Page 1: User Manual
WTC 200 Precision Balance WTC 600.1 Precision Balance WTC 2000 Precision Balance WTC 3000 Precision Balance USER MANUAL ITKU-95-03-11-16-EN www.radwag.com... - Page 2 NOVEMBER 2016 - 2 -...
-
Page 3: Table Of Contents
CONTENTS 1. GENERAL INFORMATION .......................... 5 2. PRECAUTIONS ............................5 2.1. Maintenance ............................5 2.2. Battery ..............................5 3. WARRANTY CONDITIONS .......................... 6 4. BALANCE DESIGN ............................6 4.1. Dimensions ............................6 4.2. Connection Cables - Diagrams ......................8 4.3. Connectors Description ........................8 5. - Page 4 19. MISCELLANEOUS ........................... 29 19.1. Backlight ............................30 19.2. 'Beep' Sound ............................. 30 19.3. Automatic Shutdown ......................... 30 19.4. Date ..............................31 19.5. Time ..............................31 19.6. Date Format ............................32 19.7. Time Format............................32 19.8. User Menu Default Settings ......................32 20.
-
Page 5: General Information
WTC balance is equipped with an internal battery (comes standard), so it does not have to be connected to the mains. WTC balance is equipped with the following interfaces: RS 232, USB type A, USB type B. The interfaces enable cooperation between the balance and peripheral devices (e.g. -
Page 6: Warranty Conditions
Notice: Symbols on accumulators identify harmful compounds: Pb = lead, Cd = cadmium, Hg = mercury. 3. WARRANTY CONDITIONS A. RADWAG feels obliged to repair or exchange all elements that appear to be faulty by production or by construction, B. Defining defects of unclear origin defects and means of their elimination can only be realized with assistance of manufacturer and user representatives, C. - Page 7 Fig.1. Dimensions of WTC 200 precision balance. Fig.2. Dimensions of WTC 600.1, WTC 2000 and WTC 3000 precision balances. - 7 -...
-
Page 8: Connection Cables - Diagrams
4.2. Connection Cables - Diagrams Fig. 3. Interfaces view DC IN - power outlet RS232 - RS 232 connector USB 2 - USB 'device' connector USB 1 - USB 'host' connector 4.3. Connectors Description Pin2 – RxD RS 232 DB9/M Pin3 –... -
Page 9: Start-Up
6. START-UP 6.1. Levelling • Prior first use level the balance. To level a balance turn its feet, keep turning the feet until the air bubble takes central position. 6.2. Powering the Device Caution: Balance can be connected to the mains only with a power adapter that comes standard with the particular model. -
Page 10: Battery Power
6.4. Battery Power • Simultaneously press keys. • Battery power given in % is displayed for 2s. • Wait for the home screen to be displayed. 7. MAINTENANCE ACTIVITIES Disassembly a weighing pan and other detachable components (the components differ depending on a balance type – see: UNPACKING AND INSTALLATION section). -
Page 11: Temperature Stabilization
• Any changes of temperature and humidity during operation can cause indications errors. Errors can be corrected by carrying out user adjustment. 9. KEYPAD Fig. 5. WTC series keypad 10. KEYS Press to switch the balance on/off Function button: press to select respective operation mode. -
Page 12: Program
Caution: On pressing ) keys balance menu is displayed and keys' functions change. For detailed overview of keys' functions go further down this user manual. 11. PROGRAM Main menu is divided into function groups. Function group is a group of interrelated parameters. - Page 13 3.3.2 StAb, nStAb, rEPL Save mode 3.3.3 LO Threshold 3.4. Percent weighing - 13 -...
- Page 14 3.4.1 YES, no Working mode On/Off 3.4.2 S_s, Suu Working mode 3.4.3 StAb, nStAb, rEPL Save mode 3.4.4 LO Threshold 3.5. Peak hold 3.5.1 YES, no Working mode On/Off 3.5.2 LO Threshold 3.6. Totalizing 3.6.1 YES, no Working mode On/Off 3.6.2 StAb, nStAb, rEPL Save mode...
- Page 15 6.1.6 YES, no Dashes 6.1.7 YES, no Signature 6.2. GLP Printout 6.2.1 YES, no Date 6.2.2 YES, no Time 6.2.3 YES, no 6.2.4 YES, no Tare - 15 -...
-
Page 16: Operating Balance Menu
6.2.5 YES, no Gross 6.2.6 YES, no Current result 6.2.7 YES, no Adjustment report Misc Miscellaneous no, 10, 20, 30, 40, 50, 7.1. bLbt Backlit level in [%] 60, 70, 80, 90, 100 7.2. bEEP YES, no Key sound 7.3. nonE, 1, 2, 3, 5, 10 Time-defined finish mode 7.4. -
Page 17: Return To The Weighing Mode
Press to enter particular submenu Press to select parameter that is to be modified Press to confirm introduced modifications Press to leave, parameter remains unmodified Press to move one menu level up 12.2. Return to the Weighing Mode Any changes made in balance's memory are automatically saved on return to the main window. -
Page 18: Taring
• Do not load the pan with concentrated force: • Avoid side loading, in particular side shocks: 13.1. Taring To determine net mass, put the packaging on the weighing pan. On stabilizing, press key (indication changes to zero, Net pictogram is displayed in the left upper corner): On loading the weighing pan net mass is displayed. -
Page 19: Zeroing
• Using keys set tare value, • Press key, • Balance returns to weighing mode. Tare value with '-' sign is displayed. • Tare can be entered at any moment during the weighing process. Caution: Tare cannot be entered manually when tare value is already implemented to balance's memory. -
Page 20: Units
Switching from weighing with the accuracy of the II weighing range to weighing with the accuracy of the I weighing range takes place automatically on unloading the weighing pan and returning to AUTOZERO – (symbol is displayed). II weighing range pictogram is blanked and the balance switches back to the I weighing range. -
Page 21: Balance Parameters
• Press key to view available units: Options: A. When [kg] is the main unit, then you can select the following units:: [kg, lb, N]; [lb] unavailable for verified balances, B. When [g] is the main unit, then you can select the following units:[g, ct, lb]; [lb] unavailable for verified balances, •... -
Page 22: Balance Ambient Conditions
Fast and reliable Reliable PrEc Fast FASt • Press key to confirm. Return to home screen. 14.3. Balance Ambient Conditions Parameter relating to ambient and environmental conditions in which the balance operates. If the ambient conditions are unstable (air drafts, vibrations), select 'unstable' option. -
Page 23: Tare
14.5. Tare Function enables setting appropriate parameters related with taring. Procedure: • Enter <P2.rEAd / 2.5.tArA> submenu. • Press key to view available options: Basic tare mode. Set (selected) tare value is overwritten on entering new tare value. Last tare value is stored in balance's memory. Tare value is tArF automatically displayed on restarting the balance. -
Page 24: External Adjustment
Adjustment has to be carried out: • prior weighing, • if long breaks between following measuring series occur, • if the ambient temperature has changed dynamically, • if the balance's place of use has changed. Types of adjustment: • External adjustment <1.1.CA-E> carried out with external weight of declared mass which cannot be modified. -
Page 25: Adjustment Report
• On entering and confirming the weight mass, message <UnLoAd> (unload the weighing pan) is displayed. • On unloading the weighing pan, press key. • Balance starts determining mass of an empty weighing pan. The process is signalled by dashes <- >. -
Page 26: Baud Rate
16.1.1. Baud Rate • Enter <P4.Conn / 4.1.rS / 4.1.1.bAd> submenu. • Press key to view available options: 2400, 4800, 9600, 19200, 38400, 57600, 115200. • Press key to confirm. Return to home screen. 16.1.2. Parity • Enter <P4.Conn / 4.1.rS / 4.1.2.PAr> submenu. •... -
Page 27: Continuous Transmission
17.1.2. Continuous Transmission • Enter <5.1.PC / 5.1.2.Cnt> submenu. • Press key to view available options: Continuous transmission disabled nonE Continuous transmission in basic unit. CntA Continuous transmission in current unit. Cntb • Press key to confirm. Return to home screen. 17.1.3. -
Page 28: Printouts
18. PRINTOUTS <P6.Prnt> menu enables defining printout templates of: • Adjustment report • GLP printout 18.1. Adjustment Report Printout <6.1.CrEP> menu enables declaring data that is to be printed on adjustment printout. List of data to be declared: Name Overview 6.1.1. -
Page 29: Glp Printout
18.2. GLP Printout <6.2.GLP> menu enables declaring data that is to be printed on a GLP printout. List of data to be declared: Name Overview 6.2.1. Performed weighing date. 6.2.2. Performed weighing time. 6.2.3. Net weight value of performed weighing in basic unit. 6.2.4. -
Page 30: Backlight
19.1. Backlight <7.1.bLbt> parameter enables setting display brightness. The backlight can be disabled completely. Procedure: • Enter <P7.Misc / 7.1.bLbt> submenu. • Press key to view available options, where: Maximum brightness Minimum brightness Backlight disabled. nonE • Press key to confirm. Return to home screen. 19.2. -
Page 31: Date
Automatic shutdown disabled. nonE Time in [min]. If the indication is stable during declared 1, 2, 3, 5 ,10 time, the balance is shutdown automatically. • Press key to confirm. Return to home screen. 19.4. Date <7.4.SdAt> parameter enables setting current date. Procedure: •... -
Page 32: Date Format
• Press key to confirm. Return to home screen. 19.6. Date Format <7.6.FdAt> parameter enables defining date format for printouts. Procedure: • Enter <P7.Misc / 7.6.FdAt> submenu. • Press key to view available options: Date format DD.MM.YYYY Date format MM.DD.YYYY Date format YYYY.MM.DD Date format YYYY.DD.MM •... -
Page 33: Information
• Press key to confirm.Balance restores user default settings. The process is signalled by dashes <- >. • On process completion, balance displays <7.8.dFLu> submenu. 20. INFORMATION <P8.InFo> menu comprises information on the balance. • Balance serial number – <8.1.Idb> parameter •... -
Page 34: Weighing
21.3. Weighing <UUGG> (Weighing) mode is a standard working mode that enables carrying out weighings and saving them to the database. 21.3.1. Working Mode Accessibility Press to enable or disable a working mode. Procedure: • Enter <3.1.UUGG / 3.1.1.Acc> submenu. •... -
Page 35: Lo Threshold
21.3.3. LO Threshold <3.1.3.Lo> parameter connected with automatic operation. Next measurement is saved when mass indication is below <Lo> threshold value. Procedure: • Enter <3.1.UUGG / 3.1.3.Lo> submenu. Message box for entering <Lo> threshold value is displayed. • Press key to confirm. Return to home screen. 21.4. -
Page 36: Save Mode
21.4.3. Save Mode <3.2.3.Snn> 'Save mode' parameter's settings are identical with <3.1.2.Snn> parameter's settings for 'Weighing' mode. They are described in 'Weighing' section of this user manual. 21.4.4. LO Threshold <3.2.4.Lo> 'Lo threshold' parameter's settings are identical with <3.1.3.Lo> parameter's settings for 'Weighing' mode. They are described in 'Weighing' section of this user manual. -
Page 37: Control
• Press key and select an option: Reference quantity:10 parts. Reference quantity:20 parts. Reference quantity:50 parts. Reference quantity:100 parts. Any reference quantity: - enter a value. • Press key to confirm. Message <LoAd> is displayed for 1 s. Next, the following window is displayed: •... -
Page 38: Working Mode Accessibility
21.5.1. Working Mode Accessibility <3.3.1.Acc> 'Working mode accessibility parameter's settings are identical with <3.1.1.Acc> parameter's settings for 'Weighing' mode. They are described in 'Weighing' section of this user manual. 21.5.2. Save Mode <3.3.2.Snn> 'Save mode' parameter's settings are identical with <3.1.2.Snn> parameter's settings for 'Weighing' mode. -
Page 39: Percent Weighing Against Reference Sample Mass
Caution: <Err Lo> message is displayed: 1. If value of entered low threshold (Min) is greater than high threshold value (Max). 2. If value of entered low threshold (Min) is greater than maximum capacity. 21.6. Percent Weighing Against Reference Sample Mass Working mode enables comparison of a measured sample with the reference mass. -
Page 40: Save Mode
21.6.3. Save Mode <3.4.3.Snn> 'Save mode' parameter's settings are identical with <3.1.2.Snn> parameter's settings for 'Weighing' mode. They are described in 'Weighing' section of this user manual. 21.6.4. LO Threshold <3.4.4.Lo> 'Lo threshold' parameter's settings are identical with <3.1.3.Lo> parameter's settings for 'Weighing' mode. They are described in 'Weighing' section of this user manual. -
Page 41: Peak Hold
Caution: If entered reference mass value is greater than maximum capacity, message <Err Hi> is displayed. 21.7. Peak Hold <toP> function enables snapping value of maximum force applied to the weighing pan during one loading. 21.7.1. Working Mode Accessibility <3.5.1.Acc> 'Working mode accessibility parameter's settings are identical with <3.1.1.Acc>... -
Page 42: Totalizing
21.8. Totalizing Working mode enables mass totalizing of weighed ingredients and printing totalizing report on a printer connected to the balance. It is possible to totalize max. 30 weighings (ingredients) in one process. 21.8.1. Working Mode Accessibility <3.6.1.Acc> 'Working mode accessibility parameter's settings are identical with <3.1.1.Acc>... - Page 43 • Load the weighing pan with another ingredient. On indication stabilization press key. • Sum of first and second weighings and „▲” pictogram are displayed continuously. • Press key to finish the process (with loaded or unloaded weighing pan). Message „Print?” <Prnt?> is displayed. •...
-
Page 44: Diagrams Of Connection Cables
22. DIAGRAMS OF CONNECTION CABLES Balance - EPSON printer cable Balance - computer cable 23. COMMUNICATION PROTOCOL 23.1. General Information A. A character based communication protocol balance-terminal is designed for establishing communication between a RADWAG balance and a peripheral device via RS-232C interface. B. -
Page 45: List Of Commands
D. Commands, forming the communication protocol, enable obtaining data on balance status and facilitate influencing balance operation, e.g.: acquiring measurement results from the balance, monitoring the display, etc. 23.2. List of Commands Comman Command overview Zero balance Tare balance Give tare value Set tare Send stable measurement result in basic measuring unit Immediately send measurement result in basic measuring unit... -
Page 46: Commands Overview
XX_A CR LF command understood and in progress XX_D CR LF command carried out (appears only after the XX_A command) command understood but not accessible at this moment XX_I CR LF XX _ ^ CR LF command understood but max threshold is exceeded command understood but min threshold is exceeded XX _ v CR LF ES_CR LF... - Page 47 23.4.3. Give tare value Format: OT CR LF Response: OT_TARA CR LF - command carried out Response format: 7-15 stability space space tare space unit marker Tare - 9 characters, right justification Unit - 3 characters, left justification 23.4.4. Set tare Format: UT_TARA CR LF, where TARA - tare value Response options:...
- Page 48 Response format: 7-15 stability space space character mass space unit marker Example: S CR LF – command sent from a computer S _ A CR LF – command understood and in progress S _ _ _ _ - _ _ _ _ _ _ 8 . 5 _ g _ _ CR LF - command carried out, response: mass value in basic measuring unit.
- Page 49 Response format: 7-15 stability space space character mass space unit marker Example: S U CR LF – command sent from a computer S U _ A CR LF - command understood and in progress S U _ _ _ - _ _ 1 7 2 . 1 3 5 _ N _ _ CR LF - command carried out, response: mass value in current measuring unit.
- Page 50 Response format: 7-15 stability space space stability mass space unit marker 23.4.10. Switch off continuous transmission in basic measuring unit Format: C0 CR LF Response options: command understood but not accessible at this moment C0_I CR LF C0_A CR LF command understood and carried out 23.4.11.
- Page 51 23.4.13. Lock balance keypad Format: K1 CR LF Response options: K1_I CR LF command understood but not accessible at this moment K1_OK CR LF command carried out Caution: Command is not saved on balance restart. 23.4.14. Unlock balance keypad Format: K0 CR LF Response: K0_OK CR LF - command carried out 23.4.15.
-
Page 52: Manual Printout / Automatic Printout
23.5. Manual Printout / Automatic Printout It is possible to generate printouts either manually or automatically. • Manual printout is generated for stable weighing result. Load the platform, wait for a stable result and press key. • Automatic printout is generated for stable weighing result. Load the platform, wait for a stable result. -
Page 53: Continuous Transmission
23.6. Continuous Transmission For continuous transmission mode the balance provides option of mass measurement printout in basic unit and in additional unit. The mode can be activated with command sent via interface, or by setting respective parameter values. Format of frame sent when <5.1.2.Cnt> parameter is set to CntA value: 7-15 stability space... -
Page 54: Technical Specifications
24. TECHNICAL SPECIFICATIONS WTC 200 WTC 600.1 WTC 2000 WTC 3000 Maximum capacity 200g 600g 2000g 3100g Readability [d] 0.001g 0.01g 0.01g 0.1g Tare range -200g -600g -2000g -3100g Repeatability* 0.002g 0.01g 0.01g 0.1g Linearity ±0.004g ±0.02g ±0.03g ±0.3g Stabilization time... -
Page 55: Error Messages
26. ERROR MESSAGES - E r r 2 - - Value beyond zero range. - Value beyond tare range. - E r r 3 - - Adjustment weight or start mass out of range (±1% for adjustment weight, ±10 - E r r 4 - for start mass). - Page 56 - 56 -...
