A local telephone company may make changes in its communications facilities or procedure. If these changes could reasonably be expected to affect the use of the GX500 or compatibility with the network, the telephone company is required to give advanced written notice to the user, allowing the user to take appropriate steps to maintain telephone service.
Page 5
The pictures in this manual are for illustrative purposes only; your actual hardware may look slightly different. 1.2.7 Interference and Attenuation An GX500 may interfere with sensitive laboratory equipment, medical equipment, etc. Interference from unsuppressed engines or electric motors may cause problems.
Page 20
PA_MODE PAM Mode select 3.2.1.5 USIF Interface GX500 have three USIF Drivers as follow : - USIF1 : Hardware Flow Control / SW upgrade / Calibration - USIF2 : Not used Rx, Tx and CTS, RTS use BT Interface - USIF3 : BT Interface Table 3-3.
Page 21
GX500 Operational Description Revision A 3.2.1.7 GPIO map Over a hundred allowable resources, GX500 is using as follows except dedicated to SIM and Memory. GX500 GPIO(General Purpose Input/Output) Map, describing application, I/O state, and enable level, is shown in below table...
Page 32
PAEN PA_EN PAM Power on VRAMP TX_RAMP 3.2.2.4 USART Interface GX500(SGold Radio Part) has a UART Driver as follow : - USART1 : Hardware Flow Control / SW upgrade / Calibration Table 3-8 USART Interface Spec. USART_0(USART1) Resource Name Remark...
Page 33
GX500 Operational Description Revision A 3.2.2.6 GPIO map Over a hundred allowable resources, GX500 is using as follows except dedicated to SIM and Memory. GX500 GPIO(General Purpose Input/Output) Map, describing application, I/O state, and enable level, is shown in below table.
GX500 Operational Description Revision A 3.3 Power management IC GX500 is composed of dual Power Management Part. (S-Gold3 & S-Gold Radio) 3.3.1 S-Gold3 Part 3.3.1.1 General Description SM-POWER is a highly integrated Power and Battery Management IC for mobile handsets. It has been specially designed for usage with S-Gold3.
Page 46
Vbat-0.3) the above-mentioned bit won’t be set. To support Remote power on function for factory mass production, applied an analog switch as following figure. As monitoring the RPWRON and Key matrix KP_OUT(2) & KP_IN (0), GX500 system recognize whether remote power on or End-key pushed...
3.5 Dual SIM & u-SD Interface 3.5.1 Dual SIM Interface GX500 supports dual SIM mode and each SIM supports 1.8V & 2.9V plug in SIM, SIM interface scheme is shown in (Figure 8). SIM_IO, SIM_CLK, SIM_RST ports are used to communicate with BBP(S-Gold3) and the SIM power supply enabled by PMIC.
GX500 Operational Description Revision A 3.6 Memory GX500 is composed of 3 memories. 2 MCPs(NAND+SDR) are connected each BBP(SG3 / SGR). And 1 DPRAM is used to communicate between 2 MCPs.(SG3 and SGR). 2G NAND(LB/128Mx16bit) +1G SDR SDRAM(8Mx4x32bit) EUSY0347505, Hynix...
Figure 3-19 JTAG & ETM(Embedded Trace Module) interface connector In case of GX500 mass production, the JTAG & ETM interface connector will not be mount on board. That is only for developing and software debugging purpose.( It will not be mounted on mass production PCB)
Page 60
SDIO v1.2 (4-bit and 1-bit). 3.13.2 Bluetooth The GX500 provides the Bluetooth 2.0 specification. The Bluetooth module is the optimal solution for any voice or data application that requires the Bluetooth SIG standard Host Controller Interface (HCI) using a high-speed UART and PCM. The Bluetooth solution has an integrated radio transceiver that has been optimized for 2.4GHz Bluetooth wireless systems.
