Summary of Contents for wellbots Evapolar
-
Page 1: Product Guide
Product Guide Personal air cooler... - Page 3 Intended use: Evapolar is intended to cool and humidify the air creating a local microclimate in the area of 3-4 sq. m (30-45 sq ft.). It also has a purification effect, filtering large dust particles from the air. The best effect can be achieved indoors.
- Page 4 — The manufacturer does not bear any responsibility for any damage arising from failure to comply with this product guide. — A replaceable evaporative cartridge is designed specifically for this product. If your cartridge has been broken or damaged, you can purchase a replacement at Evapolar.com or with your local retailer.
-
Page 5: First Start
First start 1. Slide the water reservoir up. 2. Open the lid to fill up the reservoir. 3. Place the reservoir on the base. Make sure it is installed properly. 4. Use the cable to connect the power supply to the device and the power source. 5. -
Page 6: Daily Use
We’ve made sure you won’t have to fine-tune your air cooler for too long. The device is ready to use right after you unpack it. Afterwards, all you need to do is follow a few simple recommendations to make your Evapolar experience as smooth as possible. Placing the device The air cooler creates a local comfort zone. - Page 7 Filling the reservoir In order to work properly the device needs only water. You should remove the reservoir on the left side of the device, fill it with water and then place it back. The water will start flowing automatically. Depending on the quality of the air in the room, the full reservoir should provide from 3 to 5 hours of uninterrupted work.
- Page 8 In order to remove the water instantly from the internal reservoir and prepare device for transportation, please do the following: 1. Disconnect the device from a power source. 2. Remove the reservoir by sliding it up. 3. Use both hands to lift the upper part of the body. Push on both sides of its bottom part to release the locks and then slide it upwards.
- Page 9 Minimal power requirements allow the device to run even from a portable power bank. Required electricity parameters: voltage 5V, current 2A and up. Important: Since outside conditions can vary greatly, Evapolar is not responsible for the way the device functions outdoors.
-
Page 10: Control Panel And Menu
Important: — Make sure that the air cooler is placed on a smooth horizontal surface to avoid leaks and spills. — Do not use the device in the temperatures exceeding 60° C (140° F). Failing to do so can damage both body and internal components of the device. - Page 11 Control elements Circular power lever Touchable screen — Circular power lever By moving the lever you increase or decrease power the airflow level and also move around menu points. — Touchable screen A single touch will let you access the menu of the device, select one of the options and confirm your choice.
- Page 12 Menu points 1. Night mode In the night mode the lighting of the device turns off and display lighting becomes minimal. To exit the night mode simply touch the display lightly. 2. Lighting color You can pick the color of the water reservoir lighting. 3.
-
Page 13: Device Maintenance
Device maintenance Reservoir 1. Three hours prior to cleaning empty the water out of the reservoir and let the device run for a few hours without water. 2. Prior to actual cleaning disconnect the device form a power source. 3. Extract the cartridge (see paragraph on Cartridge Replacement). -
Page 14: Replacing The Cartridge
Replacing the cartridge 1. Disconnect the device from a power source. 2. Remove the reservoir by sliding it up. 3. Use both hands to lift the upper part of the body. Push on both sides of its bottom part to release the locks and then slide it upwards. - Page 15 Important: — Depending on usage and storage, the cartridge can last 6-12 months. — Poor water quality reduces the longevity of the cartridge. — The new cartridge can be stored for up to 3 years without losing its evaporation potential. —...
- Page 16 Technical specifications Power supply Line 100 – 240 V / 50-60 Hz Other power sources 5V / 2A Power consumption 10 W Cooling power 100-350 W Recommended cooling square/space 4 m2/ 8 m3 (45 ft2/ 285 ft3) Water tank capacity 750 ml Size 174 x 170 x 170 mm...
- Page 17 The distributor company selling the device determines the warranty duration and conditions. All air coolers undergo a thorough quality control. Devices and cartridges purchased at evapolar.com fall under warranty details described on the website. Should you have any questions, feel free to email us at support@evapolar.com...
- Page 18 Responsible Party Address: Subject to change without notice!* Evapolar Ltd. 236 Strovolou, Strovolos, 2048 Nicosia, Cyprus 2016 Evapolar Ltd. All rights reserved, including any and all copyrights and rights on Evapolar’s trademarks and service marks, if any.
