Summary of Contents for wbox HD2s

  • Page 2: Safety Instructions

    afety Instructions afety Instructions This product has been manufactured to satisfy the international safety standards. Please read all of safety and operating instructions before operating the product and keep this manual for future reference. The information in this user manual is subject to change without notice. MAINS POWER SUPPLY AC 90~250V~, 50/60Hz.
  • Page 3 afety Instructions SERVICING Do not attempt to service this product yourself, as opening or removing covers may expose you to dangerous voltage or other hazard. Refer all servicing to qualified service personnel. This item incorporates copy protection technology that is protected by U.S. patents and other intellectual property rights of Rovi Corporation.

  • Page 4: Table Of Contents

    ontents ontents Safety Instructions ........ 2 Reminders ..........19 TV List ............ 19 Chapter 1 Before You Begin ........5 PVR ............20 General Features ......... 5 Scheduled recordings ......20 Ongoing recordings ........ 20 Accessories .......... 5 Completed recordings ......21 Chapter 2 Failed recordings........

  • Page 5: Before You Begin

    hapter 1 >> Before You Begin efore You Begin General Features • Supports DVB-C, DVB-T/T2 • MPEG-2 (MP@ML), MPEG-2 (MP@HL), MPEG4 AVC/H.264, HP@L4 • OSD Teletext supported • EPG (Electronic Program Guide) for On-screen Channel Information • Parental control function •...

  • Page 6: Controls And Functions

    hapter 2 >> Controls and Functions ontrols and Functions Front / Rear Panel Power LED Smart Card Slot Display the power ON/OFF. Smart card shall be paired by informing the CHIP-ID to your operator. You can find IR-receiver the CHIP-ID from CONAX and System IR Remote Control Receiver.

  • Page 7: Remote Control Unit

    hapter 2 >> Controls and Functions Remote Control Unit M_180_DNA_HD-T63CX_ENG_120322_jte.indd 7 2012-03-22 2:41:22...
  • Page 8 hapter 2 >> Controls and Functions Remote Control Unit Power ( ) Menu Turns your receiver On/Off. Display the main menu. Numeric (0~9) Info Access channels directly via channel Show channel and program information on number. the screen. TV/Radio ( REC ( ) Switch between TV and Radio channels.

  • Page 9: Chapter 3 Connections

    hapter 3 >> Connections onnections Connecting your TV to the set-top box with an HDMI cable will ensure a more vivid picture and enhance your viewing enjoyment. Location of your receiver • Install your receiver in a horizontal position. • Do not put any heavy items such as a TV on your receiver. •...

  • Page 10: Connecting Digital Audio System

    hapter 3 >> Connections Connecting digital audio system Connect an optical cable to the connector marked “S/PDIF” at the rear panel of your receiver and its other end to the respective S/PDIF INPUT OPTICAL connector on the digital audio system. Connecting your analog receiver Connect a coaxial cable from output terminal marked “LOOP”...

  • Page 11: First Time Installation And Basic Operations

    hapter 4 >> First Time Installation and Basic Operations irst Time Installation and Basic Operations First Time Installation When starting up your receiver for the first time, an initial setup of the receiver needs to be performed before it is ready to be used. Select your language (Finnish/Swedish/English).

  • Page 12: Basic Operation

    hapter 4 >> First Time Installation and Basic Operations Basic Operation This section explains various functions while watching TV or listening to the Radio. Switching Channel You can switch the current channel by three different methods. Method 1) Press the Arrow (▲/▼) or PR+/- buttons. Method 2) Press the Numeric (0~9) buttons to select a channel directly.

  • Page 13: Viewing The Teletext

    hapter 4 >> First Time Installation and Basic Operations Viewing the Teletext To view the teletext service: Press the Teletext button to display the teletext service, if present. Use Arrow (▲/▼) or Numeric (0~9) buttons to change pages. Use Arrow (◄/►) buttons to navigate between sub pages, if present.

  • Page 14: Electronic Program Guide (Epg)

    hapter 4 >> First Time Installation and Basic Operations Electronic Program Guide (EPG) Electronic Program Guide displays program information such as channel number / name, program titles, broadcasting schedule, and program synopsis. ※ EPG service may differ depending on the service provider. Press EPG button to enter the Electronic Program Guide.

  • Page 15: Instant Record

    hapter 4 >> First Time Installation and Basic Operations Instant Record Press the Record ( ) button to start recording the current program instantly. To stop a recording, press the the Stop ( ) button or the Record ( ) button again. The list of ongoing recordings will appear.

  • Page 16: Menu Map

    hapter 5 >> Main Menu enu Map Favorites HDTV Radio TV Guide Search Reminders Scheduled recordings Ongoing recordings Completed recordings Failed recordings Radio Parental control Change PIN Block channels Conax About Conax CA Subscription Status Event Status Tokens Status Messages Maturity Rating Change CA Pin Channel Installation...
  • Page 17 hapter 5 >> Main Menu Languages Menu language Primary Audio Language Secondary Audio Language Primary Subtitle Language Secondary Subtitle Language Hard of Hearing Subtitles User Interface Instant Timeshift Frontpanel Clock In Standby PVR Start Margin PVR End Margin Autodelete Oldest Recordings Default PVR Quota Screensaver Timeout OSD/Banner Display Time...

  • Page 18: Main Menu

    hapter 5 >> Main Menu ain Menu This menu consists of 8 different menus: • Favorites • TV • PVR • Radio • USB • Parental control • Conax • Configuration Press the Menu button to enter the Menu mode. Menu will open at the last remembered state. Use the Arrow (▲/▼/◄/►) buttons to move up, down, left, and right on the menus.

  • Page 19: Search

    hapter 5 >> Main Menu Search Select Search using the Arrow (▲/▼) buttons on the TV menu and press OK button to open the Keypad. Input a keyword using the Arrow (▲/▼/◄/►) and OK buttons. Then select enter and press the OK button to start the search.

  • Page 20: Pvr

    hapter 5 >> Main Menu Scheduled recordings This menu lists recordings that have been scheduled and are waiting for the determined time or program to come up. Select Scheduled recordings using the Arrow (▲/▼) buttons on the PVR menu and press the OK button the display the list of recordings.

  • Page 21: Completed Recordings

    hapter 5 >> Main Menu Completed recordings This menu lists recordings that have completed. Select Completed recordings using the Arrow (▲/▼) buttons on the PVR menu and press the OK button to display the list of recordings. Press the Option button to open more options. (1) Continue: Resume watching a completed recording.

  • Page 22: Schedule Keyword Recording

    hapter 5 >> Main Menu Schedule keyword recording Press the Option button on the PVR menu. Select Schedule keyword recording using the Arrow (▲/▼) buttons and press the OK button to display a list of recording settings. Use the Arrow (▲/▼) buttons to select a setting and press the OK button to change it. Available settings are listed below: (1) Channel: By default the keyword recording applies to any channel.

  • Page 23: Edit A Directory

    hapter 5 >> Main Menu Edit a directory Select the directory you wish to edit using the Arrow (▲/▼) buttons on the PVR menu and press the Option button to display a list of functions. Use the Arrow (▲/▼) buttons to select a function and press the OK button.

  • Page 24: Parental Control

    hapter 5 >> Main Menu Parental control Configure Select Configure using the Arrow (▲/▼) buttons on the Parental control menu and press the OK button. Authentication required pop-up will be displayed. Input a PIN using the Numeric (0~9) buttons and press the OK button.

  • Page 25: Configuration

    hapter 5 >> Main Menu Configuration Channel Installation Select Channel Installation using the Arrow (▲/▼) buttons on the Configuration menu and press the OK button. Automatic Channel Scanning: 2-1 Select Automatic Channel Scanning and press the OK button. 2-2 DVB-C or DVB-T Automatic scan menu will be displayed. 2-3 Select Start and press the OK button to start the channel scan.

  • Page 26: Channel Status

    hapter 5 >> Main Menu Channel Status This part of the menu can be used to view the channel parameters and signal status of the currently tuned TV channel. A/V Output Settings Select A/V Output Settings using the Arrow (▲/▼) buttons on the Configuration menu and press the OK button.

  • Page 27: User Interface

    hapter 5 >> Main Menu User Interface Select User Interface using the Arrow (▲/▼) buttons on the menu and press the OK button. Select a setting using the Arrow (▲/▼) buttons and press Configuration the OK button. Available settings are listed below: (1) Instant Timeshift: If you enable the instant timeshift, the timeshift function will operate automatically.

  • Page 28: Troubleshooting

    roubleshooting roubleshooting Problem Solution No power supply. Plug the power cord correctly. No picture. Check that the video and antenna cables are connected correctly, and that they are not damaged in any way. Check that your TV is set to the correct video input source.
  • Page 29 roubleshooting Problem Solution Pay TV channels do not work. Pay TV channels do not work if the smart card and STB are not paired. To make the pairing, inform your operator with your STB’s CHIP-ID and the number of your smartcard. You can find the CHIP-ID from CONAX an System information menu.

  • Page 30: Specifications

    pecifications pecifications TUNER & CHANNE Input Frequency 47~870MHz Input Connector IEC 169-2 Female (RF IN), IEC 169-2 Male (RF OUT) IF Frequency 36.125 MHz DVB-C FEC Mode Rate 1/2, 2/3, 3/4, 5/6, 7/8 Demodulation Constellation 16, 32, 64, 128, and 256 QAM QAM System Clock 28.92 MHz Input Frequency...
  • Page 31 pecifications Conditional Access System Smart Card 1 Smart Card Reader Accessories IR (Freq:38KHz), Battery : 2x1.5V AAA HDMI Cable 1.5M Ethernet Cable 1.5M(Optional) 1.5M(Optional) RF Cable DIN to SCART(Optional) AV Cable Manual Size(WxHxD) 180 x 33 x 132 mm Net Weight 1 Kg Operation Temperature 0~45...
  • Page 32 _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________ _____________________________________________________________________________________________________...
  • Page 33 orrect Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life.
