Summary of Contents for Bluegiga BLE113
- Page 1 BLE113 DEVELOPMENT KIT QUICK START Thursday, 14 March 2013 Version 1.5...
- Page 2 Bluegiga Technologies assumes no responsibility for any errors which may appear in this manual. Bluegiga Technologies' products are not authorized for use as critical components in life support devices or systems.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction ..............................4 What is BLE113 Bluetooth Smart Module .....................4 Key features ............................4 BLE113 Development Kit contents ........................5 Getting started with BLE113 ..........................6 Development overview .........................6 Preparations ............................7 Using the DKBLE113 for the first time ....................7 Bluegiga Bluetooth Smart Tools ........................9 Bluetooth Smart Documentation ........................ -
Page 4: Introduction
This document is a getting started guide for the Bluegiga BLE113 development kit. The guide instructs you how to set up the BLE113 development kit, power it up and access the BLE113 using the BLEGUI software. 2 What is BLE113 Bluetooth Smart Module BLE113 is a Bluetooth smart module targeted for small and low power sensors and accessories. -
Page 5: Ble113 Development Kit Contents
3 BLE113 Development Kit contents The BLE113 development kit is a ready-to-use hardware development platform for the Bluegiga BLE113 Bluetooth Smart module. The development kit consists of a single BLE113 development board, programming cables, two BLE113 modules and a BLED112 USB dongle. -
Page 6: Getting Started With Ble113
4 Getting started with BLE113 4.1 Development overview Are you familiar with Bluetooth 4.0? Read: - Bluetooth low energy technology presentation - Visit Bluetooth SIG’s Bluetooth low energy pages Are you familiar with Bluegiga’s Bluetooth 4.0 products? Read: - BLE112, BLE113 &... -
Page 7: Preparations
Note: If CR2032 battery is connected to the BLE113 development board and the power switch is turned to the USB mode a led will turn on, which will slowly drain the CR2032. It’s recommended the CR2032 is fully removed or the BATTERY CURR MEAS jumper disconnected. - Page 8 “Temp. : <temperature in Celsius> The sample firmware also starts Bluetooth low energy advertisements. To discover the BLE113 development board, start the BLEGUI application included in the bin folder of the Bluetooth Smart SDK. In BLEGUI application, select the Bluegiga Bluetooth Low Energy COM port and press Attach. Make sure the status changes to Connected.
-
Page 9: Bluegiga Bluetooth Smart Tools
5 Bluegiga Bluetooth Smart Tools BLEGUI: This application can be used to control BLE112, BLE113 or BLED112 over UART or USB. BLEGUI is a terminal like program that sends the BGAPI command to the Bluetooth Smart module and parses the responses. It's a useful tool to get familiar with the products and try out Bluetooth low energy applications. -
Page 10: Bluetooth Smart Documentation
Documentation Bluetooth low energy - getting started : This document, describes the very basics of Bluetooth Smart technology and related Bluegiga Bluetooth Smart products BGScript developer guide: Describes the BGScript scripting language, its features and limitations. Contains also a lot of practical BGScript examples. -
Page 11: Contact Information
FINLAND Sales Office / USA: Phone: +1 770 291 2181 Fax: +1 770 291 2183 Bluegiga Technologies, Inc. 3235 Satellite Boulevard, Building 400, Suite 300 Duluth, GA, 30096, USA Sales Office / Hong-Kong: Phone: +852 3972 2186 Bluegiga Technologies Ltd.
