Summary of Contents for Azoi KITO+
- Page 1 KITO+ Instructions for Use Azoi htp://azoi.com...
-
Page 2: Table Of Contents
Instructions for Use Table of Contents About Kito+............................6 Important Information........................6 Safety.................................. 6 Intended Use..............................6 Indication of Use............................6 Contraindication............................7 Unpacking............................. 7 Package Contents............................7 3.1.1 Device Unpacking............................ 7 System Requirements for App Installation..................7 Know your Device............................8 Charge your Device............................ - Page 3 Instructions for Use 5.4.2 Multiple Addresses..........................22 5.4.3 Automatically send to specified address(es)................22 Important Settings........................... 22 Adding Multiple Users..........................22 Security and Privacy..........................22 Configure Alerts............................22 Sync Fitbit™..............................22 Care............................... 22 Cleaning................................22 Storage................................23 Maintenance..............................23 Caution..............................23 Troubleshooting..........................
- Page 4 Instructions for Use About Azoi We, at Azoi, have been working on “monitoring technology” which would enable people to track their health. We intend to provide consumers an easy and accessible way to measure their critical vitals in a home environment. Azoi’s team includes experts in sensor technology, product design, application development and quality assurance to ensure that the delivered product conforms to the prescribed requirements.
-
Page 5: About Kito
Instructions for Use 1 About Kito+ Welcome to the Kito+ family! Kito+ is a hand-held device that should be used in indoor environments to measure body vitals in adults. It has a modular design so that you can easily attach and re-use it with the cover for iPhone 6, 6 Plus, 6s and 6s Plus devices. -
Page 6: Indication Of Use
Instructions for Use pertaining to their health. The Kito application allows the user to check present measurements, view previous measurements and share the data with person(s) of their choice. 2.3 Indication of Use Kito+ is a device designed for self-testing by adults only. It allows the users to measure and view their vital signs via the Kito+ mobile application interface. -
Page 7: Know Your Device
Instructions for Use iOS 7 or higher Apple ID to access the App store Android Android 4.3 or higher Additionally, your mobile device must natively support Bluetooth Low Energy and have internet connectivity. 3.3 Know your Device Kito+ Page... -
Page 8: Charge Your Device
Instructions for Use Kito+ Charger 3.4 Charge your Device Bring the charger near the charging connectors on Kito+. The charger will automatically snap into place through a strong magnetic pull. Plug-in the other end of the charger to a power outlet. Turn ON the power supply. If you see a Blue light on Kito+, it is charging. -
Page 9: Get Started
Instructions for Use The light indicator near the Switch helps you to identify the Kito+ battery levels. Please refer the following table to understand the indications: Kito+ Continuous Light Kito+ is active and the battery is sufficiently charged. Light Blinking Light Kito+ is active, but the battery is too low to measure the vitals. -
Page 10: Install The App
Instructions for Use Note: Please charge Kito+ completely before using it. For more information, please see the previous section on Charging Kito+. 4.2 Install the App Download and install “Kito” app from the App Store or Google Play. After successful installation, the Kito icon will show up on your screen. -
Page 11: Do A Test Reading
Instructions for Use Pairing is a one-time activity. For subsequent use, pairing is not required unless you replace your mobile device or Kito+. You can also unpair Kito+ as described in the section, Unpair Kito+. 4.5 Do a Test Reading Press the Switch to turn ON Kito+. -
Page 12: Remove Kito
Instructions for Use Tap Save at the top-right corner of the screen to store the readings to your account. You can review the saved readings from your timeline. Please see the section Your Health Data for more details. You can choose to discard the current reading and take a reading again. 4.6 Remove Kito+ To remove Kito+, use your thumbs to apply outward pressure on the corners of the Kito+ device. -
Page 13: The Dashboard
Instructions for Use Skin Temperature - Skin Temperature measures the temperature at the surface of your skin. Skin temperature majorly depends on the surrounding air temperature and time spent in an environment. External factors such as chilly winds and humidity can cause changes in the skin temperature. - Page 14 Instructions for Use Dashboard Components Timeline: The Dashboard timeline displays dates of the current month sequentially along a line. You can slide the timeline to move back and forth and review older readings. The dots adjacent to the dates expand and shrink based on the number of readings taken during a day; a larger dot denotes multiple reading records.
-
Page 15: Readings By Type
Instructions for Use Share Readings: To share readings, tap “Share” and select the Reading Cards you would like to send via email. Settings: Tap Settings ( to set a reminder, edit your Profile, sync Fitbit™, apply a Security Lock, register emails to Share Reports, apply ECG Filter, alter the measurement unit for Temperature vital and upgrade Firmware. - Page 16 Instructions for Use The point plotted on the graph denotes the average of readings taken in an hour. The reading which you are reviewing will be displayed at the center of the screen (72 BPM in the screen). The value in percentage at the top-right of your screen (11%) is the percentage difference between your latest reading and the one being reviewed.
-
Page 17: Spo2
Instructions for Use 5.3.2 SpO2 Tap “Blood Oxygen” to plot your measurements on the chart. Here, the X-axis (horizontal) corresponds to the hour/day/month, and the Y-axis (vertical) corresponds to the percentage of Blood Oxygen. 5.3.3 Respiration Tap “Respiration” to plot your measurements on the chart. Here, the X-axis (horizontal) corre- sponds to the hour/day/month, and the Y-axis (vertical) corresponds to the number of breaths per minute. -
Page 18: Skin Temperature
Instructions for Use 5.3.4 Skin Temperature Tap “Skin Temperature” to plot your skin temperature measurements on the chart. Here, the X- axis (horizontal) corresponds to the hour/day/month, and the Y-axis (vertical) corresponds to the configured measuring unit for Temperature (°C or °F). -
Page 19: Ecg
Instructions for Use 5.3.5 ECG ECG represents the electrical activity of the heart as measured by Kito+’s electrodes. In an ECG display, the X-axis (horizontal) corresponds to the time in seconds, and Y-axis (vertical) corresponds to the amplitude or voltage in millivolts (mV). The graph highlights a Page... -
Page 20: Share Reports
Instructions for Use repeating pattern of a tiny wave, followed by a sharp dip, a tall and a sharp spike, followed by a moderate sized wave. This wave pattern represents a single cardiac cycle. To enhance the ECG graph, you can apply a filter to remove noises from the ECG signal. Go to Settings, tap “ECG Filter”... -
Page 21: Configure Alerts
Refer to the troubleshooting section to fix the problems you may encounter during usage. You can write to us at help@azoi.com in case of further queries. 8 Caution Do not wash the unit with water or any other chemicals not identified in the “Care”... - Page 22 Instructions for Use Do not use device with lotion or cream on skin. Do not charge the device with any other charger apart from the one received with the device. Do not use the device while it is being charged. Do not use the device when battery is critically low.
-
Page 23: Troubleshooting
To reset Kito+, press and hold the Switch on the device for approximately 5 seconds till you see a blinking white light. Note: In the event that the above troubleshooting tips do not address your issue, please contact help@azoi.com. Page... -
Page 24: Specifications
Instructions for Use 10 Specifications ECG Specifications ECG channels 1 Lead Memory Limited by the phone’s memory Recording Duration 30 seconds for each reading Frequency response 0.67 Hz to 40 Hz CMRR -105 dB Input impedance 500 MΩ Differential range ±5 mV ADC sampling rate 250 Hz... - Page 25 Instructions for Use Red wavelength 660 nm Measuring Methods SpO2 Photoplethysmography Heart rate ECG driven Heart rate Respiration ECG, PPG driven Respiration Skin temperature Contact based temperature sensing Minimum operating time 30 seconds Accuracy SpO2 ±3.5% rms Heart rate ±10% or ± 5 BPM whichever is greater Respiration ±3 BrPM Skin temperature...
- Page 26 Instructions for Use Battery life 2 years * Battery capacity 53 mAh X 2 Output voltage 3.7 volts Charging mode Rechargeable Compatibility iPhone 6, 6 Plus, 6s, 6s Plus Android (OS version 4.3 or higher) Wireless communication Bluetooth 4.0 - Bluetooth Low Energy B a t te r y c h a r g i n g t i m e f r o m 3 hours depletion to 90%...
-
Page 27: Deactivate
Instructions for Use Weight 20 gms Colours Pantone Black Model Number Ingress Protection IP22 2- Protected against solid foreign objects of 12.5 mm and greater 2-Protection against vertically falling water drops when ENCLOSURE tilted up to 15° * Battery life may vary depending on usage and settings. 11 Deactivate 11.1 Unpair You can remove the existing Kito+ pairing. -
Page 28: Fcc Statement
Instructions for Use Caution or General Warning Temperature Limitation Symbol for compliance with Federal Communication Commission Waste Electrical and Electronic Equipment Refers the Manufacturer Serial number Date of Manufacture Ingress Protection CE Mark 13 FCC Statement The changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. -
Page 29: Declaration And Disclaimers
Instructions for Use Consult the dealer or an experienced radio/TV technician for help. FCC Caution This device complies with Part15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference and 2.
