- Page 1 guitar amplification proudly made in the usa neolight 10/12 full range speakers user manual models covered: , fr W W W . M A T R I X AM P L I F I C A T I O N . C O M...
-
Page 2: Table Of Contents
Thank You 3. Layout: Congratulations on the purchase of your new 3.1 Front Panel. Matrix Elements Full Range speaker. 3.2 Rear Panel. Matrix amplifiers and speakers are the result of many decades of experience in the design of 4. Before You Start . - Page 3 CAUTION: OPERATING ENVIRONMENT: OBSERVE ALL SAFETY AND This amplified speaker is designed for use in environments USAGE INSTRUCTIONS TO AVOID which protect it from rain, unusually high air humidity and POSSIBLE DAMAGE TO temperature. EQUIPMENT AND EXPOSURE TO Place on a surface where it cannot be easily dislodged, HAZARDS.
-
Page 4: Layout
FRONT AND REAR PANEL LAYOUTS: FR10 & FR12 MODELS The rear panels on FR10 and FR12 are the same whilst the front share similar features. (1) IEC Power socket: Mains power is supplied to the amplifier by a standard 10 Amp IEC mains socket. - Page 5 (6) DSP Function Indicator This light will operate briefly when the DSP select button is pressed, to provide an indication of which fuction the DSP (Digital Signal Processing) is providing within the amp module and will then turn solid. Bear in mind that throughout all functions the active crossover integrity is still held.
-
Page 6: Getting Started, Powering
GETTING STARTED, POWERING UP & CONNECTIONS: Your FR Series speaker comes equipped with a power lead specific for the requirements of your country. Use only the correct lead with the correct rated fuse for your country’s power requirements. Use of an incorrect lead or fuse rating could lead to damage of the amplifier and speaker. -
Page 7: Set-Up Examples
SOME TYPICAL SET-UP EXAMPLES: Modelling System To One* FR Cab Mono Main Mono/L Out to Input on FR Amp Link output from FR amp module Module can be used to send signal on to mixing desk, In ear monitors etc. In the case of sending to another powered speaker this would give two FR cabs running a mono signal... - Page 8 Wet/Dry/Wet Rig Hybrid FR/Traditional FX Send or Line Out from Amp to Stereo L&R Out Input of Effects Unit from FX to Inputs Main Speaker Out from Amp to on FR Amp Dry Cab (no effects) Modules. NB: Make sure cab sims are enabled! NOTE: The above system can give a “best of both worlds”...
-
Page 9: International Voltage
INTERNATIONAL VOLTAGE SELECTION Your Matrix amplifier should be set at the voltage for your specific country if selected correctly at the time of ordering. It is possible however to select alternative region voltages internally via an on-board switch. This allows for selection of 230v or 110v modes respectively at +/- 15%. This is approximately 200 to 265v or 95 to 125v. -
Page 10: Troubleshooting
TROUBLESHOOTING: (1) THE POWER LIGHT DOES NOT ILLUMINATE • Check that the mains supply is turned on. • Check that the mains switch is turned on. • Check mains lead for damage & check fuse. Replace lead if damaged, replace fuse if blown. •... -
Page 11: Troubleshooting
(5) OUTPUT IS TOO BASSY OR TOO THIN • Check the correct DSP setting is selected as at higher volumes the effects can be enhanced. • Check that patches have been “tweaked” at gig or rehearsal volumes. This could be a result of the “Fletcher-Munson Effect” or equal loudness curve to give it it’s new name. -
Page 12: Warranty
FULL 2 YEAR WARRANTY: Summary Matrix Elements warrants this FR series active speaker for a period of 2 years from date of purchase to be free of defects in materials and workmanship under normal conditions and usage. This warranty is transferable but original proof of purchase date is needed if any claim is to be made on the warranty. - Page 13 CONTACT US: Matrix is a company that prides itself on customer feedback and interaction. We like to hear from our customers with any suggestions they have to help us continually improve our service. You are very welcome to share your experience with us by contacting: support@matrixamplification.com Alternatively you can call us.
- Page 14 TECHNICAL SPECIFICATIONS: GT800 GT1600 Number of Channels: Watts Output Supply Voltage: 230V +/- 15% Internally Selectable Alternative 110V +/- 15% Voltage: Average Supply Current, Full Load: 5A (10A @ 110v) Mains Connector: 10A IEC Frequency Response (Speaker): 50–20,000 Hz +/- 2db Signal to Noise Ratio 96 dB (ref.
-
Page 15: Ce Declaration
Issuers Name and Address: Andrew Hunt MATRIX AMPLIFICATION LIMITED 32 Dewsland Park Road, Newport, South Wales. United Kingdom. NP20 4EF Products: Matrix Elements FR10 NL, FR12 NL Equipment Type: Commercial Audio Powered Speaker Safety Standard: AMD1: 2005 and IEC 60065: 2001 7th Ed. EMC Standards: EN 61000-4-2:2001 EN 61000-...
