Page 1: Table Of Contents
Page 19/ Maintenance Page 20/ General warranty terms and conditions Reproduction of this manual, or any part thereof, in any form, without the prior written permission of DEGA CZ s.r.o. is prohibited. DEGA CZ s.r.o. reserves the right to alter the specifications of the hardware and software described in this manual at any time and without prior notice.
Page 2: For Your Protection
Use the transmitter only with the appropriate certified DEGA products The device is certified and is technically and functionally suitable for authentic „DEGA“ accessories. In the event that the device is utilised with other products the manufacturer shall not liable for any damages that this may cause.
Page 3: Technical Data And Information
Cable for connecting the DEGA ZC II flood sensor: 4x1mm2 (max.100m) or UTP cat. 5e Cable for connecting the DEGA NBx-yL II external transmitter: 3x1mm2 (max. 600 m) 3x1,5mm2 (max. 1100 m) Note: In case of the need to connecting transmitters to a compact detector over a greater distance, please contact the manufacturer.
Page 4: Operational And External Conditions (Csn 33 2000-5-51)
„Operation of the compact detector“ DEGA05-V - Circuit for controlling the emergency valves When using the detector for switching on an emergency valve (e.g. the DEGA HV-DNX) it is necessary to order this circuit with the basic version. PAGE 4...
Page 5: Terminology
These sensors have a favourable selectivity and the capacity to detect very low concentrations of gases. In the DEGA systems they are utilised primarily for the detection of toxic gases. DEGA05-2-AC-x-CL with a catalytic sensor (Pelistor) These work on the principle of catalytic combustion –...
Page 6: Basic Types
BASIC TYPES Identification system of the transmitter: DEGA 05L Gas transmitter DEGA 05L-2-AC-x-yL The product type (DEGA 05L) 2-level detection Power supply 230 V AC The type of gas detected A type of sensor with a linear output DEGA05L-2-AC-x-CL (Catalytic sensor)
Page 7 DEGA05L-2-AC-x-EL (Electrochemical sensor) The type of sensor Detected gas Measuring range Standard alarm setting on the controller level 1: 45 ppm, level 2: 130 ppm, ALARM „PEL“: in accordance with CSN 50 291: 120min./30ppm Application: Detection in residential buildings If required the „PEL“ ALARM can also be set: 0 - 300 ppm DEGA05-2-AC-C-EL Carbon monoxide (CO)
Page 8 DEGA05L-2-AC-x-IL (Infrared sensor) The type of sensor Detected gas Measuring range Standard alarm setting on the controller Carbon Dioxide (CO2) 0 - 5 % vol. DEGA05-2-AC-CO2-IL level 1: 1,0%, level 2: 2,5% /Biogas (CO2) (0-100 % vol.) Methane (CH4) 0 – 100% LEL / Natural Gas (CH4) DEGA05-2-AC-M-IL level 1: 10% LEL, level 2:20% LEL...
Page 9: Description Of The Product
Reset button for the acoustic alarm detector Spanner for the assembly and disassembly of the detector Piezo-buzzer (It is necessary to remove it from the mounting plate prior to assembly!) DEGA KD (the mounting plate) Openings for mounting onto the wall PAGE 9...
Page 10 Concentration displayed * This function is activated only in the event of connecting an external DEGA05-Tc temperature sensor / an external DEGA ZcII flood sensor. ** This function is activated only in the event of the detection of toxic gases (e.g. carbon monoxide (CO) etc.).
Page 11: Installation, Assembly And Disassembly Of The Detector
± 15°. The DEGA 05L-2-AC-C-EL compact detector for the detection of carbon monoxide (CO) should be placed 150-160 cm above the floor-level. The DEGA 05L-2-AC-M-CL compact detector for the detection of methane (CH4), natural gas, CNG should be placed just below the ceiling.
Page 12: Assembly Of The Detector
2. Unscrew the two screws (where the black arrows are) and remove the plastic cover in a direction towards you 3A. Assembly of the detector directly to the wall (without utilising the DEGA KD mounting plate) The uncovered base can be installed, using a pair of dowels or screws, at the location recommended in accordance with the type of gas detected.
Page 13 3B. Assembly of the detector on the mounting plate. Remove the spanner from the central part of the mounting plate and retain it (you will need it for the disassembly of the detector); using four screws or dowels, attach the mounting plate in accordance with the type of gas detected and install the detector onto the mounting plate.
Page 14 The relay for acoustic/optical signalling The temperature relay (functional only when ordering the „DEGA05-Tc“ Terminal block for connecting the additional „DEGA internal temperature sensor) NBx-yL II“ transmitter Power supply: AC (connect the phase conductor to one terminal and the neutral conductor to the other...
Page 15: Disassembly Of The Detector
6. Attach the connector in the upper part and slide it to the central part. The assembly of the compact detector is then completed. Disassembly of the detector In the variant that does not require using the mounting plate (DEGA KD) Disconnect all the cables and then dismantle the transmitter by unscrewing the lower part of the DEGA05 from the wall.
Page 16: Sending The Detector For The Calibration
Sending the detector for CALIBRATION At least once a year it is necessary to calibrate the detector and, in the case of choosing the calibration of the detector without any physical intervention in the area of its application, it will be necessary to send the detector to the manufacturer or to an authorised service centre for calibration.
Page 17: Functions Of The Compact Detector
The compact detector remains in this mode during most of its operation. The information displayed on the LCD display is related primarily to the actual sensor that is inside the compact detector. If the external DEGA NBx-yL II transmitter is installed, displaying data from it, can be achieved by pressing .
Page 18: Detection Of Critical Temperatures
EXTERNAL GAS DETECTION TRANSMITTER One external transmitter of the DEGA NBX-yL II type can be connected to a device, communicating through an analogue 4-20 mA current loop. When purchasing a compact detector with an additional transmitter the function of the additional sensor is activated and the “[CHANNEL]”...
Page 19: Operation
THE STATUS OF THE REQUIRED SERVICE INTERVENTION (CALIBRATION OF TRANSMITTERS) The compact detector is provided with automatic monitoring of the calibration periods of the gas transmitters. Following the expiration of 12 months since the last calibration of the internal transmitter or the external sensor the user is alerted to the necessity of recalibration.
Page 20: General Warranty Terms And Conditions
DEGA products that have been used in association with other than original DEGA products, including consumables and accessories, bearing additional parts or consumables (e.g.

DEGA 05L-2-AC-x-yL Instruction Manual
