A.3.14 Get Live Title Pages (.Cgxml) To Respect All Livetext Font Attributes - NewTek tricaster advanced edition User Manual

A.3.14 GET LIVE TITLE PAGES (.CGXML) TO RESPECT ALL LIVETEXT FONT ATTRIBUTES?

TriCaster's Title Page file format (.cgxml) presently supports almost every attribute that LiveText offers – but
there are a few exceptions.
For example, multiple font styles on one text line are not supported, which means that different words on a
single line cannot be different colors, or use different typefaces. (Of course you can achieve the same effect
by using additional text objects as necessary.)
For similar reasons, text entered as paragraphs is automatically split into multiple lines in .cgxml Title Page
files.
Suppose you want to assign matching shots from one theme group of LiveSets to different M/Es (or MEM
slot).
1. Prepare the first M/E – click its tab, use the controls to select a LiveSet, assign and position a Key
source, and select a shot (position/zoom preset).
2. Move the mouse pointer to the extreme left of the screen, right-click on the Preset icon in the flyout
preset bin, and select Export.
3. Supply a filename for the Preset.
4. Click the second M/E tab.
5. Right-click on a blank Preset, and select Import from the menu.
6. Select the file you exported above, and click Open.
The second M/E will adopt the exact same settings as the first. Now all you need to do is replace the
currently assigned LiveSet with a matching one by clicking Add at upper-right in the tab, choosing the
LiveSet you want, and clicking OK.
For best visual quality, be sure that the Multiview Resolution you choose in the Dashboard's Workspace menu
corresponds to the optimum display size for the monitor connected (see Section 10.1).
NOTE: Changing Output Resolution can cause frames to be dropped briefly. Thus we do not recommend
changing this setting during live production.
A.3.15 PREPARE A MATCHED GROUP OF M/ES?
A.3.16 IMPROVE THE QUALITY OF MULTIVIEW OUTPUT?
Page | 283
