Notice to the installer

Please give this manual to the customer after installation

Wireless Faucet Controller

Thank you for choosing TOTO

products.

Before you begin the installation,

please read through this manual

thoroughly in order to better

understand the product and its

functioning.

Warranty information is included

in this manual, please keep it in a

secure place

Warranty Registration and Inquiry

For product warranty registration, TOTO U.S.A. Inc. recommends online Warranty Registration. Please visit our web site

http://www.totousa.com. If you have questions regarding warranty policy or coverage, please contact TOTO U.S.A. Inc.,

Customer Service Department, 1155 Southern Road, Morrow, GA 30260 (888) 295-8134 or (678) 466-1300 when calling

from outside of U.S.A.

Instruction Manual

WI-TOUCH™

Important Safeguards.........3-5

Model Numbers

and Components...................6

Before Use.... . .....................7-9

How to Use..........................10

How to Adjust......................11

Maintenance ..................12-18

Troubleshooting.............19-21

Specifications......................22

Warranty ............................ 23

March 2009

TEC1DS

Table of Contents

Need help?

Do you have a question about the WI-TOUCH and is the answer not in the manual?

Questions and answers

Summary of Contents for Toto WI-TOUCH

Page 1: Table Of Contents
Warranty ......23 Warranty Registration and Inquiry For product warranty registration, TOTO U.S.A. Inc. recommends online Warranty Registration. Please visit our web site http://www.totousa.com. If you have questions regarding warranty policy or coverage, please contact TOTO U.S.A. Inc., Customer Service Department, 1155 Southern Road, Morrow, GA 30260 (888) 295-8134 or (678) 466-1300 when calling...
Page 2 DECLARATION OF CONFORMITY We Toto USA 5351 E. Jurupa St. Ontario, CA 91761 (909) 974-5678 declare under our sole responsibility that the product Wi-Touch Wireless Faucet Controller, Model TEC1DS complies with Part 15 of the FCC Rule.
Page 3: Important Safeguards
Important Safeguards (For your safety, please follow the instructions below.) Warning Do not allow the hot water temperature to exceed 140° F (60° C) or scalding may occur. Under 140° F (60° C) Do not modify or alter this product in any way. Failure to follow instructions may result in personal injury and/or property damage.
Page 4 Caution It is suggested that, after using the hot water, the faucet should be returned to cold before turning off. This is to prevent the next person from scalding themselves on hot water left in the pipes. Open Before cleaning the filter, make sure the hot water valve is closed and the solenoid valve has cooled.
Page 5 Caution Do not allow the product to freeze or become So cold! wet. Do not install outdoors. Property damage may result. Warranty does not cover damage to the product due to freezing. Always use fresh batteries in unit. Do not mix new and old batteries or use batteries of different brands together.
Page 6: Model Numbers And Components
Model Number and Components TEC1DS#GY: WI-TOUCH™ Wireless Faucet Controller Controller Battery Case Pg. 17 Manual Switch Pg. 11 Connector Hot-Side Solenoid Valve Filter Ball Nut Filter Pg. 12 Accessories Remote Control Pg. 8 - 9 Cold-Side Solenoid Valve Adhesive Base Strips...
Page 7: Before Use
Before Use Check the Shut-off valve Open the shut-off valve Check both the cold and hot shut off valves. Open Check the Batteries Controller Check that the battery case is completely inserted in the controller. Battery Case Check the Connector Check the connectors.
Page 8 Installation of the Remote Control Be Careful Do not install the remote control or the controller on a metal surface, such as stainless steel. Product may malfunction if the signal is reflected or hindered. Likewise, it may not do well in a kitchen with numerous stainless steel appliances.
Page 9 Install the battery in the remote Peel-off paper on the control. Adhesive Packing Adhere 2 adhesive base strips at the installation location. Set the Adhesive distance between them to 3 1/4” Base Strips (83mm). See bottom of page. Expose the adhesive packing on the back of the remote by peeling off the protective paper.
Page 10: How To Use
How to Use Turning the Water On and Off Open the faucet and leave it in the open position. Push the remote control. (tread) Water then flows out. Use the handle of the faucet to adjust the flow rate and temperature. Push the remote control again.
Page 11: How To Adjust
How to Adjust Change Timer Setting (If both faucet and dish washer share same supply line ) Open the faucet to a position 8Hr Setting where water can flow out. Manual Switch Stop the water flow with the remote control. Twice The solenoid valves are closed.
Page 12: Maintenance
Maintenance In order to take full advantage of the product and keep it functioning in good condition, a regular maintenance schedule should be followed. Cleaning the Filter Solenoid Valve 1. Close the hot and cold shut-off valves. Loosen 2. Open the faucet and push Ball Nut the remote control in order to relieve pressure.
Page 13 Please inspect the following to ensure safe and continued use. Check for leaks (twice a year) Check for leaks Look for stains on the floor under the pipes. A leaking pipe can cause serious damage to your property. If a leak is present, close the shut-off valve.
Page 14 Replace the battery in the remote control The remote control uses one CR2032 lithium battery. It is recommended that you replace the battery in the remote control unit at least once a year. If, however, the remote control is being used excessively, the battery may need to be changed more frequently.
Page 15 How to replace the battery Hold the remote control firmly with two hands, then turn on one Turn Slowly side to un-stick it. Remove the four screws on the Remote Control back of the remote control. Screws Remove the battery cover. Notch Insert a flat screwdriver into the notch and lift the cover.
Page 16 Clean the adhesive packing If the adhesive packing on the back of the remote control is dirty, use a damp (not wet) cloth to clean it. Allow packing to dry out before resticking the remote control. Dust may reduce the adhesive force, so it should be cleared off.
Page 17 How to replace the batteries Remove the screw from the bottom of the controller. Pull out the battery case. Take out the used batteries and replace them with a new ones. Be careful not to lose any parts while replacing the batteries. Pay attention to the polarity of the batteries and insert them correctly.
Page 18 How to stop the water in case of an emergency If a leak occurs from the solenoid valve to the faucet, turn off the shut-off valves. If there is a leak elsewhere, shut-off the main valve. Close the shut-off valves at the cold and hot sides.
Page 19: Troubleshooting
Troubleshooting In case of no battery power Push the manual switch under the controller. This operation will open the cold-side solenoid valve, so that cold water will flow Manual Switch out. While there is no battery power you may continue to use the faucet by turning it off and on with its handle.
Page 20: Before Requesting Service
The following problems and their diagnosis can be performed by the owner of the faucet without voiding the warranty. If you are unsuccessful you can request service from the installer, distributor or TOTO Technical Support. Before Requesting Service Problem Inspection...
Page 21 Before Requesting Service Problem Inspection Solution Solution Is the shut-off valve open enough? Adjust flow rate. Page 7 Is the filter blocked Clean the filter. Page 12 Water flow is too Set it to an appropriate If a hot water heater is used, is it set small to an appropriate output? output.
Page 22: Specifications
Specifications Type Battery Type DC 6V (Alkaline Size AA x 4) Power Supply Battery Duration: 1 Year (Condition: 100 times/day) DC 3V (Lithium Battery CR2032 x 1) Power for Remote Battery Duration: 1 Year Control (Condition: 100 times/day) Controller: 551001 Item Number Remote Control: 9E3014 Solenoid Valve:...
Page 23: Warranty
TOTO will not charge for labor or parts in connection with warranty repairs or replace- ments. TOTO is not responsible for the cost of removal, return and/or reinstallation of the Product.
Page 24 Warranty Registration and Inquiry For product warranty registration, TOTO U.S.A. Inc. recommends online Warranty Registration. Please visit our web site http://www.totousa.com. If you have questions regarding warranty policy or coverage, please contact TOTO U.S.A. Inc., Customer Service Department, 1155 Southern Road, Morrow, GA 30260 (888) 295-8134 or (678) 466-1300 when calling...
