Summary of Contents for Thorne & Derrick THR880i Ex
- Page 1 THR880i Ex Safety Instructions...
- Page 3 02.02/EN PS10952BENAB01 This document is the property of EADS Secure Networks Oy and should not be copied or circulated without permission.
-
Page 4: Table Of Contents
Table of Contents 1 Application..................3 2 Safety information ................3 3 Safety regulations................3 4 Battery cover protection ..............5 To unscrew the battery cover ............. 5 To install the safety plug ............6 5 Faults and damage................6 6 Ex-data .................. -
Page 5: Application
1 APPLICATION The THR880i Ex is a digital radio unit based on the TETRA standard for industrial application in areas with an increased risk of explosion in zones 1 and 2, in accordance with directive 1999/92/EC (ATEX 137). 2 SAFETY INFORMATION... - Page 6 a) Opening of the battery cover is prevented with a locking screw (for the specific instructions, see chapter 4 Battery cover protection, figures 1 and 2) b) Opening of the battery cover is prevented with a specific ATEX Safety bag THR-LT1 c) Opening of the battery cover is prevented with an ATEX Safety plug (for the specific instructions, see chapter 4 Battery cover protection, figures 3 and 4)
-
Page 7: Battery Cover Protection
4 BATTERY COVER PROTECTION 4.1 To unscrew the battery cover Figure 1 1) Unscrew the screw (1) at the bottom of the terminal by using the tool in the sales package. Figure 2 2) When the head of the screw is completely out of its seating, push the battery door to open it. -
Page 8: To Install The Safety Plug
4.2 To install the safety plug Figure 3 1) Make sure that the hatches (1) on both sides of the safety plug are out and the slot is in the horizontal position (2). 2) Insert the safety plug Figure 4 3) Lock the safety plug in place by turning the slot (e.g.with a coin) to the... -
Page 9: Ex-Data
It is necessary to make sure that the radio is not restarted, not even accidentally. We recommend that the unit is returned to ecom instruments GmbH for inspection. The safety of the unit may be compromised, if, for example: - there is visible damage to the housing - the unit has been subjected to excessive loads - the unit has been improperly stored - the unit has been damaged in transit... -
Page 10: Cleaning, Maintenance And Storage
8 CLEANING, MAINTENANCE AND STORAGE - Only use a damp and suitable cloth or sponge to clean the radio unit or the CRR-1 active holder. Do not use any solvents or abrasive cleaning agents when cleaning. - It is recommended that you have the functionality and accuracy of the unit inspected by ecom instruments GmbH every two years. -
Page 11: Ec-Type Examination Certificate
9 EC-TYPE EXAMINATION CERTIFICATE Here is the original Ex certificate in German language. It is granted to ecom instruments GmbH by Prüf- und Zertifizierungsstelle ZELM Ex in Braunschweig in Germany on 23.8.2007. This document is the property of EADS Secure Networks Oy and should not be copied or circulated without permission. - Page 12 This document is the property of EADS Secure Networks Oy and should not be copied or circulated without permission.
- Page 13 Devices and shielding systems intended for regulated use in explosive areas - Directive 94/9/EC EC-Type Examination Certificate number ZELM 07 ATEX 0347 X Device: Digital trunked radio type THR880i Ex Manufacturer: ecom Instruments GmbH (6) Address: D-97959 Assamstadt The construction of this device and the various permissible details are specified in the appendix to this Type Examination Certificate.
- Page 14 EC-Type Examination Certificate ZELM 07 ATEX 0347 X (15) Description of the device The explosion-shielded digital hand-held radio THR880i Ex serves the purpose of providing communication in explosive areas. The device is available in various models, which fundamentally deal with different frequency ranges.
- Page 15 This document is the property of EADS Secure Networks Oy and should not be copied or circulated without permission.
- Page 16 CASSIDIAN is a registered trademark of EADS Defence and Security Systems. Copyright © 2012 CASSIDIAN. All rights reserved. PS10952BENAB01...
