Operating Manual
Please Read Before Operating Unit
D9 Twin Wheel Offset Stripper
Models D1, DV1, D9 Wire Strippers & Braid Combers
Eraser International Ltd.
Service and All Spare Parts Available
The Eraser Company, Inc.
Unit M, Hunting Gate
PO Box 4961/ Oliva Drive
Andover SP10 3SJ, England
Syracuse, NY 13221, USA
Phone: (01264) 351347 / Fax: (01264) 355030
Phone: (315) 454-3237 / Fax: (315) 454-3090
Website: www.eraser-international.com
Website: www.eraser.com
Email: sales@eraser-international.com
E-mail: info@eraser.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Eraser D1

  • Page 1 Always Moving Forward Operating Manual Please Read Before Operating Unit D9 Twin Wheel Offset Stripper Models D1, DV1, D9 Wire Strippers & Braid Combers Eraser International Ltd. Service and All Spare Parts Available The Eraser Company, Inc. Unit M, Hunting Gate...
  • Page 2: Specifications

    1” (25.4mm) Minimum......35 AWG (0.14mmø) Strip length: D1, DV1, with mini stop...3/8” - 1-3/4” (9.5-44mm) D1, DV1, with regular stop..5/8” - 2-1/2” (16 - 63mm) D9...............Unlimited D1 Twin Wheel Stripper Decibel rating........72 dB(A) all units Power....1/4 HP, 115V, 60Hz or 220/240V, 50Hz...
  • Page 3: Operation

    On the D1, insulation dust will gather in the trash box and inserted between the wheels. Then release all tension by should be cleaned out periodically.
  • Page 4: Troubleshooting

    No other regular maintenance is misuse, negligence, or accident; or which required. has been repaired or altered by anyone other than Eraser, or which has been used TROUBLESHOOTING: in a manner or for a purpose for which the product was not designed.
  • Page 5 Wire Stripping Operation Insert wires to be stripped between wheels Withdraw - wires are stripped Wheel Dressing Operation Dressing Fybrglass Wheels Increases Their Useful Life Stripping Wheel Selection Many factors affect wheel grade selection. The chart is for guidance only. The last digit of Grade Number before /5 indicates diameter ( in thousands of an inch (0.025mm) of the steel wire from which the brush is made.
  • Page 6 General Wheel Guide...
  • Page 7 Wheel Selection Chart...
  • Page 8 The Eraser Company, Inc. Eraser International Ltd. PO Box 4961/ Oliva Drive Unit M, Hunting Gate Syracuse, NY 13221, USA Andover SP10 3SJ, England Phone: (315) 454-3237 / Fax: (315) 454-3090 Phone: (01264) 351347 / Fax: (01264) 355030 Website: www.eraser.com Website: www.eraser-international.com...
