Shenzhen JieHe Technology Development CO., LTd.
ARM digital signage use guide
This user guide is for reference, see the actual product!
JEHE will do their best to ensure the accuracy and completeness of this manual, but they will not guarantee there is no error in this
manual since the product may upgrade in future. JEHE will not guarantee any typographical errors in this manual or be responsible for
any misunderstanding by users. JEHE may make changes to the specifications and product descriptions at any time without further
notice.
If the product has functional problems, quality issues, you can consult our dealers.
Giada's official website: www.giadatech.com
1
ARM digital signage System user guide
Advertisement
Table of Contents
Related Manuals for Giada Q30
Summary of Contents for Giada Q30
- Page 1 JEHE may make changes to the specifications and product descriptions at any time without further notice. If the product has functional problems, quality issues, you can consult our dealers. Giada‘s official website: www.giadatech.com ARM digital signage System user guide...
-
Page 2: Table Of Contents
Directory Directory ............................2 Product parameters ........................4 1:Quick Installation ........................5 1-1:Interface description ......................5 1-2:Connecting devices ....................... 6 1-3:Installation2G/3G/4G Module ....................7 1-3-A:Open the shell ..............................7 1-3-B:Installation SIM： ............................... 7 1-3-C:Installation2G/3G/4G Module： ......................... 8 1-4:System restore ........................9 1-4-A:Recovery：... - Page 3 11-5:Mobile networks Settings ....................25 11-6:Sound Settings ........................26 11-7:Display Settings ......................... 27 11-7-A:Wi-Fi Display ..............................27 11-7-B:Default Screen Orientation ..........................28 11-8:HDMI Settings ........................28 11-9:Storage Administration ...................... 29 11-10:Apps Administration ......................30 11-11:Location information access .................... 31 11-12:Security Settings ......................31 11-12-A:Equipment Management：...
-
Page 4: Product Parameters
Product parameters ARM Digital signage SPEC Giada Q30 Giada Q30W Giada Q30D RockChip RK3188 RockChip RK3188 RockChip RK3188 ARM ® Cortex ™ -A9 ARM ® Cortex ™ -A9 ARM ® Cortex ™ -A9 Quad-Core 1.6GHz Quad-Core 1.6GHz Quad-Core 1.6GHz ARM Mali-400 MP4,Open GL2.0 ARM Mali-400 MP4,Open GL2.0... -
Page 5: 1:Quick Installation
1:Quick Installation 1-1: Interface description Position Icon Description Usage DC-IN Connect the power adapter ① Wifi/GPS/3G ANT Receive Wifi/GPS/3G signal ⑩②⑪ HMDI Port Connect the HDMI digital monitor ③ RJ45 Port Connect the network ④ USB2.0 Port Connect USB devices ⑤⑫... -
Page 6: 1-2:Connecting Devices
1-2:Connecting devices When Connecting the power adapter, the green LED light will be on, press power button, the Red LED light is on and the host system will automatically boot. ARM digital signage System user guide... -
Page 7: 1-3:Installation2G/3G/4G Module
1-3:Installation2G/3G/4G Module 1-3-A:Open the shell Remove the two screws at the bottom of the machine, you can tear down the shell；As shown one after the open 2G/3G/4G Module 1-3-B:Installation SIM： In Figure Two ,Open in the direction of the arrow SIM snaps,As shown in Figure Three,In Figure Four,Insert the SIM card and the cover snaps,According to LCOK direction lock snaps,As shown in Figure Five. -
Page 8: 1-3-C:installation2G/3G/4G Module
1-3-C:Installation2G/3G/4G Module： Step 1 Insert the Mini PCIe 2G/3G/4G Module into the Mini PCI Express connector on the main board. Step 2 Press downwards to fix the Mini PCIe 2G/3G/4G Module in the module slot. Step 3 Use a screwdriver to fix the Mini PCIe 2G/3G/4G Module on the main board with one screws provided in the Mini PCIe packing box. -
Page 9: 1-4:System Restore
1-4:System restore 1-4-A:Recovery： Note：Recovery operations, the Data partition data will be restored. In order to protect your data from loss, when the System Recovery, when installing APK or writing data, please do not write into the / Data partition! When the ARM PC system can not enter the system, you can manually restore the system. A：Under ARM PC powered off, press and hold the Recovery, power on, press and hold the Recovery, until the following interface. - Page 10 B: click ，choose firmware file for system burning，then click[open] to continue； C：Cut off power supply of ARM PC, connecting ARM PC and windows PC via USB cable. Note: the USB cable must be linked to ARM PC’s USB OTG interface. For more details of ARM PC’s interfaces, please check [1-1:Interface description]).
-
Page 11: 1-5-B:usb Driver Installation
1-5-B: Driver installation If you have not installed ARM PC USB driver on Windows PC, USB driver installation dialog will pop up. Enter ―Control Panel‖ then select ―Device Manager‖. Interface will appear as following: Select ―Other devices-Unknown device‖ right click to select ―Update Driver Software‖ as following: Select ―Browse my computer for driver software‖，Click [Browse...], find corresponding driver for different RKDeviceManage V1.7＞Driver，click [Next] and systems under document... -
Page 12: 1-5-C:arm Digital Signage Interface
Then system start to install driver automatically till installation is completed. 1-5-C:ARM Digital Signage Interface Power BURN Recoveryy USB_OTG DC_IN 1-6:Enable USB debugging： Step 1: Boot up your ARM based PC, use OTG type USB cable to connect with your PC with PC‘s USB-OTG connector. - Page 13 Install ADB driver Step 3: Enter ―Device manager:to install Adb driver as follows. ARM digital signage System user guide...
- Page 14 Enable ADB Step 3: Copy adb.exe、 AdbWinApi.dll、 AdbWinUsbApi.dll 3files under ―RockChip\adb_4.04\tools‖to C:\Windows\System32 and C:\Windows\System. Verify ADB：Under MSDOS, type CMD>adb shell root@andriod:/# , if below picture has appear, then it is correct. ARM digital signage System user guide...
-
Page 15: 2:The Main Interface
2:The main interface Boot up and Enter into the system, you can see the main interface，Click enter the application's main interface； Application main interface to enter button Home Programs running in the background view switch ARM digital signage System user guide... -
Page 16: 3:Alarm Clock Settings
3:Alarm Clock Settings Click to enter into the main interface of alarm clock setting; 4:Timer ON/OFF, sleep / wake up settings Click [Timer] button to enter into time setting，You can set below options: open time, Close time, Sleep time and awake time.（Support7*24h） ARM digital signage System user guide... -
Page 17: 5:Play Music
5:Play Music Click [Music] to enter into the main interface of the music player，This will automatically scan the audio files stored on device，Click on the single music listed then music will play. ARM digital signage System user guide... -
Page 18: 6:Play Video, Boot Play Video Settings
☆Supported audio formats: acc, ape,flac,mp3,ogg,wav, amr,m4a,m4r. 6:Play video, Boot play video settings A:Click [Movie Player] to enter into the main interface of the video player，This will automatically scan the video files stored on device, Click on the single file then video will play. ARM digital signage System user guide... -
Page 19: 7:Gallery
B:Click to enter the main interface of the Boot play video settings，There are three options of ―Cancel auto play‖、―Play media store recycle‖、―Play single video recycle‖； ☆Supported video formats: asf/avi/flv/mov/mpeg1/mpeg2/mpg/ ts/vc/wmv/wmv9/3qp/mkv/mp4. 7:Gallery Click [Gallery] to enter into the main interface of the gallery, This will automatically scan all picture files stored on device. - Page 20 Delete Edit Slideshow Picture a senior editor ARM digital signage System user guide...
-
Page 21: 8:Webpage Browsing
8:Webpage browsing Click [Browser] to enter into the main interface of the webpage browser. System will automatically open homepage. Homepage can be setting according to your own preferences； Browser Settings Add Bookmarks The location to enter the URL Bookmarks 9:File Manager Click [File Manager] to enter into the main interface of the browser file manager，You can manage the file or folder, such as copy, name changes, etc;... -
Page 22: 10:Check The Program Running In The Background
10:Check the program running in the background Click ,Will show the program running in the background,Slip up can off the selected program. ARM digital signage System user guide... -
Page 23: 11:System Settings
11:System Settings Click [Settings] to enter into the main interface of the system settings，You can simply set system. 11-1:Wi-Fi Link Click ―Wi-Fi‖ you can turn ON/OFF Wi-Fi，when turn ON Wi-Fi, system will automatically scans the available Wi-Fi networks，Click the Wi-Fi names, enter the password to connect network. ARM digital signage System user guide... -
Page 24: 11-2:Bluetooth
11-2:Bluetooth Click ―Bluetooth‖ you can turn ON / OFF Bluetooth to pair with other Bluetooth devices. 11-3:Portable hotspot Select ―More‖—― Tethering & portable hotspot‖, you can open Internet sharing and portable hotspot function. You can turn On Protable Wi-Fi hotspot, Click ―Set up Wi-Fi hotspot‖ you can set network name (SSID) and password according to your requirement. -
Page 25: 11-4:Ethernet
Network SSID Access password 11-4:Ethernet select ―More‖—― Ethernet‖, You can access network with an external RJ45 Ethernet 11-5:Mobile networks Settings Click ―More‖—―Mobile networks‖. If you have installed the 3G module and SIM card, Check ―Data enabled‖, and click ―Network operators‖ –―Choose automatically‖. Will automatically search for the corresponding mobile 3G network and dial up connections ARM digital signage System user guide... -
Page 26: 11-6:Sound Settings
Note: Please check 3G module support list in the official website Note：Network priority in the following order:Wi-Fi > RJ45&3G，Please turn on / off the appropriate network settings Manually when you need to use. 11-6:Sound Settings Click on the "Sound" into the sound settings screen. You can set up the media player, notification, the sounds of alarm. -
Page 27: 11-7:Display Settings
11-7:Display Settings Click ―Display‖ enter into display setting, You can set your desktop wallpaper, font size, wireless display, the default orientation of screen. brightness、contrast and saturation setting Screen Rotation 11-7-A:Wi-Fi Display The wireless display feature is enabled automatically in Wi-Fi open state, otherwise disabled. If your device supports the Wi-Fi Display (Wireless Display) function, you can search for and connect to the device by the the menu or the application interface Wi-Fi Display ARM digital signage System user guide... -
Page 28: 11-7-B:default Screen Orientation
11-7-B:Default Screen Orientation This option can set the direction of rotation of the screen, the Setting values can be 0 ℃/90℃/180℃/270℃. 11-8:HDMI Settings Click ―HDMI‖ Into the HDMI interface configuration settings,You can set the HDMI output resolution, screen zoom. ARM digital signage System user guide... -
Page 29: 11-9:Storage Administration
HDMI Resolution： HDMI output resolution to match your monitor automatically,The maximum supported resolution is 1920 * 1080. Screen Zoom：This option can adjust the screen to full screen. 11-9:Storage Administration Click ―Storage‖ enter into Storage administration interface .you can Check out and manage the storage space. -
Page 30: 11-10:Apps Administration
11-10:Apps Administration Click ―Apps‖ enter into apps Administration interface, You can uninstall and move third-party applications. ARM digital signage System user guide... -
Page 31: 11-11:Location Information Access
11-11:Location information access Click ―Location access‖ you can enable or disable location services, positioning includes GPS, Wi-Fi and mobile networks. 11-12:Security Settings Click ―security‖ to control the installation of third-party applications AND certificate. Close or open automatically boot function when reset power (When the device connected to power, system will automatically boot) and USB-OTG&USB-HOST function ON/OFF. -
Page 32: 11-12-A:equipment Management
Closed or open the USB-OTG&USB-HOS boot on power-on T function switch Hide the taskbar 11-12-A:Equipment Management： Check or deactivate the device manager. 11-12-B:Source Location： Select this option when you need to install third-party unknown sources APK. 11-12-C:Validation Application： Proposed installation of a warning when installing third-party unknown sources APK. 11-12-D:Power boot：... -
Page 33: 11-13:Language & Input Method Settings
11-13:Language & Input Method Settings Click ―Language & Input Method‖ to set the system display language, keyboard and input method etc. System display language settings Keyboard and input settings 11-14:Backup and Reset Click ―Backup and Reset‖ enter into backup and reset interface, Support to back up you date on cloud(based on Google's servers). -
Page 34: 11-15:Date & Time Settings
11-15:Date & Time Settings Click ―Date & Time‖ set the device time，including automatic date &time, Automatic time zone. Also can be set manually; And set time or date format. Time and time zone set Time or date format 11-16:Accessibility Click ―Accessibility‖--―Set app when booting‖, you can set applications automatically run at system boot up, and set font size etc. -
Page 35: 11-17:Developer Options
11-17:Developer options Click ―Developer options‖ you can turn ON/OFF developing advanced functions of USB debugging and limiting background process. ARM digital signage System user guide... -
Page 36: 11-18:About Device
11-18:About device Click ―About device‖ you can quick Look ARM PC following information: Model number, firmware version, kernel version and Build number etc. 12:VCN Connected Running VNC-Viewer.exe clients, as follows: VNC Server: To enter the ARM PC IP address, such as: 192.168.0.194: 5901, ": 5901" is the port number (built-in, default unchanged) as follows: Click on "Connect", pop up the following screen, check the "Do not warn me about this again", select "Continue"... - Page 37 ARM PC can be remotely operated by the windows PC if this screen appears the following interface, detailed as follows: ARM digital signage System user guide...
