Summary of Contents for ETRONIX Powerpal 80w

  • Page 2 PowerPal AC Intelligent digital balance Charger Operating Manual CONTENTS Page 3 Performance parameter Page 4 Main Menu Page 5 Parameter Set-Up Page 7 Lithium Batteries Program Page 10 NiMH/NiCd Battery Program Page 11 PC Battery Program Page 12 Warning and Error Messages Page 14 Safety...
  • Page 3 Performance parameter Input voltage range DC:11~18V AC:100~240V Charge current range 0.1~6.0A Discharge current range 0.1~2.0A Charge power limited max.80W Discharge power limited max.10W Balance current max.300mA Balance tolerance 0.01V Nicd/NiMH ba ery cell count 1~18cells Lithium ba ery types Li-po,Li-ion,Li-Fe Lithium ba ery cell count 1~6series Pb ba ery voltage...

  • Page 4: Operating Instructions

    Operating instructions: Main menu Enter start PowerPal AC -check OK. Dec. Mode/Esc Dec. User set program, press key down and key upward for circulatory choose. Mode Dec. USER SET PROGRAM Press key into submenu. Enter start Dec. Mode/Esc PROGRAM SELECT Li**BATT Dec.
  • Page 5 USER SET PROGRAM Tip: please set up correctly in the “user set” menu before into the job Mode/Esc Enter Dec. LiPo Lilo LiFe V.TYPE 3.7V V.TYPE 3.6V V.TYPE 3.3V Mode Enter Dec. Start Inc. LiPo/Lilo/LiFe CHK Time 10 min You can switch at the same level menu by key.Please refer the Dec./Inc.
  • Page 6 discharge. You can connect a temperature sensor or use the charger current above 1C to avoid it. charge process at PC. (See the screen being subjected to the next process. (See the screen ) the value ranges from 1 to 60 minutes. If you are not sure, you can set it over 10minutes.
  • Page 7 Mode Enter Start Dec./Inc. PROGRAM SELECT press key to make it blink, then change the value with Key. The value will be Enter Dec./Inc. Li** BATT Start stored by pressing key once, and then press key for more than 2 seconds to start Enter Enter Start...
  • Page 8 ctly, press Enter Key for more than 2 seconds to Start start the process. This screen shows the number of cells you set up and the processor detects. LiPo CHARGE “R” shows the number of cells selected by you at the previous menu. If both 2.0A 11.1V(3S) Enter Start...
  • Page 9 According to press key you can inquire the indivi Dec./Inc. Inc. 4.20 4.20 4.20 0.00 0.00 0.00 End Voltage The nal voltage will be reached at the end of process. AUTO CHK Dec. You can inquire the safety capacity. Capacity Cut-o ON 5000mAh Dec.
  • Page 10 Enter Enter Mode start start submenu. You can switch at the same level menu to select the mode by Key. Dec./Inc. PROGRAM SELECT NiMH BATT parameter value in the program, press key to make it blink, then change the Enter start value with key.
  • Page 11 for more than 2 seconds. Enter Start The screen displays the present state of process. To stop It press key; Mode 、 NiMH CHARGE Aut CUR LINIT 5.0A DSC=discharge 、 Mode/Esc :capacity of charge/discharge NiMH DISCHARGE NiMH 2.0A 7.42V 1.0A 11.5V CHG 022:45 00890 Enter...
  • Page 12 Pb DISCHARGE 4.0A 12.0V(6P) discharge process by pressing key for more than 2 seconds. Enter Start Mode Enter Start >2S The screen displays the current state of discharge. Pb-6 0.4A 12.59V DSC 022:43 00682 save data and load data program program again.

  • Page 13: Warning And Error Messages

    Warning and error messages REVERSE POLARITV CONNECTION BREAK discharge on output. There was a short-circuit at output. Please check the charging leads. SHORT ERR INPUT VOL ERR The voltage of input power drops below the limit. VOL SELECT ERR pack carefully. BREAK DOWN The processor detects the voltage is lower than you set at Lithium program.
  • Page 14 BATTERY VOL TAGE CELL LOW VOL of the cell one by one. BATTERY VOL TAGE CELL HIGH VOL of the cell one by one. BATTERY VOL ERR CELL CONNECT carefully. The internal temperature of the unit goes too high. Cool down the unit. TEMP OVER ERR CONTROL FAILURE to be repaired.
  • Page 15 Do not charge above the required voltage recommended by battery brands. Ensure that you always select the correct type of battery type and capacity. its power supply. Always place cells in a Lipo sack when charging. Warning: Waranty and Service •...
  • Page 16 Etronix is an exclusive brand of CML Distribution, Saxon House, Saxon Business Park, Hanbury Road, Bromsgrove, B60 4AD. Web: www.etronix-rc.com e-mail: info@etronix-rc.com All specifications and figures are subject to change without notice. Printed in China ©2010...
