Note the commend name is grey once device does not support this function. The PTZ operation is only valid in one-window mode. Here you can control PTZ direction, speed, zoom, focus, iris, preset, tour, scan, pattern aux function, light and wiper, rotation and etc.
Page 32 In Figure 4-33, click to open the menu, you can set preset, tour, pattern, scan and etc. See Figure 4-35. Figure 4-35 Refer to the following sheet for detailed information. Note the above interface may vary due to different protocols. The button is grey and can not be selected once the current function is null.
Page 33 Preset Setup In Figure 4-36, click preset button and use eight direction arrows to adjust camera to the proper position. The interface is shown as in Figure 4-37. Click Set button and then input preset number. Click Set button to save current preset. Figure 4-37 Tour Setup In Figure 4-36, click tour button.
Page 34 Border Setup In Figure 4-36, click Border button. Use direction buttons to set camera left limit and then click Left button. Use direction buttons to set camera right limit and then click Right button. Now the border setup process is complete. See Figure 4-40. Figure 4-40 4.6.1.2 Call PTZ Function Call Preset...
Page 35 Aux: Click , system goes to the following interface. The options here are defined by the protocol. The aux number is corresponding to the aux on-off button of the decoder. See Figure 4-41. Figure 4-41 4.7 Record and Snapshot The record/snapshot priority is: Alarm->Motion detect->Schedule. 4.7.1 Encode 4.7.1.1 Encode Encode setting is to set IP-CAM encode mode, resolution, bit stream type and etc...
Page 36 Highlight icon to select the corresponding function. Figure 4-42 4.7.1.2 Overlay Click overlay button, you can see an interface is shown in Figure 4-43 and Figure 4-45.  Cover area: Here is for you to cover area section. You can drag you mouse to set proper section size.
Page 37 4.7.1.3 Snapshot Here you can set snapshot mode, picture size, quality and frequency. See Figure 4-44.  Snapshot mode: There are two modes: regular and trigger. If you set regular mode, you need to set snapshot frequency. If you set trigger snapshot, you need to set snapshot activation operation.
Page 38  Week day: There are eight options: ranges from Saturday to Sunday and all.  Holiday: It is to set holiday setup. Note you need to go to the General interface (Main Menu->Setting->System->General) to add holiday first. Otherwise you can not see this item.
Page 39 Check the box to select the corresponding function. After completing all the setups click save button, system goes back to the previous menu. There are color bars for your reference. Green color stands for regular recording, yellow color stands for motion detection and red color stands for alarm recording.
Page 40 Note, if you select ALL in Figure 4-51, the record setup of all channels are the same and the Copy button becomes hidden. Figure 4-51 Click OK button to save current setup. 4.7.2.2 Schedule Snapshot From Main menu->Setting->Storage->Record or on the preview interface, right click mouse and then select record item, you can see Figure 4-52.
Page 41 In the main menu, from Main menu->Setting->Storage->Schedule, you can go to schedule menu. See Figure 4-54. Here you can set snapshot period. There are total six periods in one day. The setup steps are general the same. Figure 4-54 Note ...
Page 42 mouse button on the start point of the area you want to select and drag the mouse to select the area. In the test area the best setting for sensitivity and threshold is 60 and 10 respectively. Depending on your given environment this settings can be vary. Sensitivity and threshold can be set in the range from 0 to 100.
Page 43 Figure 4-57 4.7.3.2 Motion Detect Snapshot a) From Main menu->Setting->Camera->Encode->Snapshot, you can go to snapshot interface. See Figure 4-58. b) In Figure 4-60, select trigger snapshot from the dropdown list and then set picture size, quality and snapshot frequency. Click OK button to save current setup. c) From Main menu->Setting->Event->Detect, here you can select motion detect type, motion detect channel and then check the enable box.
Page 44 offline alarm.  Local input alarm: The alarm signal system detects from the alarm input port.  Network input alarm: It is the alarm signal from the network.  IP-CAM external alarm: It is the on-off alarm signal from the front-end device and can activate the local TX-64.
Page 45 Figure 4-60 4.7.5 Manual Record/Snapshot You need to have proper rights to implement the following operations. Make sure the HDD has been properly installed. 4.7.5.1 Manual Record a) Right click mouse and select manual record or in the main menu, from Setting->Storage->Manual Record.
Page 46  All: Check the All box to select all channels. c) Click OK button to complete manual record setup. 4.7.5.2 Manual Snapshot Click button at the preview control bar, you can snapshot 1-5 picture(s). From main menu->Setting->Camera->Encode->Snapshot, you can set snapshot times. 4.7.6 Holiday Record/Snapshot It is for you to set holiday record or snapshot plan.
Page 47 c) Click Add button to complete holiday setup. Now you can enable holiday setup and then click Apply button. d) From Main menu->setting->Storage->schedule, you can go to schedule interface. See Figure 4-64. Now you can set period and record type of holiday time. Refer to chapter 4.7.6 for detailed setup information.
Page 48 Figure 4-65 Refer to the following sheet for more information. Name Function  Here is to display the searched picture or file. Display  Support 1/4-window playback. window  Here you can select to search the picture or the recorded file. ...
Page 49  In 1-window playback mode: you can select 1-X channels (X mode and channel depends on the product channel amount). selection  In 4-window playback mode: you can select 4 channels pane. according to your requirement.  The time bar will change once you modify the playback mode or the channel option.
Page 50 │ In normal play mode, when you pause current play, you can click │ and │ to begin frame by frame playback. In frame by frame playback mode, click ►/ to restore normal playback. ► Slow play In playback mode, click it to realize various slow play modes such as slow play 1, slow play 2, and etc.
Page 51  Select the file(s) you want to backup from the file list. You can check from the list. Then click the backup button, now you can see the backup menu. System supports customized path setup. After select or create new folder, click the Start button to begin the backup operation.
Page 52 implement operations such as change time bar, begin backward playback or frame by frame playback. Other channel synchroniz When playing the file, click the number button, system can ation switch to the same period of the corresponding channel to play. switch play when playback...
Page 53 Click the , you can go to the smart search playback. Click it again, system stops smart search playback. Important  System does not support motion detect zone setup during the full-screen mode.  During the multiple-channel playback, system stops playback of rest channels if you implement one-channel smart search.
Page 54  Add Mark: When system is playback, click Mark button , you can go to the following interface. See Figure 4-68. Figure 4-68  Playback Mark: During 1-window playback mode, click mark file list button ,you get to mark file list interface. Double click one mark file, you can begin playback from the mark time.
Page 55  Delete: Here you can check the mark information item you want to delete and then click Delete button, you can remove one mark item. Note  After you go to the mark management interface, system needs to pause current playback.
Page 56 Figure 4-71 h) Click backup button, system begins burning. At the same time, the backup button becomes stop button. You can view the remaining time and process bar at the left bottom. Note  During backup process, you can click ESC (right mouse click) to exit current interface for other operation (For some series product only).
Page 57 folder to save them. Click Start to backup and you can see the corresponding dialogue box after the process is finish. 4.9.3 USB Device Auto Pop-up After you inserted the USB device, system can auto detect it and pop up the following dialogue box.
Page 58 activation stays such as the buzzer, tour, PTZ activation, snapshot, channel record. The stay time here does not include the latch time. During the alarm process, the alarm signal can begin an anti-dither time if system detects the local alarm again. The screen prompt, alarm upload, email and etc will not be activated.
Page 59 occurs, SPOT OUT port displays device video output. It displays video (1-window tour) from alarm activation channel you select at the Record channel item.  Buzzer: Highlight the icon to enable this function. The buzzer beeps when alarm occurs. Highlight icon to select the corresponding function.
Page 60 Figure 4-79 Motion detect here only has relationship with the sensitivity and region setup. It has no relationship with other setups. 4.10.1.1.2 Tampering When someone viciously masks the lens, or the output video is in one-color due to the environments light change, the system can alert you to guarantee video continuity. Tampering interface is shown as in Figure 4-81.
Page 61 Figure 4-81 4.10.1.1.3 Video Loss In Figure 4-82, select video loss from the type list. You can see the interface is shown as in Figure 4-82. This function allows you to be informed when video loss phenomenon occurred. You can enable alarm output channel and then enable show message function. You can refer to chapter 4.10.1.1.1Motion detect for detailed information.
Page 62 front-end network camera will not be regarded as offline. After one successfully connection, all the disconnection events will be regarded as IP-CAM offline event.  When IP-CAM offline alarm occurs, the record and snapshot function of digital channel is null. ...
Page 63 centre and the WEB) if you enabled current function. System only uploads the alarm channel status. You can go to the WEB and then go to the Alarm interface to set alarm event and alarm operation. Go to the Network interface to set alarm centre information.
Page 64 Figure 4-84 Figure 4-85 Figure 4-86 Figure 4-87...
Page 65 Highlight icon to select the corresponding function. After setting all the setups click save button, system goes back to the previous menu. 4.10.3 Abnormality There are two types: HDD/Network.  HDD: HDDerror, no HDD, no space. See Figure 4-88 and Figure 4-89. ...
Page 66 Figure 4-90 4.11 Network 4.11.1.1 TCP/IP The single network adapter interface is shown as in Figure 4-91.  Network Mode : Includes multiple access, fault tolerance, and load balancing  IP Version: There are two options: IPv4 and IPv6. Right now, system supports these two IP address format and you can access via them.
Page 67 typical setup when there is no PPPoE or VPN. It is the default setup of some router, switch or the network adapter.  1492: Recommend value for PPPoE.  1468: Recommend value for DHCP.  Preferred DNS server: DNS server IP address. ...
Page 68 4.11.1.3 WIFI AP Note This function is for some series product only. The WIFI AP interface is shown as below. See Figure 4-93. Here you can set WIFI hotspot, so that the network camera can use the hotspot to connect to the network. ...
Page 69 4.11.1.4 DDNS DDNS setup interface is shown as in Figure 4-94. You need a PC of fixed IP in the internet and there is the DDNS software running in this PC. In other words, this PC is a DNS (domain name server). In network DDNS, select DDNS type and highlight enable item.
Page 70  Server address：www.quickddns.com  Port number：80  Domain name：There are two modes: Default domain name and customized domain name. Except default domain name registration, you can also use customized domain name (You can input your self-defined domain name.) After successful registration, you can use domain name to login installed of the device IP.
Page 71 Figure 4-95 Figure 4-96 4.11.1.6 IP Filter IP filter interface is shown as in Figure 4-97. You can add IP in the following list. The list supports max 64 IP addresses. System supports valid address of IPv4 and IPv6. Note system needs to check the validity of all IPv6 addresses and implement optimization.
Page 72 added IP address. e) System only checks start address if you add IP address. System check start address and end address if you add IP section and the end address shall be larger than the start address. System may check newly added IP address exists or not. System does not add if input IP address does not exist.
Page 73  Receiver: Input receiver email address here. System max supports 3 email boxes. System automatically filters same addresses if you input one receiver repeatedly.  SSL enable: System supports SSL encryption box.  Interval: The send interval ranges from 0 to 3600 seconds. 0 means there is no interva l. ...
Page 74 4.11.1.9 P2P (EASY4IP) The EASY4IP interface is shown as in Figure 4-101. You can scan the QR code to connect the device over the My Secure Pro App. Figure 4-101 4.11.2 Network Test In this interface, you can see network test and network load information. 4.11.2.1 Network Test From main menu->Info-Network->Test, the network test interface is shown as in Figure 4-102.
Page 75 4.12 STORAGE MEDIA Here you can view STORAGE MEDIA (HDD information) such as type, status, total capacity, record time and etc. The operation includes format, resume from error, change HDD property (Read write, Read-only). Here you can also set alarm and HDD storage position. 4.12.1 Format From Main-menu->Setting->Storage->HDD Manager, you can go to HDD management interface.
Page 76 In Figure 4-105, click one HDD item, the S.M.A.R.T interface is shown as in Figure 4-105. Figure 4-105 Parameter Function SATA 3.5‖ 1 here means there is 1 HDD. You can view the HDD amount the device connected to; ﹡ means the second HDD is current working HDD. Type The corresponding HDD property.
Page 77 4.12.3 HDD Detect Note: This function is for some series product only. The HDD detect function is to detect HDD current status so that you can clearly understand the HDD performance and replace the malfunction HDD. There are two detect types: ...
Page 78 Click View, you can see the detailed information such as detect result, backup and S.M.A.R.T. See Figure 4-108 and Figure 4-109. Figure 4-108 Figure 4-109 4.13 Device Setups 4.13.1 General From Main menu->Setting->System->General, you can go to the general interface. See Figure 4-110.
Page 79 options: stop recording or rewrite. If current working HDD is overwritten or the current HDD is full while the next HDD is no empty, then system stops recording, If the current HDD is full and then next HDD is not empty, then system overwrites the previous files. ...
Page 80 Before your time modification, stop record operation first! After completing all the setups click save button, system goes back to the previous menu Figure 4-111 4.13.3 Holiday Refer to chapter 4.7.6 for detailed information. 4.14 Device Maintenance and Manager 4.14.1 System Info 4.14.1.1 Version From main menu->Info->System->version, you can go to version interface.
Page 81 4.14.1.2.1 Online User Here is for you manage online users connected to your TX-64. See Figure 4-114. You can click button to disconnect or block one user if you have proper system right. System detects there is any newly added or deleted user in each five seconds and refresh the list automatically.
Page 82 Figure 4-116 4.14.2 Log From Main menu->Info->Log, you can go to the following interface. See Figure 4-118.  Start time/end time: Select start time and end time, then click search button. You can view the log files in a list. System max displays 100 logs in one page. It can max save 1024 log files.
Page 83  Modify user  Add group  Modify group  Modify password. For account management note:  For the user account name and the user group, the string max length is 6-byte. The backspace in front of or at the back of the string is invalid. There can be backspace in the middle.
Page 84 4.14.3.1.1 Add/Modify Group Click add group button, the interface is shown as below. See Figure 4-122. Here you can input group name and then input some memo information if necessary. There are many rights such as control panel, shut down, real-time monitor, playback, record, record file backup, PTZ, user account, system information view, system setup, log view, clear log, upgrade system, control device and etc.
Page 85 4.14.3.1.3 Secure Question With this under menu set the security question so that you can find the password of the ―admin‖ later in emergency case! The modify user interface is similar to Figure 4-124. Figure 4-124 4.14.4 Update From Mani menu->Setting->System->Update, you can go to the following interface. See Figure 4-125.
Page 86 Figure 4-126 4.14.6 Auto Maintain Here you can set auto-reboot time and auto-delete old files setup. You can set to delete the files for the specified days. See Figure 4-127. You can select proper setup from dropdown list. After all the setups click save button, system goes back to the previous menu Figure 4-127 4.14.7 Logout /Shutdown/Restart From Main menu->Operation->Shutdown, you can see an interface shown as in Figure...
Page 87 5 Web Operation 5.1 General Introduction The TX-64 supports access via Browser after installing a web plugin. The Web function provides the following settings: Channel monitor menu tree, search/playback, alarm setup, system setup, PTZ control and monitor window and etc. 5.1.1 Network Connection Before log in, make sure: ...
Page 88 If it is your first time to log in, the system pops up a warning information to ask you whether you like to install the web plug-in or not. Install the web plug-in. After you logged in, you can see the main window. See picture below. Web monitoring window Note: ...
Page 89 Figure 5-1  Section 3: Open all. Open all button is to enable/disable all-channel real-time monitor. Here you can select main stream/sub stream too. See Figure 5-2. Figure 5-2  Section 5: Instant record button. Click it, the button becomes yellow and system begins manual record.
Page 90  Section 8: PTZ operation panel. Refer to chapter 5.4 for detailed information.  Section 9: Image setup and alarm setup. Refer to chapter 5.5 for detailed information.  Section 10: From the left to the right, you can see video quality/fluency/ full screen/1-window/4-window.
Page 91  2: Local record. When you click local record button, the system begins recording and this button becomes highlighted. You can go to system folder RecordDownload to view the recorded file.  3: Snapshot picture. You can snapshot important video. All images are memorized in system client folder PictureDownload (default).
Page 92 3D Intelligent Positioning You can click this icon to display or hide the PTZ control platform. Figure 5-8 5.5 Image/Alarm-out Select one monitor channel video and then click Image button in section 9, the interface is shown as Figure 5-9 5.5.1 Image Here you can adjust its brightness, contrast, hue and saturation.
Page 93 5.7 WAN Login In WAN mode, after you logged in, the interface is shown as below. See Figure 5-11. Figure 5-11 Refer to the following contents for LAN and WAN login difference. 1) In the WAN mode, system opens the main stream of the first channel to monitor by default. The open/close button on the left pane is null.
Page 94 reference. M stands for main stream. S stands for sub stream (extra stream). 4) If you login via the WAN mode, system does not support alarm activation to open the video function in the Alarm setup interface. Important  For multiple-channel monitor mode, system adopts extra stream to monitor by default. You can not modify manually.
Page 95 Refer to the following sheet for log parameter information. Parameter Function Click Device search button, you can view the searched device Device search information on the list. It includes device IP address, port, device name, manufacturer and type. Select a device in the list and then click Add button, system can connect the device automatically and add it to the Added device list.
Page 96 Figure 5-15 Refer to the following sheet for detailed information. Parameter Function Channel Select a channel from the dropdown list. It divides one day (24 hours) to two periods. You can set different hue, Period brightness, and contrast for different periods. It is to adjust monitor video brightness and darkness level.
Page 97 Sharpness It is to adjust sharpness. The default value is 50. The larger the number is, the sharper the video is. When you input the value here, the bright section and the dark section of the video will be adjusted accordingly. You can use this function when the whole video is too dark or too bright.
Page 98 reneges from 0 to 100. Day/Night It is to set device color and the B/W mode switch. The default setup is auto.  Color: Device outputs the color video.  Auto: Device auto select to output the color or the B/W video according to the device feature (The general bright of the video or there is IR light or not.) ...
Page 99 as max. resolution. The resolution here refers to the capability of the network Resolution camera. Frame Rate PAL：1～25f/s；NTSC：1～30f/s.  Main stream: You can set bit rate here to change video Bit Rate Type quality. The larger the bit rate is, the better the quality is. Refer to recommend bit rate for the detailed information.
Page 100 5.8.1.3.3 Overlay The video overlay interface is shown as in Figure 5-18. Figure 5-18 Refer to the following sheet for detailed information. Parameter Function Check Preview or Monitor first. Cover-area Click Set button, you can privacy mask the specified video in the preview or monitor video.
Page 101 5.8.1.4 Channel Name Here you can set channel name. See Figure 5-20. Figure 5-20 5.8.1.5 IP-CAM Upgrade This interface is to upgrade network camera. See Figure 5-21. Click Browse button to select upgrade file. Or you can use filter to select several network cameras at the same time.
Page 102 Refer to the following sheet for detailed information. Parameter Function Mode There are two modes: static mode and the DHCP mode.  The IP/submask/gateway are null when you select the DHCP mode to auto search the IP.  If you select the static mode, you need to set the IP/submask/gateway manually.
Page 103 Refer to the following sheet for detailed information. Parameter Function Max connection It is the max Web connection for the same device. The value ranges from 1 to 128. The default setup is 128. TCP port The default value is 37777. You can input the actual port number if necessary.
Page 104 Figure 5-25 5.8.2.5 DDNS The DDNS interface is shown as in Figure 5-26. The DDNS is to set to connect the various servers so that you can access the system via the server. Go to the corresponding service website to apply a domain name and then access the system via the domain.
Page 105 Quick DDNS and Client-end Introduction 1) Background Introduction Device IP is not fixed if you use ADSL to login the network. The DDNS function allows you to access the TX-64 via the registered domain name. Besides the general DDNS, the quick DDNS works with the device from the manufacturer so that it can add the extension function.
Page 106 5.8.2.7 Email The email interface is shown as in Figure 5-28. Figure 5-28 Refer to the following sheet for detailed information. Parameter Function Check the box here to enable email function. Enable Insert the SMTP server address of your mail account. SMTP Server Port Default value is 25.
Page 107 Parameter Function Check the box here to enable this function. Health mail enable This function allows the system to send out the test email to check the Update period connection is OK or not. (interval) Check the box to enable this function and then set the corresponding interval.
Page 108 Figure 5-30 Refer to the following sheet for detailed information. Parameter Function Check the corresponding box to enable PAT function. Status Dsiplay UPnP function status. It is corresponding to the UPnP mapping information on the router. Check the box before the service name to enable current PAT service.
Page 109 Parameter Function managers. Make sure the device and the proxy are the same. The read community will read all the objects the SNMP supported in the specified name. The default setup is public. It is a string. It is a command between the manage process and the Write proxy process.
Page 110 5.8.2.12 P2P The P2P interface is shown as in Figure 5-33. You can scan the QR code to connect the receiver with the MY Secure Pro App. Figure 5-33 5.8.3 Event 5.8.3.1 Video detect 5.8.3.1.1 Motion Detect Tip: Set the sensitivity and the threshold under region in order to get an alarm when the detected moving signal reached the threshold you set in the device.
Page 111 Refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable motion detection function. Select a channel from the dropdown list. See Figure 5-35. Period Motion detection function becomes activated in the specified periods. See Figure 5-35 below.
Page 112 Parameter Function Buzzer Check the box here to enable this function. The buzzer beeps when an alarm occurs. Alarm upload System can upload the alarm signal to the centre (Including alarm centre. Send Email If you enabled this function, System can send out an email to alert you when an alarm occurs.
Page 113 Figure 5-36 Figure 5-37 Figure 5-38 Figure 5-39 5.8.3.1.2 Video Loss The video loss interface is shown as in Figure 5-40. Note video loss does not support anti-dither, sensitivity, region setup. For rest setups, refer to chapter 5.8.3.1.1 motion detect for detailed information.
Page 114 Figure 5-40 5.8.3.1.3 Tampering The tampering interface is shown as in Figure 5-41. After analysis video, system can generate a tampering alarm when the detected moving signal reached the sensitivity you set here. For detailed setups, refer to chapter 5.8.3.1.1 motion detect for detailed information. Figure 5-41 5.8.3.2 Alarm Before operation, make sure you have properly connected alarm devices such as buzzer.
Page 115 Figure 5-42 5.8.3.2.2 IPC Offline The IPC offline alarm interface is shown as in Figure 5-43 56. System can generate an alarm once the network camera is offline. Figure 5-43 5.8.3.3 Abnormality It includes six types: No HDD, HDD error, no space, disconnect, IP conflict, MAC conflict. See Figure 5-44 through Figure 5-49 Figure 5-44...
Page 116 Figure 5-45 Figure 5-46 Figure 5-47 Figure 5-48 Figure 5-49 Refer to the following sheet for detailed information. Parameter Function Event Type The abnormal events include: No disk, disk error, disk no space, net disconnection, IP conflict and MAC conflict. You can set one or more items here.
Page 117 Parameter Function Enable Check the box here to enable selected function. Show System can pop up a message to alarm you in the local host screen if message you enabled this function. Alarm upload System can upload the alarm signal to the centre (Including alarm centre. Send Email If you enabled this function, System can send out an email to alert you when an alarm occurs.
Page 118 Figure 5-52 Refer to the following sheet for detailed information. Parameter Function Channel Select a channel from the dropdown list. Figure 5-50 Pre-record Input pre-record time here. The value ranges from 0 to 30. Figure 5-50. Redundancy Check the box here to enable redundancy function. Note this function is null if there is only one HDD.
Page 119 Figure 5-53 5.8.4.2.2 HDD Setting The HDD interface is to set HDD group. See Figure 5-54. Figure 5-54 5.8.4.3 Record Main Stream, Sub Stream & Snapshot The main stream, sub stream & snapshot interface is shown as in Figure 5-55. Here you can set corresponding HDD group to save main stream.
Page 120 Status There are three statuses: schedule, manual and stop. System enables auto record function as you set in record schedule Schedule setup (general, motion detect and alarm). It has the highest priority. Manual Enable corresponding channel to record no matter what period applied in the record setup.
Page 121 Figure 5-58 5.8.5 Setting 5.8.5.1 General The general interface includes general, date/time and holiday setup. 5.8.5.1.1 General The general interface is shown as in Figure 5-59. Figure 5-59 Refer to the following sheet for detailed information. Parameter Function It is to set device name. Device Name Device No.
Page 122 The date and time interface is shown as in Figure 5-60 can be configured on this page. Figure 5-60 Refer to the following sheet for detailed information. Parameter Function Here you can select date format from the dropdown list. Date format There are two options: 24-H and 12-H.
Page 123 Figure 5-61 5.8.5.2 Account Note:  For the character in the following user name or the user group name, system max supports 6-digits. The space in the front or at the end of the string is null. The valid string includes: character, number, and underline.
Page 124 Figure 5-63 Modify user It is to modify the user property, belonging group, password and rights. See Figure 5-64 Modify password It is to modify the user password. You need to input the old password and then input the new password twice to confirm the new setup.
Page 125 The interface is shown as in Figure 5-56. Figure 5-65 Add group: It is to add group and set its corresponding rights. See Figure 5-66 Input the group name and then check the box to select the corresponding rights. It includes: shutdown/reboot device, live view, record control, PTZ control and etc.
Page 126 Figure 5-67 5.8.5.3 Display Display interface includes GUI, TV adjust, Tour and zero-channel encoding. 5.8.5.3.1 Display Here you can set background color and transparency level. See Figure 5-68. Figure 5-68 Refer to the following sheet for detailed information. Parameter Function There four options:...
Page 127 5.8.5.3.2 Tour The tour interface is shown as in Figure 5-69. Here you can set tour interval, split mode, motion detect tour and alarm tour mode. Figure 5-69 Refer to the following sheet for detailed information. Parameter Function Check the box here to enable tour function. Enable tour Here is for you to adjust transparency.
Page 128 Figure 5-71 Refer to the following sheet for detailed information. Parameter Function Click to select import file. Browse It is to import the local setup files to the system. Import It is to export the corresponding WEB setup to your local Export 5.8.5.6 Auto maintain The auto maintains interface is shown as in Figure 5-72.
Page 129 5.9 Information 5.9.1 Version The version interface is shown as in Figure 5-74_1 Here you can view record channel, alarm input/output information, software version, release date and etc. Note the following information is for reference only. Figure 5-74_1 5.9.2 Log Here you can view system log.
Page 130 5.9.3 Online User The online user interface is shown as in Figure 5-75. Figure 5-75 5.10 Playback Click Playback button, you can see an interface is shown as in Figure 5-76. Figure 5-76 5.10.1 Search Record Set record type, record date, window display mode and channel name. ...
Page 131 Check the corresponding box to select record type. See Figure 5-78. Figure 5-78 5.10.2 File List Click File list button, you can see the corresponding files in the list. See Figure 5-79. Figure 5-79 5.10.3 Playback Select a file you want to play and then click Play button, system can begin playback. You can select to playback in full-screen.
Page 132 5.10.4 Download Select the file(s) you want to download and then click download button, you can see an interface shown as in Figure 5-81. The Download button becomes Stop button and there is a process bar for your reference. Go to you default file saved path to view the files. Figure 5-81 5.10.5 More It is for you to search record or picture.
Page 133 You can click OK to download and view the download process. After the download operation, you can see corresponding dialog box. 5.10.5.2 Download by Time Select channel, bit stream type, start time and end time. Click Download to Local button, you can see download by time interface is shown as in Figure 5-82.
Page 134 Refer to the following sheet for detailed information. Type Parameter Function Alarm Type Video loss System alarms when video loss occurs. Motion detection System alarms when motion detection alarm occurs. Tampering System alarms when camera is viciously masking. HDD full System alarms when disk is full.
Page 135 6 Glossary  DHCP: DHCP (Dynamic Host Configuration Protocol) is a network protocol. It is one of the TCP/IP protocol cluster. It is principally used to assign temporary IP addresses to computers on a network.  DDNS: DDNS (Dynamic Domain Name Server) is a service that maps Internet domain names to IP addresses.
Page 136 7 FAQ Questions Solutions TX-64 can not boot up  Input power is not correct. properly.  Power connection is not correct.  Power switch button is damaged.  Program upgrade is wrong.  HDD malfunction or something wrong with HDD ribbon. ...
Page 137 Questions Solutions  Check first if the camera is PTZ compatible!  PTZ decoder setup, connection or installation is not correct.  Cable connection is not correct.  PTZ setup is not correct. TX-64 can not control  PTZ decoder and TX-64 protocol is not compatible. PTZ.
Page 138 Questions Solutions  Alarm setup is not correct. Alarm signal can not  Alarm output has been open manually. been disarmed.  Input device error or connection is not correct.  Some program versions may have this problem. Upgrade your system. ...
Page 139 GPL v2 without charge except for the cost of media, shipping, and handling, upon written request to Technaxx GmbH & Co. KG, Kruppstraße 105, 60388 Frankfurt am Main, Germany.
Page 140 You should have received a copy of the GNU General Public License along with this program; if not, write to the Free Software Foundation, Inc., 51 Franklin Street, Fifth Floor, Boston, MA 02110-1301, USA. (Notice from Technaxx: A copy of the GPL is included below).
Page 141 Any free program is threatened constantly by software patents. We wish to avoid the danger that redistributors of a free program will individually obtain patent licenses, in effect making the program proprietary. To prevent this, we have made it clear that any patent must be licensed for everyone's free use or not licensed at all.
Page 142 c) If the modified program normally reads commands interactively when run, you must cause it, when started running for such interactive use in the most ordinary way, to print or display an announcement including an appropriate copyright notice and a notice that there is no warranty (or else, saying that you provide a warranty) and that users may redistribute the program under these conditions, and telling the user how to view a copy of this License.
Page 143 The source code for a work means the preferred form of the work for making modifications to it. For an executable work, complete source code means all the source code for all modules it contains, plus any associated interface definition files, plus the scripts used to control compilation and installation of the executable.
Page 144 If you cannot distribute so as to satisfy simultaneously your obligations under this License and any other pertinent obligations, then as a consequence you may not distribute the Program at all. For example, if a patent license would not permit royalty-free redistribution of the Program by all those who receive copies directly or indirectly through you, then the only way you could satisfy both it and this License would be to refrain entirely from distribution of the Program.
Page 145 10. If you wish to incorporate parts of the Program into other free programs whose distribution conditions are different, write to the author to ask for permission. For software which is copyrighted by the Free Software Foundation, write to the Free Software Foundation; we sometimes make exceptions for this.
Page 146 "copyright" line and a pointer to where the full notice is found. This manual is for better understanding the product (TX-64, TX-65, TX-66, TX-67)! Copyright (C) 2016 Technaxx This program is free software; you can redistribute it and/or modify it under the terms of the GNU General Public License as published by the Free Software Foundation;...
