Summary of Contents for EXTER T40
Page 1
EXTER™ T40/T40m Installation manual English MAEN812C, 2008-05...
Page 2
Installation manual for the EXTER series operator panels Foreword The EXTER operator panel is developed to satisfy the demands of human- machine communication. Built-in functions such as displaying and controlling text, dynamic indication, time channels, alarm and recipe handling are included.
Safety Precautions Safety Precautions Both the installer and the owner and/or operator of the operator panel must read and understand this installation manual. 1.1 UL and cUL Installation – This equipment is suitable for use in Class I, Division 2, Groups A, B, C and D OR non-hazardous locations only.
Safety Precautions 1.2 General – Read the safety precautions carefully. – Check the delivery for transportation damage. If damage is found, notify the supplier as soon as possible. – Do not use the operator panel in an environment with high explosive hazards. –...
Safety Precautions 1.4 During Use – Keep the operator panel clean. – Emergency stop and other safety functions may not be controlled from the operator panel. – Do not use too much force or sharp objects when touching the keys, touch screen etc.
Installation Installation 2.1 Space Requirements – Installation plate thickness: 1.5 - 7.2 mm (0.06 - 0.28 inch) – Space requirements when installing the operator panel: 100 mm (4.0 inch) 119 mm (4.69 inch) 100 mm (4.0 inch) 50 mm 50 mm (2.0 inch) (2.0 inch) 100 mm...
Page 10
Installation 3. Secure the operator panel in position, using all the fastening holes and the provided brackets and screws: 0.5 - 1.0 Nm 4. Connect the cables in the specified order. Caution Ensure that the operator panel and the controller system have the same electrical grounding (reference voltage level), otherwise errors in communication may occur.
Installation 2.2.1 Mode Switches All mode switches must be in OFF position during operator panel use. The mode switches should not be touched unless by qualified personell. 2.2.2 Connections to the Controller For information about the cables to be used when connecting the operator panel to the controller, please refer to the help file for the driver in question.
Technical Data Technical Data Parameter EXTER T40 EXTER T40m Front panel, 155.8 x 119 x 6 mm W x H x D Mounting 57 mm (157 mm including clearance) depth Front panel IP 66 seal Rear panel IP 20 seal Touch Touch screen: Polyester on glass, 1 million finger touch operations.
Page 14
Technical Data Parameter EXTER T40 EXTER T40m Relative 5 - 85 % non-condensed humidity CE approvals Noise tested according to EN61000-6-3 emission and EN61000-6-2 immunity. UL, cUL UL 1604 Class I, Div 2 / UL 508 / UL 50 4x indoor use only...
Chemical Resistance Chemical Resistance 4.1 Metal Casing The frame and casing material is powder-coated aluminum. This powder paint withstands exposure to the following chemicals without visible change: Acetic acid 10% Phosphoric acid 4% Citric acid 10% Phosphoric acid 10% Diesel Sea water Distilled water Sodium chloride 2%...
Additional Installation Tips Additional Installation Tips When experiencing communication problems in for example noisy environments or when operating close to temperature limits, the following recommendations are to be noticed. 6.1 Grounding the Operator Panel Door Mounting plate in the cabinet Operator panel Power supply 24 V DC...
Additional Installation Tips 6.2 Ethernet Connection in the Panel Industrial Ethernet RJ45 RJ45 RJ45 RJ45 Operator panel RJ45 Operator panel RJ45 Short and Operator panel unshielded Shielded RJ45 Operator panel RJ45 0.1 uF 250 V 5351 1. In some industrial units for Ethernet, the RJ45 contact’s shield is connected to the chassis via a capacitor.
Additional Installation Tips 6.3 To Achieve Better EMC Protection – Initially, use the original cabling from Beijer Electronics primarily. – Use shielded cables for RS232 communication. – Use twisted pair and shielded cabling for RS422 and RS485. – Use the cabling intended for the bus type; Ethernet, Profibus, CC-Link, CAN, Device Net etc.
Additional Installation Tips 6.4 Ambient Temperature The maximum ambient temperature for the operator panel is provided in the specifications. The ambient temperature refers to the temperature in the device cabinet which cools the panel’s electronics. ° inside Operator Power panel Power Axial fan 120x120 mm...
Additional Installation Tips 6.5 Safety Most of the operator panels are fed with 24 V DC. Power supply 230 V AC to 24 V DC Operator panel +24 V Power supply 230 V AC to 24 V DC Operator panel +24 V Distance? Power supply...
Page 24
Additional Installation Tips 6.6 Galvanic Isolation Internal electronic Ethernet DC/DC Filter galvanic isolation DC/AC +24 V DC 0 V (GND) 1.5 m 5356 RS422/485 RS232 The operator panel has galvanic isolation against the 24 V DC feed but no galvanic isolation between the communication ports for RS232, RS422/485 and USB.
Additional Installation Tips 6.7 Cable and Bus Termination RS485 – Use shielded and twisted pair cable. The pair capacitance may not exceed 52.5 pF/m and area at least 0.25 mm (AWG 24), if you want to use the maximum transfer distance and maximum transfer speed.
Page 27
HEAD OFFICE SUBSIDIARIES SWEDEN GERMANY Beijer Electronics Products AB Elektronik-Systeme Lauer GmbH & Co. KG Beijer Electronics Inc. Box 426 Kelterstraße 59 939 N. Plum Grove Road, Suite F SE-201 24 Malmö, Sweden 72669 Unterensingen, GERMANY Schaumburg, IL 601 73, USA Tel: +46 40 35 86 00 Tel: +49 7022 9660 0 Tel: +1 847 619 6068...
