LCD TV

SERVICE MANUAL

CHASSIS : LC12C
MODEL : 32LW5500
CAUTION
BEFORE SERVICING THE CHASSIS,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
P/NO : MFL67002332 (1109-REV00)
North/Latin America
Europe/Africa
Asia/Oceania
42LW5500
47LW5500
Internal Use Only
http://aic.lgservice.com
http://eic.lgservice.com
http://biz.lgservice.com
32LW5500-CA
42LW5500-CA
47LW5500-CA
Printed in China

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 32LW5500 and is the answer not in the manual?

Questions and answers

Related Manuals for LG 32LW5500

Summary of Contents for LG 32LW5500

  • Page 1: Service Manual

    Internal Use Only North/Latin America http://aic.lgservice.com Europe/Africa http://eic.lgservice.com Asia/Oceania http://biz.lgservice.com LCD TV SERVICE MANUAL CHASSIS : LC12C MODEL : 32LW5500 32LW5500-CA 42LW5500 42LW5500-CA 47LW5500 47LW5500-CA CAUTION BEFORE SERVICING THE CHASSIS, READ THE SAFETY PRECAUTIONS IN THIS MANUAL. P/NO : MFL67002332 (1109-REV00)

  • Page 2: Table Of Contents

    CONTENTS CONTENTS ....................1 SAFETY PRECAUTIONS .................2 SPECIFICATION ..................5 ADJUSTMENT INSTRUCTION .............. 8 EXPLODED VIEW ..................28 SVC. SHEET ....................Copyright 2011 LG Electronics.Inc.All right reserved. - 1 - LGE Internal Use Only Only for training and service purposes...

  • Page 3: Safety Precautions

    When the exposed metal has no return path to the chassis the reading must be infinite. An other abnormality exists that must be corrected before the receiver is returned to the customer. Copyright 2011 LG Electronics.Inc.All right reserved. - 2 - LGE Internal Use Only Only for training and service purposes...

  • Page 4: Servicing Precautions

    Alternatively, obtain and wear a commercially available discharging wrist strap device, which should be removed to prevent potential shock reasons prior to applying power to the Copyright 2011 LG Electronics.Inc.All right reserved. - 3 - LGE Internal Use Only Only for training and service purposes...
  • Page 5 3. Solder the connections. CAUTION: Maintain original spacing between the replaced component and adjacent components and the circuit board to prevent excessive component temperatures. Copyright 2011 LG Electronics.Inc.All right reserved. - 4 - LGE Internal Use Only Only for training and service purposes...

  • Page 6: Specification

    Back Light Edge LED Color depth 10Bit(D), 1.06 Billion colors Surface treatment Hard coating(2H), Anti-glare treatment of the front polarizer (Haze 10%) Copyright 2011 LG Electronics.Inc.All right reserved. - 5 - LGE Internal Use Only Only for training and service purposes...
  • Page 7 48.363 60.00 65.00 VESA(XGA) 1280*768 47.78 59.87 79.5 WXGA 1360*768 47.72 59.8 84.75 WXGA 1920*1080 66.587 59.93 138.625 WUXGA FHD model Copyright 2011 LG Electronics.Inc.All right reserved. - 6 - LGE Internal Use Only Only for training and service purposes...

  • Page 8: Hdmi Input

    HDCP 1360*768 47.72 59.8 84.75 WXGA HDCP 1280*1024 63.595 60.0 108.875 SXGA HDCP/FHD model 1920*1080 67.5 60.00 138.625 WUXGA HDCP/FHD model Copyright 2011 LG Electronics.Inc.All right reserved. - 7 - LGE Internal Use Only Only for training and service purposes...

  • Page 9: Adjustment Instruction

    W/B scale is strong. Digital pattern 13ch and/or Cross hatch pattern 09ch), there can some afterimage in the black level area. Copyright 2011 LG Electronics.Inc.All right reserved. - 8 - LGE Internal Use Only Only for training and service purposes...
  • Page 10 4.1 MAC Address 4.1.1 Equipment & Condition ▪ Play file: Serial.exe ▪ MAC Address edit ▪ Input Start / End MAC address Copyright 2011 LG Electronics.Inc.All right reserved. - 9 - LGE Internal Use Only Only for training and service purposes...
  • Page 11 4.2 LAN PORT (Automatic IP) 4.2.1 Equipment & Condition ▪ Each other connection to LAN Port of IP Hub and Jig Copyright 2011 LG Electronics.Inc.All right reserved. - 10 - LGE Internal Use Only Only for training and service purposes...
  • Page 12 ■ Connect RS232 Signal Cable to RS-232 Jack. ■ Write Serial number by use RS-232. ■ Must check the serial number at Instart menu. Copyright 2011 LG Electronics.Inc.All right reserved. - 11 - LGE Internal Use Only Only for training and service purposes...
  • Page 13 ※ Pattern Generator Signal Source ※If TV internal pattern is used, not needed 5.1.4 Adj. Command (Protocol) <Command Format> START STOP Copyright 2011 LG Electronics.Inc.All right reserved. - 12 - LGE Internal Use Only Only for training and service purposes...
  • Page 14 -> Gain adj. complete *(wb 00 20(start), wb 00 2f(endc)) -> Off-set adj. wb 00 ff ->End white balance auto adj. Copyright 2011 LG Electronics.Inc.All right reserved. - 13 - LGE Internal Use Only Only for training and service purposes...
  • Page 15 ▪ W/B Adj. must begin as start command “wb 00 00” , and finish as end command “wb 00 ff”, and Adj. offset if need Copyright 2011 LG Electronics.Inc.All right reserved. - 14 - LGE Internal Use Only Only for training and service purposes...
  • Page 16 CA-210(CH 14) Coordinate Mode Temp △uv Cool 0.0000 0.269±0.002 0.273±0.002 13000K Medium 0.285±0.002 0.293±0.002 9300K 0.0000 Warm 0.313±0.002 0.329±0.002 6500K 0.0000 Copyright 2011 LG Electronics.Inc.All right reserved. - 15 - LGE Internal Use Only Only for training and service purposes...
  • Page 17 Step 5) Remove your hand from the Eye Q II sensor and wait for 6 seconds Step 6) Confirm that “ok” pop up. If change is not seen, replace Eye Q II sensor Copyright 2011 LG Electronics.Inc.All right reserved. - 16 - LGE Internal Use Only Only for training and service purposes...
  • Page 18 1) GND & Internal Pressure auto-check preparation - Check that Power Cord is fully inserted to the SET. (If loose, re-insert) Copyright 2011 LG Electronics.Inc.All right reserved. - 17 - LGE Internal Use Only Only for training and service purposes...
  • Page 19 EQ Off Output, L/R AVL Off (Distortion=10% Clear Voice max Output) Speaker (8Ω 10.0 15.0 EQ On Impedance) AVL On Clear Voice Copyright 2011 LG Electronics.Inc.All right reserved. - 17 - LGE Internal Use Only Only for training and service purposes...
  • Page 20 2) After automatically display 3D OSD, push the OK Key. 3) Check the pattern such as in the following Fig2 without having to wear glasses. Copyright 2011 LG Electronics.Inc.All right reserved. - 19 - LGE Internal Use Only Only for training and service purposes...
  • Page 21 Skin Colour Noise Reduction Medium Digital Noise Reduction Medium Gamma Medium Black Level Auto Eye Care Real Cinema Color Gamut Wide Copyright 2011 LG Electronics.Inc.All right reserved. - 20 - LGE Internal Use Only Only for training and service purposes...
  • Page 22 Sound Mode Standard Sound Mode Infinite Sound(Off) Treble Bass Reset Digital Audio Out TV Speaker DTV Audio Setting Auto Time Clock Manual Copyright 2011 LG Electronics.Inc.All right reserved. - 21 - LGE Internal Use Only Only for training and service purposes...
  • Page 23 1. Push "IN-START" key in service remote controller. 2. Select "Tool Option 1" and Push “OK” button. 3. Punch in the number. (Each model has their number.) Copyright 2011 LG Electronics.Inc.All right reserved. - 22 - LGE Internal Use Only Only for training and service purposes...
  • Page 24 4 : 3 576i LGEND 55 (63) CCTV F 4 : 3 576i LGEND CCTV E 4 : 3 576i LGEND Copyright 2011 LG Electronics.Inc.All right reserved. - 23 - LGE Internal Use Only Only for training and service purposes...
  • Page 25 I-11 C 11 231.25 V/UHF I-41 C 41 631.25 807.25 CATV System Band Name Freq. Factory V/UHF C 02 57.75 LGEND Copyright 2011 LG Electronics.Inc.All right reserved. - 24 - LGE Internal Use Only Only for training and service purposes...
  • Page 26 Block diagram for W5500 M/B_Input Copyright 2011 LG Electronics.Inc.All right reserved. - 25 - LGE Internal Use Only Only for training and service purposes...
  • Page 27 Block diagram for LW5500 M/B_Output Copyright 2011 LG Electronics.Inc.All right reserved. - 26 - LGE Internal Use Only Only for training and service purposes...
  • Page 28 High Chassis Block diagram Tuner(GP3) Copyright 2011 LG Electronics.Inc.All right reserved. - 27 - LGE Internal Use Only Only for training and service purposes...

  • Page 29: Exploded View

    X-RADIATION, Shock, Fire, or other Hazards. Do not modify the original design without permission of manufacturer. Copyright 2011 LG Electronics.Inc.All right reserved. - 28 - LGE Internal Use Only Only for training and service purposes...
  • Page 30 Strap Setting NAND FLASH MEMORY 8Gbit 16Gbit Boot ROM Device Select - (FA4,FAD7,FAD2,FAD1) +3.3V_Normal +3.3V_Normal +3.3V_Normal 0000: ST Micro M25P or compatible Serial Flash IC102-*1 0010: 8-bit 512Mbit 512B page SLC NAND Flash devices TH58DVG4S0ETA20 IC102 0100: 8-bit 128, 256Mbit 512B page SLC NAND Flash devices TC58DVG3S0ETA00 0110: 8-bit 1Gbit 2KB page SLC NAND Flash devices R113...
  • Page 31 C257 C264 C268 C250 4.7uF 0.1uF 4.7uF 0.1uF MODEL OPTION 4.7uF +3.3V_Normal USB_AVDD33 +3.3V_Normal HDMI_AVDD33 L212 L216 external NO_FRC internal LG FRC2 BLM18PG121SN1D BLM18PG121SN1D URSA5 C283 MODEL_OPT_0 C291 C293 0.1uF 4.7uF 0.1uF MODEL_OPT_1 HIGH IC101 +0.9V_CORE LGE35230(BCM35230KFSBG) MODEL_OPT_2 +3.3V_Normal VDAC_AVDD33...
  • Page 32 C320 0.1uF DSUB_R+ C321 0.1uF INCM_R R311 IC101 LGE35230(BCM35230KFSBG) C327 0.1uF DSUB_G+ NON_BCM_CAP C328 0.1uF INCM_G R317 VI_R VI_INCM_R VI_G BCM35230_with_CAP_220pF VI_INCM_G C322 0.1uF DSUB_B+ VI_B C323 0.1uF INCM_B VI_INCM_B IC101-*1 R312 LGE35230 DSUB_HSYNC HSYNC_IN DSUB_VSYNC VSYNC_IN COMP1_Y VIDEO INCM C329 0.1uF BCM_CAP...
  • Page 33 DUAL COMPONENT IC401,IC402 1ST : EAN61667501, 2ND : EAN61570701 IC401-*1 1ST : T-K4B2G1646B_HCK0, 2ND : T-H5TQ2G63BFR-PBC IC402-*1 DDR STRAP DDR_DQ[0] DDR_DQ[1] DDR_DQ[2] DDR_DQ[3] DDR_DQ[4] +1.5V_DDR +1.5V_DDR NFM18PS105R0J NFM18PS105R0J C410 C432 JEDEC Types : DDR_DQ[0:4] 6.3V 6.3V R401 R403 R405 R407 R409 4.7K 4.7K...
  • Page 34 NEC MICOM +3.5V_ST R641 C602 C603 MICOM_DOWNLOAD 13pF 13pF X601 For Debug 10MHz P601 +3.5V_ST 12505WS-12A00 X602 MICOM_RESET 32.768KHz R615 NEC_ISP_Tx R642 +3.5V_ST 10Mhz Crystal 4.7M R617 NEC_ISP_Rx OCD1A OCD1B +3.5V_ST JTP-1127WEM R621 FLMD0 C608 0.1uF R606 C604 0.1uF R647 R607 +3.5V_ST NEC_ISP_Rx...

  • Page 35: Hdmi Cec

    DUAL COMPONENT D707,D708 1ST : 0DD184009AA 2ND : 0DSIH00028A D710,D711 BODY_SHIELD 1ST : T-BAT54_SUZHO, 2ND : 0DSON00138A D713 5V_HDMI_4 5V_HDMI_1 BODY_SHIELD HDMI_HPD_4 HDMI_HPD_1 VR708 R729 VR706 R728 HP_DET HP_DET R727 R737 C717 C714 0.1uF 0.1uF VR707 R735 R730 VR703 * HDMI CEC 3.6K 3.6K DDC_DATA...
  • Page 36 RGB/ PC AUDIO/ SPDIF/ EARPHONE/ RS232C DUAL COMPONENT EARPHON JACK +5V_Normal RGB PC D804,D805,D806 D810 KDS184 D807,D808,D813 1ST : EAH39491601, 2ND : EAH33945901 D814 D810 1ST : 0DD184009AA, 2ND : 0DSIH00028A JK803 +3.3V_Normal KJA-PH-0-0177 Q801 1ST : 0TRIY80001A, 2ND : 0TR387500AA +5V_Normal IC801 74F08D...
  • Page 37 DUAL COMPONENT Q901,Q902,Q903 1ST : 0TRIY80001A 2ND : 0TR387500AA Q904,Q905,Q906 D903,D904 1ST : EAH42720601, 2ND : EAH60994401 D905,D906 +3.5V_ST IR & KEY IR_12P IR_15P R933 EEPROM_SCL P902 P901 R920 12507WR-12L 12507WR-15L R919 D905 CDS3C05HDMI1 5.6V EEPROM_SCL R915 +3.5V_ST KEY1 R934 EEPROM_SDA EEPROM_SDA R916...
  • Page 38 WIRELESS READY MODEL DUAL COMPONENT D1001,D1002 1ST : EAH42720601 2ND : EAH60994401 Q1001 1ST : EBK61012601, 2ND : 0TRDI80002A Q1002 1ST : EBK60752501, 2ND : EBK61011501 JK1001 KJA-PH-3-0168 Wireless power WIRELESS VCC(24V/20V/17V)_1 VCC(24V/20V/17V)_2 VCC(24V/20V/17V)_3 VCC(24V/20V/17V)_4 VCC(24V/20V/17V)_1 +24V VCC(24V/20V/17V)_1 DETECT +3.3V_Normal INTERRUPT R1002 C1002...
  • Page 39 CVBS 1 PHONE JACK CVBS2 REAR JACK +3.3V_Normal R1141 R1112 AV2_R_IN 2.7K R1113 D1109 C1118 R1116 AMOTECH C1123 5.6V 470K 560pF AV1_CVBS_DET 560pF D1105 R1142 5.6V AV2_L_IN JK1102 D1110 KJA-PH-1-0177 C1119 AMOTECH R1117 C1124 5.6V M5_GND 470K 560pF 560pF JK1104 R1136 PPJ233-01 AV1_CVBS_IN...
  • Page 40 TI solution M_REMOTE OPTION +3.3V_Normal +3.3V_Normal P1302 12507WR-12L L1303 M_REMOTE 120-ohm M_REMOTE 3.3V R1321 R1322 R1323 M_REMOTE R1315 2.7K 2.7K 2.7K M_REMOTE M_REMOTE M_REMOTE M_REMOTE_RX M_REMOTE R1316 M_REMOTE_TX M_REMOTE R1317 RESET M_RFModule_RESET M_REMOTE R1318 DC_MREMOTE M_REMOTE R1319 DD_MREMOTE 3D_M_REMOTE R1320 GPIO_0 3D_GPIO_0 3D_M_REMOTE...
  • Page 41 Ethernet Block DUAL COMPONENT D1401,D1402 D1403,D1404 1ST : EAH42720601 2ND : EAH60994401 D1405,D1406 +2.5V_BCM35230 L1401 MLB-201209-0120P-N2 JK1401 XRJH-01A-4-DA7-180-LG(B) C1401 0.1uF EPHY_TDP EPHY_TDN EPHY_RDP EPHY_RDN D1401 D1402 D1404 D1406 5.5V 5.5V 5.5V 5.5V LAN_ESD LAN_ESD LAN_ESD LAN_ESD R10[GND] +3.3V_Normal YL_C EPHY_ACTIVITY...
  • Page 42 +3.3V_Normal AMP_RESET_N DUAL COMPONENT C1834 1000pF Q1801 1ST : 0TRIY80001A 2ND : 0TR387500AA L1803 +24V_AMP BLM18PG121SN1D R1851 AUD_MASTER_CLK +24V_AMP +24V C1881 C1842 C1846 C1848 0.01uF 0.1uF 0.1uF 10uF C1832 C1883 10uF 0.1uF L1801 SPK_L+ MLB-201209-0120P-N2 D1805 1N4148W R1823 R1834 L1810 100V R1839 10.0uH...
  • Page 43 DUAL COMPONENT Q1901 1ST : 0TRIY80001A 2ND : 0TR387500AA Q1902 1ST : EBK60752501, 2ND : EBK61011501 IC1904 1ST : 0ISTLPH062A, 2ND : EAN40055001 PCM_MDI[0-7] CI_MDI[0-7] Close to BCM35230 PCM_MDI[0] R1909 22 OPT CI_MDI[0] CI_MDI[1] R1910 PCM_MDI[1] 22 OPT BCM INT Demod AR1903 22 OPT PCM_MDI[2]...
  • Page 44 H/NIM & F/NIM & T/C/S2 Combo Tuner DUAL COMPONENT OPTION TABLE IC2204 1ST:T-AP2114H(EAN61573601) / 2ND:T-TJ3940S (EAN61573501) H/NIM H/NIM H/NIM F/NIM_CN F/NIM_Brazil DVB-T/C/S2 F/NIM_T/C F/NIM_T2 (Brazil,Taiwan) (AU,Latin) (China) (Brazil) (Eu,Aisa) (EU) NON_DVB_S: use H/NIM and F/NIM DVB_S: use DVB-T/C/S2 combo Tuner Non_DVB_S Non_DVB_S Non_DVB_S...
  • Page 45 DVB-S2 LNB Part Allegro (Option:LNB) D2301 D2304 SMAB34 SMAB34 +12V_LNB C2307 C2302 C2324 C2305 0.01uF 68uF 68uF L2301 33UH C2312 SP-7850_33 DCDC_GND and A_GND are connected close to Boost pin(#1) C2311 0.1uF 2.4A 10uF DCDC_GND and A_GND are connected in pin#27 close to VIN pin(#25) DCDC_GND PCB_GND and A_GND are connected...
  • Page 46 DUAL COMPONENT Q2502,Q2503 Q2504,Q2506 1ST : 0TRIY80001A 2ND : 0TR387500AA Q2507,Q2508 Q2501 1ST : EBK61012701, 2ND : EBK58172301 1ST : 0TRIH80004A, 2ND : EBK61012501, 3RD : 0TR102009AM Q2505 D2513 1ST : T-BAT54_SUZHO, 2ND : 0DSON00138A Full Scart(18 Pin Gender) +5V_Normal +3.3V_Normal IN CASE OF SMALL= 15V +12V...
  • Page 47 NON CHB TS Output CHBO_TS_SERIAL CHBO_TS_CLK CHBO_TS_VAL_ERR CHBO_TS_SYNC CHB_RESET SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS BCM35230 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR NON CHB THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
  • Page 48 DUAL COMPONENT China Hotel Option Q2901 1ST : EBK61012601 2ND : 0TRDI80002A +24V_AMP P2901 12505WS-09A00 CN_HOTEL R2904 0 CN_HOTEL C2901 0.1uF CN_HOTEL AUDIO_R +3.3V_Normal CN_HOTEL R2903 0 AMP_RESET_N R2902 CN_HOTEL AMP_MUTE_HOTEL Q2901 R2901 200 MMBT3904(NXP) AMP_MUTE_HOTEL CN_HOTEL CN_HOTEL SPK_R+_HOTEL SPK_R-_HOTEL SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
  • Page 49 LVDS LOCAL DIMMING P3501 [51Pin LVDS OUTPUT Connector] FI-RE51S-HFK-A [41Pin LVDS OUTPUT Connector] [To LED DRIVER] +3.3V_FRC R3512 2D/3D_CTL LGD_2D/3D_CTRL LVDS_SEL P3503 +3.3V_Normal R3509 12507WR-08L +3.3V_Normal R3511 3.3K PLACE SERIAL RESISTORS CLOSE TO URSA4 AUO_65_MIRROR R3501 R3510 AUO_65_MIRROR 3.3K LVDS_SEL P3502 LVDS_SEL_HIGH FI-RE41S-HFK-A...
  • Page 50 VDDC10 +1.5V_FRC_DDR +1.5V_FRC_DDR +1.26V_FRC VDDC10 [SPI FLASH(2Mbit)] +3.3V_FRC L5205 CIC21J501NE C5210 C5211 C5243 C5225 C5228 C5213 C5244 C5231 C5232 C5234 C5247 C5201 0.1uF 0.22uF 0.1uF 0.1uF 0.1uF 0.1uF 22uF 22uF 0.22uF 0.1uF 0.1uF IC5202 6.3V 6.3V 6.3V R5244 R5246 W25X20BVSNIG PLACE TERMINATION RESISTORS CLOSE TO URSA5 4.7K +1.26V_FRC...
  • Page 51 +1.5V_FRC_DDR Close to DDR Pin R5301 +1.5V_FRC_DDR +1.5V_FRC_DDR MVREFCA DDR3 1.5V De-Cap Place near Memory R5302 C5301 0.1uF C5303 C5304 0.1uF 22uF Place the serail damping resistors +1.5V_FRC_DDR in the middle of DRAM pattern Place Close to DDR Pin R5303 MVREFDQ R5311 FRC_DMU...
  • Page 52 CORE +1.26V_FRC +1.5V_FRC TYPICAL 980mA TYPICAL 350mA +3.3V_FRC +1.5V_FRC_DDR +3.3V_FRC +12V IC5401 +1.26V_FRC IC5403 R5405 AOZ1072AI AP7173-SPG-13 HF(DIODES) L5403 POWER_ON/OFF2_2 3.6uH R5409 L5402 [EP] NR8040T3R6N PGND LX_2 CIC21J501NE R5414 LX_1 4.3K R5406 3.3K C5406 C5407 R5404 0.1uF AGND R5415 R5407 C5412 C5414 3.9K...
  • Page 53 MLB-201209-0120P-N2 OUT_2 2 IN_1 120-ohm OUT_1 3 IN_2 R5502 C5505 C5501 4 EN C5502 2.7K 100uF 10uF 0.1uF SIDE_USB_CTL2 3AU04S-305-ZC-(LG) JK5501 SIDE_USB_OCD2 WIFI_DM WIFI_DP D5501 D5502 CDS3C05HDMI1 CDS3C05HDMI1 5.6V 5.6V COMMON JP FOR WIFI MODEL JP1201 JP1202 JP1203 +3.3V_Normal JP1204...
  • Page 54 M1-*3 M1-*2 M1-*1 MDS62110206 MDS62110208 MDS62110210 MDS62110204 GASKET_6.5T GASKET_5.0T GASKET_4.5T GASKET_5.5T M2-*2 M2-*1 M2-*3 MDS62110208 MDS62110206 MDS62110210 MDS62110204 GASKET_4.5T GASKET_6.5T GASKET_5.0T GASKET_5.5T M3-*3 M3-*1 M3-*2 MDS62110206 MDS62110208 MDS62110210 MDS62110204 GASKET_6.5T GASKET_4.5T GASKET_5.0T GASKET_5.5T M4-*2 M4-*1 M4-*3 MDS62110208 MDS62110206 MDS62110210 MDS62110204 GASKET_4.5T GASKET_6.5T GASKET_5.0T...
  • Page 55 DUAL COMPONENT +12V PANEL_POWER FROM LIPS & POWER B/D Q501,Q504, 1ST : 0TRIY80001A 2ND : 0TR387500AA L511 TYP 1450mA Q505,Q506 12V_PANEL +3.5V_ST RT1P141C-T112 MLB-201209-0120P-N2 1ST : 0TRIH80004A, 2ND : EBK61012501, 3RD : 0TR102009AM Q502 Q502 PANEL_VCC C551 Q507 C550 1ST : EBK60752501, 2ND : EBK61011501 0.1uF R508 0.01uF...
