Coitech V-3299 User Manual

Charger
Art.no 18-5106
18-5107
36-5106
36-5107
Please read the entire instruction manual before use and save it for future reference. We reserve the right for any errors in text or images and for
making any necessary technical changes to this document. If you should have any questions concerning technical problems please contact our
Customer Services.

Battery Charger with USB

• Easy and convenient. Charges 2–4 HR03/HR6 Ni-MH batteries.
• The charger is equipped with a 5 V DC 500 mA USB outlet.
• Microprocessor controlled charging.
• Charging time: Two to four hours.
• Comes with eco-friendly NiMH batteries.
36-3313 4 × HR6
36-3314 4 × HR03
• 2 LED charge indicators:
RED lit Quick charging
RED flashing Wrong battery type or bad contact
RED unlit Charging complete
GREEN lit USB outlet ready for use
• Safety functions:
Negative delta-V cut off
Timer
Short-circuit protection
Polarity protection

Warning

1. Read the entire instruction manual before using the charger.
2. The charger is only designed for charging Ni-MH batteries, size
HR03 or HR6. Attempts to charge other types of batteries can
lead to personal injury or damage the charger. The batteries can
leak or explode if incorrectly inserted, thrown in a fire, mixed with
other types of batteries or short circuited.
3. Do not expose the charger to rain or moisture.
The product is only intended for indoor use.
4. Unplug the adaptor from the power point when
the charger is not in use.
5. Do not use an extension lead or other accessory besides
the ones included with the charger. Doing so can lead to
an electrical fire or personal injury.
6. Do not use the equipment if damaged. Allow a qualified
repairman to perform any necessary repairs.
7. Use only the included adaptor. Do not disassemble or
modify the product in any way.
8. Remove the adaptor from the mains before and
cleaning of the charger of adaptor.
9. The charger is not a toy. Do not allow small
children near the charger without supervision.

Charging

Note: The rechargeable batteries are not pre-charged. They must be
charged first before using them for the first time.
1. Insert 2 or 4 Ni-MH batteries; size HR6/HR03 in the battery slots.
The batteries must be charged in pairs. When charging 2 batteries,
they must both be charged either in the right or left section
(Fig. 1 and Fig. 2).
Fig. 1
GREAT BRITAIN • CUSTOMER SERVICE contact number: 0845 300 9799
e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.com/uk
Model V-3299-UK
V-3299-UK
V-3299
V-3299
Fig. 2
2. Insert the batteries according to the (+ and -) markings
in the battery compartment.
3. Charge only one battery size at a time. Don't mix
HR6 and HR03 batteries.
4. Connect the charger to a power point (100–240 V AC). The built-in
power supply will adjust automatically. The red LED light is lit when
charging is in progress.
5. The LED turns off when the batteries are fully charged and ready
to use.
6. Remove the charged batteries from the charger and remove
the charger from the outlet. Never let charged or even remain in
the charger when it is unplugged or for extended periods of time.

Battery status

The charger automatically senses the battery status
when charging commences.
• If any of the batteries is unchargeable, short circuited,
or are mispositioned in the battery compartment, the LED
will flash rapidly.
• Remove the defective battery and dispose of it. Refer to Disposal.

Charging time

Note: The charging time can vary depending on the capacity and
condition of the battery.
Battery size Capacity
1800–2000 mAh
HR6 2100–2300 mAh
2500–2800 mAh
700–800 mAh
HR03
900–1100 mAh

USB outlet

• Charging of the batteries in the battery compartment is stopped
when the USB outlet is used.
• The green LED lights when the USB outlet is ready for use.
• The connected USB devices power consumption cannot
exceed 500 mA.

Disposal

Follow local ordinances when disposing of this product. If you are
unsure please contact your municipality.

Specifications

Power Supply 100–240 V AC, 50/60 Hz
Secondary outlet HR6: 2 × 2.8 V DC, 600 mA, 3.36 VA
HR03: 2 × 2.8 V DC, 350 mA, 1.96 VA
USB outlet 5 V DC 500 mA
Charging time
3–3,5 hours
3,5–4 hours
4,5–5 hours
2–2,5 hours
3–3,5 hours
