Installation and Operation Manual ASP-101-02-x Surround Sound Processor Document # 540183 7300 Industry Drive, North Little Rock, AR 72117 Phone: 501-955-2929 Fax: 501-955-2988 www.audiointl.com...
Audio International, Inc. Neither this document nor the data contained herein shall be reproduced, used, or disclosed to anyone without the written authorization of Audio International, Inc. Document #540183, Rev IR, 6/2000...
General Information Introduction This manual contains information for the proper application, installation, and operation of the Audio International, Inc. (AI), Surround Sound Processor, Model # ASP-101-02-x. The “-x” suffix in the model number designates the type of connector utilized. Also included are relative physical and electrical characteristics of the unit.
Some features are set upon installation using an external PC (typically a laptop) and an MSM2912-01-x, RS-232 / RS-485 Converter Module. A software program designed by Audio International specifically for this task sets the power-up state for each audio output, trim levels for each audio input source, and cabin audio Surround Sound Processor and FiberLink...
Inspect the unit for shipping damage. 3.2.2 If damage has occurred during shipping, a claim should be filed with Audio International within 24 hours and a Return Request Authorization Number shall be obtained from AI. Refer to the front cover of this manual for address and telephone number of Audio International, Inc.
Audio International, Inc. ASP-101-02-x Installation & Operation Cautions & Warnings 3.3.1 All analog audio output lines from the Surround Sound Processor unit shall be shielded and properly grounded. Analog audio input lines shall be shielded and grounded at the source, unless indicated otherwise.
Audio International, Inc. ASP-101-02-x Installation & Operation 3.4.3 Power Wires All power and ground wires shall be 20 AWG, MINIMUM. Power ground wires shall be grounded within twelve inches of the unit. Protect power wires with circuit breakers or fuses located close to the electrical power source bus.
Audio International, Inc. ASP-101-02-x Installation & Operation 3.5.3 The unit shall be rigidly mounted to its location using the appropriate fastening hardware supplied by the installing agency. 3.5.4 When mounting the unit to the aircraft’s frame, allow sufficient space for mating connectors.
Audio International, Inc. ASP-101-02-x Installation & Operation Pinout Assignments and Descriptions P1 Pinout Chart Pin # Description Pin # Description +28 VDC Input (Digital) Left Analog Audio Output High Ground Input Left Analog Audio Output Low Data Bus A Left Analog Audio Output Shield...
Audio International, Inc. ASP-101-02-x Installation & Operation 3.8.4 All aircraft audio functions should be tested for proper operation. If all audio functions are operational, the ASP-101-02-x has been properly installed. Refer to Section 5.0, Troubleshooting, if problems are encountered. Operation...
Audio International, Inc. ASP-101-02-x Installation & Operation Troubleshooting Chart Problem Possible Cause Solution Audio is not Audio source not selected or Ensure an active audio present in activated source input is present Unit is not properly connected Ensure the unit has been...
Audio International, Inc. ASP-101-02-x Installation & Operation Specifications Physical Specifications Housing Black Brushed Aluminum Dimensions 9.4" x 10.5" x 2.4" (l x w x h) 23.88 cm x 26.67 cm x 5.08 cm Weight 2.5 lbs / 1.13 kg Power Requirement Specifications...
Audio International, Inc. ASP-101-02-x Installation & Operation Reference Drawings The following diagrams show the unit dimensions and connector locations for the ASP-101-02-x. All dimensions are shown in inches. Document #540183, Rev IR, 6/2000 Page...
