Assembly Instructions
Table of contents
1.1 Gate operator kit
1.7 Compliance to norms
3.3 Settings
3.8 Transmitter encoding
4.1 Help ...trouble shooting
812/300;
812/400; 812/400 MONO
812.03 ; 412.03pro;
812.03/400pro
ALLDUCKS Srl
via Alessandro Volta,1 - 20060 Ornago (MI) Italy
Tel. +39/039/6010654 Fax +39/039/6011243
service@allducks.it
www.allducks.it
1
Advertisement
Table of Contents
Summary of Contents for Allducks 812/300
-
Page 1: Table Of Contents
Assembly Instructions 812/300; 812/400; 812/400 MONO 812.03 ; 412.03pro; 812.03/400pro Table of contents 1.1 Gate operator kit 1.2 Technical features 1.3 How to operate the device 1.4 Safety recommendations 1.5 For higher safety 1.6 Emergency control 1.7 Compliance to norms 2.0 Actuators assembly to “K”... - Page 2 Fig.1 HC812.03/400 protop HC412.03/400 protop HC812.03 1.1 Kits composition Fig.1 HC 812.03 max 2.5 x 2 m No. 2 12V actuators 300 mm stroke. A No. 1 CTR42 Programmer with radio receiver. B No. 2 remote transmitters with 12V built-in battery. C No.
-
Page 3: Technical Features
1.2 Technical features A: Actuators provided with triple trapezoidal screw driven by an irreversible worm screw gear motor provided with EMERGENCY UNLOCKING SYSTEM. 12 V DC Motor - Maximum thrust: 150N - Piston rod speed: 1.5 cm per sec. - Possibility of continuous work. Protop - Operating temperature: -15 + 45°C. -
Page 4: How To Operate The Device
1.3 How to operate the device Fig.2 The pulse is sent to the remote transmitter “C” and is received by the electronic programmer “B” which provides to supply the energy to motors “A” which drive the gate wings. Two operating modes are available: step-to-step and auto- matic. -
Page 5: Actuators Assembly To "K" Plate
Fig.6 Fig.4 Fig.5 2.0 Actuators assembly to “K” plate Fig.4 ssemble the adjustable “K” plate and fix it to the wall. This operation is extremely important as it shall determine the following parameters: 1. Gate opening speed 2. Actuator thrust strength Fundamental elements to make this choice are the following: 3. -
Page 6: Second Actuator Assembly
Fig.8 Fig.7 - Open the gate wing till the desired position is reached Now the “H” front plate can be fixed following this scheme. - You have to unlocked the actuator by means of the key through the plug. Fig.3 1. -
Page 7: Wiring
Fig.9 Fig.13 Fig.12 230V 50Hz 110V 60Hz Fig.11 Fig.10 Fig.12a 3.0 Wiring Fig. 9 AC line input 12 V electromechanical pistons Electronic control equipment Fig.14 Key selector 12V max 10W blinker 1: Connection cable motor M1 - Bipolar cable 1.5 mm_ cross section 2: Connection cable motor M2 - Bipolar cable 1.5 mm_ cross section 3: Blinker connection cable (not supplied) 4: Key selector connection cable (not supplied) -
Page 8: Standard Electric Connections
Fig.14 Fig.14a Connections: 1 – antenna pole 2 – antenna sheath 3 - start 4 - photocell 5 - start/photocell common 9 - pedestrian start (only CTR42/S) 10 – photocells power supply positive 11 - photocells power supply negative 12 – blinker 13 –... -
Page 9: Special Connections
Fig.14 3.3 Settings Fig.14 1.Motor 1 RV1 trimmer and motor 2 RV2 trimmer ampere set- ting or safety setting: it shall be set as to ensure safety in case of obstacle, however with enough power to move wings. Turn the trimmer clock-wise to increase the power. Caution: during winter months or when a strong wind blows, the settin 2.PROGRAM: RV3 trimmer allows to manage two operating... -
Page 10: Special Electric Connections: Photocells
Fig.16/a Fig.16 Fig.17/a Fig.17 3.4 Special electric connections : photocells (optional for HC812.03) The protection system by means of photocells is composed of one or more PAIRS of devices, one of them is the TRANSMITTER and the other is the RECEIVER. Fig.16-17 The first transmits an invisible infrared beam picked up by the receiver;... -
Page 11: Emergency Battery
Fig.18 Fig.19 10 cm 12 cm 5 cm 5 cm 3.5 Emergency battery and C/M/BATT battery charger (optional) Fig. 12 The system can also operate AUTOMATICALLY, that is without power supply coming from the mains supply. By installing a 12V 6,3 Amp. battery, it will be possible to carry out approx. 30 emergency operations without power supply. The battery can be fit in the proper space inside the plastic casing containing the control unit. - Page 12 Fig. 20 9 10 11 12 9 10 11 12 9 10 11 12 9 10 11 12 9 10 11 12 9 10 11 12 3.8 Transmitter and receiver encoding The newly designed remote transmitter ref. 6203 is standard PRE-CODED in the factory, fig.20a. The pre-set codes will be transmitted by pressing T1-T2-T3 keys Fig.20 Gate operator Garage operator...
-
Page 13: Advanced Functions
Fig.14 3.9 Advanced functions 1) Function of opening one wing only with the remote transmitter. Proceed as follows: a) ON THE REMOTE TRANSMITTER: - select a new key (T1, T2 or T3) different from the one used to open the two wings and code the remote transmitter with a NEW CODE (see paragraph 3.8) b) ON THE PROGRAMMER Fig.14: - Press the P1 key TWICE, let 1 second elapse from one pressing to the other - Press the key of the chosen channel (T1, T2 and T3) of the remote transmitter to transmit the code to the programmer... -
Page 14: Control List: 20 Points
4.0 Control list: 20 points 4.1 HELP..TROUBLE SHOOTING (S = PROBLEM, C = CAUSE R = REMEDY) S-The gate does not open when a pulse is given We suggest to check the following points in order to be absolutely sure to have C- 1. -
Page 15: Spare Parts
R4/R28 CTR42/S CTR42 HC412 HC312 4.2 Spare parts: CRT42/S Programmer card for professional models REF. DESCRIPTION HC 312 12V motor, 300 mm stroke with tie rods (R38) Stainless steel tube with clevis and nut screw, 300 mm HC 412 12V motor, 400 mm stroke with tie rods (R38/400) R1/400 Stainless steel tube with clevis and nut screw, 400 mm 12V Motor (R22 ball bearing for drive shaft type 6002zz-R26 type, motor body... -
Page 16: Guarantee
EN55014, EN61000-3, EN60529, ETS 300 683, EN60555, 2.Allducks obligations are limited to the repair or, at its own discretion, to the defective parts & EN60335-1, EN60034 according to the European Directives: R&TTE 99/05/CE,73/23/CEE, replacement.
