Summary of Contents for Kaiser Baas KBA04041
- Page 1 started. let’s get...
-
Page 2: Table Of Contents
Contents Introduction Features Safety notice What’s in the box Product description Getting started Transferring your media files Windows Playing a slideshow Playing video files Playing music files Playing Ebook files Explorer mode Clock and Calendar Contact us Frequently asked questions Product specifications Warranty Information... -
Page 3: Introduction
Introduction Congratulations on the purchase of your 8.0” Digital Photo Frame. This user guide will help you with the setup and playback of your photo, music and video collection. Features • 8.0 inch display with 4:3 aspect ratio • 2GB internal memory, copy files from your computer, memory card or USB memory stick directly to the internal memory •... -
Page 4: Safety Notice
Safety notice Do not place your Kaiser Baas 8.0” Digital Photo Frame in places that are exposed to oil, water or dust. Keep your Kaiser Baas 8.0” Digital Photo Frame away from heated sources such as heaters. Do not try and disassemble or remodel your Kaiser Baas 8.0” Digital Photo Frame. Doing so my cause the unit to malfunction and may void the warranty. Do not touch the power cable with wet hands or use defective power cables as it may cause electric shocks or fire. Do not drop your Kaiser Baas 8.0” Digital Photo Frame as it may cause serious damage and may void the warranty. -
Page 5: What's In The Box
What’s in the box 8.0” Digital Photo Frame USB cable Power adaptor MODE Bracket User guide Remote control... -
Page 6: Product Description
Product description Right side USB input Memory card slot DC input... - Page 7 Back side Power button Up / previous photo / previous music track / previous video Play / pause Left / volume + Right / volume - MENU Down / next photo / next Menu / return music track / next video Speaker Kensington Slot...
-
Page 8: Remote Control
Remote control Power: Turn the device on or off Return: Exit Directional button, press to display a previous photo, play a previous music track or rewind a video file Left: Directional button, press to decrease volume Down: Directional button, press to display the next photo, play the next music track or forward a video file MODE... -
Page 9: Getting Started
Getting started To prevent scratches on the display when transporting, there is a protective plastic sheet covering the screen. Please remove this before use. Connect the power adaptor to the DC input located on the right-hand side of the frame – MENU... - Page 10 Connect the other end into the mains power point – Connect the bracket into the back of the frame clockwise –...
- Page 11 Remove the plastic tab from the remote control before use – MODE...
- Page 12 When power is connected, the frame will turn on automatically. You will see the ‘Kaiser Baas’ logo and a slideshow will start playing. There are a number of picture files on the on-board memory for demonstration purposes that are accessible when selecting the ‘Favourite’ option. The demon- stration files cannot be deleted. Press the ‘Return’ button to exit the slideshow and go to the main menu. You will now...
- Page 13 Press the directional button to select ‘Setup’, press the directional button to select ‘Common’ then press the ‘Play/Pause’ button to select. You will now see the following screen –...
- Page 14 There are a number of options that you can change – Language: Change the on-screen language Background: Choose a different background colour USB mode: If you want to connect a USB memory stick to the USB port, select UDISK. If you want to connect the frame to your computer to access the on-board memory, select PC Product info: Display firmware information and how much space is available on the on-board memory Update: Update firmware when available Factory default: Select default settings Boot mode: Allows you to select which mode the frame will run when it is turned on Press the ‘Return’...
-
Page 15: Transferring Your Media Files
Transferring your media files The 8.0” Digital Photo Frame has 2GB of on-board memory. To play your photo, music and video files from the on-board memory, you need to connect the device to your computer to copy over your files. Connect the USB cable into the USB input on the device – MENU Connect the other end of the cable into a spare USB port on the computer –... - Page 16 Go to ‘Setup’, select ‘Common’, for PC connection change ‘USB Mode’ to ‘PC’ then press the ‘Play/Pause’ button to confirm. You will see a ‘Connecting with the PC’ message on the frame and the computer will detect the frame as a removable device.
-
Page 17: Windows
Windows Click ‘Start’ > ‘Computer’, you will see a ‘Removable Disk’ icon with 1.72GB free. Double click this to access the on-board memory. It is recommended to create folders as it will be easier to organise your files. Click ‘New folder’ and create a ‘Photos’ folder for your picture files, a ‘Music’ folder for your music files and a ‘Videos’ folder for your video files. You can also create sub-folders within those folders, for example, ‘Photos’... -
Page 18: Mac
On the desktop you will see this icon – It is recommended to create folders as it will be easier to organise your files. Click ‘File’ > ‘New Folder’ and create a ‘Photos’ folder for your picture files, a ‘Music’ folder for your music files and a ‘Videos’ folder for your video files. You can also create sub-folders within those folders, for example, ‘Photos’... -
Page 19: Playing A Slideshow
Playing a slideshow To play a slideshow, press the or directional buttons to select ‘Photo’, then select the location of your photo files. For the on-board memory select ‘MEMORY’. For the SD card select ‘SD’. For the USB memory stick select ‘USB’. Press the ‘Play/Pause’ button to confirm. The slideshow will automatically start playing. If you have photos in multiple sub-folders, the sub-folder that was created first will play. Press the directional buttons to select a different photo to display. - Page 20 Press the ‘On-screen menu’ button to adjust settings for playback, enable background music, zoom, rotate, brightness, transition type and slideshow duration. If you would like to display a thumbnail of your photos press the ‘Return’ button – Use the directional buttons to select a different photo to display. If you would like to play a slideshow from a different sub-folder, press the ‘Return’ button again to select a different location.
-
Page 21: Playing Video Files
Playing video files To play video files press the or directional buttons to select ‘Movie’, then select the location of your video files. For the on-board memory select ‘MEMORY’. For the SD card select ‘SD’. For the USB memory stick select ‘USB’. Press the ‘Play/Pause’ button to confirm. Select the folder that contains your video files and press the ‘Play/Pause’ button to confirm. Select a video file that you want to play and press the ‘Play/Pause’... - Page 22 Pause: Press the ‘Play/Pause’ button to pause and resume playback. When a video is paused, information about the video such as file name, file type, file size and resolution will appear on-screen. Volume: Press the or directional buttons to adjust the volume level. On-screen menu: Press the ‘On-screen menu’...
-
Page 23: Playing Music Files
Playing music files To play music files press the or directional buttons to select ‘Music’, then select the location of your music files. For the on-board memory select ‘MEMORY’. For the SD card select ‘SD’. For the USB memory stick select ‘USB’. Press the ‘Play/Pause’ button to confirm. Select the folder that contains your music files and press the ‘Play/Pause’ button to confirm. Select a music file that you want to play and press the ‘Play/Pause’... - Page 24 Previous track / next track: Press the directional button to select the previous track and press directional button to select the next track. Pause: Press the ‘Play/Pause’ button to pause and resume playback. Volume: Press the or directional buttons to adjust the volume level. On-screen menu: Press the ‘On-screen menu’...
-
Page 25: Playing Ebook Files
Playing Ebook files To play Ebook files press the directional button to select ‘Others’ then press the ‘Play/Pause’ button to select. Select the location that contains your Ebook files and then press the ‘Play/Pause’ button to confirm. Select an Ebook file that you want to display and then press the ‘Play/Pause’ button. On-screen menu: Press the ‘On-screen menu’... -
Page 26: Explorer Mode
Explorer mode Explorer mode allows you delete files and to copy files from a SD card or USB memory stick to the on-board memory. To access explorer mode, press the or buttons then press the ‘Play/Pause’ button. For the on-board memory select ‘MEMORY’. For the SD card select ‘SD’. For the USB memory stick select ‘USB’. Press the ‘Play/Pause’ button to confirm. Select the folder that you want to access and press the ‘Play/Pause’ button to confirm. You will now see the files located in the folder. -
Page 27: Clock And Calendar
Clock and Calendar To access the clock and calendar, press the directional button to select ‘Others’, to select ‘Clock’ then press the ‘Play/Pause’ button to select. press the directional button There are four viewing modes available, press the ‘Play/Pause’ button to select a different mode. Press the ‘On-screen menu’... -
Page 28: Contact Us
Contact us: Need further assistance? Please contact our friendly helpdesk staff: www.kaiserbaas.com/support helpdesk@kaiserbaas.com... -
Page 29: Frequently Asked Questions
Frequently asked questions I have pressed the power button but there is no power. Please check that you have connected the power adaptor and the mains power is turned on. The remote control is not functioning. Check that the plastic tab has been removed and the battery has been inserted correctly. It is recommended to replace the battery every 12 months. - Page 30 Which video formats are supported? A. The following video formats are supported: MPEG-2 (.mpg) Maximum resolution: 720 x 576 Frame rate: 24fps, 25fps, 29.97fps and 30fps Video bitrate: Up to 10Mbps Audio: LPCM and MP3 Audio bitrate: Up to 320kbps Divx (.divx) Maximum resolution: 720 x 576 Frame rate: 24fps, 25fps, 29.97fps and 30fps Video bitrate: Up to 4Mbps Audio: Audio bitrate: Up to 320kbps...
-
Page 31: Product Specifications
Product specifications Screen size: 8.0 inch Screen type: Digital display Resolution: 800 x 600 Aspect ratio: USB: USB 2.0 Host Picture format: JPEG (maximum resolution 9000 x 9000) Picture capacity: Maximum 1000 picture files Video format: MPEG-2, Divx, Xvid (maximum resolution 720 x 576) Audio format: Memory cards: SD, SDHC (maximum 32GB) Language: English, Chinese Working temperature:... -
Page 32: Warranty Information
Warranty information A. AUSTRALIAN WARRANTY The warranties and conditions below apply to products sold in Australia only. B. THE KAISER BAAS TWELVE (12) MONTH WARRANTY In relation to your purchase of a Kaiser Baas Product (“Product”), in addition to any warranties/guarantees that cannot by law be excluded, Kaiser Baas warrants to you that subject to the conditions and exclusions below, Kaiser Baas will, at its option, repair or replace any Product which is defective and is returned to Kaiser Baas within twelve (12) months of the date of purchase. C. DETAILS OF WARRANTOR The details of the Warrantor are as follows: • Warrantor:... - Page 33 D. PROCEDURE FOR WARRANTY CLAIMS To make a warranty claim, you must: (1) Deliver or send the defective Product to Kaiser Baas at its address shown above, together with proof of purchase in the form of a dated receipt or tax invoice, and a description of the Product’s defect/s. It is your responsibility to ensure that in delivering the defective Product to Kaiser Baas, the Product is suitably packaged so that it is adequately protected against damage during transit. (2) Prior to delivering the defective Product to Kaiser Baas, you should (if applicable), remove all files or data stored on the Product which you consider private or confidential.
- Page 34 E. EXCLUSIONS FROM TWELVE (12) MONTH WARRANTY The Kaiser Baas twelve (12) month warranty does not apply if the Product: • Is modified or tampered with; • Is damaged by act of God, power surge, misuse, abuse, negligence, accident, mishandling, wear and tear, misapplication, or other causes unrelated to defective materials or workmanship; • Is damaged by programs, data, viruses or files, or during shipment; • Is not used in accordance with the accompanying documentation and instructions; • Is repaired, modified or altered by anyone other than Kaiser Baas; • Is on-sold, assigned, transferred or leased to a third party. F. EXCLUSIVE REMEDY It is a condition of the Kaiser Baas twelve (12) month warranty that in making your claim: (1) Kaiser Baas is not liable to you for any loss of your data or information stored on the Product resulting from the repair or replacement of the Product; and (2) The repair or replacement of the Product is your exclusive remedy. G.
- Page 35 created by any other documents or packaging. No information (oral or written) or statements made by Kaiser Baas, its agents or suppliers, or its or their employees are to be taken as amounting to a warranty or condition or expanding the scope of the Kaiser Baas twelve (12) month warranty, and if any such information or statements have been made they are hereby withdrawn. H. CONSUMER RIGHTS You may have the benefits of other rights and remedies pursuant to law in relation to your purchase of the Product in respect of which liability may not be excluded or restricted.
