User Manual

ODM-300
CONTENTS
2,
Foreword, Safety, Mains Connection, Enclosed Parts.
3,
Front/Back Panel Description.
4,
Remote Control Handset Description & Functions.
5,
Connector Pin Out Details.
6,
Connection Diagram.
7,
Installation Connect Up Details.
8,
LNB Setup.
9,
Automatic Channel & Network Search.
10,
Manual Channel Input & Edit.
11/12,
Menu Flow Chart.
13,
Edit Name, Line Up, Parental Control & Time.
14,
Receiver Settings.
15,
Technical Specification.
Digital "Free To Air" Receiver
ODM-300
FOREWORD
We congratulate you on your choice of digital satellite tv receiver. The ODM300 is
manufactured in Scotland, UK by RSD Communications Ltd. to very high standards
and is continually upgraded with new software. Please consult your dealer or the
RSD WWW site at http://www.rsd-communications.co.uk for the latest details.
SAFETY INSTRUCTIONS
Place your satellite receiver on a protected, dry and well ventilated spot. Never put
anything on top of the satellite receiver as this prevents the necessary ventilation.
The satellite receiver contains sensitive, hazardous parts and should therefore be
placed away from childrens reach and so that it cannot fall down. Clean the exterior
of your satellite receiver with a dry and soft cloth. Never let any form of liquid
come into contact with the receiver as this can damge the components and destroy
the receiver. Never use abrasive materials to clean the receiver as this will damage
the receiver finish.
WARNING !!!
Never remove the receiver cover - risk of electric shock!.
MAINS LEAD CONNECTION
The satellite receiver should be connected directly to the mains outlet socket. The
use of a mains extension lead is not recommended.
ENCLOSED PARTS
The following parts are enclosed:
ODM300 satellite receiver.
Remote control handset.
Two LR3 (AAA) batteries.
Coaxial cable (UHF connection).
User manual.
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ODM-300 and is the answer not in the manual?

Questions and answers

Summary of Contents for RSD ODM-300

  • Page 1: User Manual

    ODM-300 We congratulate you on your choice of digital satellite tv receiver. The ODM300 is manufactured in Scotland, UK by RSD Communications Ltd. to very high standards and is continually upgraded with new software. Please consult your dealer or the RSD WWW site at http://www.rsd-communications.co.uk for the latest details.
  • Page 2: Remote Control

    USER MANUAL ODM-300 USER MANUAL ODM-300 Descriptions Remote Control ODM300 RECEIVER FRONT VIEW Stand-by (on/off). Digital Turns the sound off and on. Select channel, teletext page numbers and 0–9 MENU settings. Change audio soundtrack. AUDIO Direct Program Access, Displays TV programme list in TV mode &...
  • Page 3: Connector Details

    USER MANUAL ODM-300 USER MANUAL ODM-300 Connector Details Connection Connecting the ODM300 to TV, VCR, dish, TV antenna, & P .C. TV Scart Connector: VCR Scart Connector: 1. Right audio out. 1. Right audio out. 3. Left audio out. 2. Right audio in.
  • Page 4: Installation

    USER MANUAL ODM-300 USER MANUAL ODM-300 Installation LNB Setup CONNECT UP The local oscillator settings (LO) for the LNB's connected to the ODM300 must be Before connecting up the ODM300 it is essential that your satellite dish is installed set before channel search can be carried out. Many LNB's have 2 LO which are as per the manufacturers recommendations.
  • Page 5: Automatic Channel Search

    USER MANUAL ODM-300 USER MANUAL ODM-300 Automatic Search Manual Input & Edit AUTOMATIC CHANNEL SEARCH Some channels may require manual entry either because they do not transmit the Select MENU with the MENU key on the remote control. Select 4 (Installation).
  • Page 6: Menu Flow Chart

    USER MANUAL ODM-300 USER MANUAL ODM-300 Menu Flow Chart Menu Flow Chart cont. PARENTAL CONTROL MAIN MENU CHANGE PIN SAVING - - - - No Parental Block Parental Control New PIN - - - - Block 12 Information Confirm New Pin...
  • Page 7: Receiver Settings

    USER MANUAL ODM-300 USER MANUAL ODM-300 Editing Name, Line Up etc. Receiver Settings EDITING CHANNEL NAME RECEIVER SETTINGS Message Cause Action Choose the required channel. Select MENU. Select 4 (Installation). Select 4 Select MENU. Select 4 (Installation). Select 2 (Receiver Setup).
  • Page 8: Technical Specification

    SCART (video, L/R audio & RGB out) SCART (video, L/R audio out & A company with vision since video/RGB/audio loop through) our launch in 1987, RSD to- Modulator PAL I, channel 30-45, 77dBuV typical day is a leading force in the Antenna F type, 14/18V (400mA max.)&...
