STI Wireless Driveway Monitor
Thank you for purchasing the STI Wireless Driveway Monitor. Your satisfaction is very important to us.
Please take the time to read this manual carefully to get the most from your new product.
How the products works:
Because of its patented magnetometer sensor transmitter system, the Driveway Monitor will only be
triggered by cars or trucks - not people, animals and so forth. When a vehicle passes the Motion Alert
Sensor Transmitter next to the driveway, the receiver unit inside the office or home sounds a chime
and flashes the alert light. The earth has a uniform magnetic field around it. A vehicle creates a slight
disturbance in the earth's field. The sensor transmitter detects this disturbance and transmits a signal
to the receiver.
Before you start:
Refer to this drawing to become familiar with all the parts.
SENSOR
TRANSMITTER
CAP
SENSOR
TRANSMITTER
BASE
MOUNTING
TUBE CAP
12" MOUNTING TUBE
MOUNTING STAKE
BATTERY POWERED SENSOR
TRANSMITTER
Installation and Operation Manual
Part of the Wireless Alert Series
Models:
STI-34150 - Battery Power Kit
STI-34100 - Solar Power Kit
STI-34151 - Battery Powered Sensor
STI-34101 - Solar Power Sensor
SENSOR TRANSMITTER
2 "C" BATTERIES
(NOT INCLUDED)
WALL MOUNT (INCLUDED)
NOT NEEDED FOR POLE
MOUNT INSTALLATION
SENSOR
TRANSMITTER
SENSOR
TRANSMITTER
BOTTOM
MOUNTING
TUBE CAP
12" MOUNTING TUBE
MOUNTING STAKE
SOLAR POWERED SENSOR
TRANSMITTER
— 1 —
TM
RECHARGEABLE
NiMH BATTERIES
SENSOR TRANSMITTER
BOTTOM SCREWS
WALL MOUNT (INCLUDED)
NOT NEEDED FOR POLE
MOUNT INSTALLATION
®
Advertisement
Table of Contents
Summary of Contents for STI 34150
- Page 1 STI-34151 - Battery Powered Sensor STI-34101 - Solar Power Sensor Thank you for purchasing the STI Wireless Driveway Monitor. Your satisfaction is very important to us. Please take the time to read this manual carefully to get the most from your new product.
- Page 2 Sensor transmitter can be activated by rotating and will make a faint clicking noise to verify operation. 6. Sensor should be programmed to receiver before mounting outdoors. Refer to receiver instructions for programming. (Model STI-34100 is factory programmed for your convenience.) Sensitivity Adjustment: The factory default setting (HIGH) may be adjusted by changing the jumper position inside the sensor transmitter.
- Page 3 STI-30104 the receiver. LAMP CONTROLLER (OPTIONAL) 12’ STI recommends the use of the stake and tube included with your Driveway PLACE SENSOR AC ADAPTER 3’OR TRANSMITTER 3' OR Monitor. However, if you choose to mount the unit to an alternate mounting...
- Page 4 STI-6200WIR4 Wireless Fire Extinguisher Theft Stopper w/Receiver STI-V34104 4-Channel Voice Receiver STI-6400WIR Wireless Exit Stopper Door Alarm STI-34108 8-Channel Receiver STI-6400WIR4 Wireless Exit Stopper Door Alarm with Receiver STI-34101 Solar Powered Driveway Monitor Sensor STI-6517A Stopper Station Shield with Sound STI-34151 Battery Powered Driveway Monitor Sensor...
