FR6822+ Frames
Installation and Operation Manual
Edition E
175-100048-00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FR6822+ and is the answer not in the manual?

Questions and answers

Summary of Contents for Harris FR6822+

  • Page 1 FR6822+ Frames Installation and Operation Manual Edition E 175-100048-00...
  • Page 3 FR6822+ Frames Installation and Operation Manual Edition E July 2011...
  • Page 4 Mason, OH USA 45040 Harris Corporation reserves the right to revise this documentation and to make changes in content from time to time without obligation on the part of Harris Corporation to provide notification of such revision or change. UNITED STATES GOVERNMENT LEGEND If you are a United States government agency,...

  • Page 5: Table Of Contents

    6800+ETH Resource Module ..................5 Signal Flow ........................7 Chapter 2 Installation ....................... 9 Unpacking the Frame ....................9 Checking the Packing List ..................9 Available Frame Configurations ................10 Choosing 6800+ETH Upgrade Options ..............10 Copyright © 2008-2011, Harris Corporation...
  • Page 6 Discovering Frames and Modules Using a CCS Application ........32 Monitoring 6800+ Modules in CCS Navigator ............33 Using Q-SEE Compliant Modules in FR6822+QXFE Frames ........33 Upgrading Module Firmware Using CCS Software ........... 37 Correcting a Failed Upgrading Procedure ..............40 Activating a 6800+ETH License in CCS Software ............
  • Page 7 FR6822+ Frames Installation and Operation Manual Control and Monitoring FR6822+QXFE Using SNMP ..........60 Configuring SNMP Settings Using HTTP ..............61 Configuring SNMP Agent and System Settings ............64 Configuring SNMP Settings in CCS Software ............64 Configuring Third-Party SNMP Software Control ............66 Monitoring and Control Using MIBs .................
  • Page 8 Contents Copyright © 2008-2011, Harris Corporation...

  • Page 9: Preface

    September 2008 Initial release December 2008 Updates to firmware upgrade section August 2009 Addition of temperature sensing submodule February 2010 Addition of security features and video streaming to HTTP browser July 2011 Reformatting; parallel software upgrade Copyright © 2008-2011, Harris Corporation...

  • Page 10: Writing Conventions

    Remove all packaging material from the product and its associated components before you install the unit. Keep at least one set of original packaging, in the event that you need to return a product for servicing. Copyright © 2008-2011, Harris Corporation...

  • Page 11: Product Servicing

    Spare parts supplied for the repair and upgrade of equipment sold before July 1, 2006 are exempt from the legislation. Equipment that complies with the EU directive will be marked with a RoHS-compliant emblem, as shown in Figure P-1. Figure P-1 RoHS Compliance Emblem Copyright © 2008-2011, Harris Corporation...

  • Page 12: Waste From Electrical And Electronic Equipment (Weee) Compliance

    If this product has a provision for external earth grounding, it is recommended that the frame be grounded to earth via the protective earth ground on the rear panel. IMPORTANT! Only qualified personnel should perform service procedures. Copyright © 2008-2011, Harris Corporation...

  • Page 13: Safety Terms And Symbols In This Manual

    Statements identifying conditions or practices that may in this result in personal injury or loss of life. High voltage is Manual present. CAUTION Statements identifying conditions or practices that can result in damage to the equipment or other property. Copyright © 2008-2011, Harris Corporation...
  • Page 14 Preface Copyright © 2008-2011, Harris Corporation...

  • Page 15: Chapter 1 Introduction

    When a 6800+ETH module is installed in a FR6822+ frame, the frame becomes a FR6822+QXFE frame. This frame provides monitoring thumbnails and enhanced alarm monitoring options for compatible modules. To determine whether the modules installed in your frame have these capabilities, see the manuals applicable to those products.An interface to Ethernet via the 6800+ETH allows connectivity with all other Command and ™...

  • Page 16: Component Descriptions

    FR6822+ frame; and identifies the location of status LEDs, cooling fans, and front panel release screws. Figure 1-2 shows the inside of the frame with the front panel removed. Copyright © 2008-2011, Harris Corporation...

  • Page 17: Rear Panel

    FR6822+ rear panel components. Table 1-1 briefly Rear Panel describes each of the connectors and switches found on the rear panel. See Making System Connections on page 22 for more information on system connections. Copyright © 2008-2011, Harris Corporation...

  • Page 18: Fan Assembly

    5) decodes and monitors these signal to determine fan health. Local and remote alarms report undesirable conditions that may arise. Features of the FR6822+ fan assembly include the following: Low fan-noise emissions  Copyright © 2008-2011, Harris Corporation...

  • Page 19: Power Supply

    The 6800+ETH module provides 10/100Base-T Ethernet access, while the CCS software application provides a graphical user interface (GUI). Figure 1-5 is a top-front view of the 6800+ETH module. Descriptions of card-edge components are found in Table 1-2. Copyright © 2008-2011, Harris Corporation...
  • Page 20 Use this optional upgrade with any SNMP-based control application to monitor and control modules in the host frame. See Control and Monitoring FR6822+QXFE Using SNMP page 60. Installing and Removing Resource Modules on page 14 for information on locating, removing, and installing resource modules.

  • Page 21: Signal Flow

    Powersupply 1 +6.8V (left) -6.8V Frame ID 0 Frame ID1 +6.8V Current Ground share -6.8V PSU 2 Fail Mains Inlet 2 Powersupply 2 +6.8V (right) -6.8V Frame ID0 Frame ID1 Figure 1-6 FR6822+ Signal Flow Diagram Copyright © 2008-2011, Harris Corporation...
  • Page 22 Chapter 1 Introduction Copyright © 2008-2011, Harris Corporation...

  • Page 23: Chapter 2 Installation

    Additional pair of spade terminals for a second DC PSU, LPN 138-000003Q00  Back connector product packages (installed)  One left and one right rear support bracket, each with a corresponding slotted bracket  One cable support bar  Copyright © 2008-2011, Harris Corporation...

  • Page 24: Available Frame Configurations

    FR6822+F+48 2RU frame with fan module, resource module, and one 48-volt power supply FR6822+RM Rear support extension rail, 6800+ series frames 6800+ETH Ethernet resource card for FR6822+QXFE, CCS 6800+ETHSNMP Ethernet resource module with SNMP 6800+48V 48-volt power supply 6822+AC Redundant, single 6822+AC power supply Choosing 6800+ETH Upgrade Options The basic 6800+ETH module is enabled for CCS and HTTP control.

  • Page 25: Maximum 6800+ Frame Power Ratings

    An AC unit requires an independent supply of 100 to 250 V AC, at 47 to 63 Hz. DC units require an independent supply of 36 to 72 V DC. Voltage FR6822+ frames do not have voltage selector switches. Voltage selection is automatic Selection upon power-up. Copyright © 2008-2011, Harris Corporation...

  • Page 26: Installing The Frame In A Rack

    In order to protect the frame and the modules installed within it, you may choose to add rear brackets to the frame. Note: For mobile deployment of frames, rear mounting brackets are mandatory. Figure 2-1 Frame With Rear-Support Bracket Copyright © 2008-2011, Harris Corporation...
  • Page 27 Thread the cable support bar into each rear-support bracket, and then secure with the provided screws. See Figure 2-3. Figure 2-3 Installing a Cable Support Bar Note: Attach the two tongue-shaped frame-support brackets to the sides of the FR6822+ frame, Figure 2-4. using the provided screws. See Copyright © 2008-2011, Harris Corporation...

  • Page 28: Installing And Removing Resource Modules

    Installing and Removing Resource Modules Resource modules can be upgraded in the field. To purchase a resource module, contact Customer Service. See Table 2-1 on page 10 for a list of available modules and their part numbers. Copyright © 2008-2011, Harris Corporation...

  • Page 29: Installing A Resource Module

    IP address to default, or to set the module to Fail-Safe mode. To remove an existing resource module, follow these steps: Pull out the finger-release screws on the right and left sides of the front panel, and then open it. Copyright © 2008-2011, Harris Corporation...

  • Page 30: Installing And Removing 6800+ Modules

    Up to 20 front modules connected to single-slot back connectors fit in an FR6822+ frame. Up to 10 front modules can fit in an FR6822+ frame if they are connected to double-slot back connectors (2 spaces are required to accommodate the extra width of the back connector). Copyright © 2008-2011, Harris Corporation...

  • Page 31: Installing 6800+ Modules In An Fr6822+ Series Frame

    Install the new back connector by inserting the bottom lip into the required frame slot and then screwing it into place. See Figure 2-8 on page 18. Note: The module lip must be inserted fully and securely into the bottom frame slot to ensure proper module operation. Copyright © 2008-2011, Harris Corporation...
  • Page 32 Slide the module into the guides on the frame floor. See Figure 2-9 on page 19. The module is properly seated when its edge is flush with the guide edge and the extractor handle closes. See Figure 2-10 on page 19. Copyright © 2008-2011, Harris Corporation...

  • Page 33: Removing 6800+ Modules

    To remove a module from an FR6822+ series frame, follow these steps: Pull out the finger-release screws on the right and left side of the front panel, and then open it. Copyright © 2008-2011, Harris Corporation...

  • Page 34: Replacing A Failed Fan Unit

    Figure 2-11 Removing the Fan Assembly from the Front Panel Remove the fan assembly from the front panel. Identify the fan you are replacing, and then remove the corresponding header wires from the PCB board along the top of the assembly (see Figure 2-12). Copyright © 2008-2011, Harris Corporation...
  • Page 35 The LEDs on the fan assembly PCB with the corresponding holes on the front panel  The fan assembly screw holes with the holes on the front panel  Close the front panel, and then reapply power to the frame. Copyright © 2008-2011, Harris Corporation...

  • Page 36: Making System Connections

    To make genlock connections for signal synchronization, connect the reference signal to one of the genlock loop-through BNC connectors on the FR6822+ frame. The other connector can be used to route the reference signal to other locations. Terminate the reference signal at its final routed location. Copyright © 2008-2011, Harris Corporation...

  • Page 37: Chaining Legacy Frames

    FR6822+ Frames Installation and Operation Manual Chaining If you have older FR6802+QXF, FR6802+XF, and/or FR6802+DM frames that contain low-end resource modules, you can chain them to an FR6822+QXFE frame to create a Legacy communication network. Frames By chaining three of these older frames to the FR6822+QXFE frame and connecting them to the Ethernet network, you can monitor and control all four frames and their installed devices.
  • Page 38 Identify each frame on the network by setting a unique switch combination for every frame. Frame ID rocker switches Figure 2-17 Left Rear of FR6822+ Frame Switch 0 Switch 1 Figure 2-18 Frame ID Rocker Switches Copyright © 2008-2011, Harris Corporation...

  • Page 39: Connecting The Gpi Alarm Relay To A Monitoring System

    Switch 1 Connect one end of a straight-through RJ-45 Ethernet cable to the RJ-45 Ethernet port on the back right of the FR6822+QXFE frame, and connect the other end to a PC or Ethernet hub or switch. FR6822+QXFE Configuration, Monitoring, and Control on page 31 for information on setting up and using the 6800+ETH.
  • Page 40 Chapter 2 Installation Copyright © 2008-2011, Harris Corporation...

  • Page 41: Chapter 3 Fr6822+F Frame And Module Operation

    FR6822+F Frame and Module Operation Note: All the frame and module functionality described in this chapter also applies to FR6822+QXFE frames. For information on remote control and monitoring of FR6822+QXFE frames, see Chapter Monitoring the Frame Using Frame Status LEDs Status LEDs indicate the health of your frame.

  • Page 42: Operating Installed Modules

    PC via an Ethernet connection if they are Installed installed in a FR6822+QXFE frame. Certain 6800/7000 series modules that may be housed Modules in an FR6822+ frame offer the same local operation choices, although they cannot be monitored remotely.

  • Page 43: Using Card-Edge Controls

    FR6822+ Frames Installation and Operation Manual Some modules have a great number of parameters and alarms. If you have control and monitoring software available and the required hardware (FR6822+QXFE frame), it is strongly recommended that you use it. Using Many modules contain controls that include two control switches and a series of LED indicators on the module’s card edge.

  • Page 44: Operating Notes

    CCS Navigator, an HTTP web browser, or a third-party SNMP-based control application (if your 6800+ETH module has the optional license key). Chapter 4, FR6822+QXFE Configuration, Monitoring, and Control for more information.

  • Page 45: Chapter 4 Fr6822+Qxfe Configuration, Monitoring, And Control

    6800+ETHSNMP resource modules. Using CCS Software with FR6822+QXFE CCS configuration and control of FR6822+QXFE frames begins with the discovery process. When you enter the IP address of the 6800+ETH module and run a discovery, all modules in theFR6822+QXFE host frame are also discovered.

  • Page 46: Preparing For Configuration

    Ethernet hub/switch) Discovering Frames and Modules Using a CCS Application If your FR6822+QXFE and its associated modules do not appear in the Navigation pane of CCS Navigator, you will need to discover it. You may also run discoveries periodically when you switch, add, or remove modules in the frame.

  • Page 47: Monitoring 6800+ Modules In Ccs Navigator

    CCS software online Help also has extensive information on discovering devices. Monitoring 6800+ Modules in CCS Navigator Once you have discovered your FR6822+QXFE frame in CCS Navigator and saved the results of the discovery, the frame and modules will appear in the Navigation pane.
  • Page 48 Thumbnails in a Module Control Dialog Box Each Q-SEE compliant module will have an additional Video Streaming tab in its Control dialog box when installed in a FR6822+QXFE frame with a 6800+ETH module. Thumbnails on Graphical Navigation Pages Graphical Navigation pages are available in Navigator only, and for Navigator 4.0 or later require a Graphical Navigation license.
  • Page 49 Adding Thumbnails From the Navigation Pane To add a thumbnail to any Graphical Navigation page, follow these steps: Drag a Q-SEE compliant module from below the FR6822+QXFE in the Navigation pane to a Graphical Navigation page. Right click on the module’s icon, and then choose View > Thumbnail.
  • Page 50 Chapter 4 FR6822+QXFE Configuration, Monitoring, and Control Table 4-1 Streaming Player Options (Continued) Option Function Hide Player Controls Check here to turn off display of the thumbnail’s name, audio meters, alarm border, and Waveform and Vectorscope buttons Aspect Ratio For informational purposes only, displays either 4:3 or...

  • Page 51: Upgrading Module Firmware Using Ccs Software

    Upgrade packages come in the form of ZIP files. You do not need to extract the files; this is done by the software as part of the upgrade process. If the FR6822+QXFE frame and its modules have not been discovered, perform the Discovery operation. See...
  • Page 52 Chapter 4 FR6822+QXFE Configuration, Monitoring, and Control The Software Upgrade dialog box appears or is brought to the foreground. Version Info lists the firmware version currently installed on the module. Package Info includes a list of the components contained in the ZIP file.
  • Page 53 Choose a number between 1 and 10 (the simultaneously upgrade default is 5). This determines the number of IP addresses that are upgraded per batch. If the network load is too high, choose a lower number. Copyright © 2008-2011, Harris Corporation...

  • Page 54: Correcting A Failed Upgrading Procedure

    Chapter 4 FR6822+QXFE Configuration, Monitoring, and Control Press Browse to select the software upgrade package (ZIP file). A standard Windows File Selection dialog box appears. Choose the upgrade ZIP file on a local or network drive. The selected file’s path name is displayed in the edit box to the left of the Browse button.
  • Page 55 Catalog folder into the Network or Discovery folder. Right-click the device icon, and then select Properties. On the Device tab of the Navigation Properties box, enter the IP address of the frame that holds the module. (See Figure 4-8.) Copyright © 2008-2011, Harris Corporation...
  • Page 56 3 on page 38. Correcting a Firmware Upgrade with a 6800+ETH If the upgrade fails, remove and then reapply power to the FR6822+QXFE host frame. After a failed upgrade, the 6800+ETH should automatically go into a fail-safe mode where new software can be loaded but other functions are not enabled.

  • Page 57: Activating A 6800+Eth License In Ccs Software

    You are now ready to configure the options you have unlocked. Note: You can also activate 6800+ETH license keys using an HTTP browser. See Activating a 6800+ETH License Using an HTTP Browser on page 59. Copyright © 2008-2011, Harris Corporation...

  • Page 58: Using An Http Browser With Fr6822+Qxfe

    Chapter 4 FR6822+QXFE Configuration, Monitoring, and Control Using an HTTP Browser with FR6822+QXFE The 6800+ETH provides HTTP control and monitoring for 6800+ frames and modules. A generic HTTP control interface allows up to 20 simultaneous monitoring connections. Each connection shows device alarm and parameter information. When a change occurs to a device, such as an alarm or a parameter change, that change may take 3–5 seconds to...
  • Page 59 Click on any nested item to go straight to the options on that page of the interface. Note: Names of items in the navigation tree cannot be changed within the HTTP interface. Copyright © 2008-2011, Harris Corporation...

  • Page 60: Managing User Accounts

    Chapter 4 FR6822+QXFE Configuration, Monitoring, and Control The upper right side of the screen updates to display the path of the currently displayed contents. You can click portions of the path to navigate backwards. The lower right side of the screen updates to display the controls available on the selected level.

  • Page 61: Deleting A User Account

    Type the same password (case-sensitive) in the Password and Confirm Password fields. Click Add. Deleting a User Account Only the administrator account can delete user accounts. The administrator account cannot be deleted. Click Administration > User Accounts (in either the Navigation pane or the control pane). Copyright © 2008-2011, Harris Corporation...

  • Page 62: Changing A Password

    Chapter 4 FR6822+QXFE Configuration, Monitoring, and Control The control pane displays the account administration options. Figure 4-15 Deleting User Accounts in HTTP Control Interface Place checkmarks beside the user(s) you want to delete. Click Delete Account. If the deleted user account is logged on from another PC, that account will continue to work until it is logged off.

  • Page 63: Logging Off From 6800+ Http Control Interface

    Figure 4-17 Logging out of the 6800+ Control Interface Control and Monitoring 6800+ Modules and Frames over HTTP You can navigate the frame and the devices in the frame, view and change parameters, and view streaming video. Copyright © 2008-2011, Harris Corporation...
  • Page 64 Chapter 4 FR6822+QXFE Configuration, Monitoring, and Control Browsing a Frame Click a frame link in either the left (Navigation) or right (Control) pane. A Frame View pane appears. Click on this item to open a frame view Click a module...
  • Page 65 55 for more information. Input—Appears on QSEE6800+ modules only. Open the + to see all the module inputs  to the QSEE6800+ module. Each module has its own Parameters, Alarms, and Configuration options. Copyright © 2008-2011, Harris Corporation...

  • Page 66: Streaming Video

    Chapter 4 FR6822+QXFE Configuration, Monitoring, and Control Streaming With 6800+ETH firmware version 4.2 and higher, you can stream video to the HTTP page for the 6800+ frame. Video When viewing alarm streaming, the border of the thumbnail indicates if the source card has an alarm.
  • Page 67 Figure 4-21 6800+ETH Streaming in the HTTP Control Interface Thumbnails are provided for all Q-SEE compliant modules installed in slots in the FR6822+QXFE frame that contains the 6800+ETH. To determine if a module is Q-SEE compliant, see that module’s documentation or visit our website.
  • Page 68 Chapter 4 FR6822+QXFE Configuration, Monitoring, and Control Figure 4-22 Display Option for QSEE6800+ Module Note: Unlike streaming from the 6800+ETH module, you cannot change the names of the input devices on the QSEE6800+ Video Streaming page. At the top of the page are parameters that determine the configuration of the MPEG-4 stream (the largest image) and accompanying audio.

  • Page 69: Using Presets With 6800+Eth

    QSEE6800+, but not for a group of modules or an entire frame. HTTP presets can be read like any other XML document. You can e-mail presets and perform other normal functions just like any other file. Copyright © 2008-2011, Harris Corporation...
  • Page 70 Chapter 4 FR6822+QXFE Configuration, Monitoring, and Control Creating a Preset You cannot create presets for multiple modules at the same time, or for the entire contents of a frame. To create a preset using the 6800+ HTTP control interface, follow these steps: Browse to the module for which you want to create a preset.

  • Page 71: Upgrading Module Firmware Using An Http Browser

    Upgrading Module Firmware Using an HTTP Browser You can use the 6800+ HTTP control interface to upgrade the firmware on any module in the FR6822+QXFE frame, including the 6800+ETH module. Follow these steps: Download the most recent appropriate upgrade package from our website or from your product CD-ROM.
  • Page 72 Chapter 4 FR6822+QXFE Configuration, Monitoring, and Control Note: When a module is in Boot Loader mode, it appears as “Unknown Device” in the Frame Upgrade tab. Click the slot for the device you want to upgrade. Information similar to this appears on the screen:...

  • Page 73: Activating A 6800+Eth License Using An Http Browser

    FR6822+ Frames Installation and Operation Manual If the upgrade fails, remove and then reapply power to the FR6822+QXFE host frame. After a failed upgrade, the module should automatically go into a Boot Loader mode where new software can be loaded but other functions are not enabled. You may now try the upgrade procedure again.

  • Page 74: Control And Monitoring Fr6822+Qxfe Using Snmp

    In Navigator’s Control mode, you can now double click on the 6800+ETH to launch a web browser, where you can monitor the frame and modules. Control and Monitoring FR6822+QXFE Using SNMP SNMP is an industry-standard protocol that allows third-party control software to remotely monitor and control devices.

  • Page 75: Configuring Snmp Settings Using Http

    6800+ETH module. To connect to the frame and modules using a standard web browser, Logging In To 6800+ HTTP Control Interface on page 44. Click Administrator > SNMP (in either the Navigation pane or the control pane). The control pane displays the following: Copyright © 2008-2011, Harris Corporation...
  • Page 76 Chapter 4 FR6822+QXFE Configuration, Monitoring, and Control Figure 4-30 SNMP Administration Tab of 6800+ HTTP Control Interface Click Read. This triggers a poll of the 6800+ETH card to retrieve its current settings. The fields on the SNMP screen fill in with the settings that are on the module.
  • Page 77 The IP Address, Port #, and SNMP Version fields update to contain the data for the selected row. The Add button is replaced by OK and Cancel buttons. Make changes to the fields, and then click OK. The selected entry in the Trap Destination IP Addresses field is updated. Copyright © 2008-2011, Harris Corporation...

  • Page 78: Configuring Snmp Agent And System Settings

    Configuring SNMP Settings in CCS Software You can use CCS Navigator, in Build mode, to configure SNMP. Follow these steps: If the FR6822+QXFE frame and its modules have not been discovered, perform the Discovery operation, and then save the results of the discovery.
  • Page 79 6800+ETH module. To add a new SNMP trap destination, follow this procedure: Click Add beneath the Trap Destination IP Addresses field. The Add Trap Destination dialog box appears. Copyright © 2008-2011, Harris Corporation...

  • Page 80: Configuring Third-Party Snmp Software Control

    Chapter 4 FR6822+QXFE Configuration, Monitoring, and Control Figure 4-32 Add Trap Destination Dialog Box Choose the SNMP version that the receiving device uses. Enter the IP address of that trap destination. Choose the port number. The default is 162. You may need to change this depending on how your network servers are configured.
  • Page 81 Configure your MIB browser to connect to the 6800+ETH module by entering the IP address, Port (if you have changed the Port from its default in the configuration), and other standard configuration settings. Your browser should now connect to the SNMP agent running on the 6800+ETH module. Copyright © 2008-2011, Harris Corporation...

  • Page 82: Monitoring And Control Using Mibs

    Chapter 4 FR6822+QXFE Configuration, Monitoring, and Control To receive traps, start up the trap receiver in your MIB browser software. To verify that your configurations are correct, you can walk MIB2. To facilitate monitoring more than one of the same device (for example, multiple VSD6800+ Distribution Amplifiers), MIBs index devices by slot, with the 6800+ETH module being in frame 0.

  • Page 83: Basic 6800+Eth Module Operation

    If your 6800+ETH module includes the SNMP option, you can also access these parameters using a third-party SNMP-based control application. See Control and Monitoring FR6822+QXFE Using SNMP on page 60 for more information. All parameters clip unless otherwise indicated.

  • Page 84: Telnet Commands

    Chapter 4 FR6822+QXFE Configuration, Monitoring, and Control Legend Bold option=Indicates that this is the default setting for the parameter. Table 4-7 Remote Control Parameter Options on 6800+ETH Parameter Function Options Name IP Address Specifies the module’s String (Default: IP address 192.168.100.250)
  • Page 85 Alternatively, if the parameter is not configured, the output may appear in this format: IP Address: 10.1.1.101 Subnet Mask: <deleted> Gateway Address: <deleted> getmacaddr Definition This command returns the MAC address of the target module. Copyright © 2008-2011, Harris Corporation...
  • Page 86 Chapter 4 FR6822+QXFE Configuration, Monitoring, and Control Syntax getMACAddr Table 4-9 getMACAddr Commands and Parameters Command Description Parameter getMACAddr Get MAC information None Response The getMACAddr command returns the MAC address of the target module in the following format: MAC Address: 02:90:F9:00:01:2A...
  • Page 87 FR6822+ Frames Installation and Operation Manual Syntax reboot Table 4-11 reboot Commands and Parameters Command Description Parameter reboot Remote restart of the None 6800+ETH Copyright © 2008-2011, Harris Corporation...
  • Page 88 Chapter 4 FR6822+QXFE Configuration, Monitoring, and Control Copyright © 2008-2011, Harris Corporation...

  • Page 89: Chapter 5 Power Supplies

    Installing a New Power Supply on page 76  Disconnecting and Removing an Existing Power Supply Note: A redundant 6822+AC or 6800+48V power supply is hot-swappable and can be replaced without removing power from the remaining power supply. Copyright © 2008-2011, Harris Corporation...

  • Page 90: Installing A New Power Supply

    76 for the screw location. Connect the new power supply to a grounded electrical source, and then toggle the Power switch to the “On” position (toggle left) at the front of the supply. Copyright © 2008-2011, Harris Corporation...

  • Page 91: Protecting The Power Supply

    Both LEDs are located on the front panel of the FR6822+ frame. PSU status LEDs: Alarm/Power Figure 5-3 Location of PSU Status LEDs The Alarm LED automatically turns off once the condition that triggered it is resolved. Copyright © 2008-2011, Harris Corporation...
  • Page 92 Chapter 5 Power Supplies Copyright © 2008-2011, Harris Corporation...

  • Page 93: Chapter 6 Specifications

    Note: HD (tri-level sync) support is card dependant. Please see manual for a particular product for details. 6800+ETH Specifications Table 6-2 Power, Ethernet, and Connector Specifications Item Specification Power dissipation 8.4 W Ethernet RJ-45, 10/100 Mb Connectors 75, shunt terminated Copyright © 2008-2011, Harris Corporation...

  • Page 94: Power Supply Specifications

    Inrush current 25 A (maximum peak) Efficiency >70% at 117 V AC, 120 W output (typical) >0.90 at 130 W output power  Power factor 100 to 250 V AC input voltage  Copyright © 2008-2011, Harris Corporation...

  • Page 95: 6800+48V

    +6.8 V to -6.8 V (9.6 A)  Initial setting +6.8 V to DGND (15.0 A)  -6.8 V to DGND (10.0 A)  130 W combined maximum with fans  Output power 50 W without fans  Copyright © 2008-2011, Harris Corporation...
  • Page 96 <1.2 msec for recovery to within 2% for a step current change of 50-100% of rated Inrush current limiting  Protection Input transient protection  Short circuit protection on all outputs  Reverse input voltage protection  Input fuse  Copyright © 2008-2011, Harris Corporation...

  • Page 97: Appendix A Servicing Instructions

    TYPE RECOMMENDED BY THE MANUFACTURER. DISCARD USED BATTERIES ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS. Finland VAROITUS: Paristo voi rajahtaa, jos se on virheellisesti asennettu. Vaihda paristo ainoastaan valmistajan suosittelemaan tyyppun. Havita kaytetty paristo valmistajan ohjeiden mukaisesti. Copyright © 2008-2011, Harris Corporation...

  • Page 98: Fuse Replacement Caution

    Korea Fuse Replacement Caution CAUTION: WARNING FOR CONTINUED PROTECTION AGAINST RISK OF FIRE, REPLACE ONLY WITH THE SAME TYPE OF FUSE. France ATTENTION: REMPLACER UNIQUEMENT PAR UN FUSIBLE DE MEME TYPE. Copyright © 2008-2011, Harris Corporation...
  • Page 99 F1 (6822+AC power supply) T 3.15 A H 250 V F1 (6800+48V DC power supply) F 8 A 250 V F1, F2 (back connectors) T 2 A 63 V or 3 A 15 V (resettable fuses) Copyright © 2008-2011, Harris Corporation...
  • Page 100 Appendix A Servicing Instructions Copyright © 2008-2011, Harris Corporation...

  • Page 101: Appendix B Troubleshooting

    192.168.100.250 and 192.168.100.245) The FR6822+QXFE frame is turned on last and is given 3 to 4 minutes to initialize  All front modules are securely plugged in (including the resource module on the left side ...

  • Page 102: Pinging An Installed 6800+Eth Module

    In the DOS entry above, “192.168.100.250” is the factory default IP address. If you have changed the IP address of your 6800+ETH module since receiving it, use the new IP address instead at the DOS prompt. Press ENTER. You will get one of two possible responses: Copyright © 2008-2011, Harris Corporation...

  • Page 103: Using 6800 Series Modules In Fr6822+ Frames

    Select the Protocols tab in the Network box. Select TCP/IP Protocol from the Network Protocols list, and then click Properties..The Microsoft TCP/IP Protocol dialog box appears. Select the DNS tab of the Microsoft TCP/IP Protocol box. Copyright © 2008-2011, Harris Corporation...

  • Page 104: Ccs Application Cannot Control 6800+Eth Module

    Hardware Fails to Communicate with PC after Power Failure After a power failure, a FR6822+QXFE frame requires sufficient time to recover and restore communication with the PC. To restore communications between the PC and the frame, give the frame three or more minutes to recover from the power failure before you exit the application and log back on.

  • Page 105: Index
