- Page 1 TECHNICAL MANUAL WATER PURIFIER RO400C RO400C : RO400CI020 : - With 20L storage tank RO400CC060 : - With 60L storage tank RO400CC075 : - With 75L storage tank RO400CC120 : - With 120L storage tank RO400CC150 : - With 150L storage tank...
-
Page 2: Table Of Contents
Contents GENERAL VIEW OF THE APPLIANCE....ERRORE. IL SEGNALIBRO NON È DEFINITO. TECHNICAL DATA ............. ERRORE. IL SEGNALIBRO NON È DEFINITO. THANKS ................. ERRORE. IL SEGNALIBRO NON È DEFINITO. TECHNICAL IMPOSSIBILITIES......ERRORE. IL SEGNALIBRO NON È DEFINITO. APPLICATION LIMITS IN GLASS WASHINGERRORE. IL SEGNALIBRO NON È DEFINITO. UNPACKING.............. - Page 3 11. Machine flexible feed hose 6. 1/4 turn valve * Only when the water purifier RO400C is used with a storage tank (optional). The storage tank in the picture is a 20L stainless steel tank. It’s available also 60L, 75L, 120L and 150L (coupled).
- Page 4 Technical data Size Height 466 mm Depht 460 mm Width 225 mm Weight 29 kg when supplied 33kg when filled with water Capacity (water temp. 15°C) 3,1 (+0,4) litres/minute Total water consumption the double of produced water Electrical supply 230V, 50Hz, 10A, earthed socket Total power consumption 530 W Max.
- Page 5 Thanks Lamber thanks you for the confidence you have shown by buying one of its products. Your water purifier is conceived to have a long life. You will find into this manual all necessary information concerning installation, start, functioning, maintenance and repair of the appliance.
-
Page 6: Unpacking
1. Unpack the water purifier - open the box - recover the accessories box - lift out the RO400C by taking it hold from the hand-grip. 2. Open the accessories box and check the equipment - the technical manual you are reading... -
Page 7: Connection
Connection 1. remove the 3 red plugs ATTENTION : for the purified water outlet, keep the grey ring pressed while you remove the red plug. 2. Screw and tighten by hand the cold water inlet flexible hose 3. Place the drain hose by using the clamp 4. -
Page 8: Storage Tank Connection
Ø They allow the RO400C to function on longer and less frequent cycles, so to have a water and energy economy, a longer life of the parts that wear down and a better quality water. - Page 9 (about 30 sec.). FLUSHING The flushing operation should be carried out in the following cases: • the first time RO400C is used ; • put back on working after storage ; • after a descaling ; • after replacing the membrane;...
-
Page 10: Installation / Calibration
At the opening of the ¼ turn valve, the storage tank fills itself till a • pressure of 4,5 Bar. On duty, RO400C starts functioning when the pressure in the storage tank • goes under 3 Bar. The end. The water purifier is ready to start working. -
Page 11: Maintenance
The grid ( a coarse filter) is conceived to intercept large particles; it’s located inside the union where you connect the RO400C’s feed water hose. If the LEDs on the control panel show that the intake pressure is too low, the reason may be that the grid is clogged. -
Page 12: Replacing The Filters
Replacing the filters Replace the filters when the water purifier requires it (see diagnostic section) and at least once every 6 months. 1. Disconnect the electrical plug. 2. Pull the filters containers support outwards as far as they will come. 3. -
Page 13: Descaling
Descaling In time, the substances which RO400C removes from the water tend to clog the membrane and so to reduce the flow of pure water. Frequency of descaling prolong the life of the membrane, it has to be descaled (preventive... - Page 14 7. Screw the container (filled with the descaling solution) into place with the aid of the filters spanner. 8. Open the tap for purified water and let RO400C operate for 45 seconds. 9. While the tap is still open, disconnect the electrical plug. Then close the tap. Don’t touch the water purifier for 10 hours ( for example during the night).
-
Page 15: Preparing The Water Purifier To Storage And Protecting It Against Freezing
(picture C). 7. Connect the electrical plug again. RO400C will now automatically pump the mixture inside the appliance. Let the water purifier suck for 40 seconds, then disconnect the electrical plug. Repeat twice this step. -
Page 16: Trouble-Shooting Table
Trouble shooting table light off light on light flashing Symptoms Possible cause Action to take Waiting for 1 restart (3 min) LED of Filter 1: short flash / LED stop : long flash Automatic restart Waiting for 2° restart (20 min) After 3 attempts of automatic restart Flash of Filter 1 LED = LED Flash stop (3 min., 20 min., 4 hours), if the... - Page 17 Leakage (even very little) between • Check all connections. own (briefly, with RO400C and the hoses. closed tap) If the temperature is higher than The flow of water • Check the water temperature, that should be 30°C, the rate of flow will increase to...
-
Page 18: Control Functions
Control functions The water purifier is equipped with some control functions to facilitate the diagnostic in case of trouble. Displaying of the functioning times Close the tap for purified water – Press for 3 sec. “Calibration” – Release for 1 sec. – Press again “Calibration” for 1 sec. The water purifier cannot show a number of functioning hours lower than 10 hours... -
Page 19: Technical Information
Technical information Situation of the main parts See the exploded view for more details Membrane High pressure pump Pressure regulator Inlet solenoid valve Drain solenoid valve (flush) Purified water outlet Outlet pressure switch Pressure switch for purified water Conductivity meter 10. - Page 20 Technical information (continuation) Top and cover disassembling: Unscrew the 2 screws in the upper and back side of RO400C Lift and pull the top. Unscrew the 2 screws in the upper part of the filter compartment Unscrew the 2 screws in the upper and back side of the cover Remove the cover.
-
Page 21: Pressure Switches Re-Initialisation
¼ turn valve. ¼ turn valve . • Press « Calibration » button and keep it pressed. • Connect again Ro400C to the electrical supply, “Calibration” button is always kept pressed. • Keep pressed « Calibration » button till when the red light «... -
Page 22: Wiring Diagram
Wiring diagram Manuel Technique OsmsoeurRO400C Version 3 Page 22 / 26... -
Page 23: Exploded View - Spare Parts
Exploded view – Spare parts Manuel Technique OsmsoeurRO400C Version 3 Page 23 / 26... - Page 24 Exploded view – Spare parts (continuation) Position Description Article n° Support Cushion Driving belt CPRO400C Dust protection Driving pulley for motor Support for motor Driving pulley for pump Insulation ring Protection for pump Circlips Bracket Drain solenoid valve (flush) EVVRO400C Pressure switch PRRO400C Valve for pressure regulation...
- Page 25 Exploded view – Spare parts (continuation) Position Description Article n° Body Handle Cable clamp (Stuffing box) Protection for power cord Power cord CSRO400C Sealing ring for top JCSRO400C Lead-through Control panel FPRO400C Anti-trouble filter Slide bar Filters cover PARO400C Base Plate Float Float housing...
-
Page 26: Declaration Of Conformity
Nous déclarons sous notre seule responsabilité que les produits suivants : We declare, under own responsibility that the followings products : OSMOSEUR SERIE RO400C WATER PURIFIER REVERSE OSMOSIS SERIE RO400C Est conforme aux dispositions de la directive suivante : - 73/23/CEE et 93/68 "Basse Tension"...
