- Page 1 HD DIGITAL CAR CAMCORDER PROCAM X18 USER MANUAL 取扱説明書...
-
Page 3: Instructions Before Use
Instructions before use ◆ Forword Thank you for purchasing the XTRONS PROCAM X18 vehicle data recorder. Before first use, please read this manual carefully, to ensure correct use of the product. Keep this manual for future use. ◆ Infringement of copyright warning... - Page 4 Do not use in damp environments. Please note that in a closed environment, the moisture in the air is easy to condense and attached to the equipment. Do not use equipment and its accessories near flammables and explosives, corrosive liquid or gas. Do not remove, modify or repair the equipment.
-
Page 5: Product Structure
Please use the original or suitable packaging to transport the equipment. ◆ Car adapter (car charger) Car adapter for use in car cigarette lighter socket (DC 12 or 24 v). ◆ Features Low illumination high-definition video (1080FHD, ① 720P/60FPS,720P/30FPS） Built-in low illumination 170degree lens. ②... - Page 6 ◆ Back 3. Indicator LED 4. Screen ◆ Left 5. OK button 6. Mode button 7. Lock button 8. Power button ◆ Right TF Card slot 10. Up button 11. Menu button 12. Down button...
- Page 7 ◆ Right 13. HDMI 15. USB 14. Stent Hole ◆ Bottom 16. Mic 17. Reset...
-
Page 8: Method Of Use
Method of use ◆ Insert the memory card 1. According to the instructions carefully insert the card into the card slot to avoid damage to the card slot. 2. Inserting the memory card allows images to be recorded onto it. 3. - Page 9 ◆ Switch work mode This machine has three work modes: Video, Photo and Playback. Press to switch. Video： Video mode Video resolution M-sensor Record Video time TF Card Date/time Video segmentation time Battery Motion detecting Start / Stop Recording: Insert the car charger, the unit will start to record automatically.
- Page 10 Photo mode: Photo mode Remaining photos Photo resolution White balance Image quality SD Card Anti-shake Battery Photos: Aim the camera and hold the unit still and press "OK" button until a "cut" sound is heard. Users can choose different shooting settings according to requirements.
-
Page 11: Playback Modes
Playback modes: Playback mode：Press "up" or "down" key files were selected, press "OK" button to confirm play. Playback mode：Press " " button twice to enter the playback menu, under this menu to delete the file and protection, can also choose the slide show. ◆... - Page 12 WDR: ON EV: -2 ── +2 Motion Detection: ON/OFF Recording audio: ON/OFF Date stamp: ON/OFF G-sensor: OFF/High/medium/low LDWS: function switch(ON/OFF), Vehicles model (cars/vans/trucks), Sensitivity (high/low/high), Area selection (China/Taiwan), the vehicles speed (very slow /slow /fast,Warning tone(ON/OFF). Interval video: Off/100ms/200ms/400ms. ◆ System Settings Parking monitor: Off/High/Standard/Low Date/time: 2015/01/01 00:11 Year/Month/Day Key tone: ON/OFF...
- Page 13 Continuous Shooting: ON/OFF Image quality: High quality/Standard/Common Sharpness: Enhance/Standard/Soft White balance: Auto/ Sun/Cloudy/Tungsten filament lamp/ Fluorescent Color: Normal/Black and white/Brown ISO: Auto/100/200/400 EV: +2 ── -2 Anti-shake: ON/OFF Time: Off/Date/Date-Time ◆ Playback options Delete: Delete the current/Delete all Protection: Lock current /Unlock current/ Lock all /Unlock all Slide play: 2s, 5s, 8s ◆...
- Page 14 ◆ Set the language Open the device, the machine automatically switches to video standby mode. Press the button twice, enter the system, select the option, press the button to enter into the options. Then press the up/down key to change language settings. ◆...
- Page 15 of removable disk, you can copy or cut the files to the PC to play. Alternatively the memory card can be removed from the device, and insereted into a card reader connected to your PC. If you choose “CAMERA” mode, the unit can also used as a PC CAM. Playback modes: 3.0 inch TFT LCD screen size...
-
Page 16: Frequently Asked Questions
Support Microphone/speaker English/Simplified Chinese/ Traditional Chinese/Japanese / Language French/German /Korean /Italian/ Portuguese/Russian Note: The specification may be due to the upgrade and update changes such as reason, in kind prevail Frequently asked questions: In the event of failure, please try to use the following method. If you cannot be ruled out, please contact the after sales and maintenance.
