Sune SE-A302 Installation Manual

Audi a3 8v 7" multimedia hd capacitive touch screen

Advertisement

Quick Links

Easy Operation Manual
Audi A3 8V
7" Multimedia HD Capacitive touch screen

installation manual

CarNavi-Tech Model: SE-A302
SUNE TECHNOLOGY ELECTRONIC CO.,LTD
No.9,Lane 606,Anping Rd,Tainan City
70849,TAIWAN
TEL:+88662292246 FAX:+88662288104
Http://www.sune-tech.com
Shop http://www.carnavi-tech.com
SKYPE:sune_tech or hsin_

Advertisement

loading
Need help?

Need help?

Do you have a question about the SE-A302 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sune SE-A302

  • Page 1: Installation Manual

    Mercedes-Benz Parking Assistant System Easy Operation Manual —————————————————————————————————————————————————————————— Audi A3 8V 7" Multimedia HD Capacitive touch screen installation manual CarNavi-Tech Model: SE-A302 SUNE TECHNOLOGY ELECTRONIC CO.,LTD No.9,Lane 606,Anping Rd,Tainan City 70849,TAIWAN TEL:+88662292246 FAX:+88662288104 Http://www.sune-tech.com Shop http://www.carnavi-tech.com SKYPE:sune_tech or hsin_...
  • Page 2: Accessory List

    Accessory List Handle special camera:1pcs 7inch HD Capacitive touch screen:1pcs HD screen pcb board:1pcs Video interface built-in system:1pcs LVDS cable,Camera cable,Av in/out cable,GPS Antenna,Plug & play harness: Each 1pcs...
  • Page 3: Installation

    Installation 1.Use tool to open the front 2.Remove the screws passenger seat side of the trim 3.Remove the CD machine using the 4.Remove the screws behind the cd tool, machine red circle Remove the glove box a total of three screws at the top of the red circle...
  • Page 4 6.Remove the glove box red circle at 5.Remove the glove box near the door the bottom of two screws red circle at the fixing screws 8.Apart inside the trim, removing the 7.Open the trunk. Remove the handle screws, remove the original red circle screws handle replaced handle camera, you can replace the original car handle functions...
  • Page 5 9.Remove the red circle position two 10.Camera line from the original car side clips, remove the trim and casing through gracefully camera line 12.The camera wire and wire-ting long 11.The camera line penetrate the body butt, pulled in front of the docking module...
  • Page 6 Installation Operating Instructions 13.Remove the air conditioning 14.Tilt the screen with a rocker, as vent, turn on the screen screws, as shown above shown above 16. The first black box underneath the screen removed, then remove the black 15.Remove of the screen screws,put bars on both sides of the screen, the turn the matching circuit board, as shown on fixed firefly...
  • Page 7 19. Remove original LVDS cable(pink) from the car into the interface LVDS output, interface black LVDS cable into the original car LVDS connector another side plug into the interface LVDS input connector, the other line was inserted into the interface to the corresponding connector, as shown above 20.Start the engine Hanging reverse gear Check module is working or not...
  • Page 8 DTV,DVD Model selection DTV type -for Taiwan DTV(option) Factory IR touch code default : DVD DVR type-for Taiwan DVD DVR(option) DVD input DTV input For touch code option For touch code only for Taiwan use DVR input DTV input All function you can touch on touch All function you can touch on touch screen screen (option) to control function...
  • Page 9 Function 2.Touch the screen(more than 2sec.) or click 1.System language : English,Chinese "Menu" button(more than 2sec.),will change to multimedia system 4.DVD player or DTV input(option) 3.Click GPS or use MMI system to goto GPS sysem, will running IGO Tomtom or route66 map 5.There are Six buttons on GPS screen: 1.)Goto OEM screen 6.360 or DVR input(option)
  • Page 10 1.In addition to reversing the screen, the other screen all support touch screen operation, when the original screen switches to the multimedia interface can touch the touch screen by tapping. 2.On original screen long press "MENU" button (approximately 2 seconds) to switch to Multimedia Interface , a single finger press touch screen (about 2 seconds) can also be switched to the multimedia interface.
  • Page 11 *Press NAV button (hold more than 2 seconds): 1) Click on the GPS / digital TV / video /OEM screen *Short on the NAV button : 1) goto original MMi system Factory setting: 1.Car without AMI system 2.Car without B&O sound system PS:if your car with AMI or B&O sound system please info us after buy it(cable different).
  • Page 12: Dip Switch

    System diagram Dip switch...
