Installation Guide

PRODUCT #:

LM917135

FEATURES:

Treat your clients to the Biarritz, featuring plush comfort, Italian design, and a noiseless water pump. For comfort, the

adjustable seat reclines and swivels. For pedicures, the acrylic spa has 2 SaniJet pipeless water jet assemblies plus an

adjustable footrest and hand sprayer. For manicures, hand baths and manicure rests are included. Patented adjustable

headrest. (shown with Limoge stool, see below) The SaniJet water jet assemblies are completely removable for

maximum hygiene, and so quiet the sound of flowing water is barely audible. Since the water pump is included in each

assembly there is no internal piping to allow stagnant water or bacteria buildup. Marine grade vinyl fabric (shown in

Teak) is available in wide range of colors. 110V AC. 60" long (71" with seat fully reclined) x 37" wide x 54" high. Requires

3/4" Hot and Cold water supply and 1 1/2" drain connection. 1 Year parts and labor (excluding fabric), 2 Year shell. UL,

CE and CSA Certified. Oversized item - ships by Truck.

SPECIFICATIONS:

Dimensions:

Electrical:

Suggested Outlet:

Plumbing:

Notes:

Warranty:

Certifications:

Country of Origin:

Installed By:

www.spaequip.com

ITEM:

Biarritz Pedi Pipeless Spa from

Cosmopro

Upright 56" L x 36.5" W x 54" H; Reclined up to 73" L x 36.5" W x 50" H

115V AC - North America; 200-240V AC, 15 Amps - International; 50/60 Hz, GFCI

Hard wired, GFI

3/4" hot & cold, 1 1/2" (38mm) PVC floor drain for waste

See detailed specifications

CO: 1 Year parts and labor (excluding fabric), 2 Year shell

UL, CSA, CE

United States

Client's Contractor

P: 707.737.1100 F: 707.737.1150

Cosmopro

SOURCE FOR PURCHASE:

SpaEquip, Inc.

211 Wappo Ave.,

Calistoga, CA 94515

p: 707.737.1100

f: 707.737.1150

www.spaequip.net

LIST PRICE (USD):

Product Code: LM917135

Page 1 of 18

Table of Contents

Need help?

Do you have a question about the LM917135 and is the answer not in the manual?

Questions and answers

Summary of Contents for CosmoPro LM917135

Page 1 Product Code: LM917135 Installation Guide ITEM: PRODUCT #: Biarritz Pedi Pipeless Spa from LM917135 Cosmopro Cosmopro SOURCE FOR PURCHASE: SpaEquip, Inc. 211 Wappo Ave., Calistoga, CA 94515 p: 707.737.1100 f: 707.737.1150 www.spaequip.net LIST PRICE (USD): FEATURES: Treat your clients to the Biarritz, featuring plush comfort, Italian design, and a noiseless water pump. For comfort, the adjustable seat reclines and swivels.
Page 2: General Overview
Product Code: LM917135 General Overview Photo #1 3 - Biarritz™ Installation Manual v.1.3 www.spaequip.com P: 707.737.1100 F: 707.737.1150 Page 2 of 18...
Page 3 Product Code: LM917135 General Overview Item Descriptions (See Photo #1) 1) Tub Fill Port 2) Hand Shower 3) Hand Shower Flow Control 4) Basin Fill Valve 5) Footrest Height Adjusting Hand Screw 6) Footrest Receiver 7) Thermostatic Control Valve 8) Jet Pump On / Off Control...
Page 4: Installation Requirements
Product Code: LM917135 Installation Requirements LOCATION: IMPORTANT NOTE: This system has been designed to be installed as a free standing unit and should be located on a suitable, structurally sound and stable floor of concrete or similar non-combustible material. The entire system containing water at normal operating level, without the client, weighs approximately 282 lbs (128 kg).
Page 5 Product Code: LM917135 Plumbing Connections PLUMBING CONNECTIONS: Drain connection (waste line) is by means of the 1 1/2 inch (38 mm) PVC drain assembly (See Photo #3). Connect to drain in accordance with local and national plumbing code requirements. IMPORTANT NOTE: We recommend the use of anti-slip graded tiles on surrounding floor surfaces.
Page 6: Very Important
Product Code: LM917135 Electrical Connections ELECTRICAL CONNECTIONS: WARNING: RISK OF ELECTRIC SHOCK THIS SYSTEM MUST BE CONNECTED TO A SUITABLE ELECTRICAL SUPPLY SOURCE IN ACCORDANCE WITH LOCAL AND NATIONAL ELECTRICAL CODES. The branch circuit supplying this system must be provided with a main disconnect in the fixed wiring.
Page 7 Product Code: LM917135 Electrical Connections ELECTRICAL CONNECTIONS (see Photo # 4A-C) N. American European VOLTAGE VOLTAGE 110V-115V 200V-230V CURRENT CURRENT 6 AMPS 3 AMPS FREQUENCY FREQUENCY 60 Hz 50 Hz PHASES PHASES / 3 Wire / 2 Wire IMPORTANT NOTE: THERE ARE NO USER SERVICEABLE PARTS ON OR INSIDE THIS SYSTEM.
Page 8: Seat Installation
Product Code: LM917135 Seat Installation Photo #5 CHAIR INSTALLATION: 1. Position chair assembly as shown in Photo #5. 2. Align attaching bolts of chair base with pre-drilled holes in base assembly shell. 3. Using supplied nuts and washers (4 each), install from the underside and secure/ tighten using a 1/2”...
Page 9 Product Code: LM917135 Ventilation VENTILATION This system is designed to be normally operated and cooled by the designed ventilation means, allowing normal air flow beneath and around electrical and jet pump assemblies. Additionally, each adjustable foot may be used to level the entire unit during installation.
Page 10 73” FRONT 185.4 cm (In the reclined position) This information is provided as a guide only. Cosmopro, Inc., as supplier, reserves the right to amend specifications without prior notice. Updated 10.06.05 11-Biarritz™ Installation Manual v.1.3 www.spaequip.com P: 707.737.1100 F: 707.737.1150...
Page 11 Product Code: LM917135 Installation and Testing Procedures • Remove all packaging material and inspect system thoroughly to ensure that no damage has occurred during handling/transportation. In the event of damage due to shipping, immediately notify the freight carrier so that an appropriate claim may be filed with the carrier.
Page 12 Product Code: LM917135 Installation and Testing Procedures • Press the pump on /off speed control button (See Photo #9) to allow the system to operate for approximately fifteen (15) minutes, while thoroughly inspecting the system’s plumbing for leaks that may have been caused as a result of mishandling during transportation. If leaks are detected, turn the system off by depressing the pump on/off control button.
Page 13: Important Safety Instructions
Product Code: LM917135 Important Safety Instructions WARNING : When using this unit, basic precautions should always be followed, including the following: CAREFULLY AND THOROUGHLY READ AND FOLLOW ALL INSTRUCTIONS . WARNING: This hydrotherapy pedicure spa is designed for your safety, comfort, and relaxation.
Page 14: Warranty
Product Code: LM917135 Warranty 1 Year on Components Parts manufacturing defects. Manufacturer reserves the right to repair or replace defective parts. *PLEASE NOTE: All parts subject to warranty must be returned to the address below for proper credit to your account. Unused non-warrantied parts that are returned and in original containers may be subject to restocking fees.
Page 15: Technical Specifications
Product Code: LM917135 Technical Specifications EQUIPMENT, MATERIALS DIMENSIONS, CAPACITIES & CONTROLS & WARRANTIES 2 SANIJET ® Assemblies: Dimensions: • (Upright) 56" (144 cm) L x Pump/ Motor: 42" (108 cm) W x • 2 each 1/10 HP AC Industrial Duty 57"...
Page 16: Limited Warranty
Techno-Spa. After ninety (90) days, Techno-Spa’s liability under this warranty shall be limited to repairing or providing replacement parts, at Cosmopro’s option, without charge to the original purchaser, F.O.B. Techno-Spa’s facilities. Techno-Spa will not be liable for any costs of removal, installation, transportation, or other charges that may arise in connection with a warranty claim.
Page 17: Troubleshooting Guide
Product Code: LM917135 Troubleshooting Guide Important U.S. Version This System is supplied with a 3 connector Plug and must be connected to a 115 volt, 60 Hz, standard power outlet. Problem Solution No Power to Biarritz Check in house breaker panel, make sure breaker is on.
Page 18: Important Note
Product Code: LM917135 Troubleshooting Guide Jets make Noise when in Operation Make sure Pump Impellers are installed correctly. Make sure water level is above impeller housings. No Hot Water in Biarritz Basin Check for Hot water on feed pipe to Biarritz.
