Gallagher W810 v2 User Manual
Gallagher W810 v2 User Manual

Gallagher W810 v2 User Manual

Weigh scale and data recorder
Table of Contents

Advertisement

WEIGH SCALE AND DATA
RECORDER
W810 v2
Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W810 v2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Gallagher W810 v2

  • Page 1 WEIGH SCALE AND DATA RECORDER W810 v2 Instructions...
  • Page 2   PUBLISHED BY  Gallagher Group Limited  Kahikatea Drive, Private Bag 3026  Hamilton, New Zealand  www.gallagher.co  Copyright© Gallagher Group Limited 2010.  All rights reserved.    Patents Pending.  Weigh Scale and Data Recorder W810 v2 User Manual    3E2364 ‐ Edition 5 – September 2014                                              DISCLAIMER:     While every effort has been  made to ensure accuracy, neither Gallagher Group ...
  • Page 3: Table Of Contents

    3E2364 Weigh Scale W810 v2 User Manual      Table of Contents  Introduction  .........................  1   Care and maintenance ......................  2   First‐time use ..........................  2   Installation ..........................  3   Installing the Weigh Scale bracket ....................  3   Installing the loadbars  ........................  4   Installing the Weigh Scale ......................  4   Power and batteries ......................  5   The Weigh Scale's controls  ....................  8   Soft Keys  ............................  8   The mode select switch ...
  • Page 4   Zero tracking ..........................87  Memory full warning  ........................88  Printing  ............................89  Invalid Session EID's ........................89  Interfacing software: APS ....................  9 1   Loadbar and platform options ...................  9 2   Gallagher Standard Loadbars  .......................92  Gallagher Heavy Duty Loadbars ....................92  Gallagher Super Heavy Duty Loadbars  ..................93  Gallagher Heavy Duty Weigh Feet ....................93  Gallagher Suspension Load Cell 250 kg  ..................94  Gallagher Suspension Load Cell 500 kg  ..................94  Specifications  ........................  9 5   Weigh Scale W810 v2 Dimensions  ....................95 ...
  • Page 5: Introduction

    3E2364 Weigh Scale W810 v2 User Manual      INTRODUCTION  Thank you for purchasing the Gallagher Weigh Scale W810 v2.  Gallagher has been making agricultural weighing equipment for over 60 years.    In that time we have earned a reputation for the manufacture of quality  equipment that is simple, tough, innovative and reliable.  The Weigh Scale range of Weigh Scales is specifically designed to accurately  weigh live animals.    However the Gallagher range is also well suited to weighing  static loads and can be used for this purpose in industrial applications.  As well as weighing, Weigh Scale W810 v2 includes the following features;   You can type animal management information in plain text using the  QWERTY keyboard.   You can identify animals using Electronic IDs and/or Visual Tag  Numbers.   You can record a condition score or note for each animal, or up to eight  animal traits.   You can use graphs as an aid to analysing changes in animal weight over  time.   You can draft up to 9 ways either by weight or from a list.   You can view session statistics, analysed by draft group for the current  session.   You can view statistics for closed sessions.   You can store up to 10 Trait tables in the Weigh Scale and select the  required table when creating a new session.   You can edit the Visual Tag Number in the current session.  ...
  • Page 6: Care And Maintenance

        3E2364 Weigh Scale W810 v2 User Manual    CARE AND MAINTENANCE  The Weigh Scale W810 v2 is a tough and reliable product designed for use in  typical livestock environments. However, proper care and maintenance can  extend its life.    Listed below are guidelines for keeping the Weigh Scale in good condition:   Don't submerge the Weigh Scale in any liquid.     Store the Weigh Scale in a cool, dry place. Avoid storing it in direct sunlight     After use, clean the Weigh Scale with a damp cloth.    Take care not to  scratch the display.     Fit the connector caps to keep the connections clean and dry.    First‐time use  When you open the Weigh Scale the first time, you will find that the display  screen is covered with a transparent overlay.    The overlay is printed with the  number 630 and other characters.    Remove this overlay before starting to use the Weigh Scale.    The overlay is  easily removed after first grasping the tab.  Page 2   ...
  • Page 7: Installation

    3E2364 Weigh Scale W810 v2 User Manual      INSTALLATION  Installing the Weigh Scale bracket  The bracket can be mounted on a flat vertical surface, or on a round post.  To mount the bracket on a  flat vertical surface, for  example a square post or  board, use the outer holes.  To mount the bracket on a  round post, use the inner  holes.    Don't mount the Weigh Scale bracket on the weighing crate or chute.    Page 3   ...
  • Page 8: Installing The Loadbars

        3E2364 Weigh Scale W810 v2 User Manual    Installing the loadbars  To install the loadbars, follow these steps:  Note:    Fit the loadbars as per the manufacturer's instructions.  Bolt the platform to the loadbars.    Ensure the platform is placed on a flat and level surface. Make sure it is not  touching any rails or gates.    Either bolt the loadbars to the concrete pad or locate them on studs set into  the concrete. This will prevent the platform from moving during the  weighing session.    Connect the loadbar cables to the Weigh Scale.  Note:    If you are using non Gallagher, loadbars ensure the loadbars are correctly  calibrated.  Installing the Weigh Scale  The Weigh Scale can be placed on a table top or mounted on the Weigh Scale  bracket supplied.  Position the Weigh Scale:     clear of the platform to ensure it does not interfere with the flow of  animals during the weighing cycle   within easy reach of the loadbar leads   within easy reach of the operator (for manual weighing), and   in a well‐lit area  Page 4   ...
  • Page 9: Power And Batteries

    3E2364 Weigh Scale W810 v2 User Manual      POWER AND BATTERIES  During a weighing session, the Weigh Scale can be powered by its internal  battery alone or by its internal battery and either the battery charger or an  external 12 volt battery.    The battery charger connects between an AC outlet and the Weigh Scale.  If either the battery charger or an external 12 volt battery is connected to the  Weigh Scale, the Weigh Scale's internal battery will be charged while the Weigh  Scale is in use.    For optimum performance, switch off the Weigh Scale and charge its internal  battery overnight.    When fully charged, the internal battery on its own will  power the Weigh Scale continuously for a minimum of eight hours.    Battery life may be reduced if the Weigh Scale is being used to power an  Electronic ID reader.  Charging the battery  The battery in the Weigh Scale can be recharged using either a battery charger or  an external 12 volt battery.    Recharging the battery will take up to sixteen hours depending on the level of  charge already in the battery. The Weigh Scale can be in use or can be switched  off while the battery is being charged.  Using the battery charger  To charge the battery using the battery charger, follow these steps:    Connect the lead between the battery charger and the Weigh Scale.    Plug the battery charger into an AC outlet and switch on.    Open the Weigh Scale case and make sure the battery charge icon    on the main screen is flashing. This indicates that the battery is charging and  will be displayed whether the Weigh Scale is turned on or off.     ...
  • Page 10     3E2364 Weigh Scale W810 v2 User Manual    Using an external 12 volt battery  To charge the Weigh Scale's internal battery using an external 12 volt battery,  follow these steps:    Connect the supplied black and red battery leads to the Weigh Scale.    Connect the other end of the battery leads to the 12 volt battery.      Connect the Red clip to the Positive terminal.    Connect the Black clip to the Negative terminal.    Open the Weigh Scale case and make sure the battery charge icon    on the main screen is flashing. This indicates that the battery is charging and  will be displayed whether the Weigh Scale is turned on or off.    Battery charge status  The battery icon displays in the bottom left corner of the Weigh Scale's upper  screen.  It is important to note that the battery icon will only ever show the actual  amount of charge left in the battery when the Weigh Scale is turned on and  disconnected from external power.  Fully Charged  Battery Icon bars are all displayed constantly.  Partially  Battery Icon shows first four bars constantly.    Charged  Battery Flat  No Battery Icon bars are displayed.    When the Weigh Scale is connected to the external power supply the battery  icon will display the charging status.  Charging  Battery Icon shows all the bars constantly filling ...
  • Page 11 3E2364 Weigh Scale W810 v2 User Manual      Low voltage shutdown  When the battery charge drops to a critical level, the Weigh Scale will shut down.    At this stage it is necessary to recharge the battery.  Battery voltage warning  If the voltage supplied from the charger to the Weigh Scale is not within the  required range (10.5V ‐ 15V) or the battery temperature rises above 50° C the  Weigh Scale will beep and the battery charge icon will start to flash. It is  important that you remove the charger from the Weigh Scale immediately.  Battery conditioning  When the Weigh Scale detects the battery voltage is very low, it will perform a  battery conditioning charge process. This process will protect the battery by  limiting the amount of current that is used to recharge the battery cells. Due to  the current limitation, the charge cycle will take 16 hours to complete. By  performing a full conditioning charge, the life of the battery will be greatly  extended.  The Weigh Scale can be used while the battery conditioning is in progress. The  remaining charge time will be displayed on the lower screen when the Weigh  Scale is switched off.  Note:    If the charge cycle is interrupted, theWeigh Scale will attempt a conditioning  cycle the next time it is plugged into a charger.      Page 7   ...
  • Page 12: The Weigh Scale's Controls

        3E2364 Weigh Scale W810 v2 User Manual    THE WEIGH SCALE'S CONTROLS    Soft Keys  Five soft keys are arranged along the bottom of the lower screen.    The function  of these soft keys changes depending on what the lower screen displays.    For  any given screen, not all soft keys have a function.    Those that do are labelled in  the screen.     Buttons like      ,    and    allow  movement vertically up and down the screen.   Buttons like      and    allow movement horizontally  across the screen.   The function of other buttons is described elsewhere in this user manual.    Page 8   ...
  • Page 13: The Mode Select Switch

    3E2364 Weigh Scale W810 v2 User Manual      The mode select switch  The Weigh Scale can operate in three weighing modes and a setup mode.      The mode select switch is located on the left hand side of the Weigh Scale.    The mode select switch has five positions:    ,  ,  ,   and  .    Immediately  after you turn the switch to any position except  , explanatory information will  display on the lower of the two Weigh Scale screens.    The explanatory  information will display only for a few seconds; after it disappears, the screen  displays information relevant to the selected option.  This position turns the Weigh Scale off.    This position selects weighing in Automatic mode.    You can also store Electronic IDs and update the Weigh Scale's  cross‐reference table when there are no loadbars connected.  This position selects weighing in Manual mode.    You can also record animal information, without weighing, when there  are no loadbars connected.  This position selects weighing in Fine mode. It is designed for    static‐load weighing. .  This position accesses the setup options.     ...
  • Page 14: Setup

        3E2364 Weigh Scale W810 v2 User Manual    SETUP  To access the Setup menu, turn the mode select switch to  .  The setup menu displays on the lower of the two screens on the Weigh Scale. In  setup mode, the main screen normally displays the time in 24 hour format. Every  minute the main screen momentarily displays the date, then automatically  reverts to displaying the time again.    The setup menu contains six options:    DRAFT MENU ‐ select the drafting mode and specify the drafting limit(s).    SESSION MENU ‐ select a session and view, print or delete the session.    SET TIME AND DATE ‐ set the current time and date.  USER OPTIONS ‐ select weight units, turn Visual Tag Number checking on or  off, turn live printing on or off, turn ADG display on or off.      COMMUNICATIONS ‐ set up a connection to a computer, printer, Electronic  ID reader or other external device and enable drafting via the auto Drafter.  SELECT COUNTRY ‐ for a specific country, selects a language and  country‐specific terminology and weight unit.  Page 10   ...
  • Page 15: Selecting A Setup Option

    3E2364 Weigh Scale W810 v2 User Manual      Selecting a setup option  When you turn the mode select switch to  , one of the setup menu options is  displayed.      To select an option from the Setup menu:  Press the      or      soft key to display the required  menu option.    Press  .  Alternatively, using the keypad, you can press the number of the menu item that  you want to select.    For example:   to select the Session Menu, press  ,   to select Communications, press  .  To change the screen contrast:  The contrast on the screen may need to be made lighter or darker for ease of  viewing.  Press    once.  Follow the on‐screen instructions to alter the contrast.  Press    again to change the backlighting. See Backlighting (p 12)  for further details. ...
  • Page 16     3E2364 Weigh Scale W810 v2 User Manual    Backlighting  The default setting for this option is OFF. When backlighting is turned on, both  the upper and lower LCD screens are backlit for added visibility.  Using backlighting:  From a Setup menu option, press    twice.  Press      repeatedly to scroll through the list until you find the  backlight option you require.  Press    again to return to the Setup menu.  The options for backlighting are as follows:  Options  Description  Backlighting is switched off.  The backlighting will automatically turn off  after 30 seconds of inactivity. The backlight  will switch back on in the event of further  activity.    The backlighting will automatically turn off  after 1 minute of inactivity. The backlight will  switch back on in the event of further activity.  The backlighting will automatically turn off  after 2 minutes of inactivity. The backlight will  switch back on in the event of further activity.  The backlighting will automatically turn off  after 5 minutes of inactivity. The backlight will  switch back on in the event of further activity.  If the backlight option is switched to Always  On, and the Weigh Scale is using an external  power supply, the back‐lighting will stay on  until; ...
  • Page 17 3E2364 Weigh Scale W810 v2 User Manual      Note: User activity is determined as:   User input on keyboard, pushbuttons or rotary dial   Any Electronic ID data received from RS232 or Bluetooth ports   A weight change greater than 5kg or 11lb.    Page 13   ...
  • Page 18: Draft Menu

        3E2364 Weigh Scale W810 v2 User Manual    Draft menu  The Draft menu lets you set:   the drafting mode,   the drafting limits,     the drafting gate number (if you have set up auto drafting), and   a drafting gate for when draft limits are turned off.  Drafting can be completed:   Manually  For manual drafting the Weigh Scale displays the appropriate drafting gate  to open.   Automatically  Using an autodrafter.  About drafters  A drafter uses the weight of the animal or a Draft list (requiring EID tags on  animals) on the Weigh Scale to determine which draft gate to open for the  animal.    For manual drafting the Weigh Scale displays the appropriate draft  gate.    For autodrafting the Scale sends the drafting gate number to the drafter  controller which opens the correct gate or gates.  Depending on the drafter used the Weigh Scale can control up to 9 drafting  gates.  Page 14   ...
  • Page 19 3E2364 Weigh Scale W810 v2 User Manual      Manual & Automatic drafting  To set up the Weigh Scale for manual or auto drafting, complete the following:  Manual Drafting: Ensure that no port is set for drafting.  For further details see Communications (p 28).  Automatic Drafting: Configure the connection between the Weigh Scale and  the Drafter.    For further details see Communications (p 28).  Set the required draft mode.  a) Turn the mode selection switch to  .  1. DRAFT/SORT MENU b) Select   and press the    soft key.  The current mode displays at the top of the screen.    c) Press the    soft key until the required drafting mode is  displayed.  The drafting mode cycles between Drafting Off and Drafting from 2‐way  up to 9‐way.    Set the required draft limits and gate number.  a) Press the    soft key to select the draft limit you wish to  change.  To change a gate number:  Note:      If no drafter is enabled in the Communications menu (Manual  drafting), then gate numbers are not displayed. ...
  • Page 20     3E2364 Weigh Scale W810 v2 User Manual     H Gates  sets the gate number for animals that weigh anything  igher  than the Draft Limit.   L Gates  sets the gate number for animals that weigh the Draft Limit or  anything  ower than the Draft Limit.   On the 3 WAY DRAFTING screen, gate numbers are shown against the H  Gates, C Gates and L Gates labels.   H Gates  sets the gate number for animals that weigh anything  igher  than the Upper Limit.   C Gates  sets the gate number for animals that weigh anything higher  than the Lower Limit and inclusive of the Upper Limit.   L Gates  sets the gate number for animals that weigh the Lower Limit or  anything  ower than the Lower Limit.   On the 4 WAY or more DRAFTING screen, gate numbers are shown as  numbers, with gate 1 as the lowest limit.  Page 16   ...
  • Page 21: Session Menu

    3E2364 Weigh Scale W810 v2 User Manual      Session menu  SESSION MENU The   lets you select and then view, print, rename or delete  sessions.    To display the Session Menu screen:  Turn the mode selection switch to  .  SESSION MENU Select  .  The following screen displays:      The currently selected session displays in the title bar of the screen.    You can use the      and    buttons to move between the  options.    Note:    Depending on the type of session (Standard, Trait or Draft list) currently selected  the soft keys displayed will change.  Selecting a session  To select a particular session, complete the following steps:  Turn the mode selection switch to  .  SESSION MENU Select  .  SESSION Press the ...
  • Page 22     3E2364 Weigh Scale W810 v2 User Manual    Renaming a session  You can rename any of the Standard or Trait    sessions stored on the Weigh  Scale from the Session menu.  To rename a session, complete the following steps:  Select the session, see Selecting a Session (p 17).  Press the    soft key.    The existing session name displays on the screen.    Press the      button to delete characters, as required.  Type in the new name, using the Weigh Scale keypad.    The session name can contain up to 17 characters.  Press    to save the new session name and return to the Session  menu.    The new session name is displayed in the title bar of the screen.  Page 18   ...
  • Page 23 3E2364 Weigh Scale W810 v2 User Manual      Editing session notes  You can edit the existing session note of the Standard, Draft list or Trait sessions  stored on the Scale from the Session menu.    If no session note was entered  when the session was created you cannot add one.  To edit a session note, complete the following steps:  Select the session, see Selecting a Session (p 17).    Press the      soft key.  Press the      soft key.    Note Note:    If the   soft key does not display, the session does not have a  session note.  Press the      button to delete the existing note, as required.  Type in the new note, using the keypad.  The session note can contain up to 13 characters.  Press      to save the new session name and note, and return to  the Session menu.    The new session name is displayed in the title bar of the screen.   ...
  • Page 24     3E2364 Weigh Scale W810 v2 User Manual    Viewing a session  To view the details of a session, complete the following steps:  Select the session, see Selecting a Session (p 17).  VIEW Press the      or    soft keys to highlight  .  Press the      soft key.  The details of the session display.    Press the      and    soft keys to scroll through the  details of the session.      In a Standard session, the details include the Visual Tag Number, weight,  condition score or any note entered for each record.    In a Trait session, the condition score is not available and the traits are  stored in the "Trait" column. In this view you cannot see the labels  associated with each trait field. You can only see a list of the data you  entered during the session.  Press      to return to the Session menu.    Note: ...
  • Page 25 3E2364 Weigh Scale W810 v2 User Manual      Displaying statistics for a closed session  To display the statistics of a closed session, complete the following steps:  Select the session, see Selecting a Session (p 17).    VIEW Press the      or    soft keys to highlight  .  Press the      soft key.  The details of the session display.    Press the      soft key.  Depending on the method of drafting (by weight or not) one of the following  screens displays:   Weight Stats   Draft Stats  For details on these stats screens see Statistics screen (p 40).    Page 21   ...
  • Page 26     3E2364 Weigh Scale W810 v2 User Manual    Printing a session  Make sure a serial printer is connected to the Weigh Scale. To configure the port  that the printer connects to on the Weigh Scale, see Communications (p 28) later  in this section.  Select the session, see Selecting a Session (p 17).    PRINT Press the    or    soft key to highlight  .  Press    to print the session details or press    to return  to the Session menu.  Press    to print the session on the attached printer.  Note:    If a printer is not installed the Weigh Scale displays "No Printer Available".    Deleting a session  Note:    Deleting a session removes it permanently from the Weigh Scale's memory.  Before deleting a session it is recommended that you copy weighing sessions to  your computer using the APS software supplied with the Weigh Scale.    Using  APS, you can restore the deleted session to the Weigh Scale, by copying it from  the computer at a later date. See Interfacing Software: APS for more  information. ...
  • Page 27: Set The Time And Date

    3E2364 Weigh Scale W810 v2 User Manual      Set the time and date  SET TIME AND DATE The   screen lets you set the current time and date on the  Weigh Scale's internal clock.    The system time and date is recorded each time you create a new weighing  session.    You can view the current system time on the Weigh Scale's main  screen when it is in Setup mode.  Note:    The date format changes depending on how the country options are set up, see  Select a country (p 33).    In New Zealand and Australia the date format used is  DD‐MM‐YYYY. In the USA the date and time format is MM‐DD‐YYYY.    In French  Canada the date format used is YYYY‐MM‐DD.  The time must be entered in 24‐hour format i.e.     8:35 pm would be 20:35   8:35 am would be 08:35.    To change the time or date, complete the following steps:  Turn the mode selection switch to  .  SET TIME AND DATE Select  .  The following screen displays.      Press the ...
  • Page 28: User Options

        3E2364 Weigh Scale W810 v2 User Manual    User options  This screen enables you to see the following user options:   Weighing Mode   EID required   Weight Units ‐ to use when weighing animals.     Live Printing   Tag Checking   Average daily weight gain (ADG)  Changing a user option  To change a user option, complete the following steps:  Turn the mode selection switch to  .  USER OPTIONS Select  .    Press the      or    soft keys to highlight the option  you want to change.  Press    to toggle between the available options.  Press    to save the changes and return to the Setup menu.   ...
  • Page 29 3E2364 Weigh Scale W810 v2 User Manual      Weighing Mode  Weighing Mode allows you to select the speed at which the scale will lock a  weight.      Max Accuracy mode will take longer to lock a weight but will calculate a weight  within ~99% of the animal's true weight.    This is well suited to weighing larger  animals such as cattle or deer, where the speed of weight lock is less critical.  The Max Speed (sheep only) mode has been specifically developed to increase  the throughput of sheep in an Auto drafter.    While less accurate at ~97% of the  animal's true weight, this mode is significantly faster and well suited to  applications where mob average weights are of interest, or where a high  throughput is required.    The    soft key allows you to specify when the animal data is recorded  in the scale. By default, this will occur once 30% of the animal's locked weight  has been removed from the load bars, however there are some applications  where this may need to be set higher (so that more weight must be removed) or  lower (so that less weight must be removed).      EID required  No  If you do not require an EID to be read by the Weigh Scale, the EID Required is  set to   (default setting). This option enables the configuration of a draft  override gate and a time delay, to which, an animal without an Electronic ID will  be drafted to, after the selected time delay has elapsed.   EID Required From the User Options screen, select  and press the   ...
  • Page 30     3E2364 Weigh Scale W810 v2 User Manual    scroll through gates 1‐9 and back to Others.      Delay Draft / Weight lock Use the arrow key to select   and press the  Change  soft key to select the time delay before an animal is drafted out.  The values available are 0, 2, 4, 8, 16 seconds.  Note: The value selected is the time allowed for an EID to be read before the  animal is drafted out to the override gate or locking a weight.  Press    to confirm the settings made.  Note:   These settings only have an effect when the scale is set up for weighing. i.e. the  loopback cable is plugged into the scale not the Autodrafter.  Yes   YES When EID Required is set to , and an animal doesn’t have a successful read  of an EID or it does not have an EID, then it is not released from the drafter.    The animal will need to be manually drafted out using the remote control or by  other means, depending on the drafter type, as the Scale will have no further  communication with the drafter for the current animal.  Note:   When drafting and weighing, the weight will not be locked until an Electronic ID  is received, no information for the animal will be recorded in the session file.      If you apply an Electronic ID tag to the animal, and scan that Electronic ID tag,  then the animal will be released, and information will be recorded in the session  file.    Weight units  You can specify whether the Weigh Scale uses kilograms (kg) or pounds (lb) for ...
  • Page 31 3E2364 Weigh Scale W810 v2 User Manual      Tag checking  Tag Checking  If  is on, the Weigh Scale checks for duplicate Visual Tag Numbers.  If a duplicate occurs within a weighing session, the Weigh Scale lets you edit  either the current Visual Tag Number or the one that occurred earlier in the  session.  A duplicate Visual Tag Number can occur for any of the following reasons:   The same Visual Tag Number is entered twice during a session.   A Visual Tag Number is entered using the keypad and an Electronic ID is  scanned that has the same Visual Tag Number assigned in the Weigh Scale's  cross‐reference table.   Two Electronic IDs are scanned and each has the same Visual Tag Number  assigned in the Weigh Scale's cross‐reference table.  Note:     The Weigh Scale checks for a duplicate Visual Tag Number, not a duplicate  Electronic ID. This means duplicate Electronic IDs can occur in a session, provided  that the Electronic ID does not have a Visual Tag Number linked to it in the  Weigh Scale's cross‐reference table.  See Checking for Duplicate Visual Tag Numbers (p 84) for instructions on editing  duplicate Visual Tag Numbers when they occur.    ADG Display  ADG Display With   turned on, the Weigh Scale calculates the average daily gain  (kg/day or lb/day) of the animal being weighed. It is calculated between the  animal's current weight and the most recent previous weight recorded for that  animal.  The default setting for this option is ON.  When ADG Display is turned OFF, the indicator does not display the ADG nor  recalculate it.    Note: ...
  • Page 32: Communications

        3E2364 Weigh Scale W810 v2 User Manual    Communications  The Communications menu enables you to tell the Weigh Scale what device is  connected to each port. The ports are located on the upper left hand edge of the  Weigh Scale.    Once you attach a device to a port, you must configure the port  to suit.      The W810 v2 has Bluetooth functionality that enables the Weigh Scale to receive  Electronic ID data from a Bluetooth equipped EID Reader.      To display the Communications menu, complete the following steps:  Turn the mode selection switch to  .  COMMUNICATIONS Select  .    A screen similar to the following displays:      Note:    Depending on the current settings ‐ different buttons may be displayed.  To connect a device by cable, refer to Setting up a port (p 29).  To connect an EID Reader by Bluetooth, refer to Setting up a Bluetooth port (p  31).    Page 28   ...
  • Page 33 Press    to save the Port settings.  Note:    When connecting to Port 2, an extra menu option, External Port  Power will be displayed. Select ON or OFF for this option which enables  voltage between Pin 5 (Ground) and Pin 9 (RI ‐ Ringing Indicator).  Press    to save settings and return to the Setup menu.    See the following table for the Port options available on the scale:    Device  Options  Description  Unused  The port is unused (this is the default  option).  Computer  Standard  Enables the connection of a computer.    Used to copy weighing sessions to or from  the computer.  ASCII  Used for third party applications.  EID Reader ‐  Standard  Enables the connection of a  Gallagher/Standard Electronic ID stick  reader with a set baud rate.    See Using  electronic tags (p 34).    Page 29   ...
  • Page 34     3E2364 Weigh Scale W810 v2 User Manual    Device  Options  Description  Destron  Enables the connection of a Destron  Electronic ID reader.  Drafter  Sheep Auto  Enables the connection of a Gallagher Sheep  Drafter  Auto Drafter.  H‐Dale / CWC  Select the type of Auto Drafter connected to  the scale.  Heenan    Prattley    Racewell    Custom  Allows the drafter protocol to be adapted  for custom applications.  Data‐Output  Printer  Enables the connection to a serial (ASCII)  printer.    Used to print weighing session  data either during or after the session.  Data Logger  Enables the connection of a data logger.  Used to log weight records during a  weighing session.  Press the CONFIG soft key to select the type  of information to be captured. ...
  • Page 35 3E2364 Weigh Scale W810 v2 User Manual      Setting up a Bluetooth port  The Weigh Scale W810 v2 has internal Bluetooth that allows communication  with a Bluetooth Electronic ID reader. Your Electronic ID reader will need to be  paired with the Weigh Scale.  Note:    The Bluetooth port must be configured to a device and not "Unused" before it  will be discoverable and able to be searched for by other devices.    To attach a Gallagher HR3 Reader to the Bluetooth port, complete the following  steps:  From the Communications menu, press the    button to select  Bluetooth the   port.  EID Reader ‐  Press      and    if required, to display  Standard .    Press the    soft key.  Press    to display the MAC address for the scale.      You will need to configure your HR3 reader with the Scale MAC address. This  is usually done with the Configurator software supplied with your Electronic ...
  • Page 36     3E2364 Weigh Scale W810 v2 User Manual    Autodrafter  The Weigh Scale can interface directly with autodrafters. There are six drafter  options for communicating with the connected port.  The Weigh Scale sends drafting commands to the autodrafter during the  weighing session.  To connect an autodrafter with the Weigh Scale, complete the following steps:  Turn on the Weigh Scale.  Ensure the autodrafter is turned off.  Connect the autodrafter to one of the ports on the Weigh Scale.  Set the port to the required option. See Communications (p 28) for more  information.  Turn the autodrafter on.  Note:    For information about setting up the autodrafter into three‐way drafting, see  Draft menu. (p 14)    Power feed to Electronic ID readers  The Weigh Scale can supply power to an Electronic ID reader.    Power is supplied  only if the reader is connected to Port 2 and if either one of the Electronic ID  reader options is selected.  With Port 2, if you nominate a device other than an Electronic ID reader, the  power feed is disabled but can be manually configured via the advanced setup  menus.    If the Electronic ID Reader you are using does not require power from  the Weigh Scale, you can connect it to either Port 1 or Port 2.  Page 32   ...
  • Page 37: Select Country

    3E2364 Weigh Scale W810 v2 User Manual      Select country  The Select Country menu lets you select the required country settings.      The Weigh Scale country settings determine the following:   the language used with the screens and prompts;   some country‐specific terminology; and   some default options.  To display the Select Country menu, complete the following steps:  Turn the mode selection switch to  .  SELECT COUNTRY Select  .  The following screen displays:    Changing the country and language  To change the country, press the    or    soft key to  select the desired country.  Language To change the language, press the   soft key.  The following screen displays:     Press the    or      soft key to select the desired  language. ...
  • Page 38: Using Electronic Ids

        3E2364 Weigh Scale W810 v2 User Manual    USING ELECTRONIC IDS  The Weigh Scale can be used with an electronic ear tagging system. During a  weighing session an animal can be identified by reading its Electronic ID. You can  use Electronic IDs on their own, or the Weigh Scale can also link and store the  Visual Tag Number that identifies the same animal. The Visual Tag Number is  whatever alpha numeric (up to 15 characters) code that you choose to enter  against an Electronic ID for a given animal. It might be based on the visible  number printed on the ear tag or a combination of the number and the colour of  the ear tag:    "1234" or "123RED" etc.  Setting up the Weigh Scale to use Electronic IDs  The Electronic ID reader connects to one of the serial ports on the Weigh Scale.   EID Reader  As described in Communications (p 28), this port must be set to read ‐ Standard .  Cross‐referencing Visual Tag Numbers  The Weigh Scale maintains a cross‐reference table that links an animal's  Electronic ID with the animal's Visual Tag Number.    Once it makes this link, the  Weigh Scale remembers the Visual Tag Number the next time the Electronic ID is  read.  The Weigh Scale can store up to 21000 links between Electronic IDs and Visual  Tag Numbers. If the limit is exceeded, new links between an Electronic ID and its  Visual Tag Number cannot be stored. In this case, the next time the Electronic ID  is read, its Visual Tag Number will not display. Warnings will appear leading up to  this. See Memory full warning (p 88).  Page 34   ...
  • Page 39 3E2364 Weigh Scale W810 v2 User Manual      Linking an Electronic ID to its Visual Tag Number  The first time you use an Electronic ID, follow these steps:    Read the animal's Electronic ID. You can read the Electronic ID before the  animal steps on the platform or while the animal is on the platform.    The last four digits of the Electronic ID, preceded by a colon, display on the  Weigh Scale's screen:      If you want to assign a Visual Tag Number to the Electronic ID, enter the  number now, using the keypad. You must not enter the Visual Tag Number  until the Electronic ID is displayed on the Weigh Scale's screen. The Visual  Tag Number must also be entered before the animal leaves the platform.  After the animal has left the platform, the Electronic ID and Visual Tag  Number will be linked together in the cross reference table in the Weigh  Scale's memory. A record is also stored in the current session according to  normal Weigh Scale behaviour.  If you do not assign a Visual Tag Number, each time you read the Electronic ID in  future, the last four digits of the Electronic ID, preceded by a colon, will display  on the Weigh Scale's lower screen. Each time the Electronic ID is displayed you  have the opportunity to enter, and link it to, a Visual Tag Number.  Once you have linked an Electronic ID with a Visual Tag Number, only the Visual  Tag Number will display on the Weigh Scale's screen each time the Electronic ID  is read in a future weighing session. See Assigning Visual Tag Numbers to  Electronic IDs (p 81).  You can follow these steps during a weighing session or without having to weigh.  In the latter case, you must use Manual mode with no loadbars connected. See  Recording standard animal information (p 82).  Updating Incorrect Visual Tag Numbers in the Cross‐Reference Table  Once a link between an Electronic ID and its Visual Tag Number has been made,  you can edit it if it is incorrect using one of the following methods:  Editing the weight record in the current session. See Editing weight records  (p 77).  Using APS to update the cross‐reference table. Refer to the APS User  Manual for detailed instructions.         ...
  • Page 40: Sessions

        3E2364 Weigh Scale W810 v2 User Manual    SESSIONS  A session is a collection of weight records for which the Weigh Scale displays  statistics.  Sessions have a start date but can remain open for a period of time. Each  weighing event adds a record to the current session. To keep weight gain  calculations accurate, it is recommended that you start a new session whenever  you weigh a new group of animals.  Each time data is collected a record is created.    The date on which a new record  is created is stored within the session but is not displayed on the Weigh Scale.    This date is used to calculate the weight gain for an animal and is copied to APS  with the session.  Note:    Session files on the Weigh Scale should be closed regularly ‐ generally at the end  of a weighing session.    If sessions are left open for longer than 2.5 years the  oldest record dates may become inaccurate.  Sessions overview  There are three types of sessions:  Standard Session  These sessions allow recording of standard animal  information (note and condition score).  Trait Session  These sessions let you record up to eight traits for each  animal. The traits that you can record in the session are  defined in APS and copied to the scale, prior to the  session.      Up to 10 trait tables can be defined and  copied to the Scale.    When a Trait session is created  you can select which trait table to use as a template. ...
  • Page 41 3E2364 Weigh Scale W810 v2 User Manual      Loadbars Connected  Automatic Mode  Manual Mode  Fine Mode     Store Animal  Store Animal  Store Animal  Standard  Weights  Weights on Key  Weights on Key  Session  Automatically  Press  Press     Record Animal  Record Animal  Record  Information  Information    Information (two  fields)    Draft by Weight  Draft by weight     Store Animal  Store Animal ...
  • Page 42: Session Naming Formats

        3E2364 Weigh Scale W810 v2 User Manual    Session naming formats  Each session file name has the following format:  YYYY-MM-DD hh-mm NAME  Where…  Is the…  Example…  YYYY  4 digit year  2003  MM  2 digit month  06  DD  2 digit day  24  hh  2 digit hour in 24 hour format  13  mm  2 digit minutes  15  NAME  Name of the weighing session that will display    on the Weigh Scale. The name varies  depending on session type, as below;  STANDARD  The name can contain up to 17 characters and  STEERS  SESSION  is chosen by the user. All letters will be upper  NAME  case.  Note:  When the Weigh Scale creates an unnamed ...
  • Page 43: Storage Capacity

    3E2364 Weigh Scale W810 v2 User Manual      Storage capacity  The information gathered each time the Weigh Scale makes a measurement is  called a record.  The Weigh Scale can store up to 60000 records.    These include the records of all  sessions including the current one. See Memory Full Warning (p 88).  For information about the maximum number of cross references the Weigh Scale  can store, see Cross‐referencing Visual Tag Number's (p 34).  Session statistics  The Weigh Scale gathers statistics as it weighs.  Statistics can be presented in four ways:   a summary of weights.    See Statistics screen (p 40).   a summary of weight‐gains.    See Weight gain screen (p 42).   a list of all the weights recorded.    See Weight records screen. (p 43)   a summary of carcass weights.    See Carcass weight screen (p 45).  The Weigh Scale displays statistics of the current session in the lower screen.      As weighing progresses, the statistics screen updates.  Selecting a view  To select a different data view during a weighing session:    Turn the mode select switch to either  ,   or ...
  • Page 44: Statistics Screen

        3E2364 Weigh Scale W810 v2 User Manual    Statistics screen  The Weight Stats or Draft Stats screen displays summary weight data for animals  in the current weighing session. The screen that is displayed depends on the  weighing mode that you are using and whether drafting is turned on or off.  Statistics can be displayed for closed sessions, see Displaying statistics for a  closed session. (p 21)  Weight statistics  The Weight Stats screens displays if:   drafting is switched off, or     you are weighing in fine mode.  This Weight Stats screen shows the number, average, total, highest and lowest  weights for all the animals in the current session.  The left hand side of the lower screen displays information about the animal  currently being weighed.        Note:    If the ADG Display is turned to Off in User Options, the weight gain will not be  displayed on the screen.  Page 40   ...
  • Page 45 3E2364 Weigh Scale W810 v2 User Manual      Draft statistics  The Drafting Stats screen displays if:   drafting is turned on, and         you are in either automatic or manual weighing modes    The details on the lower screen change depending on the drafting mode  selected.    The screen shows the number, average and total weight of the  animals in each drafting category as well as the gate through which the animal  was drafted. The following screen shows the details for three way drafting.    If you are drafting four ways or more, the statistics screen displays as shown:    If you are drafting by Draft List, the Statistics screen changes to      Note:  The    soft key is only displayed if one of the Weigh Scale's ports is  configured for a printer.    For information on connecting a printer to the Weigh  Scale see Communications (p 28).    With a printer connected and configured you  can print the statistics on this screen.    Page 41   ...
  • Page 46: Weight Gain Screen

        3E2364 Weigh Scale W810 v2 User Manual     Pressing the        soft key allows you to scroll through the draft  statistics for the other gates.   Pressing the        soft key changes which statistic screen  displays.  Weight gain screen  The Weight gain screen shows weight gain data for the animal being weighed  and weight gain statistics for all animals in the session.      The weight gain graph on the left side of the screen shows the change in an  animal's weight gain from one session to the next. The vertical axis represents  weight gain, the horizontal axis represents time. Each point on the graph  represents the weight gain (in /day) that occurred between two weighing  sessions.    For example, if the graph slopes upward, the rate of weight gain has increased. If  the graph slopes downward the rate of weight gain has decreased.  Note:    Provided the weight gain figure is positive the animal has gained weight. The  graph plots changes in weight gain not changes in weight.    A downward slope in  the line on the graph indicates a decrease in the rate of weight gain, not a  decrease in actual weight.    The weight gain (in /day) for the animal currently being weighed is displayed in ...
  • Page 47: Weight Records Screen

    3E2364 Weigh Scale W810 v2 User Manual      Weight records screen  Weight records screen for a standard or draft list sessions  During a Standard or Draft list weighing session, the Weight Records screen  shows the data recorded for each animal:     Visual Tag Number   Weight     Condition score     Notes  You can use    and    to scroll up or down the list and  view or edit other weight records in the current session.  The last weight to be recorded is displayed at the top of the screen.      This screen can also be used to edit the weight records in the current session. For  further information, see Editing a weight record from a standard or draft list  session (p 77).    The Tag Count value represents the number of Electronic ID tags read when the  loadbars are not connected.    Page 43   ...
  • Page 48     3E2364 Weigh Scale W810 v2 User Manual    Weight records screen for a Trait session  During a trait session, the Weight Records screen shows the data recorded for  each animal:     Visual Tag Number   Weight   Trait entries  You can use    and    to scroll up or down the list and  view other weight records in the current session.  The last weight to be recorded is displayed at the top of the screen.      This screen can also be used to edit a Visual Tag Number in the current session.  For further information, see Editing a weight record from a Trait session (p 78).    Page 44   ...
  • Page 49: Carcass Weight Screen

    3E2364 Weigh Scale W810 v2 User Manual      Carcass weight screen  The Carcass Weight screen displays the carcass weight of the animal. The carcass  weight is calculated using the kill‐out percentage that you enter. The carcass  weight statistics are displayed on the right hand side of the screen. The format is  the same as that used in the WEIGHT STATS or DRAFTING STATS screens.          The carcass weights on the screen shown above are based on a kill‐out  percentage of 53%. Within each drafting category, the average and total carcass  weights displayed will be 53% of the average and total weights recorded for the  session. The number of animals in each drafting category is displayed. If drafting  is turned off, the lowest and highest carcass weight is also displayed.    Note:    If the kill‐out percentage is changed during the weighing session, the carcass  weights are recalculated.    Kill out percentage  To change the kill‐out percentage:  Press  .    The current kill‐out percentage screen displays.    Press    to delete the current kill‐out percentage.    Each time you press    one character is deleted.    Enter the new kill‐out percentage using the keypad.    Press ...
  • Page 50: Preparing To Weigh

        3E2364 Weigh Scale W810 v2 User Manual    PREPARING TO WEIGH  Weighing modes  Automatic  Automatic mode is recommended for yards that allow a smooth flow of animals  across the weighing platform.  In Automatic mode, the Weigh Scale automatically starts the weight  measurement process as soon as the animal steps onto the platform.    After the  weight has been captured, the Weigh Scale beeps and displays the captured  weight.    The captured weight continues to display until the next animal steps  onto the platform.  After the animal leaves the platform, the Weigh Scale attempts to compensate  for the weight of any accumulation of mud or dung left on the platform.    If it  succeeds, the Weigh Scale displays a zero icon. If it does not you can manually  restore zero by pressing the blue zero button.  Manual  Manual mode is recommended for yards that do not allow a smooth flow of  animals across the weighing platform or where the animals are restless.    This  mode allows the operator to decide when the measurement is made.  In manual mode, the operator presses the green weigh button to start the  weight measurement process.    After the weight has been captured, the Weigh  Scale beeps and displays the captured weight.    The captured weight continues  to display until the next animal steps onto the platform.  After the animal leaves the platform, the Weigh Scale attempts to compensate  for the weight of any accumulation of mud or dung left on the platform.    If it  succeeds, the Weigh Scale displays a zero icon. If it does not you can manually ...
  • Page 51 3E2364 Weigh Scale W810 v2 User Manual      Fine  Fine mode is recommended for weighing static loads such as fleeces or produce.  In Fine mode, the Weigh Scale displays the weight on the platform in the same  way as a bathroom scale.  If a weight measurement is to be added to the session statistics, the operator    presses the green weigh button.    The weight is captured at this point, but it is  not stored in the weight record until the weight is removed from the platform.  After the weight has been captured, the statistics are updated. For information  about statistics, see Session statistics (p 39). The displayed weight continues to  reflect the actual weight on the platform.      In Fine mode, automatic zero tracking is switched off. This means the Weigh  Scale does not automatically compensate for the weight of objects left on the  platform after the load has been removed. For more information, see Zero  tracking (p 87).    The blue zero button has a function in Fine mode if you want to make net‐weight  measurements of a load inside a container.    For example, you could place an    empty container on the weighing platform and press the blue zero button.    If  you then filled the container, the weight indication will be only that of the  container's contents.      Note:    In Fine mode, after the blue zero button has been pressed, the weight indication ...
  • Page 52: Weigh Scale Layout

        3E2364 Weigh Scale W810 v2 User Manual    Weigh Scale layout      Note:    If you are using the Weigh Scale without connection to an external power source,  ensure that the battery has been charged overnight before use.    Page 48   ...
  • Page 53: Connecting The Weigh Scale To The Loadbars

    3E2364 Weigh Scale W810 v2 User Manual      Connecting the Weigh Scale to the loadbars  Before you begin the weighing session, complete the following steps:  Open the Weigh Scale case.  Mount the Weigh Scale on a flat surface or clip it onto the Weigh Scale  bracket.                                    Ensure all required accessories are connected and setup, for example:   Loadbars   Drafters   Electronic ID readers    Determine if you require additional power for the Weigh Scale.  Either connect to an AC outlet via the battery charger or connect to a 12 volt  battery.  If you are not connecting to an external power source, the Weigh Scale's  internal battery should be fully charged. See Charging the Battery (p 5), if  required.    Check and update the setup options, as required. ...
  • Page 54: Setting The Tag Prefix

        3E2364 Weigh Scale W810 v2 User Manual    Setting the tag prefix  Tag numbers can have common prefixes. Once you configure a tag number prefix  on the Weigh Scale it is inserted at the start of any Visual Tag Number you enter  during the session.  To set the tag number prefix, complete the following steps.  Turn the mode select switch to A (Automatic) or M (Manual).  Press  .  Type in the prefix, using the keypad.    The prefix can contain up to four  characters.  Press    to save the prefix.  Page 50   ...
  • Page 55: Weighing In A Standard Session

    3E2364 Weigh Scale W810 v2 User Manual      WEIGHING IN A STANDARD SESSION  Creating a new standard weighing session  To create a new standard weighing session, complete the following steps:  Turn the mode select switch to A (Automatic) or M (Manual).  Press the    soft key.  NEW SESSION  The  screen displays:    The options for Trait or Draft List only show when there are such sessions  present in the Scale:  Type in the required session name using the keypad.  The name can be up to 17 alpha‐numeric characters long.  Press the    key to delete characters.  Note: You can leave the session unnamed.  Press  .  If prompted, type in a session note (can be left blank).    The session note can be up to 13 alpha‐numeric (including full stop, forward  slash and space) characters long.  Press the    key to delete characters.  Press the    soft key to save the note.  Note:   Session note The APS software sets whether the   option displays on  the Weigh Scale, via the APS ‐ Configure menu.  ...
  • Page 56     3E2364 Weigh Scale W810 v2 User Manual    The Weighing Mode Setup screen will display.  a) To change the default weighing mode, press the    soft key to  select the weighing mode. See User Options ‐ Weighing Modes (p 25) for  more information.  b) Press the    soft key for advance options regarding the  weighing mode.  Press    to save the session.  The new session is created and a statistics screen displays with all values set  to zero.    The previous session is closed and stored in the Weigh Scale's memory and can  be viewed using the Session menu.    See Session menu (p 17).  Page 52   ...
  • Page 57: Procedure For Weighing Animals In A Standard Session

    3E2364 Weigh Scale W810 v2 User Manual      Procedure for weighing animals in a standard session  To weigh an animal in a standard session follow this procedure:  Select the weighing mode that you want to use by turning the mode select  A  M  switch to  (automatic) or  (manual).  When the Weigh Scale is switched on, the previous weighing session is still  the current session.    You can choose to create a new weighing session, see Creating a new  standard weighing session for more details.  If required, you can enter an ear tag prefix for the animals being weighed.  See Setting the tag prefix (p 49) for further details.  Check that the    icon is displayed. If it is not displayed, press the blue  "zero" button to zero off any weight (e.g. dirt or manure) left on the  platform.    Load the animal onto the platform. Ensure the animal is contained on the  platform (e.g. no hooves off the platform and no one holding the animal).  If required, you can record the animal's Visual Tag Number or scan an  Electronic ID.   Using Electronic IDs:  Scan the animal's Electronic ID.    The Electronic ID can be scanned at any time before or while the animal  is on the platform.    If you are using Electronic ID numbers only, the last 4 digits of the tag  number preceded by a colon (:) displays on screen.    If you entered a Visual Tag Number the first time the Electronic ID was  scanned, the Visual Tag Number displays on screen.    If this is the first time you have scanned the Electronic ID and you want ...
  • Page 58     3E2364 Weigh Scale W810 v2 User Manual    option is not switched ON when you scan an EID, the previous note, either  trait or user entered note data, will not be displayed.  If you want to view the most recent trait record, recorded for this animal in  more detail, press the    key. When this key is released, the  display will revert to the previous screen.  If required, you can store information about the animal being weighed using  the "Condition Score" and "Notes" fields.    Refer to the following table for instructions on entering a condition score or  note. You can enter this information before the animal steps onto the  platform (i.e. when the platform is empty) or while the animal is on the  platform.  Field  What can be stored  How to use  Condition  One or two digits  Press the    button on  Score  the keypad and type the score.  Notes  Up to 13 characters,  Press the    button on the  alphabetic or numeric.  keypad and type the note.  If an incorrect entry is made, press    to delete each incorrect character  and then re‐enter the correct information.  Follow the instructions for the weighing mode you have selected.  ...
  • Page 59 3E2364 Weigh Scale W810 v2 User Manual      If available on the Weigh Scale, the last recorded weight for the identified  animal displays:      Note: If the ADG Display is turned to OFF in User Options, the weight gain,  last recorded weight, either Trait or user entered note data, will not be  displayed on the screen.  Note: If the weight gain statistics screen is displayed prior to an animal  stepping on the platform, when the weight locks, the animal's weight gain  will be displayed on the lower screen along with the Electronic or Visual  Identification number, Condition Score and Note.  To view the statistics for the session press and hold the    soft  key.    The statistics displayed are:   Weight statistics screen ‐ if drafting is disabled.   Draft by weight screen ‐ if drafting by weight is enabled.  Note: Draft by list statistics are shown once the animal has left the weighing  platform.  To view the trait record information in the same layout as it was originally  entered, press and hold the    soft key.  10. If the weight has locked on but you want to re‐weigh the animal, press the  green weigh key. The Weigh Scale re‐weighs the animal and locks onto the  weight again. The new weight replaces the original weight and the statistics  are updated.  For example, if the animal was not completely on the weighing platform, the  Weigh Scale may have locked onto an incorrect weight.    You do not need to re‐enter the Visual Tag Number, condition score or note  if you have re‐weighed the animal.  11.
  • Page 60     3E2364 Weigh Scale W810 v2 User Manual    will be deleted from the Weigh Scale's memory and the following screen will  display.        The creation date of the record is saved into the session file.  12. The Weigh Scale automatically zero's off any weight left on the platform  (e.g. dirt or manure). When this has occurred the    icon is displayed  on the screen.    If the    icon does not display, press the blue zero button.  The Weigh Scale does not need to return to zero before the next animal is  loaded onto the platform.    Once the weight has dropped by 30%, the  display will unlock ready for the next animal to be loaded onto the platform.  This is a useful feature when weighing sheep.  13. Repeat the process from step 4 until all animals are weighed.      To edit the current session data, see Editing a weight record in a standard or  draft list session (p 77).    Page 56   ...
  • Page 61: Procedure For Weighing Static Loads Standard

    3E2364 Weigh Scale W810 v2 User Manual      Procedure for weighing static loads standard  Turn the mode select switch to   (Fine mode).  Follow the procedure outlined in Creating a new standard weighing session.  Ensure that the displayed weight is zero. To zero the Weigh Scale, press the  Zero blue   button.  Note: The    icon is not displayed in Fine mode.  Place the load onto the platform.  If you want to store information, enter desired values into the "Tag  Number", "Condition Score" and "Notes" fields.  For example, you may want to enter a wool bale reference number or a  note to identify specific bales.  Refer to the following table to select the field that you want to use. You  can enter this information before the load is placed on the platform (i.e.  when the platform is empty) or while the load is on the platform.  Field  What can be stored  How to use  Tag number  Up to 15 characters,  Use the keypad to enter the  (Reference  alphabetic or numeric.  reference number.  number)  Condition  One or two digits.  Press the    button on  score  the keypad and type the score.  Notes  Up to 13 characters, ...
  • Page 62: Drafting By Weight

        3E2364 Weigh Scale W810 v2 User Manual    Drafting by weight  To draft animals by weight you need to set up the following:  Connect the loadbar to the Weigh Scale.    See Connecting the Weigh Scale  to the loadbar. (p 49)  Connect the Drafter to the Weigh Scale and set up the correct  communications for the Drafter.    See Communications (p 28).  Set up drafting limits on the Weigh Scale.    See Draft menu. (p 14)  Create a standard session.    See Creating a new standard weighing session  (p 51).  Weigh and draft the animals.  Page 58   ...
  • Page 63: Weighing In A Trait Session

    3E2364 Weigh Scale W810 v2 User Manual      WEIGHING IN A TRAIT SESSION  Trait sessions allow you to record details of individual animals by entering values  against various characteristics.    A Trait table is the template on which a Trait  session is based.    They define which traits can be recorded in a session and the  maximum number of characters in each. Trait tables are created in APS and  copied to the Scale.    When you create a new Trait session on the Scale, you select from the displayed  list.    You can customise the traits recorded or use breeder society values. Refer  to the APS User Manual for further information.  Note:    Up to ten trait tables can be stored on the Scale at any one time.   When new Trait tables are copied to the Scale from APS, all existing Trait  tables are overwritten.   The    option is only available if Trait tables are stored on the  Scale.  Creating a new trait weighing session  To create a new trait session there must first be a trait table present in the  Weigh Scale. This must be copied from your computer using the APS program.  To create a new trait session, follow this procedure;  Turn the mode select switch to A (Automatic) or M (Manual).  Press the    soft key.  NEW SESSION  The  screen displays: ...
  • Page 64     3E2364 Weigh Scale W810 v2 User Manual    Press the    and    soft keys to select the required  trait table.  Press    to select the Trait table.  If prompted, type in a session note (can be left blank).    The session note can be up to 13 alpha‐numeric (including full stop, forward  slash and space) characters long.  Press the    key to delete characters.  Press the    soft key to save the note.  Note:   Session note The APS software sets whether the   option displays on  the Weigh Scale, via the APS ‐ Configure menu.   Adding a session note reduces the number of records stored on the  Weigh Scale by one.   The entered session note is transferred to APS with the session data.   The session note details are stored in the first record of the session file.  The Weighing Mode Setup screen will display.  a) To change the default weighing mode, press the    soft key to  select the weighing mode. See User Options ‐ Weighing Modes (p 25) for ...
  • Page 65: Procedure For Weighing Animals In A Trait Session

    3E2364 Weigh Scale W810 v2 User Manual      Procedure for weighing animals in a trait session  To weigh an animal in a trait session follow this procedure:  Select the weighing mode that you want to use by turning the mode select  A  M  switch to  (automatic) or  (manual).  When the Weigh Scale is switched on, the previous weighing session is still  the current session. You can choose to create a new Trait session, see  Creating a new trait weighing session (p 59).    If required, you can enter an ear tag prefix for the animals being weighed.  See Setting the tag prefix (p 49) for further details.  Check that the    icon is displayed. If it is not displayed, press the blue  "zero" button to zero off any weight (e.g. dirt or manure) left on the  platform.    Load the animal onto the platform. Ensure the animal is contained on the  platform (e.g. no hooves off the platform and no one holding the animal).  If required, you can record the animal's Visual Tag Number or scan an  Electronic ID.   Using Electronic IDs:  Scan the animal's Electronic ID.    The Electronic ID can be scanned at any time before or while the animal  is on the platform.    If you are using Electronic ID numbers only, the last 4 digits of the tag  number preceded by a colon (:) displays on screen.    If you entered a Visual Tag Number the first time the Electronic ID was  scanned, the Visual Tag Number displays on screen.    If this is the first time you have scanned the Electronic ID and you want ...
  • Page 66     3E2364 Weigh Scale W810 v2 User Manual    previous note, either trait or user entered note data, will not be  displayed.  If you want to view the most recent trait record, recorded for this animal in  more detail, press the    key. When this key is released, the  display will revert to the previous screen.  If the trait table is not already displayed, press the    key to display it.      Note:    The animal's Electronic ID or Visual Tag Number displays in the top  left corner of the trait table. The weight gain, if one can be calculated for  this animal, displays in the top right corner of the trait table.  The cursor flashes in the field adjacent to the first trait label. The number of  characters able to be entered against each label is indicated by the blank  underlines. Use the arrow soft keys to navigate between the traits and enter  the values for this animal.      Note:    Pressing the    key alternates the display between the Visual  Tag Number entry screen and the trait table. You cannot return to the  statistics or weight record screens until the weight is removed from the  Weigh Scale.  Follow the instructions for the weighing mode you have selected.   Automatic Mode    When the Weigh Scale has determined an accurate  weight for the animal, it locks on to the weight and holds it on the ...
  • Page 67 3E2364 Weigh Scale W810 v2 User Manual      If available on the Weigh Scale, the last recorded weight for the identified  animal displays:    Note 1:    The note will be displayed if there are no prior trait sessions for  the animal, otherwise the note will only be displayed until the last trait    record is found.  Note 2:    If the ADG Display is turned to OFF in User Options, the weight  gain, last recorded weight, and previous note, either Trait or user entered  note data, will not be displayed on the screen.  To view the statistics for the session press and hold the    soft  key.    The statistics displayed are:   Weight statistics screen ‐ if drafting is disabled.   Draft by weight screen ‐ if drafting by weight is enabled.  Note: Draft by list statistics are shown once the animal has left the weighing  platform.  11. If the weight has locked on but you want to re‐weigh the animal, press the  green weigh key. The Weigh Scale re‐weighs the animal and locks onto the  weight again. The new weight replaces the original weight and the statistics  are updated.  For example, if the animal was not completely on the weighing platform, the  Weigh Scale may have locked onto an incorrect weight.    You do not need to re‐enter the Visual Tag Number, condition score or note  if you have re‐weighed the animal.  12. Move the animal off the platform. The weight of the animal and the traits  will be recorded as soon as the animal leaves the platform (the weight ...
  • Page 68     3E2364 Weigh Scale W810 v2 User Manual    including the traits, will be deleted from the Weigh Scale's memory and the  statistics updated. The following screen displays.      The    key has no function in a trait session.  The creation date of the record is saved into the session file.  13. The Weigh Scale automatically zero's off any weight left on the platform  (e.g. dirt or manure). When this has occurred the      icon is displayed  on the screen.    If the    icon does not display, press the blue zero button.  The Weigh Scale does not need to return to zero before the next animal is  loaded onto the platform.    Once the weight has dropped by 30%, the  display will unlock ready for the next animal to be loaded onto the platform.  This is a useful feature when weighing sheep.    14. Repeat the process from step 4 until all animals are weighed.    To edit the current Trait session data, see Editing a weight record from a Trait  session (p 78).    Page 64   ...
  • Page 69: Procedure For Weighing Static Trait Loads

    3E2364 Weigh Scale W810 v2 User Manual      Procedure for weighing static Trait loads  Turn the mode select switch to   (Fine mode).  Follow the procedure outlined in Creating a new trait weighing session (p  59).  Ensure that the displayed weight is zero. To zero the Weigh Scales, press the  Zero blue   button.  Note: The    icon is not displayed in Fine mode.  Place the load onto the platform.  To record trait values, press    to display the Trait table.  Note: The Trait fields displayed depend on the trait table selected when you  created the session.  Enter the values into the "Trait" fields adjacent to the relevant labels.  Weigh  Press the green  button, to record the weight.    The statistics screen updates immediately. The weight screen does not  update until the load is removed from the weighing platform .    Remove the load from the platform. The weight screen updates.  Repeat the procedure from Step 3, for subsequent items to be weighed.  To edit the entered Trait details see Editing a weight record from a Trait session  (p 78).  At the end of the weighing session  Switch the Weigh Scale off by turning the mode select switch to the    position.    Disconnect the loadbar cables.    Fit the protective caps to the loadbar cables. ...
  • Page 70: Weighing While Drafting By List

        3E2364 Weigh Scale W810 v2 User Manual    WEIGHING WHILE DRAFTING BY LIST  What is a Draft List?  The Draft List enables farmers to identify, using its Electronic ID, a specific group  of animals to be drafted off during a session.  A Draft List is a session file created on the computer with a particular naming  format that identifies it when it is copied to the Weigh Scale.  During a Draft List session you can:   weigh and draft animals, or   only draft animals.    The results of the Draft List session are recorded in the Draft List.  The Draft List can be copied to and from the Weigh Scale using APS.  Page 66   ...
  • Page 71: Setting Up The Draft List

    3E2364 Weigh Scale W810 v2 User Manual      Setting up the Draft List  The Draft List is created on the computer and copied to the Weigh Scale using  APS.    Refer to the APS User Manual for instructions on creating the Draft List  and copying it to the Weigh Scale.  When a Draft List is copied to the Weigh Scale it replaces any Draft List that  already exists on the Weigh Scale.  After you have completed your Draft List session you can copy the Draft List back  to the computer for analysis or to update data in your farm management  software program.  Drafting groups and drafting gates:    At the time you prepare a Draft List in APS,  you do not need to know which of the drafter's gates will be available for your  purpose.    When you prepare the list, you simply assign animals to groups.    After you copy the Draft List to the Weigh Scale, you decide which drafting group  will pass through which drafter gate.  Outsiders:    Outsiders are animals which:   are not on the list;   have no group number assigned to them in the list; or   have no Electronic ID.  If an outsider passes through the drafter, the Weigh Scale assigns the animal to a  Others special group called  .    When you select a Draft List session, the Weigh  Others Scale gives you the opportunity to assign a drafter gate specifically to the ...
  • Page 72: Connecting The Equipment

        3E2364 Weigh Scale W810 v2 User Manual    Connecting the equipment  Before you begin a draft list session follow these steps:  Connect the automatic drafter to Port 1 on the Weigh Scale.  Connect the Electronic ID reader to Port 2 or via Bluetooth on the Weigh  Scale.  Tag Checking Ensure   is turned OFF.    See Tag checking (p 27).  Configure both ports.    See Communications (p 28).  Ensure you have selected the draft list and set the gates for drafting.    See  Selecting the Draft List and setting gates (p 69).  Page 68   ...
  • Page 73: Selecting The Draft List And Setting Gates

    3E2364 Weigh Scale W810 v2 User Manual      Selecting the Draft List and setting gates  To select a Draft List session, complete the following steps:  Turn the mode select switch to A (Automatic) if loadbars are connected or  M (Manual) if you are not weighing.  Press the    soft key.  NEW SESSION The   screen displays.    Press the    softskey.  NEW SESSION The   screen displays    Press    .  Note: The session name cannot be changed.  Set the required gates for each displayed draft group.  Press the    or    soft keys, to select the required  draft group.  Use the keypad to set the required gate number(s).    Press  , to save the Draft list session details.  Note: You do not need to change the draft limit, as it is not used during a  draft list session.    Page 69   ...
  • Page 74     3E2364 Weigh Scale W810 v2 User Manual    If prompted, type in a session note (can be left blank).    The session note can be up to 13 alpha‐numeric (including full stop, forward  slash and space) characters long.  Press the    key to delete characters..  Note:   Adding a session note reduces the number of records stored on the  Scale by one.   The entered session note is transferred to APS with the session data.  Session note The APS software sets whether the   option displays on the  Scale.   The session note details are stored in the first record of the session file.  Press  , to save the session.  The new session is created and a statistics screen displays with all values set  to zero.      The previous session is closed and stored in the Scale's memory and can be  viewed using the Session menu. See Session menu (p 17).  Page 70   ...
  • Page 75: Procedure For Weighing And Drafting Animals By Draft List

    3E2364 Weigh Scale W810 v2 User Manual      Procedure for weighing and drafting animals by Draft  List  This section of the manual outlines the procedure to follow to weigh animals and  draft them by list. You can also enter a note or condition score for each animal.  Select the weighing mode that you want to use by turning the mode select  switch to A (Automatic) if loadbars are connected or M (Manual) if you are  not weighing.  When the Weigh Scale is switched on, the previous weighing session will still  be the current session.    See Selecting the Draft List and setting gates (p  69).  If required, you can enter an ear tag prefix for the animals being weighed.  See Setting the tag prefix (p 49) for further details.  Check that the    icon is displayed. If it is not displayed, press the blue  "zero" button to zero off any weight (e.g. dirt or manure) left on the  platform.    Load the animal onto the platform. Ensure the animal is contained on the  platform (e.g. no hooves off the platform and no one holding the animal).  Scan the animal's Electronic ID.    The Electronic ID can be scanned at any time before or while the animal is  on the platform.    If you are using Electronic ID numbers only, the last 4 digits of the tag  number preceded by a colon (:) displays on screen.    If you entered a Visual Tag Number the first time the Electronic ID was  scanned, the Visual Tag Number displays on screen.    If this is the first time you have scanned the Electronic ID and you want to  enter an associated Visual Tag Number, you can enter it now. In future, each  time you scan the Electronic ID, the associated Visual Tag Number will  display on screen.    As soon as the Electronic ID has been read: ...
  • Page 76     3E2364 Weigh Scale W810 v2 User Manual    If you want to record a Note for this animal, press the    key. The  cursor displays and you can enter notes between the > < symbols. You can  enter up to 13 characters.    If you want to record a Condition Score for this animal, press the    key. You can enter a 1 or 2 digit value.      Note:    Both the    and the    keys enable you to switch  between either of the values that you have entered.    10. When the Weigh Scale has determined an accurate weight for the animal, it  locks on to the weight and holds it on the screen.    11. The time taken to lock on to the weight varies depending on the movement  of the animal.  12. When the Weigh Scale has locked onto the weight:     the "Weight OK" light illuminates;     displays on the screen;   the Weigh Scale beeps; ...
  • Page 77 3E2364 Weigh Scale W810 v2 User Manual      Note: If the ADG Display is turned to OFF in User Options, the weight gain,  last recorded weight, and previous note, either Trait or user entered note  data, will not be displayed on the screen.  To view the statistics for the session press and hold the    soft  key.    The statistics displayed are:   Weight statistics screen ‐ if drafting is disabled.   Draft by weight screen ‐ if drafting by weight is enabled.  Note: Draft by list statistics are shown once the animal has left the weighing  platform.  13. Drafting by list, the statistics update in the following way: When an animal  on the draft list is seen, the Actual Total column (Act Total) will increase by 1  and the Expected Total (Exp Total) column will decrease by 1. If the animal  was not on the draft list the Actual Total column increases by 1, but the  Expected Total column does not change.    The same occurs for the Actual (Act) or Expected (Exp) totals for the draft  group the animal belongs to.    Note:  The Exp Total column records the total number of animals on the draft list  that are yet to be seen.      14. If the weight has locked on but you want to re‐weigh the animal, press the  green weigh key. The Weigh Scale re‐weighs the animal and locks onto the  weight again. The new weight replaces the original weight and the statistics  are updated.  For example, if the animal was not completely on the weighing platform, the  Weigh Scale may have locked onto an incorrect weight.    You do not need to re‐enter the Visual Tag Number, condition score or note ...
  • Page 78     3E2364 Weigh Scale W810 v2 User Manual    Condition Scores you have to use the process outlined in Editing weight  records (p 77).  The weight remains on the screen until the next animal steps onto the  platform.  If the animal has left the platform and you want to delete the weight that  has just been recorded, press the red delete button. The last weight entered  will be deleted from the Weigh Scale's memory and the following screen will  display.        The creation date of the record is saved into the session file.  16. The Weigh Scale automatically zero's off any weight left on the platform  (e.g. dirt or manure). When this has occurred the    icon is displayed  on the screen.    If the    icon does not display, press the blue zero button.  The Weigh Scale does not need to return to zero before the next animal is  loaded onto the platform.    Once the weight has dropped by 30%, the  display will unlock ready for the next animal to be loaded onto the platform.  This is a useful feature when weighing sheep.    17. Repeat the process from step 4 until all animals are weighed.      Note:    Drafting can be turned off at any time by pressing the F3 key.  Page 74 ...
  • Page 79: Drafting By List Without Weighing

    3E2364 Weigh Scale W810 v2 User Manual      Drafting by list without weighing  To draft animals by list, without weighing, follow these steps:  M  Disconnect loadbars. Turn the mode select switch to  (Manual).  Scan the animal's Electronic ID.  After the animal's Electronic ID has been read the draft gate is displayed on  the main Weigh Scale screen. If you have an automated drafter connected  and configured, the designated gate will open.  Although it is not visible on the Weigh Scale, the session records the fact  that this animal was drafted. The draft result for each animal can be viewed  in APS, once the session has been copied back to the computer.    When drafting by list the statistics update in the following way. When an  animal on the draft list is seen, the Actual Total column (Act Total) will  increase by 1 and the Expected Total (Exp Total) column will decrease by 1.  If the animal was not on the draft list the Actual Total column increases by 1,  but the Expected Total column does not change.    The same occurs for the Actual (Act) or Expected (Exp) totals for the draft  group the animal belongs to.    Note:      The Exp Total column records the total number of animals on the draft list  that are yet to be seen.      The Weight Stats screen does not appear.  Repeat Step 2 for each subsequent animal that you want to draft.    Note:    Drafting can be turned off at any time by pressing the F3 key.       ...
  • Page 80: At The End Of The Weighing Session

        3E2364 Weigh Scale W810 v2 User Manual    At the end of the weighing session  Switch the Weigh Scale off by turning the mode select switch to the    position.    Disconnect the loadbar cables.    Fit the protective caps to the loadbar cables.    Fit the protective caps to the Weigh Scale.    Page 76   ...
  • Page 81: Editing Weight Records

    3E2364 Weigh Scale W810 v2 User Manual      EDITING WEIGHT RECORDS  About editing weight records   Only records in the current session can be edited on the Weigh Scale. To  edit records in other sessions you need to copy them to the computer. Refer  to the APS User Manual for more information.   The Tag Number, Condition Score and Notes can be edited during or after a  standard session.   Trait table data can be edited in the current session.   Weights cannot be edited.     Weight records cannot be edited while viewing the session in setup mode.  Editing a weight record in a Standard or Draft List  session  In a standard or draft list session;  A  Turn the mode select switch to  or  .    Note:    You must have loadbars connected to edit the weight records in the  current session.  Press    until the screen listing the individual weights is  displayed.    Press    to edit weigh records.       ...
  • Page 82: Editing A Weight Record In A Trait Session

        3E2364 Weigh Scale W810 v2 User Manual    Editing a weight record in a Trait session  In a Trait session;  A  Turn the mode select switch to  or  .    Press    until the screen listing the individual weights is  displayed.    Press    to edit weigh records.        Use the arrow soft keys to highlight the Tag data you wish to alter.  Press the    button to delete characters, as required.  Type in the new Tag number using the keypad.  Use the arrow soft keys to highlight the Trait data you wish to alter.  When you highlight the Trait data field the trait data screen displays.    Type in the required information in the appropriate fields and press  .  When you have made all the required changes, press    to save  the changes and exit edit mode.  Page 78   ...
  • Page 83: Deleting A Weight Record In The Current Session

    3E2364 Weigh Scale W810 v2 User Manual      Deleting a weight record in the current session  Turn the mode select switch to  ,   or  .    Press    until the screen listing the individual weights is  displayed.  Press    to edit weigh records.        Use the arrow soft keys to highlight the weight record you wish to delete.  Delete  Press the red  button.  The selected record is deleted from the session and the statistics are  updated.    Page 79   ...
  • Page 84: Recording Animal Information Without Weighing

        3E2364 Weigh Scale W810 v2 User Manual    RECORDING ANIMAL INFORMATION  WITHOUT WEIGHING  The Weigh Scale W810 v2 lets you record details about animals against animal  tags (electronic or visual) without needing to record a weight. The information is  added to the current session (Standard only) in the same way as a normal record,  but with the weight set to zero.    Note:      Only records that contain a weight are added to the session statistics.  Automatic storing of Electronic IDs  You can use the Weigh Scale in a hands‐free mode, to record the Electronic IDs  for a group of animals. The Electronic IDs are stored in the current session. This  can be used, for example, as a method of recording which animals arrived or left  your farm on a particular day. In this case, it is recommended that you start a  new standard session before storing the Electronic IDs.  The procedure for storing Electronic IDs automatically is:  Make sure there are no loadbars connected to the Weigh Scale W810 v2.  Turn the mode select switch to  .  Read each Electronic ID.  Each Electronic ID is stored in a separate record in the current session. The  weight is set to zero. The session statistics do not change. A count of  scanned Electronic IDs displays next to the tag field. This will recount tags  that are scanned for a second or subsequent time in the same session.  Note:    If the Weigh Scale's cross‐reference table already stores a Visual Tag Number  linked to an Electronic ID you have read, the weight record on the Weigh Scale  will display the Visual Tag Number, not the Electronic ID. When you copy the  session to the computer, both the Electronic ID and Visual Tag Number will be  visible.    Page 80   ...
  • Page 85: Assigning Visual Tag Numbers To Electronic Ids

    3E2364 Weigh Scale W810 v2 User Manual      Assigning Visual Tag Numbers to Electronic IDs  In the current Weigh Scale session, you can assign a Visual Tag Number to an  Electronic ID once.    To change an assigned Visual Tag Number in the Weigh  Scale's cross‐reference table, you must transfer the cross‐reference table to APS.  To assign a Visual Tag Number to an Electronic ID:  Make sure there are no loadbars connected to the Weigh Scale W810 v2.  Turn the mode select switch to  .  Scan the Electronic ID.  Enter the Visual Tag Number using the keypad and press the green Weigh  button.  The Visual Tag Number you entered is now linked to the Electronic ID in the  Weigh Scale's cross‐reference table.  A record is added to the current session containing the Visual Tag Number  and with the weight set to zero. The session statistics are unchanged.  For information on editing weight record in the current session, see Editing  weight records (p 77).  Generally, the Visual Tag Number is assigned to the Electronic ID     during the normal weighing process, or   via the tag bucket file.  Note:    Copying a Session file from the computer to the Weigh Scale will always update  the Cross Reference Table in the Weigh Scale for any animals contained in that  Session. This will be regardless of the date that the weighing Session was  conducted. If multiple sessions are copied, the most recent session that each  animal appeared in will be that animal's new record in the Weigh Scale's Cross  Reference Table.    Page 81   ...
  • Page 86: Recording Standard Animal Information

        3E2364 Weigh Scale W810 v2 User Manual    Recording standard animal information  To store condition scores and notes about animals without recording a weight,  follow these steps:  Make sure there are no loadbars connected to the Weigh Scale W810 v2.  Turn the mode select switch to  .  Ensure you are in a standard session (not a trait session). If you are not, you  will need to start a new standard session. See Creating a new standard  weighing session.  If you are using Electronic IDs to identify the animal, scan the animal's  Electronic ID.  Enter the animal's Visual Tag Number using the keypad, if it is not already  displayed.  Note:    If you read an Electronic ID that was already linked to a Visual Tag  Number in the Weigh Scale's cross‐reference table, it will be displayed and  you will not be able to edit it.  Press    and enter a one or two digit condition score.  Press    and enter the note (up to 13 characters) using the keypad.    Press the green Weigh button to save the record.  A text record is added to the current session containing the information you  entered and with the weight set to zero. The session statistics do not  change.  None of the fields are compulsory (Electronic ID, Visual Tag Number, Condition  Score or Note), however, you must enter some information before the record is  saved. Normally, you will want to identify the animal (using the Electronic ID or  Visual Tag Number) before saving information about the animal using the  condition score or note.  Page 82   ...
  • Page 87: Recording Animal Traits

    3E2364 Weigh Scale W810 v2 User Manual      Recording animal traits  The Weigh Scale W810 v2 lets you record values against animal characteristics  for a specific animal tag number (electronic or visual) without needing to record  a weight. The information is added to the current session in the same way as a  normal record, but with the weight set to zero.    The traits against which you can record information for each animal are defined  in APS and copied to the Weigh Scale. When you start a new trait session on the  Weigh Scale you can select which trait table to base the session on which then  becomes permanently associated with that session. This defines the traits you  can enter data against in this session. Refer to the APS User Manual for more  information.  To store animal trait information without a weight, follow these steps:  Make sure there are no loadbars connected to the Weigh Scale W810 v2.  Turn the mode select switch to  .  Ensure you are in a Trait session. If you are not you will need to start a new  trait session. See Creating a new trait weighing session (p 59).  If you are using Electronic IDs, scan the animal's Electronic ID.  If the Electronic ID is already linked to a Visual Tag Number in the Weigh  Scale's cross‐reference table, the Visual Tag Number displays briefly and is  then replaced by the trait table.  If the Electronic ID is not linked to a Visual Tag Number in the Weigh Scale's  cross‐reference table, you can enter one now (this is not compulsory). The  Visual Tag Number, if you enter one, replaces the Electronic ID on the Weigh  Scale's display.  If you are using Visual Tag Numbers only, enter it now. The Visual Tag  Number is displayed as you enter it.  If the trait table is not already displayed, press      to display it now.  Enter the trait data using the keypad. The number of characters available for  each is indicated by the blank underlines.  Press the green Weigh button to save the record.  The animal information you entered is added to the current session as a  new record with the weight set to zero. The session statistics do not change.   ...
  • Page 88: Checking For Duplicate Visual Tag Numbers

        3E2364 Weigh Scale W810 v2 User Manual    CHECKING FOR DUPLICATE VISUAL TAG  NUMBERS  The Weigh Scale lets you check for duplicate Visual Tag Numbers during a  weighing session. Duplicates can occur if the same animal is weighed twice in a  session. They can also occur because a Visual Tag Number has been entered  incorrectly. In this case, you can edit the incorrect Visual Tag Number  immediately. For instructions on turning Tag Checking on and information about  when a duplicate can occur, see User options.  If a Visual Tag Number duplicate occurs within a session, a screen similar to the  following displays. The duplicate Visual Tag Number is displayed and the Weigh  Scale beeps three times.    This duplicate tag screen enables you to:   accept both Visual Tag Numbers (i.e. the duplicate remains), or   edit the Visual Tag Number just entered, or     edit the Visual Tag Number recorded earlier in the session.    Notes:   If you do not make a selection before the animal leaves the platform the  duplicate Visual Tag Numbers remain.   Some Electronic ID readers can be set up so that they are unable to read the  same Electronic ID twice in a session.    If you want to use the Weigh Scale's  tag checking feature to prevent an animal being weighed more than once in  a session, you need to set up the reader so that it can read the same  Electronic ID more than once.   To prevent multiple recordings of an Electronic ID, the Weigh Scale records  the number once after the first reading.    It will not record this Electronic ID  again until after a different Electronic ID has been read. ...
  • Page 89: Editing A Duplicate Visual Tag Number

    3E2364 Weigh Scale W810 v2 User Manual      Editing a duplicate Visual Tag Number  If a duplicate Visual Tag Number occurs, the following screen will be displayed  and the Weigh Scale will beep three times.    This screen lets you change the current Visual Tag Number or the Visual Tag  Number that was entered earlier in the session.    To change the current Visual Tag Number:    Use the backspace key    to delete the Visual Tag Number. If the Visual  Tag Number is linked with an Electronic ID, pressing    deletes the entire  number. If the Visual Tag Number isn't linked with an Electronic ID, pressing    deletes one digit.  Use the keypad to enter a new Visual Tag Number.    To change the Visual Tag Number that was entered earlier in the session:  Press the    button.    Use the backspace key    to delete the Visual Tag Number. If the Visual  Tag Number is linked with an Electronic ID, pressing    deletes the entire  number. If the Visual Tag Number isn't linked with an Electronic ID, pressing    deletes one digit.  Use the keypad to enter a new Visual Tag Number.  Accepting duplicate Visual Tag Numbers  If you do not want to change either of the duplicate Visual Tag Numbers, press  the ...
  • Page 90: Updating The Cross-Reference Table With Tag Checking

        3E2364 Weigh Scale W810 v2 User Manual    Updating the Cross‐Reference Table with Tag Checking  When a duplicate tag number occurs and you change a Visual Tag Number that is  already linked to an Electronic ID, the cross‐reference table in the Weigh Scale,  as well as the current session, is automatically updated.  For more information about the Weigh Scale's cross‐reference table or about  linking a Visual Tag Number to an Electronic ID, see Using Electronic ID (p 34).  The following procedure provides an example of how duplicate tag number  checking can be used to update the Weigh Scale's cross‐reference table:  In different sessions you read two Electronic IDs. By mistake you assign both  the same Visual Tag Number of 500. The cross‐reference table in the Weigh  Scale records this information as shown below.  Electronic ID  Visual Tag Number  90000000555  500  90000000444  500  You start a new session and read the first Electronic ID (90000000555). Later  in the session you read the second Electronic ID (90000000444). The  duplicate tag number screen displays with the Visual Tag Number 500  displayed.  You realise the Visual Tag Number linked with Electronic ID 90000000444  should be 600 not 500.  To correct the mistake, you press the    soft key to delete the 500 and  use the keypad to enter the correct Visual Tag Number of 600.  When the animal leaves the platform the current session and the  cross‐reference table are automatically updated. The cross‐reference table  now records the information shown below.  Electronic ID  Visual Tag Number  90000000555  500  90000000444  600   ...
  • Page 91: Additional Features

    3E2364 Weigh Scale W810 v2 User Manual      ADDITIONAL FEATURES  Zero tracking  As animals pass through the weighing crate, an accumulation of mud and dung  may build up on the weighing platform.    The Weigh Scale can compensate for  the weight of this accumulation by subtracting it from the total weight.    The  automatic subtraction of the residual weight from the total weight is called zero  tracking.  Zero tracking ensures that the Weigh Scale captures the animal's weight and not  the mess left on the platform.    The way zero tracking is initiated depends on the weighing mode.  Automatic and Manual modes  In the Automatic and Manual weighing modes, zero tracking is automatically  implemented if, after the animal leaves the weighing platform, the residual  weight is within a defined zero tracking range.   If the residual weight is within the defined range, the    icon displays.   If the residual weight is outside the defined range, the icon does not display.  To manually compensate for the residue, press the blue zero button.    The    icon displays.  During a weighing session, if the Weigh Scale consistently does not restore to  zero, check that there are no obstructions under or around the platform or crate.  Fine mode  In the Fine weighing mode, automatic zero tracking is disabled.      The   ...
  • Page 92: Memory Full Warning

        3E2364 Weigh Scale W810 v2 User Manual    Memory full warning  The Weigh Scale can store up to 60000 records. This is a total of 60000 records  across all weighing sessions, not just the current session.    When the record tally is 1000 records short of the limit, the Weigh Scale beeps  and a memory full warning displays. The warning displays again 50 short of the  limit accompanied by three beeps. When the record tally is only 20 short of the  limit, the warning displays and three beeps sound each time a new record is  added.    When the record tally reaches 60000, the Weigh Scale beeps four times and will  not accept any more records.    To continue weighing, switch the Weigh Scale to Set Up mode and use the  Session Menu screen to select and delete a previous session.  Before deleting a session, you can also copy the weighing sessions to a  computer, so that you can keep a record of the data. Refer to the APS User  Manual, for more information.    Page 88   ...
  • Page 93: Printing

    3E2364 Weigh Scale W810 v2 User Manual      Printing  A serial printer can be attached to the Weigh Scale W810 v2. If the printer is  connected during a weighing session, you can configure the Weigh Scale to print  each animal's tag number, weight and condition score when the Weigh Scale  locks on to the weight.    For instructions on printing weights at the end of the weighing session, or from a  previous session, see Session menu (p 17).    Printing weights during a weighing session  To print each weight record during a weighing session, follow these steps.    Connect the printer cable to one of the two serial ports on the Weigh Scale.    Turn the mode select switch to   to display the setup menu.  5. COMMUNICATIONS Select  .    Printer Ensure the port to which the printer is connected is set to  .    When  the Weigh Scale case is open, Port 1 is on the top, left side of the Weigh  Scale. Port 2 is directly below.      Press    to return to the setup menu.    4. USER OPTIONS Select   on the setup menu.    LIVE PRINTING Ensure ...
  • Page 94     3E2364 Weigh Scale W810 v2 User Manual    pass the validation, the following error message is displayed on the lower screen  of the Weigh Scale.        To clear this message, turn the rotary dial to a different mode. e.g. Automatic,  Manual, Fine, or Setup.    Page 90   ...
  • Page 95: Interfacing Software: Aps

    3E2364 Weigh Scale W810 v2 User Manual      INTERFACING SOFTWARE: APS  Animal Performance Software (APS) is software that can be run on a personal  computer.    After a connection has been made between the computer and the  Weigh Scale, APS can process information obtained from the Weigh Scale.  With APS you can:   retrieve sessions from the Weigh Scale.   copy sessions to the Weigh Scale.   edit sessions.   edit Electronic ID and Visual Tag Number links.   prepare Draft lists.   prepare trait tables.   copy trait tables to the Weigh Scale.   prepare session statistics more advanced than those displayed by the Weigh  Scale itself.   view animal weight‐gain graphs across sessions.   email sessions to selected recipients.   change Weigh Scale setup   create reports.  Detailed instructions are contained in the MyScale Pro User Manual.    Page 91   ...
  • Page 96: Loadbar And Platform Options

        3E2364 Weigh Scale W810 v2 User Manual    LOADBAR AND PLATFORM OPTIONS  It is recommended that you use Gallagher Loadbars with the Weigh Scale W810  v2.    The Weigh Scale W810 v2 Scale recognises most commonly available Loadbar  sets. To connect to some Loadbar sets, adapter cables may be required.    If you are not using Gallagher Loadbars, a calibration check will be required prior  to first use.    Gallagher Standard Loadbars  Features     2000 kg weighing capacity ‐ Available in 600mm (23") and 1000mm (39")  lengths     Tough rugged steel loadbars     Bottom feet mounting holes extend beyond top covers for ease of bolting  down     Slotted top mounting holes fit all sizes of platforms and crushes     6m (20') long tough loadbar cables fitted with high quality connectors     Fully waterproof     No rubber mounts   ...
  • Page 97: Gallagher Super Heavy Duty Loadbars

    3E2364 Weigh Scale W810 v2 User Manual      Gallagher Super Heavy Duty Loadbars  Features     4500 kg weighing capacity     1000 mm (39") rugged steel loadbars     Bottom feet mounting holes extend beyond top covers for ease of bolting  down     6 m (20') long tough loadbar cables fitted with high quality connectors     Fully waterproof     No rubber mounts     High capacity load cells withstand large shock loads     Heavy steel chassis construction absorbs the harshest of impacts     Set them and forget them for permanent installation under the largest  crushes    Talk to your Gallagher dealer about the best platform and/or crate for your  requirements.    Gallagher Heavy Duty Weigh Feet  Features   ...
  • Page 98: Gallagher Suspension Load Cell 250 Kg

        3E2364 Weigh Scale W810 v2 User Manual    Gallagher Suspension Load Cell 250 kg  Features:   250 kg capacity loadcells     Replaces mechanical scale for hanging crates     Compact sturdy design     No rubber to delaminate or rot     Spiral spring metal reinforced cable     High quality moisture proof connectors      Gallagher Suspension Load Cell 500 kg  Features:   500 kg capacity loadcells     Replaces mechanical scale for hanging crates     Compact sturdy design     No rubber to delaminate or rot    ...
  • Page 99: Specifications

    3E2364 Weigh Scale W810 v2 User Manual      SPECIFICATIONS  Weigh Scale W810 v2 Dimensions    Metric Imperial Length  232 mm 9.25"  Width  212 mm 8.5"  Height  90 mm 3.5"  Weight  2 kg 4.4 lb   General  Operating Temperature  ‐20º to 50º C    ‐5º to 120º F  Accuracy  ± 1%  Environmental Protection  IP65  Rating  Input Voltage  11 ‐ 14 VDC    Not for Trade  This Weigh Scale is not certified "Legal for Trade".      Page 95   ...
  • Page 100: Weight Increments

        3E2364 Weigh Scale W810 v2 User Manual    Weight increments  For Gallagher Loadbar sets, the weight increments are preset as shown in the  table. For other loadbar sets talk to your Gallagher dealer.      Gallagher Heavy Duty    Gallagher Standard  Loadbars (3500 kg)  Weight Range  Loadbars    and  (2000 kg)  Gallagher Super Heavy Duty  Loadbars (4500 kg)    Automatic or Manual modes:      0 ‐ 49.9 kg  200 g increments  500 g increments  50 ‐ 199.9 kg  500 g increments  500 g increments  200 ‐ 499.9 kg  1 kg increments  1 kg increments  500 ‐ 1999.9 kg  2 kg increments    2 kg increments  2000 ‐ 4999.9 kg  Not Applicable  5 kg increments ...
  • Page 101: Waste Electrical And Electronic Equipment

    3E2364 Weigh Scale W810 v2 User Manual      WASTE ELECTRICAL AND ELECTRONIC  EQUIPMENT  This symbol on the product or its packaging indicates that this product must  not be disposed of with other waste.    Instead, it is your responsibility to  dispose of your waste equipment by handing it over to a designated  collection point for the recycling of waste electrical and electronic  equipment.    The separate collection and recycling of your waste  equipment at the time of disposal will help conserve natural resources and    ensure that it is recycled in a manner that protects human health and the  environment.    For more information about where you can drop off your  waste equipment for recycling, please contact your local city recycling office  or the dealer from whom you purchased the product.          Page 97   ...
