- Page 1 Jordan LebanonSyria NeOvo User Manual Oil-fired Condensing Boiler NeOvo Condens EFU C 40 EFU C 50...
- Page 2 Dear Customer, Thank you very much for buying this appliance. Please read through the manual carefully before using the product, and keep it in a safe place for later reference. In order to ensure continued safe and efficient operation we recommend that the product is serviced regularly. Our service and customer service organisation can assist with this.
-
Page 3: Table Of Contents
Contents Contents Safety ................... . 5 General safety instructions . - Page 4 Contents 8.2.2 Setting the heating ..............29 8.2.3 Setting the domestic hot water temperature .
-
Page 5: Safety
1 Safety Safety General safety instructions Danger This appliance is not intended for use by persons (including children) with reduced physical, senso ry or mental capabilities, or lack of experience and knowledge, unless they have been given su pervision or instruction concerning use of the ap pliance by a person responsible for their safety. - Page 6 1 Safety Important The installation must comply on all points with prevailing regulations and directives, which gov ern work and interventions in individual homes, blocks of flats and other buildings. Hydraulic safety Important Respect the minimum and maximum water inlet pressure to ensure correct operation of the boiler: refer to the chapter Technical Specifications.
-
Page 7: Recommendations
1 Safety Danger If you smell flue gases: 1. Switch off the appliance. 2. Open the windows. 3. Evacuate the premises. 4. Contact a qualified professional. Caution Do not neglect to service the boiler. Contact a qualified professional or take out a maintenance contract for the annual boiler service. -
Page 8: Liabilities
1 Safety Caution Have the boiler and heating system drained by a qualified professional if the home is left empty for a long period of time and there is a chance of frost. Liabilities 1.3.1 Manufacturer's liability Our products are manufactured in compliance with the requirements of the various Directives applicable. - Page 9 1 Safety Call on a qualified professional to carry out installation and initial commissioning. Get your installer to explain your installation to you. Have the required inspections and maintenance car ried out by a qualified installer. Keep the instruction manuals in good condition close to the appliance.
-
Page 10: About This Manual
2 About this manual About this manual Symbols used 2.1.1 Symbols used in the manual This manual uses various danger levels to draw attention to special in structions. We do this to improve user safety, to prevent problems and to guarantee correct operation of the appliance. -
Page 11: Technical Specifications
Mixture of low-sulphur oil (<50 mg/kg) plus 3 to 5.9% (in volume) of FAME (1) Liquid petroleum products — Fatty Acid Methyl Esters used as heating fuel Technical data Tab.2 Technical parameters for boiler space heaters Product name EFU C 40 EFU C 50 Condensing boiler Low-temperature boiler B1 boiler Cogeneration space heater... - Page 12 3 Technical specifications Product name EFU C 40 EFU C 50 Ignition burner power consumption Annual energy consumption Sound power level, indoors Emissions of nitrogen oxides mg/kWh (1) Low temperature means for condensing boilers 30°C, for low temperature boilers 37°C and for other heaters 50°C return temperature (at heater inlet).
-
Page 13: Description Of The Product
4 Description of the product Description of the product General description Floor-standing condensing oil boilers from the EFU C range have the fol lowing specifications: Heating only with possibility to produce domestic hot water by combining them with a domestic hot water tank High-efficiency heating Low polluting emissions Heating body in cast iron... -
Page 14: Description Of The Display
4 Description of the product 4.3.2 Description of the display Fig.4 Hour run meter Malfunctions Maintenance Reset necessary Burner status Heating mode Outside temperature sensor Domestic hot water mode Description of the control panel IniControl 2 4.4.1 Description of the keys Fig.5 1 Back to the previous level without saving the modifications made : manual reset... - Page 15 4 Description of the product Malfunction menu: the appliance has malfunctioned. This informa tion is signalled by an error code and a flashing display PCB selection menu: access to information on the additional PCBs connected Display of PCBs Fig.9 Name of the PCB for which the parameters are displayed Fig.10 Central unit PCB CU-OH1 Fig.11...
- Page 16 4 Description of the product Other Information Fig.15 Chimney Sweep Menu: forced operation in full load mode Three-way valve connected Pump running EFU C 7642053 - v03 - 17112016...
-
Page 17: Utilisation With The Control Panel B-Control
5 Utilisation with the control panel B-Control Utilisation with the control panel B-Control Use of the control panel 5.1.1 Browsing in the menus Press any key to turn on the backlight for the control panel screen. Important If no key is pressed within 3 minutes, the backlight will go out. key is used to access the various menus: Tab.3 Menus available... -
Page 18: Stopping Domestic Hot Water Production
5 Utilisation with the control panel B-Control 5.3.2 Stopping domestic hot water production Fig.20 1. Turn the setting button all the way to the left until is dis played. Note Frost protection continues to run on the domestic hot water tank. The venting cycle is not tripped when domestic hot water produc... -
Page 19: Utilisation With The Control Panel Inicontrol 2
6 Utilisation with the control panel IniControl 2 Utilisation with the control panel IniControl 2 Use of the control panel 6.1.1 Browsing in the menus Press any key to turn on the backlight for the control panel screen. Important If no key is pressed within 3 minutes, the backlight will go out. Fig.21 Press the 2 right-hand keys together to access the different menus: Tab.4... -
Page 20: Selecting A Pcb
6 Utilisation with the control panel IniControl 2 6.1.2 Selecting a PCB Fig.26 1. Accessing the PCB selection menu. Important The PCB selection menu is available only when the icon flash 2. Scroll through the names of the connected additional PCBs by pressing the keys. -
Page 21: Stopping Domestic Hot Water Production
6 Utilisation with the control panel IniControl 2 Fig.29 4. Select the heating shut-down pressing the key. The screen displays: The frost protection function continues to run. The heating has been shut down. Note Press the key to restart the appliance: the screen will display 5. -
Page 22: Shutting Down The Installation
6 Utilisation with the control panel IniControl 2 For more information, see Setting the timer program, page 30 6.3.3 Shutting down the installation It is recommended that the boiler is kept powered on to ensure frost pro tection. Frost Protection Caution The frost protection function does not work if the boiler is powered off. -
Page 23: Control Panel Settings B-Control
7 Control panel settings B-Control Control panel settings B-Control List of parameters 7.1.1 Information menu Tab.5 Information list Information Description Display Heating water temperature (°C) °C The symbol flashes Domestic hot water temperature (°C) The symbol flashes °C If no domestic hot water sensor connected: dis play —... -
Page 24: Modifying The Domestic Hot Water Temperature Setpoint
7 Control panel settings B-Control 7.2.2 Modifying the domestic hot water temperature setpoint Note This setting is available if a domestic hot water tank sensor is con nected. Fig.35 1. Set the domestic hot water temperature setpoint by turning the set ting button Fig.36 2. -
Page 25: Control Panel Settings Inicontrol 2
8 Control panel settings IniControl 2 Control panel settings IniControl 2 List of parameters 8.1.1 User menu Caution The name of the PCB is displayed. Check that it is actually the PCB on which the setting must be made. Certain parameters are displayed: according to certain system configurations, according to the options, circuits or sensors actually connected. - Page 26 8 Control panel settings IniControl 2 Tab.7 List of parameters CP: Circuits Parameters = Parameters for the heating circuit Parameter Description Factory setting Factory setting Heating water flow temperature set point for the area heated if no 75°C 40°C outside temperature sensor has been connected. For the PCB: Can be set from 7 to 90°C.
-
Page 27: Counters / Time Prog / Clock Menus
8 Control panel settings IniControl 2 8.1.2 COUNTERS / TIME PROG / CLOCK menus This menu contains the following sub-menus: COUNTERS TIME PROG CLOCK Caution The name of the PCB is displayed. Check that it is actually the PCB on which the setting must be made. For more information, see Browsing in the menus, page 19 Selecting a PCB, page 20... - Page 28 8 Control panel settings IniControl 2 Tab.12 List of parametersPC: Process Counter Parameter Description Unit Number of burner start-ups. available not available Number of hours of burner operation. hours available not available Number of safety lock-downs (E36). available not available TIME PROG Sub-menu Tab.13 List of parameters...
-
Page 29: Setting The Parameters
8 Control panel settings IniControl 2 Setting the parameters 8.2.1 Modifying the User parameters Caution The name of the PCB is displayed. Check that it is actually the PCB on which the setting must be made. Altering the factory settings may impair operation of the appliance. Fig.37 1. -
Page 30: Setting The Domestic Hot Water Temperature
8 Control panel settings IniControl 2 8.2.3 Setting the domestic hot water temperature Note Domestic hot water production can be managed via the TIME PROG sub-menu dedicated to timer programming. Fig.41 1. Access the domestic hot water production parameters by pressing key twice. - Page 31 8 Control panel settings IniControl 2 Fig.45 6. Select the desired day number by pressing the key until the icon dedicated to the desired day flashes. Day selected Description every day of the week Monday Tuesday Wednesday Thursday Friday Saturday Sunday Note key is used to move to the right.
-
Page 32: Maintenance
9 Maintenance Maintenance General We recommend having the boiler inspected and serviced at regular inter vals. Boiler maintenance and cleaning must be carried out at least once a year by a qualified professional. Have an inspection carried out and the flues swept at least once a year or more, depending on the regulations in force in your country. -
Page 33: Venting The Installation
9 Maintenance Venting the installation Fig.48 Venting the installation Any air in the appliance, the pipes or the valves must be removed in order to prevent annoying noises that may occur during heating or when tapping water. Proceed as follows: 1. -
Page 34: 10 Troubleshooting
10 Troubleshooting 10 Troubleshooting 10.1 Error messages B-Control 10.1.1 Error code display If an error is detected, the error code is displayed automatically. Fig.49 Error code display Note icons flash. 10.1.2 Fault code display If a fault is detected, the fault code is displayed automatically. Fig.50 Fault code display 10.2... - Page 35 10 Troubleshooting Fig.55 3. Press the keys to scroll through the error code history. 4. Press the key to access the details of the error code displayed. 7642053 - v03 - 17112016 EFU C...
-
Page 36: 11 Environmental
11 Environmental 11 Environmental 11.1 Disposal and Recycling Fig.56 Recycling Warning Removal and disposal of the boiler must be carried out by a quali fied installer in accordance with local and national regulations. MW-3000179-03 11.2 Energy savings Tips on saving energy: Do not block ventilation outlets. -
Page 37: 12 Warranty
12 Warranty 12 Warranty 12.1 General We would like to thank you for buying one of our appliances and for your trust in our product. In order to ensure continued safe and efficient operation we recommend that the product is regularly inspected and maintained. Your installer and our service department can assist with this. -
Page 38: 13 Appendix
13 Appendix 13 Appendix 13.1 Product fiche Tab.15 Product fiche for boiler space heaters EFU C 40 EFU C 50 Seasonal space heating energy efficiency class (Prated or Psup) Rated heat output Seasonal space heating energy efficiency Annual energy consumption... -
Page 39: Product Fiche
13 Appendix 13.4 Product fiche Fig.57 The boiler's product fiche indicates the space heating energy efficiency of the product. Seasonal space heating energy effi ciency of boiler ‘I’ Temperature control Class I = 1%, Class II = 2%, Class III = 1.5%, Class IV = 2%, Class V = 3%, Class VI = 4%, from fi... - Page 40 (1) The intermediate values are calculated by linear interpolation between the two adjacent values. (2) Prated is related to the preferential space heater or combination heater. Tab.19 Package efficiency EFU C 40 EFU C 50 Seasonal space heating energy efficiency of package combined with IniControl 2...
- Page 41 13 Appendix 7642053 - v03 - 17112016 EFU C...
- Page 42 13 Appendix EFU C 7642053 - v03 - 17112016...
- Page 43 © Copyright All technical and technological information contained in these technical instructions, as well as any drawings and technical de scriptions supplied, remain our property and shall not be multiplied without our prior consent in writing. Subject to alterations.
- Page 44 DE DIETRICH THERMIQUE S.A.S 129164, Россия, г. Москва Зубарев переулок, д. 15/1 +49 (0)25 72 / 9161-0 Бизнес-центр «Чайка Плаза», +49 (0)25 72 / 9161-102 офис 309 info@remeha.de +7 (495) 221-31-51 info@dedietrich.ru DE DIETRICH THERMIQUE Iberia S.L.U. DE DIETRICH SERVICE www.dedietrich-calefaccion.es www.dedietrich-heiztechnik.com Freecall 0800 / 201608...
