- Page 1 API Commands HJ-PXC HJ-PXC IP Control Unit Commands Manual Number: 140731 Version 1.0.4...
-
Page 2: Table Of Contents
User Guide TABLE OF CONTENTS Configure Set Parameter ......................1 Configure Get Parameter ......................3 Matrix Parameter ........................4 Video-Wall ..........................4 Video-Wall 2 ..........................5 Multiple View ..........................7 Serial ............................7 Notify ............................8 Command device-name message-body ................. 8... -
Page 3: Configure Set Parameter
User Guide Configure Set Parameter Note: The HJ-PXC is controlled via Telenet Port 23. Set console-box’s parameter. Command config set ip4addr xx.xx.xx.xx netmask xx.xx.xx.xx gateway xx.xx.xx.xx ip setting will change to: ipaddr xx.xx.xx.xx netmask xx.xx.xx.xx Return gateway xx.xx.xx.xx Change the IP address which is used for communicating with TX and Note RX. - Page 4 User Guide ‘、’ ‘@’ ‘*’ ‘&’ ‘_’ ‘ ’(space) Command config set device remove hostname1 hostname2 ... The following device’s record will be removed: <cr> hostname1 <cr> Return hostname2 <cr> Remove the record of hostname1, hostname2…, Hostname can be Note alias.
-
Page 5: Configure Get Parameter
User Guide Configure Get Parameter Get console-box’s information. Command config get version API version: Vx.x Return System version: Vx.x.x Note Obtain API version and system version. Command config get devicelist Return devicelist is hostname1 hostname2 ... Obtain device list. JPX-TX1-xxxx represents TX, JPX-RX1-xxxx Note represents RX. -
Page 6: Matrix Parameter
User Guide Matrix Parameter Command matrix set TX1 RX1 RX2,TX2 RX3 RX4,... Return matrix set: TX1 RX1 RX2,TX2 RX3 RX4,... Represent one or Multiple TX was displayed by one or Multiple RX. Each TX and its connected RX compose a record, and separated by Note a commas. -
Page 7: Video-Wall 2
User Guide Command vw change rx tx videowall config change: rxhostname moved from vw-name and Return connect to txhostname Set RX full-screen display TX. Mainly used for: RX displays a partial Note area of TX before, now need to display the TX full-screen. If the tx is null, that means the video wall configuration of tx is removed. - Page 8 User Guide rx21 ... rxnm Add a video wall layout n*m, subsequently the RX based on display Note order. The Parameter Rx could be character ‘0’, indicates no need to change the corresponding RX. Command vw2 add vw-name rx1 position rx2 position videowall2 item vw-name(n*m) configuration added: rx1 position1 Return...
-
Page 9: Multiple View
User Guide TX/RX2 ...] set videowall2 vw-name’s pictureparam: xx xx xx xx TX/RX1 Return TX/RX2 ... Configure the TX/Rx1, TX/RX2...image shift (Unit: 1 pixel for TX, 8 pixels for RX, a negative number indicates to move left or up) / scale (Horizontal scale units: 1/Columns ;... -
Page 10: Notify
User Guide command-string can’t contain symbol “ and ”. -b param, configure the RS232 parameter of TX/Rx and connected peripherals, including Baud rate、Data bits、Parity and Stop bits. E.g.: -b 115200-8n1. Parameters optional, it is 115200-8n1 by default. -r {on|off}, to add “Enter” or not following the command-string to final peripherals. - Page 11 User Guide This product warranty extends to the original purchaser only and will be null and void upon any assignment or Aurora Multimedia Corp. 205 Commercial Court Morganville, NJ 07751 Phone: 732-591-5800 Fax: 732-591-6801...
